Hycontrol REFLEX RC Series Handbook

24 ghz radar (fmcw) level transmitter for solids from granulates to rocks
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REFLEX RC SERIES
REFLEX RC SERIES
REFLEX RC SERIES
REFLEX RC SERIES
24 GHz Radar (FMCW) Level Transmitter for solids from
granulates to rocks
© HYCONTROL 01/2019 - RC SERIES MANUAL v1
Handbook
Handbook
Handbook
Handbook

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REFLEX RC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hycontrol REFLEX RC Series

Summary of Contents for Hycontrol REFLEX RC Series

  • Page 1 REFLEX RC SERIES REFLEX RC SERIES REFLEX RC SERIES REFLEX RC SERIES Handbook Handbook Handbook Handbook 24 GHz Radar (FMCW) Level Transmitter for solids from granulates to rocks © HYCONTROL 01/2019 - RC SERIES MANUAL v1...
  • Page 2 IMPRINT :::::::::::::::::::::::::::::::::: All rights reserved. It is prohibited to reproduce this documentation, or any part thereof, without the prior written authorisation of HYCONTROL. Subject to change without notice. Copyright 2019 by HYCONTROL www.hycontrol.com 01/2019 - RC SERIES MANUAL v1...

  • Page 3: Table Of Contents

    CONTENTS REFLEX RC SERIES 1 Safety instructions 1.1 Software history ....................... 7 1.2 Intended use ........................8 1.3 Certification ........................8 1.4 Radio approvals ........................ 9 1.4.1 European Union (EU)....................... 9 1.4.2 U.S.A. and Canada......................... 13 1.5 Safety instructions from the manufacturer ..............16 1.5.1 Copyright and data protection ....................
  • Page 4 CONTENTS REFLEX RC SERIES 4.3 Electrical installation: output options with cable gland ..........46 4.4 Electrical installation: output options with an M12 male connector......50 4.5 Electrical connection for current output ............... 50 4.5.1 Non-Ex devices ........................50 4.5.2 Devices for hazardous locations................... 51 4.6 Ingress protection ......................
  • Page 5 7.1.3 How to clean the top surface of the device................. 119 7.1.4 How to clean horn antennas under process conditions............. 120 7.2 Service warranty......................120 7.3 Replacement of the VG6 signal converter with the REFLEX RC Series signal converter. 7.4 Spare parts availability....................123 7.5 Availability of services ....................123 7.6 Returning the device to the manufacturer..............
  • Page 6 CONTENTS REFLEX RC SERIES 9.10 HART® menu tree for PDM..................156 9.10.1 Overview PDM menu tree (positions in menu tree)............157 9.10.2 PDM menu tree (details for settings) ................158 10 Appendix 10.1 Order code ........................161 10.2 Spare parts ......................... 165 10.3 Accessories: general items..................

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.1 Software history "Firmware revision" agrees with NAMUR NE 53. It is a series of numbers used to record the revision status of embedded software (firmware) in electronic equipment assemblies. It gives data on the type of changes made and the effect that changes have on compatibility.

  • Page 8: Intended Use

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.2 Intended use CAUTION! Responsibility for the use of the measuring devices with regard to suitability, intended use and corrosion resistance of the used materials against the measured fluid lies solely with the operator. INFORMATION! The manufacturer is not liable for any damage resulting from improper use or use for other than the intended purpose.

  • Page 9: Radio Approvals

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.4 Radio approvals 1.4.1 European Union (EU) INFORMATION! LPR (Level Probing Radar) LPR (Level Probing Radar) LPR (Level Probing Radar) LPR (Level Probing Radar) devices measure level in the open air or in a closed space (a metallic tank etc.).
  • Page 10 SAFETY INSTRUCTIONS REFLEX RC SERIES S/N: xxxxxxxxxxxxxxxxxxx Manufacturing date: YYYY-MM-DD Tag No: Figure 1-1: European Union: radio approval information on the nameplate Order code 1 Type code (defined in order). For more data, refer to on page 161. 2 HVIN (Hardware Version Identification Number). This number gives the radar signal frequency (24GHZ = 24 GHz), the...
  • Page 11 SAFETY INSTRUCTIONS REFLEX RC SERIES TLPR (Tank Level Probing Radar) devices only Use approved personnel to install the device. The device and the tank agree with the RED (Radio Equipment Directive) if you obey the instructions that follow: • TLPR (Tank Level Probing Radar) are required to be installed at a permanent fixed position at a closed (not open) metallic tank or reinforced concrete tank, or similar enclosure structure made of comparable attenuating material;...
  • Page 12 SAFETY INSTRUCTIONS REFLEX RC SERIES Radio quiet zones: locations of radio astronomy sites (stations) in Europe and northern Eurasia Country Name of the station Location Latitude, ϕ Longitude, λ Finland Metsähovi 60°13'04" N 24°23'37" E Tuorla 60°24'56" N 22°26'31" E...

  • Page 13: And Canada

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.4.2 U.S.A. and Canada INFORMATION! LPR (Level Probing Radar) LPR (Level Probing Radar) devices measure level in the open air or in a closed space (a metallic LPR (Level Probing Radar) LPR (Level Probing Radar) tank etc.).
  • Page 14 SAFETY INSTRUCTIONS REFLEX RC SERIES LEGAL NOTICE! IC IC IC IC This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause un- desired operation.
  • Page 15 SAFETY INSTRUCTIONS REFLEX RC SERIES The Product Marketing Names (PMN) for this series of devices are "REFLEX RB SERIES FMCW RADAR", "REFLEX RC SERIES FMCW RADAR" and "REFLEX RE SERIES FMCW RADAR". S/N: xxxxxxxxxxxxxxxxxxx Manufacturing date: YYYY-MM-DD Tag No: Figure 1-2: U.S.A. and Canada: radio approval information on the nameplate Order code 1 Type code (defined in order).

  • Page 16: Safety Instructions From The Manufacturer

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.5 Safety instructions from the manufacturer 1.5.1 Copyright and data protection The contents of this document have been created with great care. Nevertheless, we provide no guarantee that the contents are correct, complete or up-to-date.

  • Page 17: Product Liability And Warranty

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.5.3 Product liability and warranty The operator shall bear responsibility for the suitability of the device for the specific purpose. The manufacturer accepts no liability for the consequences of misuse by the operator. Improper installation or operation of the devices (systems) will cause the warranty to be void. The respective "Standard Terms and Conditions"...

  • Page 18: Warnings And Symbols Used

    SAFETY INSTRUCTIONS REFLEX RC SERIES 1.5.5 Warnings and symbols used Safety warnings are indicated by the following symbols. DANGER! This warning refers to the immediate danger when working with electricity. DANGER! This warning refers to the immediate danger of burns caused by heat or hot surfaces.

  • Page 19: Device Description

    DEVICE DESCRIPTION REFLEX RC SERIES 2.1 Scope of delivery INFORMATION! Do a check of the packing list to make sure that you have all the elements given in the order. Figure 2-1: Scope of delivery 1 Signal converter, process connection and antenna in the ordered version 2 Antenna extensions (option).

