McAlpine Fyne Quick Start Manual

Before You Start

This tap is suitable for use at water supply pressures of
1 bar (min.) to 5 bar (max.).
This product must be connected to the water supply in
accordance with the UK Building Regulations. If you are
in any doubt about these requirements，contact a
qualified plumber,your local Water Company, or the
Water Regulations Advisory Scheme(WRAS).
(a) Identify all components and check pack contents.
(b) Turn off mains water supply. The main stopcock is
usually situated where the supply enters the buiding
(c) It is also recommended that the water heating
arrangements are turned off.
(d) Drain the cold and hot water system. It is
recommended to ensure complete drainage,that all taps
are opened. There is no need to drain the heating system.

After Care

Ensure the tap is fully turned off after use.
To maintain the appearance of this fitting, ensure it is
cleaned only using a clean soft damp cloth. A solution of
warm water and mild liquid detergent may be used
where necessary and then rinsed thoroughly.
Abrasive cleaners or acidic cleaners MUST NOT BE USED
under any circumstances.
Avoid contact with solvents.
Manufacturer's Guarantee
This tap is guaranteed to be free from faults arising from
manufacturing defects for a period of 5 Years from the
date of purchase.
Retain proof of purchase.
To validate your Guarantee you must visit our website
within 30 days of purchase or guarantee is void. Link for
registration: www.mcalpineplumbing.com/brregistration
Caution
Contains parts which if these become loose could
be a choking hazard to small children. After installation
please check that the bar levers into the tap heads and
the plug lift rod are secure, if required please use low
strength thread lock to secure these parts.
Please pass these instructions back onto householder for
retention for future reference.
Do not over bend the flexible hoses.
NOTE!
max.
3Nm
min.
80mm
min.
15mm
Fyne Basin Mixer
[01] x 1 [02] x 1
[03] x 1
[05] x 1 [06] x 2 [07] x 2

Tools Required:

Barcode: 5036484097507
[04] x 1
