McAlpine SCA-STA Installation Manual And User's Manual

Scale defender starter kit

Installation manual and user instructions

Scale Defender Starter Kit: SCA-STA

Warranty

In the unlikely event that you should experience any defect in the materials or workmanship of this product within ONE

year of purchase, the purchaser's sole remedy shall be the replacement (at the manufacturer's discretion) of all or any

part of the product that is defective. All working parts, O-rings and valves are guaranteed for a period of ONE year from

purchase provided that our advice concerning care has been observed. This is provided that the product has been used for

normal domestic purposes in the UK and that the care, installation and maintenance instructions have been observed.

The warranty extends to the original purchaser only. You should retain a copy of your dated invoice as proof of purchase to

validate any claims under this guarantee.

Free lifetime guarantee registration:

www.mcalpineplumbing.com/sdregistration

Guarantee covers free replacement of all parts (excluding cartridges)

Table of Contents

Do you have a question about the SCA-STA and is the answer not in the manual?

Page 1 Installation manual and user instructions Scale Defender Starter Kit: SCA-STA Warranty In the unlikely event that you should experience any defect in the materials or workmanship of this product within ONE year of purchase, the purchaser’s sole remedy shall be the replacement (at the manufacturer’s discretion) of all or any part of the product that is defective.
Page 2 Important Technical Data Minimum operating pressure: Minimum water temperature: water 100% safe for drinking 100% safe for drinking under BS EN 1212 and NEN-EN 0.3 bar 0.3 bar 1°C 1°C* * 1212 regulations Maximum operating pressure: Maximum water temp. (feed): 10.0 bar 10.0 bar* * 40°C...
Page 3 Installation Description 22 x 15mm olive / reducers ¾” (22mm) compression nuts 22mm olives ¾” brass connectors Seals System head (with check valve in outlet side) O Ring Dosing cartridge Housing 1. 1. 6. 6. Create a break in the cold water pipe after the stopcock, If connecting to a 22mm pipe: place the compression the length of this break will change according to the nuts (B)
Page 4 Replacing the dosing cartridges The dosing filter capacity is a maximum of 40,000 litres and should be replaced when exhausted to maintain the effectiveness of protection. Inside the dosing filter is a small red ball. When the ball is at the bottom of the dosing filter (H) (H), the filter should be replaced.
