Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
Page 3 Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •...
Page 4 • Only use attachments/accessories specified by the manufacturer. • When a cart is used, use with caution when moving the cart/equipment combination to avoid injury from tipping over. • Disconnect the power plug from the AC outlet if the device is not being used for a long period of time.
Page 5: Table Of Contents
Contents Safety Precautions ............3 Introduction .............. 10 Package Contents ....................10 Wall Mount Kit Specifications (VESA) ..............11 Product Overview ....................12 Front View ......................12 Rear View ......................12 Control Panel ......................13 I/O Panels ......................14 Front I/O ......................15 Rear I/O ......................
Page 6 Using Your ViewBoard ..........35 Turning On/Off the ViewBoard ................35 Initial Launch Setup ....................36 Home Screen ......................39 How to Sign Up ...................... 39 Use as Guest ......................40 Sign In ........................40 Home Screen Message ..................41 Toolbar .........................42 Toolbar Icons ......................43 On-Screen Display (OSD) Menu - General Settings ..........44 Input Settings ......................
Page 7 ViewBoard Settings ........... 52 Wireless & Network ....................52 Wi-Fi ........................53 Ethernet ........................ 54 Wireless Hotspot ....................55 Bluetooth ......................56 VPN ........................57 File Sharing ......................59 Samba ........................60 Display ........................61 Wallpaper ......................62 Protection ......................63 HDMI Out ......................64 Preference ......................65 Touch ........................
Page 8 Pre-installed Applications and Settings ...... 87 myViewBoard Display ...................87 myViewBoard Manager ..................88 myViewBoard Whiteboard ...................89 vCast ........................92 Display Group Settings ..................94 Synchronized Group Screen All the Time .............. 96 Share a Screen to the Display Group (One to Many Casting) ........ 96 Moderator Mode ....................
Page 9 Appendix ..............133 Specifications ......................133 Display Modes ....................135 DisplayPort ......................135 HDMI ........................135 USB Type C ......................136 VGA ........................136 HDMI Out ......................137 Troubleshooting ....................138 Maintenance.......................140 General Precautions .................... 140 Cleaning the Screen ..................... 140 Cleaning the Case ....................140 Regulatory and Service Information ......
Page 10: Introduction
(30.16 cm) rádiové a televízne vysielanie Izjava o skladnosti 4 inches 4 inches (10 cm) (10 cm) 4 inches (10 cm) ViewSonic Europe Limited Haaksbergweg 75 1101 BR Amsterdam ship by region Netherlands +31 (0) 650608655 EPREL@viewsoniceurope.com IFP110 Support Center www.viewsonic.com...
Page 11: Wall Mount Kit Specifications (Vesa)
Model VESA Spec. (A x B) Standard Screw (C x D) Quantity IFP110 1000 x 800 mm M8 x 20 mm NOTE: Do not use screws that are longer than the standard dimension, as they may cause damage to the inside of the display.
Page 12: Product Overview
Product Overview Front View TOUCH NFC Reader Front I/O 8-array Microphone Speaker Speaker Control Panel Rear View OPS Slot Wi-Fi Slot Side I/O Rear I/O Power Switch & AC IN...
Page 13: Control Panel
Control Panel Number Item Description NFC reader. Ambient light sensor. Remote control IR receiver. • Power indicator light. • Press to turn on the display. • Once on, press again to turn on or off the backlight only. • Once on, press and hold to turn off the display. Return to the ViewBoard's main interface.
Page 14: I/O Panels
I/O Panels TOUCH Front I/O OPS Slot Wi-Fi Slot Side I/O Rear I/O...
Page 15: Front I/O
Front I/O Number Item Description • USB Type C input • USB 3.0 standard • Supports DP v. 1.2 with audio, video, and touch (FRONT TYPE C) • Supports LAN by 10M/100M • Supports power charge up to 65W. Power charge supported: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A •...
Page 16: Rear I/O
Rear I/O AUDIO IN TOUCH 2 AUDIO OUT Number Item Description External computer video input AUDIO IN External computer audio input • USB Type B • Touch signal output to external computer • After connection (with an external computer), the TOUCH 2 device connected to the USB port can directly be used by the external computer...