  • Page 20: Device Description

    DEVICE DESCRIPTION REFLEX RC SERIES 2.2 Device description This device is a 24 GHz FMCW-radar level transmitter. It is a non-contact technology and is 2- wire loop-powered. It is designed to measure the distance, level, mass, volume and reflectivity of Measuring granulates and powders.

  • Page 21: Visual Check

    DEVICE DESCRIPTION REFLEX RC SERIES 2.3 Visual Check WARNING! If the display screen glass is broken, do not touch. INFORMATION! Inspect the packaging carefully for damages or signs of rough handling. Report damage to the carrier and to the local office of the manufacturer.

  • Page 22: Nameplates

    DEVICE DESCRIPTION REFLEX RC SERIES 2.4 Nameplates INFORMATION! Look at the device nameplate to ensure that the device is delivered according to your order. Check for the correct supply voltage printed on the nameplate. 2.4.1 Nameplate (examples) Figure 2-5: Non-Ex nameplate attached to the housing...

  • Page 23: Installation

    INSTALLATION REFLEX RC SERIES 3.1 General notes on installation INFORMATION! Inspect the packaging carefully for damages or signs of rough handling. Report damage to the carrier and to the local office of the manufacturer. INFORMATION! Do a check of the packing list to make sure that you have all the elements given in the order.

  • Page 24: Transport

    INSTALLATION REFLEX RC SERIES 3.3 Transport Figure 3-2: How to lift the device WARNING! Lift the device carefully to prevent damage to the antenna. If you remove the signal converter to lift the device, do not interchange this part with a different signal converter. This can have an effect on the performance of the device.

  • Page 25: Pressure And Temperature Ranges

    INSTALLATION REFLEX RC SERIES 3.5 Pressure and temperature ranges WARNING! The process connection temperature range must agree with the temperature limits of the gasket material. The operating pressure range is subject to the process connection used and the flange temperature.

  • Page 26: General Notes

    INSTALLATION REFLEX RC SERIES 3.6.1 General notes Recommended nozzle position for solids Figure 3-4: Recommended nozzle position for solids 1 Position of the process fitting from the silo wall, r/2 (for DN80 (3¨), DN100 (4¨), DN150 (6¨) or DN200 (8¨) horn antennas, and DN80 (3¨), DN100 (4¨), or DN150 (6¨) Drop antennas)

  • Page 27: Tanks With Dish-Shaped And Conical Bottoms

    INSTALLATION REFLEX RC SERIES Number of devices that can be operated in a silo Figure 3-6: There is no maximum limit to the number of devices that can be operated in the same silo There is no maximum limit to the number of devices that can be operated in the same silo. They can be installed adjacent to other radar level transmitters.

  • Page 28: Mounting Restrictions

    INSTALLATION REFLEX RC SERIES 3.7 Mounting restrictions CAUTION! Follow these recommendations to make sure that the device measures correctly. They have an effect on the performance of the device. We recommend that you prepare the installation when the tank is empty.
  • Page 29 INSTALLATION REFLEX RC SERIES Figure 3-8: Equipment and obstacles: how to prevent measurement of interference signals 1 We recommend that you do an empty spectrum recording if there are too many obstacles in the radar beam (for more Empty spectrum recording data, refer to on page 100).

  • Page 30: Process Connections

    INSTALLATION REFLEX RC SERIES Product inlets Figure 3-9: Product inlets 1 The device is in the correct position. 2 The device is too near to the product inlet. CAUTION! Do not put the device near to the product inlet. If the product that enters the silo touches the antenna, the device will measure incorrectly.
  • Page 31 INSTALLATION REFLEX RC SERIES Recommended nozzle size for flange connections The nozzle must be as short as possible. Refer to the table below for the maximum height of the nozzle: Nozzle and antenna diameter, Maximum nozzle height, h Ød Metallic Horn antenna...
  • Page 32 INSTALLATION REFLEX RC SERIES Special equipment needed: • 3 mm Allen wrench (not supplied) WARNING! If you attach the antenna in a closed space, make sure that there is a good airflow in the area. Make sure that a person not in the silo can always hear you.
  • Page 33 INSTALLATION REFLEX RC SERIES Threaded connections: installation procedure Figure 3-12: Threaded connections: installation procedure Recommended socket size for threaded connections The socket must be as short as possible. If the socket is in a recess, then use the maximum limits for nozzle dimensions (flange connections) in this section.
  • Page 34 INSTALLATION REFLEX RC SERIES If the antenna is larger than the process connection (threaded) Figure 3-13: How to attach the device if the antenna is larger than the process connection Special equipment needed: • 3 mm Allen wrench (not supplied) WARNING! If you attach the antenna in a closed space, make sure that there is a good airflow in the area.

  • Page 35: How To Attach Antenna Extensions

    INSTALLATION REFLEX RC SERIES • Metallic Horn antennas without an antenna extension: Metallic Horn antennas without an antenna extension: Metallic Horn antennas without an antenna extension: Metallic Horn antennas without an antenna extension: Attach the locking screw to the antenna with a 3 mm Allen wrench.
  • Page 36 INSTALLATION REFLEX RC SERIES Procedure 1: How to attach an antenna extension • Attach the antenna extensions 1 below the flange. Use a 36 mm open-end wrench to tighten each antenna extension. Make sure that the antenna extensions 1 fully engaged.
  • Page 37 INSTALLATION REFLEX RC SERIES • 36 mm open-end or box-end wrench CAUTION! Locking screws Locking screws Locking screws Locking screws The lengths of the locking screws for the antenna extensions and the Drop antenna are different. Make sure that you use the correct screw when you assemble the device. For more data, refer to the list that follows.

  • Page 38: Orientation System (Accessory)

    INSTALLATION REFLEX RC SERIES 3.9 Orientation system (accessory) 3.9.1 How to attach the orientation system to the device If it is necessary to tilt the antenna at the product with angle more than 2° from the vertical axis, attach an orientation system to the device. This part is available as an accessory for devices with threaded connections.
  • Page 39 INSTALLATION REFLEX RC SERIES • ISO 228-1 (G) connection: ISO 228-1 (G) connection: ISO 228-1 (G) connection: Make sure that you use the applicable gasket for the connection ISO 228-1 (G) connection: dimensions and the process. Align the gasket correctly. Put the device carefully on the orientation system.

  • Page 40: How To Tilt The Device

    INSTALLATION REFLEX RC SERIES The antenna is not attached to the device. Make sure that the O-ring stays in the groove on the process connection. • ISO 228-1 (G) connection: ISO 228-1 (G) connection: ISO 228-1 (G) connection: Make sure that you use the applicable gasket for the connection ISO 228-1 (G) connection: dimensions and the process.

  • Page 41: How To Turn Or Remove The Display Module (Option)

    INSTALLATION REFLEX RC SERIES Equipment needed: • 5 mm Allen wrench (not supplied) • Loosen the 4 socket head screws around the orientation system with a 5 mm Allen wrench. • Tilt the device to the correct angle. • Tighten the 4 socket head screws. This step locks the orientation system to prevent movement.

