Making Connections

Connecting External Devices and Touch Connection

Type-C
or
TOUCH
HDMI
or
TOUCH
VGA
Your external device(s) can be connected in any of the following configurations:

Type C Connection

To connect via Type C:
Connect a Type C cable from your external device to the Type C port on the
ViewBoard.

HDMI Connection

To connect via HDMI:
1. Connect an HDMI cable from your external device to the HDMI 1/2/3 port on the
ViewBoard.
2. Connect a USB cable to the external device from the TOUCH port of the
ViewBoard.
NOTE: The TOUCH 1 port is for the HDMI 1 port. The TOUCH 2 port is for the
HDMI 2 and HDMI 3 ports.
Type-C Cable
USB Cable
HDMI Cable
USB Cable
VGA Cable
24
Computer