Page 17: Side I/O
Side I/O TOUCH 1 HDMI OUT HDMI 1 HDMI 2 Number Item Description • USB Type A input • USB 3.0 standard • Connect USB devices such as hard disks, keyboard, mouse, etc. • Automatically switches between the external computer and ViewBoard •...
Page 18: Ops And Wi-Fi Slot
OPS and Wi-Fi Slot VPC35 / VPCF5 / VPC37 / VPC-A31 Wi-Fi module VB-WIFI-005/VB-WIFI-001 NOTE: OPS output: 18V/5A.
Page 19: Remote Control
Remote Control Number Description Power on/off Screen capture Startup writing Back to the ViewBoard player Home Screen Back/Return to the previous page Increase/Decrease the Volume Number Keypad Information Input source selection Media control buttons: • Red: Play/Pause • Green: Stop •...
Page 20 Inserting Remote Control Batteries To insert batteries into the remote control: 1. Remove the cover on the rear of the remote control. 2. Insert two “AAA” batteries, ensuring the “+” symbol on the battery matches the “+” on the battery post. 3.
Page 21 Remote Control Receiver Range The working range of the remote control is shown here. It has an effective range of ° 8 meters, 30 degrees left and right. Ensure there is nothing obstructing the remote control’s signal to the receiver. TOUCH 30°...
Page 22: Using Gestures
Using Gestures Touch gestures allow the user to use pre-determined commands without using a keyboard or mouse. Using gestures on the ViewBoard, the user can select/deselect objects, change the location of an object, access settings, erase digital ink, and much more. Select and Deselect an Object (Clicking) Press and release the ViewBoard to select/deselect options or objects.
Page 23 Moving an Object Press and hold the object on the ViewBoard and slowly drag it with your finger to your desired location. TOUCH Erasing Digital Ink Use your flattened hand, palm, or fist on the ViewBoard and move your hand across the area which you wish to erase.
Page 24: Making Connections
Making Connections Connecting to Power 1. Connect the power cord to the AC IN jack at the rear of the display. 2. Plug the power cord plug into a power outlet.
Page 25: Connecting To External Devices And Enabling Touch
Connecting to External Devices and Enabling Touch Type C Cable Type-C USB Cable TOUCH HDMI Cable HDMI USB Cable TOUCH Computer DP Cable USB Cable TOUCH VGA Cable...
Page 26: Usb Type C Connection
Your external device(s) can be connected in any of the following configurations: USB Type C Connection To connect via Type C: Connect a Type C cable from your external device to a Type C port on the ViewBoard. HDMI Connection To connect via HDMI: 1.
Page 27: Rs-232 Connection
RS-232 Connection RS-232 Computer When you use a RS-232 serial cable to connect the display to an external computer or control system, certain functions can be controlled remotely such as: power on and off, volume adjustment, input select, brightness, and more.
Page 28: Usb Connection
USB Connection Just like any PC, it is easy to connect various USB devices and other peripherals to your ViewBoard. USB Type A USB Device Plug the USB device or storage drive into a USB Type A port of the ViewBoard. USB Type C USB Device Plug the USB device or storage drive into the USB Type C port of the ViewBoard.
Page 29: Network Connection
Network Connection Network To connect to a local network, connect an Ethernet cable to your network, then connect the other end to a LAN port of the ViewBoard.
Page 30: Media Connection
Media Connection HDMI IN Media Source To connect to a media source: 1. Connect an HDMI cable to a HDMI port on your ViewBoard and peripheral device. Plug in the power cord of your ViewBoard, and turn on the power supply switch. Press the Power button on the ViewBoard to turn the screen on.
Page 31: Audio Connection
Audio Connection The ViewBoard supports Audio In, Audio Out, and SPDIF. Audio In To play audio from your external device through the ViewBoard’s speakers, connect one end of an audio cable to your external device, and the other end to the ViewBoard’s AUDIO IN port.
Page 32: Video Output Connection (Hdmi Out)
Video Output Connection (HDMI Out) HDMI OUT Projector To output video via a display device: 1. Connect an HDMI cable to the HDMI IN port of your display device, and the other end to the HDMI OUT port of the ViewBoard. Plug in the power cord of the ViewBoard, and turn on the power supply switch.