  • Page 42: Weather Protection

    INSTALLATION REFLEX RC SERIES • Display extractor CAUTION! Disconnect the power supply. Follow this procedure: • Remove the housing cover with the cover wrench. • Find the two clips that hold the display module in the housing. • Use the display extractor to remove the display module from the housing. Put the display extractor in the slots on the module for these clips.
  • Page 43 INSTALLATION REFLEX RC SERIES The overall dimensions of the weather protection are on page 138. Figure 3-21: Installation of the weather protection 1 Put the weather protection clamp around the top of the device. 2 Attach the two locking nuts to the threads on the weather protection clamp. Tighten the lock- ing nuts with a 10 mm socket wrench.

  • Page 44: How To Open The Weather Protection

    INSTALLATION REFLEX RC SERIES 3.11.2 How to open the weather protection Figure 3-22: How to open the weather protection 1 Remove the R-clip from the hole at the front of the weather protection cover. 2 Remove the weather protection cover.

  • Page 45: Electrical Connections

    ELECTRICAL CONNECTIONS REFLEX RC SERIES 4.1 Safety instructions DANGER! All work on the electrical connections may only be carried out with the power disconnected. Take note of the voltage data on the nameplate! DANGER! Observe the national regulations for electrical installations! DANGER! For devices used in hazardous areas, additional safety notes apply;...

  • Page 46: Electrical Installation: Output Options With Cable Gland

    ELECTRICAL CONNECTIONS REFLEX RC SERIES 4.3 Electrical installation: output options with cable gland Figure 4-1: Terminals for electrical installation: standard cable gland 1 Grounding terminal in the housing (if the electrical cable is shielded) 2 Current output - 3 Current output +...
  • Page 47 ELECTRICAL CONNECTIONS REFLEX RC SERIES Figure 4-2: How to open the terminal compartment cover Equipment needed: • 3 mm Allen wrench (not supplied) • Cover wrench Procedure 1 Loosen the lock screw with a 3 mm Allen wrench. 2 Remove the cover stop.
  • Page 48 ELECTRICAL CONNECTIONS REFLEX RC SERIES Figure 4-3: Procedure for electrical installation Equipment needed: • POZIDRIV® PZ1 screwdriver (not supplied) Procedure 1 Loosen the cable gland. Put the electrical wires into the cable entry. Loosen the terminal screws with a POZIDRIV® PZ1 screwdriver. Connect the electrical wires to the connector.
  • Page 49 ELECTRICAL CONNECTIONS REFLEX RC SERIES Figure 4-4: How to close the terminal compartment cover Equipment needed: • 3 mm Allen wrench (not supplied) 1 Put the cover on the housing 2 Turn the cover clockwise until it is fully engaged.

  • Page 50: Electrical Installation: Output Options With An M12 Male Connector

    ELECTRICAL CONNECTIONS REFLEX RC SERIES 4.4 Electrical installation: output options with an M12 male connector Figure 4-5: Terminals for electrical installation: 4-pin male M12 connector 1 Pin 1: current output + 2 Pin 2: not connected 3 Pin 3: current output -...

  • Page 51: Devices For Hazardous Locations

    ELECTRICAL CONNECTIONS REFLEX RC SERIES 4.5.2 Devices for hazardous locations DANGER! For electrical data for device operation in hazardous locations, refer to the related certificates of compliance and supplementary instructions (ATEX etc.). This documentation can be downloaded from the website.

  • Page 52: Networks

    ELECTRICAL CONNECTIONS REFLEX RC SERIES 4.7 Networks 4.7.1 General information The device uses the HART® communication protocol. This protocol agrees with the HART® Communication Foundation standard. The device can be connected point-to-point. It can also have a polling address of 1 to 63 in a multi-drop network.

  • Page 53: Multi-Drop Networks

    ELECTRICAL CONNECTIONS REFLEX RC SERIES 4.7.3 Multi-drop networks Figure 4-9: Multi-drop network (non-Ex) 1 Address of the device (each device must have a different address in multidrop networks) 2 4 mA + HART® 3 Resistor for HART® communication (typically 250 ohms) 4 Power supply 5 HART®...

  • Page 54: Start-Up

    START-UP REFLEX RC SERIES 5.1 Start-up checklist Check these points before you energize the device: • Are all the wetted components (antenna, flange and gaskets) chemically resistant to the product in the silo? • Does the information on the signal converter nameplate agree with the operating data? •...

  • Page 55: Digital Display Screen

    START-UP REFLEX RC SERIES 5.4 Digital display screen If you remove the housing cover, you can push the buttons on the keypad. If you cannot remove Keypad the housing cover, you can operate the keypad with a bar magnet. For more data, refer to buttons on page 56.

  • Page 56: Keypad Buttons

    START-UP REFLEX RC SERIES Display in Program mode Figure 5-2: Display screen layout in Program mode 1 Menu number or menu item number 2 Location (menu) of sub-menu or menu item 3 Menu item name 5.4.2 Keypad buttons Functions of keypad buttons...
  • Page 57 START-UP REFLEX RC SERIES How to push the keypad buttons with your hand Figure 5-3: How to push the keypad buttons with your hand Equipment needed • Cover wrench 1 Remove the housing cover with the cover wrench supplied with the device.

  • Page 58: Remote Communication With Pactware

    START-UP REFLEX RC SERIES INFORMATION! It is not necessary to remove the display housing cover to do this procedure. • Hold the bar magnet near to a keypad button. The keypad button will operate. If you must operate the button more than one time, remove the bar magnet and then hold it near to the button again.

  • Page 59: Remote Communication With The Ams™ Device Manager

    START-UP REFLEX RC SERIES 5.6 Remote communication with the AMS™ Device Manager The AMS™ Device Manager is an industrial Plant Asset Management (PAM) software tool. Its role is to: • Store configuration information for each device. • Store and read process data.

  • Page 60: Operation

    OPERATION REFLEX RC SERIES 6.1 User modes Normal mode Normal mode This mode shows measurement data and status messages. For more data Normal mode Normal mode about measurements, refer to Normal mode on page 60. For more data Status messages and diagnostic data about status messages, refer to page 111.
  • Page 61 OPERATION REFLEX RC SERIES INFORMATION! Current output and LCD display settings Current output and LCD display settings Current output and LCD display settings Current output and LCD display settings When you do the Standard setup Standard setup procedure, the measurement value on the first measurement...
  • Page 62 OPERATION REFLEX RC SERIES Measurement data format errors Figure 6-2: Error symbol: the number of digits and decimal places is not sufficient for the measurement data 1 Error symbol: the number of digits and decimal places is not sufficient for the measurement data. It is possible that the length units must be changed from "mm"...
  • Page 63 OPERATION REFLEX RC SERIES Measurement type definitions Measurement type Description Available units Level This is a display and an output function option. m, cm, mm, in (inches), It is the height from the bottom of the tank to ft (feet), custom length unit the surface of the liquid (Tank height - Distance).

  • Page 64: Program Mode

    OPERATION REFLEX RC SERIES 6.3 Program mode 6.3.1 General notes Change the settings of your device in Program Mode Program Mode. Data about the menus is given on page 77. Program Mode Program Mode You can: • Use the A Quick Setup...

