MULTI-SPLIT TYPE ROOM AIR CONDITIONER
ACONDICIONADOR DE AIRE DOMÉSTICO SISTEMA MULTI SPLIT
E S F
DB98-05640A(4)
CLIMATISEUR DE TYPE MULTIPLE
OWNER'S INSTRUCTIONS &
INSTALLATION MANUAL
MANUAL DE INSTRUCCIONES &
MANUAL DE INSTALACIÓN
MANUEL D'UTILISATION &
MANUEL D'INSTALLATION
Indoor Unit
AM18B1(B2)C09
AM26B1(B2)C13
AM27B1(B2)C07
AM27B1(B2)C13
( Refroidissement )
Outdoor Unit
UM18B1(B2)C2
UM26B1(B2)C2
UM27B1(B2)C3
( Cool )
( Refrigeración )
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Samsung AM18B1B2C09
Summary of Contents for Samsung AM18B1B2C09
- Page 1 OWNER’S INSTRUCTIONS & INSTALLATION MANUAL MANUAL DE INSTRUCCIONES & MANUAL DE INSTALACIÓN MANUEL D’UTILISATION & MANUEL D’INSTALLATION Indoor Unit Outdoor Unit AM18B1(B2)C09 UM18B1(B2)C2 AM26B1(B2)C13 UM26B1(B2)C2 AM27B1(B2)C07 UM27B1(B2)C3 AM27B1(B2)C13 MULTI-SPLIT TYPE ROOM AIR CONDITIONER ( Cool ) ACONDICIONADOR DE AIRE DOMÉSTICO SISTEMA MULTI SPLIT ( Refrigeración ) CLIMATISEUR DE TYPE MULTIPLE ( Refroidissement )
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when using your air conditioner. Make sure that the indoor unit is correctly ventilated at all times; do NOT place clothing or other materials over it. NEVER spill liquid of any kind into the indoor unit. Should this happen, switch off the breaker used for your air conditioner and contact your installation specialist. -
Page 3: Table Of Contents
Contents REPARING YOUR AIR CONDITIONER Safety Precautions ........2 View of the Unit . -
Page 4: View Of The Unit
View of the Unit The design and shape are subject to change according to the model. Indoor Unit Air Inlet Air flow blades (outlet) Air filter (under the grille) Timer indicator Remote Control Sensor SAVING indicator STANDARD indicator SILENCE indicator NATURE indicator POWER indicator On/Off &... - Page 5 Outdoor Unit UM18B1(B2)C2 Air Inlet(Rear) Air Outlet Connection Valve Outdoor Unit UM26B1(B2)C2 Air Inlet(Rear) Air Outlet Connection Valve Outdoor Unit UM27B1(B2)C3 Air Inlet(Rear) Air Outlet Connection Valve...
-
Page 6: Remote Control-Buttons And Display
Remote Control - Buttons and Display Remote control transmission indicator Mode selection button Operating mode (AUTO, COOL, DRY, FAN) AUTO, COOL, DRY, FAN) Temperature adjustment Temperature setting buttons Turbo mode Turbo/Sleep mode Sleep mode selection button Fan speed Fan speed adjustment button Air flow direction Swing button... -
Page 7: Getting Started
etting Started You have just purchased a split type air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contains valuable information on using your air conditioner. Please take the time to read it as it will help you take full advantage of the unit’s features. -
Page 8: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when : You purchase the air conditioner The remote control does not work correctly Use two AAA, LR03 1.5V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 9: Way Function
5 Way Function You can select the 5 Way function with operating mode of the air conditioner for more comfortable circumstances. You can use the 5 Way function with the indoor unit as well as the remote control. Thus, you can use this function even though you have lost your remote control. -
Page 10: Selecting The Automatic Operating Mode
Selecting the Automatic Operating Mode You can start the air conditioner in Automatic mode from your remote control. In the Automatic mode, the standard temperature and the optimum fan speed is selected automatically. You can adjust the standard temperature but not the fan speed. If necessary, press the (On/Off) button. -
Page 11: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to adjust the: Cooling temperature Fan speed when cooling If necessary, press the (On/Off) button. Result: The 5 Way indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used. -
Page 12: Changing The Room Temperature Quickly
Changing the Room Temperature Quickly The Turbo cooling function is used to cool your room as quickly as possible. You have just come home and find that the room is very hot. You wish to cool it down as quickly as possible. The Turbo function operates for 30 minutes with the maximum settings before returning automatically to the mode and temperature previously selected. -