Page 33: Optional Connections
Optional Connections The ViewBoard comes with an OPS Slot as well as a Wi-Fi Slot for optional add-ons such as a slot-in PC (e.g., VPC-35) or Wi-Fi card (e.g., VB-WIFI-005). Slot-in PC (OPS Slot) Installation 1. Remove the OPS Slot cover of the display. 2.
Page 34: Wi-Fi Card (Wi-Fi Slot) Installation
Wi-Fi Card (Wi-Fi Slot) Installation 1. Remove the Wi-Fi Slot cover of the display. 2. Carefully insert the slot-in Wi-Fi card into the Wi-Fi Slot of the display. 3. Secure the slot-in Wi-Fi card to the display.
Page 35: Using Your Viewboard
Using Your ViewBoard Turning On/Off the ViewBoard 1. Make sure the power cord is connected, plugged into a power outlet, and the Power Switch is in the “on” position. NOTE: The Power Switch is located at the bottom of the display. 2.
Page 36: Initial Launch Setup
Initial Launch Setup When you first turn on your ViewBoard, an initial setup wizard will launch. 1. Choose your preferred Language. 2. Setup and connect to Ethernet or Wi-Fi.
Page 37 3. Set and adjust the Date and Time as needed. 4. Setup the Power Saving Plan. 5. Accept or decline the Privacy and Copyright Protection Terms.
Page 38 6. Select your preferred System Mode.
Page 39: Home Screen
Home Screen On the Home Screen select from Use as Guest and Sign In. How to Sign Up Select the How to Sign Up button at the bottom of the screen, then scan the QR code and follow the directions to log in.
Page 40: Use As Guest
Use as Guest Select the Use as Guest button to log in with a guest account. NOTE: Please note that user settings cannot be saved when logging in with a guest account. Sign In Select the Sign In button to log in with various accounts.
Page 41: Home Screen Message
Home Screen Message The Home Screen message can be edited by selecting it directly on the Home Screen. Additionally, a password can be set by selecting the Set Up Password button.
Page 42: Toolbar
Toolbar The Toolbar is where applications and tools can be found. Trigger icons are on the right, left, and bottom edge of the screen for quick access. To launch an application or tool: 1. Tap a Toolbar trigger icon. 2. Tap on your desired application or tool. NOTE: ...
Page 43: Toolbar Icons
Toolbar Icons Description Icon Return to the previous operation screen. NOTE: Only for the ViewBoard source. Return Return to the Home Screen. Home Display all currently open applications. Select the small frame to display in a PIP window. Recent View all installed applications. Applications Browse and open files.
Page 44 Description Icon Quickly view and adjust various frequently used tools. Tools Select and change the input source signal. Input Source...
Page 45: On-Screen Display (Osd) Menu - General Settings
On-Screen Display (OSD) Menu - General Settings Access Input, Display, and other general settings through the OSD Menu. Input Settings Display Settings Open the OSD Menu by pressing INPUT on the remote control or touching the Input Source icon (...
Page 46 Input sources can also display the signal source icon.
Page 47: Input Settings
Input Settings To select an input source: Press INPUT on the remote control or touch the Input Source icon ( display the Input Settings menu. Press on the remote control to select the input source you want. q/p/t/u NOTE: The PC source will only be visible when a slot-in computer is installed. Press ENTER on the remote control, or touch the input source.
Page 48 To adjust the volume: Press INPUT on the remote control or touch the Input Source icon ( display the Input Settings menu. Touch and drag the volume slider directly to adjust the value, or press +/- on the remote control to adjust. Additionally, pressing Mute ( ) on the remote control will mute/unmute the volume.
Page 49: Display Settings
Display Settings To adjust the display settings: Press INPUT on the remote control or touch the Input Source icon ( display the Input Settings menu. Then select the Display tab. Press on the remote control to select the menu option you want. q/p/t/u Press ENTER on the remote control to confirm or press to adjust the menu...
Page 50: Eye Care
Display Settings - Menu Options Description Item Automatic brightness adjustment. Adjusts maximum brightness Auto Brightness according to ambient light levels. Adjusts the filter that blocks high-energy blue light for a more Eye Care comfortable viewing experience. Select a predefined picture setting. Mode Description Standard...
Page 51 Eye Care Eye Care blocks high-energy blue light for a more comfortable viewing experience. Calculating Breaks When viewing screens for extended periods, it is recommended to take periodic breaks from viewing. Short breaks of at least 10 minutes are recommended after one (1) hour of continuous viewing.