  • Page 65: Protection Of The Device Settings (Access Levels)

    OPERATION REFLEX RC SERIES 6.3.2 Protection of the device settings (access levels) The settings of this device have three different access levels: "User", "Operator" and "Expert". "Expert" is the highest access level. The highest access level lets you change all available functions.
  • Page 66 OPERATION REFLEX RC SERIES • Enter the password used at this time for a given access level ("Operator" or "Expert"). If it is the default password, refer to the value given in the "Access levels and applicable functions in Program mode" table in this section.

  • Page 67: How To Get Access To The Quick Setup Menu

    OPERATION REFLEX RC SERIES 6.3.3 How to get access to the Quick Setup menu The Quick Setup menu contains the menu items that are necessary for most configurations of the device. The menu items are divided into 2 groups: "Standard Setup" and "Empty Spectrum".

  • Page 68: Keypad Functions

    OPERATION REFLEX RC SERIES 6.3.4 Keypad functions Menu navigation Figure 6-4: Menu navigation 1 Menu number or menu item number 2 Location (menu) of sub-menu or menu item 3 Menu item name This is what you see when you are in Program mode. The functions of the buttons are given in the...
  • Page 69 OPERATION REFLEX RC SERIES Lists of parameters in menu items Figure 6-5: Lists of parameters in menu items 1 Menu item with parameter stored at this time (first screen). Push [> > > > ] to enter the menu item.
  • Page 70 OPERATION REFLEX RC SERIES Values in menu items Figure 6-6: Values in menu items 1 Menu item with values stored at this time (first screen). Push [> > > > ] to enter the menu item. A cursor shows on the first digit.

  • Page 71: How To Save Settings Changed In Program Mode

    OPERATION REFLEX RC SERIES INFORMATION! Values in menu items Values in menu items Values in menu items Values in menu items If the digit is part of a custom unit name, then refer to the list of available characters that...

  • Page 72: Menu Overview

    OPERATION REFLEX RC SERIES 6.3.6 Menu overview Menu overview: A – Quick Setup Normal Program Menu A Submenus ↓ ↑ ↓ ↑ ↓ ↑ > ^ > ^ > ^ > ^ A Quick Setup A Quick Setup A Quick Setup...
  • Page 73 OPERATION REFLEX RC SERIES Menu overview: B – Test Normal Program Menu B Submenus ↓ ↑ ↓ ↑ ↓ ↑ ↓ ↑ > > ^ > ^ > ^ > ^ B Test B Test B Test B Test B1 Simulation...
  • Page 74 OPERATION REFLEX RC SERIES Menu overview: C – Full Setup Normal Program Menu C Submenus ↓ ↑ ↓ ↑ ↓ ↑ ↓ ↑ > > ^ > ^ > ^ > ^ C1 Install C1.1 Tank Type Parameters C1.2 Tank Height C1.5 Blocking...
  • Page 75 OPERATION REFLEX RC SERIES Normal Program Menu C Submenus ↓ ↑ ↓ ↑ ↓ ↑ ↓ ↑ > > ^ > ^ > ^ > ^ C5.1. HART C5.1. HART C5.1.1 Current Loop Mode C5.1. HART C5.1. HART Communication Communication...
  • Page 76 OPERATION REFLEX RC SERIES Normal Program Menu C Submenus ↓ ↑ ↓ ↑ ↓ ↑ ↓ ↑ > > ^ > ^ > ^ > ^ C6 Display C6 Display C6.4 1st Meas. page C6.4 1st Meas. page C6.4.1 Function...

  • Page 77: Function Description

    OPERATION REFLEX RC SERIES Normal Program Menu C Submenus ↓ ↑ ↓ ↑ ↓ ↑ ↓ ↑ > > ^ > ^ > ^ > ^ C7.5 Units C7.5 Units C7.5.1 Length C7.5 Units C7.5 Units C7.5.2.1 Cst. Length / Text C7.5.2.2 Cst.
  • Page 78 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default A4 Application Assistant A4 Application Assistant A4 Application Assistant A4 Application Assistant A4.1 Standard Setup This starts a quick set-up procedure applicable to most applications. You can set the length unit, installation specifications (tank type, tank height etc.) and current output specifications...
  • Page 79 OPERATION REFLEX RC SERIES B – Test menu Menu Function Function description Selection list Default B1 Simulation B1.1 Set Value B1.1 Set Value B1.1 Set Value B1.1 Set Value B1.1.2 Level This sets the device to a given test level min-max: value.
  • Page 80 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default B1.1.5 Level Lin. This sets the device to a given test level min-max: value (linearized). This menu item is -5000.0...+5000.0 m / only available if you set up a -196.85...
  • Page 81 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default B1.1.8 Distance Lin. This sets the device to a given test min-max: distance value (linearized). This menu -5000.0...+5000.0 m / item is only available if you set up a -196.85...
  • Page 82 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default B1.2 Output B1.2 Output B1.2 Output B1.2 Output B1.2.1 Current Output 1 This sets analogue output 1 to a test 3.6...21.5 mA value [mA]. Output will change to the selected value, independent of the measured value.
  • Page 83 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default — B2.11 Ullage Volume This menu item shows the ullage Read only volume readings measured at this time. This measurement data is shown with the units set in menu C7.5 Units C7.5 Units...
  • Page 84 OPERATION REFLEX RC SERIES C – Full Setup menu Menu Function Function description Selection list Default C1 Install. Parameters C1.1 Tank Type The conditions in which the device is used. If Flat Surface, Medium Steep Slope the surface of the product is flat, select Slope, Steep Slope "Flat surface".
  • Page 85 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C1.9 Distance piece Optional distance piece between the min-max: 0 mm / 0¨ converter and the process connection. This 0.0…2000 mm / is for the high-temperature version of the 0.0...78.740¨...
  • Page 86 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C2.4 Measuring This menu item is set by default to "Direct Direct, Direct Plus Direct Mode Measuring" to measure the level of most tank contents. The device uses the largest radar signal to monitor level.
  • Page 87 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C2.8 Empty This function starts and stops the Disabled, Enabled Disabled Spectrum interference signal filter. Interference Enable signals are the result of fixed and moving obstacles inside the tank. If you must do a spectrum analysis, record an empty spectrum first.
  • Page 88 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C4 Output C4.1 Current Output 1 C4.1 Current Output 1 C4.1 Current Output 1 C4.1 Current Output 1 C4.1.1 Current Out. 1 Make a selection from the available output...
  • Page 89 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C4.1.7 Low Error This menu item is available if C4.1.5 Error min-max: 3.5 mA Current Function is set to "Low". You can change the 3.5...3.6 mA value to which the current output will change if an error occurs.
  • Page 90 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default — — C5.1.2.3 Long Tag Use this menu item to change the long Tag name. It can have a maximum of 32 characters. For more data about the Keypad...
  • Page 91 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C5.1.4.3 Tertiary Var. This is the third measurement type shown Level, Distance, Sensor Reflection on HART® controllers. Make a selection Value, Reflection from the list. Minimum access level to change the...
  • Page 92 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C6.4.4 100% Range This is the 100% value given to the bar graph Refer to "Function Refer to indicator in Normal mode. The range is description". "Function related to the measurement type set in description".
  • Page 93 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C6.5 2nd Meas. Page C6.5 2nd Meas. Page C6.5 2nd Meas. Page C6.5 2nd Meas. Page C6.5.1 Function This menu item changes the configuration One Value, One Value &...
  • Page 94 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C6.5.8 3rd Value This changes the measurement type of the Level, Distance, Sensor Reflection Variable third value on the measurement page. This Value, Reflection menu item is only available if you set C6.5.1 Function to "Three Values".
  • Page 95 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default — — C7.2.3 Reset This is a special password that makes your Passwords passwords for the "operator" and "expert" access levels go back to the default passwords. This password is supplied on request by the after-sales service department.
  • Page 96 OPERATION REFLEX RC SERIES Menu Function Function description Selection list Default C7.5.5 Mass The mass unit shown in Normal mode if you kg, t, lb, tn.sh., tn.l., Cst. made a mass table in the C3 Conversion Mass menu. If you set this menu item to "Cst.