Page 13: Removing Excess Humidity
Removing Excess Humidity If the atmosphere in your room is very humid or damp, you can remove excess humidity without lowering the room temperature too much. If necessary, press the (On/Off) button. Result: The 5 Way indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used. -
Page 14: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air the room using the Fan feature. If necessary, press the (On/Off) button. Result: The 5 Way indicator on the indoor unit lights up. The air conditioner starts up in the mode selected when the unit was last used. -
Page 15: Adjusting The Air Flow Direction Vertically
Adjusting the Air Flow Direction Vertically Depending on the position of the indoor unit on the wall of your room, you can adjust the position of the outer air flow blade on the bottom of the unit, thus increasing the efficiency of the air conditioner. Press the SWING button one or more times as required. -
Page 16: Setting The On Timer
Setting the On Timer The On Timer enables you to switch on the air conditioner automatically after a given period of time. You can set the period of time from 30 minutes to 24 hours. To set the operating time, press the ON TIMER button one or more times until the required time is displayed. -
Page 17: Setting The Off Timer
Setting the Off Timer The Off Timer enables you to switch off the air conditioner automatically after a given period of time. You can set the period of time from 30 minutes to 24 hours. To set the operating time, press the OFF TIMER button one or more times until the required time is displayed. -
Page 18: Setting The Sleep Timer
Setting the Sleep Timer The Sleep Timer can be used when you are cooling your room to switch the air conditioner off automatically after a period of six hours. If you wish to switch the unit off at a specific time, refer to page 17. -
Page 19: Operating Recommendations
Operating Recommendations Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation Power failure If a power failure occurs when the air conditioner is operating, the unit is switched off. When the power returns, you must press the (ON/OFF) button to restart it. -
Page 20: Temperature And Humidity Ranges
Temperature and Humidity Ranges The following table indicates the temperature and humidity ranges within which the air conditioner can be used. If the air conditioner is used at... Then... High temperatures The automatic protection feature may be triggered and the air conditioner stopped. -
Page 21: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner To get the best possible use out of your air conditioner, you must clean it regularly to remove the dust that accumulates on the air filter. Before cleaning your air conditioner, ensure that you IMPORTANT have switched off the breaker used for the unit. Open the front grille by lifting the tabs on the lower right and left sides of the indoor unit. -
Page 22: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary call. Problem Explanation/Solution The air conditioner does not Check that the breaker used for the air conditioner is switched on. operate at all Check that the 5 Way indicator on the indoor unit is on;... -
Page 23: Installing A Filter (Option)
Installing a Filter (Option) The air conditioner can be fitted with a deodorizing and Bio-Pure filter to remove minute dust particles or odours. The service life of the filter is approximately three months depending on the time during which the air conditioner is used. Remove the vinyl packing from the filter. -
Page 24: Technical Specifications
Technical Specifications Indoor unit Outdoor unit Indoor unit Outdoor unit MODEL AM18B1(B2)C09 UM18B1(B2)C2 AM26B1(B2)C13 UM26B1(B2)C2 2 Comp + 2 Room 2 Comp + 2 Room Type Btu/h Capacity Cooling Performance A/B-Unit : 9000 A/B-Unit : 12500 Ratings SEER 10.0 10.0 Pts/h Moisture Removal Air FLOW(Cooling, HIGH) - Page 25 Indoor unit Indoor unit Outdoor unit MODEL AM27B1(B2)C07 AM27B1(B2)C13 UM27B1(B2)C3 2 Comp + 3 Room Type Btu/h Performance Capacity Cooling A-Unit : 13000, B/C-Unit : 7000 Ratings SEER 10.0 Pts/h Moisture Removal Air FLOW(Cooling, HIGH) Sound Rating-Outdoor The number of operation 1 Unit operation 2 Unit operation 3 Unit operation...