  • Page 97: Further Information On Device Configuration In Program Mode

    OPERATION REFLEX RC SERIES 6.4 Further information on device configuration in Program mode 6.4.1 Standard setup Use this procedure (menu item A4.1 Standard Setup) to change the length unit, tank type, tank height, current output variable, 0% range, 100% range, current output range and error function.
  • Page 98 OPERATION REFLEX RC SERIES Screen Steps Description • [> > > > ] to change the position of the Tank height. The distance from the flange face / thread stop of the tank connection cursor. down to the tank bottom. If the tank has a •...
  • Page 99 OPERATION REFLEX RC SERIES Screen Steps Description • [> > > > ] to change the position of the 100% range. Use this step to give the 100% output setting in the tank. Refer to the cursor. illustrations that follow. Illustration 1 •...

  • Page 100: Empty Spectrum Recording

    OPERATION REFLEX RC SERIES 6.4.2 Empty spectrum recording The empty spectrum recording procedure is important for the performance of the device. We recommend that the tank is empty or only filled to the minimum level before you do the procedure.
  • Page 101 OPERATION REFLEX RC SERIES Screen Steps Description • [ ], [> > > > ], [ ] and 2 × [> > > > ]. Push these buttons to start the Record Spectrum (Empty Spectrum) procedure. • [ ] or [ ] for the selection of the empty spectrum type (Full Empty spectrum type.

  • Page 102: Hart® Network Configuration

    OPERATION REFLEX RC SERIES Screen Steps Description • [ ] or [ ] to change the Empty Spectrum Enable. If you set the menu item to "Enable", the device will use parameter ("Disable" or "Enable"). the empty spectrum recording data. If you •...

  • Page 103: Distance Measurement

    OPERATION REFLEX RC SERIES • Push [ ] or [ ] to set the screen to "Yes" and push [^ ^ ^ ^ ]. The output is set to point-to-point mode. The current output changes to a range of 4...20 mA or 3.8...20.5 mA (this range is set in menu item C4.1.4 Current Out.
  • Page 104 OPERATION REFLEX RC SERIES Figure 6-7: Distance measurement 1 Tank Height (C1.2) 2 Reference point. You can use menu item C1.10 Reference Offset to move the reference point. 3 Blocking Distance (C1.5) 4 0% Range (C4.1.2), if menu item C4.1.4 Current Out. Range is set to "4-20mA" or "3.8-20.5mA"...

  • Page 105: Level Measurement

    OPERATION REFLEX RC SERIES 6.4.5 Level measurement The device gives a current output signal that is related to level measurements when the menu item C4.1.1 Current Out. 1 Var. (Current Output 1 Variable) C4.1.1 Current Out. 1 Var. (Current Output 1 Variable) C4.1.1 Current Out.
  • Page 106 OPERATION REFLEX RC SERIES Figure 6-8: Level measurement 1 Tank Height (C1.2) 2 Tank bottom reference point. You can use menu item C1.11 Tank Bottom Offset to move the position of the tank bottom reference point. 3 Blocking Distance (C1.5) 4 100% Range (C4.1.3), if menu item C4.1.4 Current Out.

  • Page 107: How To Configure The Device To Measure Volume Or Mass

    OPERATION REFLEX RC SERIES 6.4.6 How to configure the device to measure volume or mass The device can be configured to measure volume or mass. It can also be configured to a custom quantity to be measured. You can set up a strapping table in the conversion menu (C3 Conversion).
  • Page 108 OPERATION REFLEX RC SERIES Figure 6-9: A plot of points for a volume or mass table 1 Silo with reference points 2 Silo model with plotted points How to delete a volume or mass table • Enter Program mode. • Push 2 × [ ], [> > > > ], 2 × [ ] and 2 × [> > > > ] to go to C3.1.1 Erase Table?.

  • Page 109: How To Measure Correctly In Silos With Curved Or Conical Bottoms

    OPERATION REFLEX RC SERIES 6.4.7 How to measure correctly in silos with curved or conical bottoms It is possible that the device cannot find the bottom of the silo if it is installed in a silo with a dish- shaped or conical bottom. The form of the silo bottom causes a delayed radar reflection and the device will display the error message "Measurement is lost in the tank bottom".

  • Page 110: How To Make A Filter To Remove Radar Signal Interference

    OPERATION REFLEX RC SERIES 6.4.8 How to make a filter to remove radar signal interference If the device measures level in a silo that contains obstructions (ladder, supports etc.), these objects can cause radar signal interference (parasitic signals). You can use the empty spectrum function (menu A4.2) in the Quick Setup menu to make a filter to remove radar signal...

  • Page 111: Status Messages And Diagnostic Data

    OPERATION REFLEX RC SERIES 6.5 Status messages and diagnostic data Device status and error messages are shown on a device status page in Normal mode and in menu item "C7.3.1 Messages View" in Program mode. Messages shown agree with NAMUR Guidelines NE 107.
  • Page 112 OPERATION REFLEX RC SERIES Normal mode: device status messages There is also a device status page in Normal mode. This page shows a list of short status messages and gives the status of the device at this time. Push the [ ] or [ ] button to get to the status device status page in Normal mode.
  • Page 113 OPERATION REFLEX RC SERIES Description of errors and corrective actions Status Error message Description Corrective action type F F F F Sensor Sensor Sensor Sensor Corrupt Sensor Parameter The sensor memory is bad. De-energize and then energize the device again.
  • Page 114 OPERATION REFLEX RC SERIES Status Error message Description Corrective action type F F F F Configuration Configuration Configuration Configuration Inconsistent NVRAM Incorrect data in the parameter De-energize and then energize the memory. device again. If the message is shown again, tell the supplier.
  • Page 115 OPERATION REFLEX RC SERIES Status Error message Description Corrective action type C C C C Configuration Configuration Configuration Configuration Sensor Sim. Active The device simulates a Push "Enter" to stop the test. measurement value that is set in menu item B1.1 Set Value B1.1 Set Value...
  • Page 116 OPERATION REFLEX RC SERIES Status Error message Description Corrective action type S S S S Process Process Process Process CO Saturated Low The measurement value is less Do a check of the process than the minimum value of the conditions and the minimum current output range.
  • Page 117 OPERATION REFLEX RC SERIES Status Error message Description Corrective action type M M M M Sensor Information Sensor Information Sensor Information Sensor Information Failed Sensor MCU Test The sensor electronics does a De-energize and then energize the continuous self-test procedure.

  • Page 118: Service

    SERVICE REFLEX RC SERIES 7.1 Periodic maintenance 7.1.1 General notes In normal operational conditions, no maintenance is necessary. If it is necessary, maintenance must be done by approved personnel (the manufacturer or personnel approved by the manufacturer). INFORMATION! For more data about regular inspections and maintenance procedures for devices with Ex and other approvals, refer to the related supplementary instructions.

  • Page 119: How To Clean The Top Surface Of The Device

    SERVICE REFLEX RC SERIES CAUTION! Use multi-purpose grease that is applicable for the operating temperature range of the O-ring with the properties that follow: Operating temperature range of -40...+130 ° C / -40...+266 ° F without a negative effect on the •...

  • Page 120: How To Clean Horn Antennas Under Process Conditions

    Replacement of signal converters of other radar devices: Replacement of signal converters of other radar devices: converter and installation of the REFLEX RC Series signal converter. For the procedure, refer Replacement of the VG6 signal converter with the REFLEX RC Series signal converter page 121.

  • Page 121: Replacement Of The Vg6 Signal Converter With The Reflex Rc Series Signal Converter

    • Find the serial number on the VG6 nameplate. • Record this number. • Create an order code for the REFLEX RC Series signal converter. Make sure that the REFLEX RC Series signal converter has the adaptor option for the VG6 flange system.
  • Page 122 For more data about electrical connection procedures, refer to Electrical installation: output options with cable gland on page 46 • Put the REFLEX RC Series signal converter on the VG6 flange system. Make sure that the flange system fully engages in the mating part (signal converter).

  • Page 123: Spare Parts Availability

    SERVICE REFLEX RC SERIES Procedure 4: Device configuration (REFLEX RC Series) Standard setup • For the Quick Setup procedure refer to on page 97. For more data about device Operation configuration, refer to on page 60. CAUTION! You recorded the device settings of the VG6 level transmitter before you attached the new signal converter.

  • Page 124: Returning The Device To The Manufacturer

    SERVICE REFLEX RC SERIES 7.6 Returning the device to the manufacturer 7.6.1 General information This device has been carefully manufactured and tested. If installed and operated in accordance with these operating instructions, it will rarely present any problems. WARNING! Should you nevertheless need to return a device for inspection or repair, please pay strict...

  • Page 125: Form (For Copying) To Accompany A Returned Device

    SERVICE REFLEX RC SERIES 7.6.2 Form (for copying) to accompany a returned device CAUTION! To avoid any risk for our service personnel, this form has to be accessible from outside of the packaging with the returned device. Company: Address: Department: Name: Tel.

  • Page 126: Technical Data

    TECHNICAL DATA REFLEX RC SERIES 8.1 Measuring principle A radar signal is emitted via an antenna, reflected from the product surface and received after a time t. The radar principle used is FMCW (Frequency Modulated Continuous Wave). The FMCW-radar transmits a high frequency signal whose frequency increases linearly during the measurement phase (called the frequency sweep).
  • Page 127 TECHNICAL DATA REFLEX RC SERIES Measurement modes "Direct" mode "Direct" mode "Direct" mode "Direct" mode The device uses the largest radar signal to monitor level. "Direct Plus" mode "Direct Plus" mode "Direct Plus" mode "Direct Plus" mode If it is possible there will be an interference signal in the measurement zone that is larger than the level signal, select "Direct Plus"...

  • Page 128: Technical Data

    TECHNICAL DATA REFLEX RC SERIES 8.2 Technical data INFORMATION! • The following data is provided for general applications. If you require data that is more relevant to your specific application, please contact us or your local sales office. Additional information (certificates, special tools, software,...) and complete product •...
  • Page 129 TECHNICAL DATA REFLEX RC SERIES Beam angle Metallic Horn, DN 80 (3¨): 9° (antenna) Metallic Horn, DN 100 (4¨): 8° Metallic Horn, DN150 (6¨): 6° Metallic Horn, DN200 (8¨): 5° PP Drop, DN80 (3¨): 9° PP Drop, DN100 (4¨): 7°...
  • Page 130 TECHNICAL DATA REFLEX RC SERIES Pressure Pressure Pressure Pressure Process pressure -1…16 barg / -14.5…232 psig Subject to the process connection used and the process connection temperature. Guidelines for maximum operating pressure For more data, refer to on page 136.
  • Page 131 TECHNICAL DATA REFLEX RC SERIES Process connections Thread G 1 A...1½ A (ISO 228); 1...1½ NPT (ASME B1.20.1) Flange version Flange version Flange version Flange version EN 1092-1 Low-pressure flanges: DN80...200 in PN01; Standard flanges: DN80...200 in PN10, PN16 and PN40 (Type B1); others on request Optional flange facing for standard flanges: Type A ASME B16.5...
  • Page 132 TECHNICAL DATA REFLEX RC SERIES PROFIBUS PA PROFIBUS PA (pending) PROFIBUS PA PROFIBUS PA Type PROFIBUS MBP interface that agrees with IEC 61158-2 with 31.25 kbit/s; voltage mode (MBP = Manchester-Coded, Bus-Powered) Function blocks 1 × Transducer Block Level (TB-Level), 1 × Physical Block (PB), 4 × Analog Input Block (AI), 1 ×...
  • Page 133 TECHNICAL DATA REFLEX RC SERIES NAMUR NAMUR NE 21 Electromagnetic Compatibility (EMC) of Industrial Process and Laboratory Control Equipment NAMUR NE 43 Standardization of the Signal Level for the Failure Information of Digital Transmitters NAMUR NE 53 Software and Hardware of Field Devices and Signal Processing...

  • Page 134: Measuring Accuracy

    TECHNICAL DATA REFLEX RC SERIES 8.3 Measuring accuracy Use these graphs to find the measuring accuracy for a given distance from the transmitter. Figure 8-2: Measuring accuracy (graph of measuring accuracy in mm against measuring distance in m) X: Measuring distance from the thread stop or flange facing of the process connection [m]...

  • Page 135: Minimum Power Supply Voltage

    TECHNICAL DATA REFLEX RC SERIES 8.4 Minimum power supply voltage Use these graphs to find the minimum power supply voltage for a given current output load. Non-Ex and Hazardous Location approved (Ex i / IS) devices Figure 8-4: Minimum power supply voltage for an output of 21.5 mA at the terminals (Non-Ex and Hazardous Location...

  • Page 136: Guidelines For Maximum Operating Pressure

    TECHNICAL DATA REFLEX RC SERIES 8.5 Guidelines for maximum operating pressure WARNING! Make sure that the devices are used within their operating limits. Figure 8-6: Pressure / temperature de-rating (EN 1092-1), flange and threaded connection, in °C and barg Figure 8-7: Pressure / temperature de-rating (EN 1092-1), flange and threaded connections, in °F and psig 1 Process pressure, p [barg] 2 Process connection temperature, T [°C]...
  • Page 137 TECHNICAL DATA REFLEX RC SERIES INFORMATION! CRN certification (pending) CRN certification (pending) CRN certification (pending) CRN certification (pending) There is a CRN certification option for devices with process connections that agree with ASME standards. This certification is necessary for all devices that are installed on a pressure vessel and used in Canada.

  • Page 138: Dimensions And Weights

    TECHNICAL DATA REFLEX RC SERIES 8.6 Dimensions and weights Metallic Horn antennas with threaded connections Figure 8-10: Metallic Horn antennas with G or NPT threaded connections INFORMATION! The diameter of the outer sheath of the cable must be 7 …...
  • Page 139 TECHNICAL DATA REFLEX RC SERIES Metallic Horn antenna versions with standard flange connections Figure 8-11: Metallic Horn antennas with standard flange connections 1 Metallic Horn antenna with a flange connection 2 Metallic Horn antenna with a flange connection and the 2° slanted flange option...
  • Page 140 TECHNICAL DATA REFLEX RC SERIES Metallic Horn antenna versions with low-pressure flange connections Figure 8-12: Metallic Horn antennas with low-pressure flange connections 1 Metallic Horn antenna with a low-pressure flange attached to a G threaded connection (ISO 228-1) 2 Metallic Horn antenna with a low-pressure flange attached to an NPT threaded connection (ASME B1.20.1)
  • Page 141 TECHNICAL DATA REFLEX RC SERIES Drop antennas with threaded connections Figure 8-13: Drop antennas with threaded connections INFORMATION! The diameter of the outer sheath of the cable must be 7 12 mm or 0.28 0.47 • … … ¨ Cable glands for cQPSus-approved devices must be supplied by the customer.
  • Page 142 TECHNICAL DATA REFLEX RC SERIES Drop antennas with standard flange connections Figure 8-14: Drop antennas with standard flange connections 1 Drop antenna with a flange connection 2 Drop antenna with a flange connection and a flange plate protection option 3 Drop antenna with a flange connection and a 2° slanted flange option...
  • Page 143 TECHNICAL DATA REFLEX RC SERIES Drop antennas with standard flange connections: Dimensions in mm Drop antenna Dimensions [mm] [°] version Øe DN80/3¨ PP 205...215.6 126...136 331...352 DN80/3¨ PTFE 205...215.6 128...139 333...355 DN100/4¨ PP 205...215.6 149...159 354...375 DN100/4¨ PTFE 205...215.6 152...162 357...378...
  • Page 144 TECHNICAL DATA REFLEX RC SERIES Drop antennas with low-pressure flange connections Figure 8-15: Drop antennas with low-pressure flange connections 1 Metallic Horn antenna with a low-pressure flange attached to a G threaded connection (ISO 228-1) 2 Metallic Horn antenna with a low-pressure flange attached to an NPT threaded connection (ASME B1.20.1) INFORMATION! •...
  • Page 145 TECHNICAL DATA REFLEX RC SERIES Drop antennas with low-pressure flange connections: Dimensions in mm Drop antenna Dimensions [mm] version Øe DN80/3¨ DN100/4¨ DN150/6¨ 1 This is the dimension without the antenna extension option. A maximum of 5 antenna extensions are available. Each antenna extension is 105 mm long.
  • Page 146 TECHNICAL DATA REFLEX RC SERIES Purging option Figure 8-16: Purging options 1 1/8 NPTF threaded connection for purging system (the plug is supplied by the manufacturer) INFORMATION! Purging system Purging system Purging system Purging system This option is available for all Metallic Horn antennas. Flange connections must have a pressure rating of PN16 (EN 1092-1), PN40 (EN 1092-1), Class 150 (ASME B16.5), Class 300 (ASME B16.5),...
  • Page 147 TECHNICAL DATA REFLEX RC SERIES Converter weight Type of housing Weights [kg] [lb] Compact aluminium housing Compact stainless steel housing Antenna option weights Antenna options Min./Max. weights [kg] [lb] Standard options, without converter Standard options, without converter Standard options, without converter Standard options, without converter DN80 / 3¨...

  • Page 148: Description Of Hart Interface

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.1 General description The HART® Protocol is an open digital communication protocol for industry. It is free to use by anyone. It is included in the software embedded in signal converters of HART-compatible devices.

  • Page 149: Software History

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.2 Software history INFORMATION! In the table below, "x" is a placeholder for possible multi-digit alphanumeric combinations, depending on the available version. Release date Devices HART® Device Revision DD Revision 2016-04 All revisions HART®...

  • Page 150: Multi-Drop Connection (2-Wire Connection)

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.3.2 Multi-Drop connection (2-wire connection) Up to 63 devices may be installed in parallel (this signal converter and other HART® devices). For an illustration of multi-drop networks, refer to Multi-drop networks on page 53.

  • Page 151: Operation

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.5.2 Operation INFORMATION! The Field Communicator will not give you access to the service menu. A simulation is only possible for current outputs. The Field Communicator and the device's local display use almost the same procedures to operate the signal converter.

  • Page 152: Field Device Tool / Device Type Manager (Fdt / Dtm)

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.7 Field Device Tool / Device Type Manager (FDT / DTM) A Field Device Tool Container (FDT Container) is a PC program used to configure HART®, PROFIBUS and FOUNDATION™ fieldbus devices. To configure a device, an FDT container uses the applicable Device Type Manager (DTM).

  • Page 153: Hart® Menu Tree For Ams

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.9 HART® menu tree for AMS Abbreviations of the following tables: • Optional, depending on device version and configuration • Read only 9.9.1 Overview AMS menu tree (positions in menu tree) Configure / Setup...

  • Page 154: Ams Menu Tree (Details For Settings)

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.9.2 AMS menu tree (details for settings) Configure / Setup Quick Setup General Language / Tag / Long Tag Security Login / Change Password / Reset Passwords / Lock Status / Lock / Unlock Device / Write Protect...
  • Page 155 DESCRIPTION OF HART INTERFACE REFLEX RC SERIES Full Setup Device Information / Long Tag / Serial Number / Manufacturer Device Name / V Number Electronic Revision / Field Device Revision / Software Revision / Hardware Revision / Electronics Serial / Production Date...

  • Page 156: Hart® Menu Tree For Pdm

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES Device Diagnostics Device Status Condensed Status (NE 107) Condensed Status (NE 107) Device Simulation Active Standard Device Status / Ext. Device Status / Write Protect / Device Diagnostic Status 0 / Device Diagnostic Status 1...

  • Page 157: Overview Pdm Menu Tree (Positions In Menu Tree)

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.10.1 Overview PDM menu tree (positions in menu tree) Overview: Device Menu Download To Device... Upload To PG/PC... Quick Setup General Security Units Application Assistant Full Setup Process Install. Parameters Process Conversion Output...

  • Page 158: Pdm Menu Tree (Details For Settings)

    DESCRIPTION OF HART INTERFACE REFLEX RC SERIES 9.10.2 PDM menu tree (details for settings) Device Menu Download To Device... Upload To PG/PC... Quick Setup General Language / Tag / Long Tag Security Login / Change Password / Reset Passwords / Lock Status...
  • Page 159 DESCRIPTION OF HART INTERFACE REFLEX RC SERIES Device Information / Long Tag / Serial Number Manufacturer / Device Name / V Number Electronic Revision / Field Device Revision Software Revision / Hardware Revision Electronics Serial No. / Production Date Security...
  • Page 160 DESCRIPTION OF HART INTERFACE REFLEX RC SERIES Diagnosis Device Status Condensed Status Condensed Status (NE 107) / Device Simulation Active (NE 107) Standard Device Status / Ext. Device Status / Write Protect / Device Diagnostic Status 0 / Device Diagnostic Status 1...

  • Page 161: Appendix

    Make a selection from each column to get the full order code. 4 REFLEX RC Series FMCW Radar - 24 GHz radar (FMCW) level transmitter for solids from granulates to REFLEX RC Series FMCW Radar - 24 GHz radar (FMCW) level transmitter for solids from granulates to...
  • Page 162 APPENDIX REFLEX RC SERIES Display – Documentation language Display Documentation language Display Display Documentation language Documentation language English German French Italian Spanish Portuguese Japanese Chinese (simplified) A Russian B Czech C Turkish D Polish Process conditions (Pressure, temperature, material and remarks) / Process...
  • Page 163 APPENDIX REFLEX RC SERIES Process connection: Size / Pressure class / Flange face finish Process connection: Size / Pressure class / Flange face finish Process connection: Size / Pressure class / Flange face finish Process connection: Size / Pressure class / Flange face finish...
  • Page 164 APPENDIX REFLEX RC SERIES Alternative flange facing Alternative flange facing Alternative flange facing Alternative flange facing EN 1092-1 flange Type A (Flat Face) ASME B16.5 flange B FF (Flat Face) Calibration certificate Calibration certificate Calibration certificate Calibration certificate Without: Accuracy ±2 mm (±0.08¨) Calibration certificate ±2 mm (±0.08¨) up to 10 m...

  • Page 165: Spare Parts

    161 and use the RC order code. When you send an order to replace a VG6 signal converter with an REFLEX RC Series signal converter, use the reference numbers in the "Replacement signal converter for mechanical sub- assembly of the VG6"...
  • Page 166 Replacement signal converter for mechanical sub-assembly of the VG6 4 REFLEX RC Series FMCW Radar - 24 GHz radar (FMCW) level transmitter for solids from granulates to REFLEX RC Series FMCW Radar - 24 GHz radar (FMCW) level transmitter for solids from granulates to...
  • Page 167 APPENDIX REFLEX RC SERIES Display – Documentation language Display Documentation language Display Display Documentation language Documentation language English German French Italian Spanish Portuguese Japanese Chinese (simplified) A Russian B Czech C Turkish D Polish Process conditions (Pressure, temperature, material and remarks) / Process...
  • Page 168 APPENDIX REFLEX RC SERIES Other spare parts Figure 10-1: Other spare parts 1 Cover stop 2 Terminal compartment cover 3 Gasket for terminal compartment cover 2 4 Terminal cartridge 5 Cable gland 6 Signal converter 7 Display module 8 Gasket for display cover 9 or blind cover 11...
  • Page 169 APPENDIX REFLEX RC SERIES Description Quantity Part reference Aluminium terminal compartment cover (2) (2) + gasket (3) (3) + cover stop XFDX010502 Stainless steel terminal compartment cover (2) (2) + gasket (3) (3) + cover XFDX010602 stop (1) Plastic sun cover for display cover (13)

  • Page 170: Accessories: General Items

    APPENDIX REFLEX RC SERIES 10.3 Accessories: general items We supply accessories for this device. When you send an order for accessories, please give the reference numbers that follow: Figure 10-2: Accessories: general items 1 Weather protection 2 Viator RS232 / HART converter...

  • Page 171: Accessories: Process Connection Kits

    APPENDIX REFLEX RC SERIES 10.4 Accessories: process connection kits Figure 10-3: Accessories: process connection kits 1 316L low-pressure flange disc for G (ISO 228) thread connection on level transmitter 2 316L low-pressure flange disc for NPT (ASME B1.20.1) thread connection on level transmitter 3 PP or PTFE 2°...
  • Page 172 APPENDIX REFLEX RC SERIES Item Description Quantity Part reference 316L low-pressure flange disc (max. 1 barg at +20°C ) for G 1½ process connection on level transmitter Disc with holes, drilled according to DN80 PN2.5...PN40 / 3¨ 150 lb XF70000010 Disc with holes, drilled according to DN100 PN2.5...PN40 / 4¨...
  • Page 173 APPENDIX REFLEX RC SERIES Item Description Quantity Part reference Orientation system (max. tilt 30°) with 316L low-pressure flange disc (atmospheric pressure) for 1½ NPT process connection on level transmitter Disc with holes, drilled according to DN80 PN2.5...PN40 / 3¨ 150 lb XF70000N61 Disc with holes, drilled according to DN100 PN2.5...PN40 / 4¨...

  • Page 174: Glossary

    APPENDIX REFLEX RC SERIES 10.5 Glossary Dielectric constant Dielectric constant Dielectric constant Dielectric constant An electrical property of the product to be measured used in radar measurement. Also known as εr, DK and relative permittivity. Defines the strength of the wave reflected back to the device's signal converter.
  • Page 175 APPENDIX REFLEX RC SERIES Mass Mass Total mass of silo contents. Mass Mass PACTware PACTware PACTware PACTware™ Software that operates and configures field devices from a remote workstation. It is not necessary to use fieldbus software or programs developed by the manufacturer.
  • Page 176 APPENDIX REFLEX RC SERIES Figure 10-4: Measurement definitions: distance 1 Distance 2 Blocking distance 3 Flange facing 4 Gas (Air) 5 Tank height 6 Ullage volume or mass Figure 10-5: Measurement definitions: level 1 Level 2 Volume or mass www.hycontrol.com...
  • Page 177 NOTES REFLEX RC SERIES 01/2019 - RC SERIES MANUAL v1 www.hycontrol.com...
  • Page 178 NOTES REFLEX RC SERIES www.hycontrol.com 01/2019 - RC SERIES MANUAL v1...
  • Page 179 NOTES REFLEX RC SERIES 01/2019 - RC SERIES MANUAL v1 www.hycontrol.com...
  • Page 180 Hycontrol Ltd Larchwood House Orchard Street Redditch Worcestershire B98 7DP United Kingdom Tel: +44 (0) 1527 406800 Fax: +44 (0) 1527 406810 Email: sales@hycontrol.com Web: www.hycontrol.com Company registered in England No: 1755684...

This manual is also suitable for:

Reflex rc 4 seriesReflex rc 5 seriesReflex rc 6 seriesReflex rc 7 seriesReflex rc a seriesReflex rc b series ... Show all

Table of Contents