Page 52 Eye and Neck Exercises Eye Exercises Eye exercises can help minimize eye strain. Slowly roll your eyes to the left, right, up, and down. Repeat as many times as needed. Exercises for the eyes (1) Keep the body and the (3) Move the eyes to look (2) Move the eyes le and head upright.
Page 53: Applications
Description Icon myViewBoard Display Wirelessly mirror screens to a larger display. myViewBoard Manager Remotely manage multiple installations of ViewSonic devices. myViewBoard Whiteboard A digital whiteboarding application. Settings Access the System Settings. vCast Working with ViewBoard Cast software, receive vCastSender laptop screens (Windows/Mac/Chrome) and mobile (iOS/Android) users’...
Page 54: Viewboard Settings
ViewBoard Settings The ViewBoard input source is the default source that is active when turning on the ViewBoard. Press MENU ( ) on the remote control or tap the setting icon ) to enter the Settings menu. Wireless & Network Check current network connection status, set up and manage Wi-Fi, Ethernet, Bluetooth, and VPN, and establish a Wireless hotspot.
Page 55: Wi-Fi
Wi-Fi Setup and manage wireless access points. • Tap the toggle button to turn Wi-Fi On or Off. • Once On, you can: Add a Network, view Saved Networks, Refresh the network list, or view Advanced settings. • In Advanced settings, you can toggle Network notifications On or Off and view Network card info.
Page 56: Ethernet
Ethernet Set the local network and proxy. • Tap the drop down menu to connect/disconnect the Ethernet. • You can adjust Local network and Proxy settings as well.
Page 57: Wireless Hotspot
Wireless Hotspot Set and share my internet connection with other devices. • Tap the toggle button to turn Wireless hotspot On or Off. • Tap Set up to set the Network name, Security, and Password.
Page 58: Bluetooth
Bluetooth Manage connections, set the device name and discoverability. • Tap the toggle button to turn Bluetooth On or Off. Once On, users can select a listed device to pair and connect to, rename their device, remove a device.
Page 59: Vpn
Setup and manage Virtual Private Networks. To create a VPN profile: 1. Go to: Settings > Network & Internet > VPN and tap Add VPN. 2. Key in the Name.
Page 60 3. Select the VPN Type. 4. Choose to enable/disable PPP encryption (MPPE) and/or show Advanced options.
Page 61: File Sharing
File Sharing Share files through Samba.
Page 62: Samba
Samba The Samba Service provides file sharing via LAN. When the SAMBA Service is enabled, the user can explore the ViewBoard file system with a PC or mobile equipment. 1. Go to: Settings > File Sharing > SAMBA. 2. Tap the toggle button to enable the SAMBA Service. 3.
Page 63: Display
Display Adjust the Wallpaper, Protection, and HDMI Out settings.
Page 64: Wallpaper
Wallpaper Users can change their wallpaper with default images, or use their own by tapping the add icon ( ) and selecting the image file.
Page 65: Protection
Protection Set a HDCP & Copyright on or off.
Page 66: Hdmi Out
HDMI Out Adjust the HDMI Out Resolution setting, enable video output, and mute/unmute the display speaker when connected via HDMI Out. NOTE: The disable ViewBoard speakers option box is not selected by default.
Page 67: Preference
Preference View and adjust Touch, Language, Keyboard & Input, Date & Time, Boot Mode & Advanced, Start up & Shut down, and Toolbar settings.
Page 68: Touch
Touch Adjust Touch Settings and toggle Touch Sounds and Windows Ink On/Off. Language Adjust and choose the preferred language from the available languages.
Page 69: Keyboard & Input Method
Keyboard & Input Method Enable/disable the visual keyboard and/or change the default input method. • Tap on Settings to adjust the advanced keyboard settings.
Page 70: Date & Time
Date & Time Set the system time and format. Item Description Automatic Date & When enabled, the ViewBoard will automatically synchronize Time the date and time via the Internet. Time Zone Select the appropriate time zone. Choose from 12-hour or 24-hour time format. Simply toggle 24- Time Format hour format On/Off.
Page 71: Boot Mode & Advanced Settings
Boot Mode & Advanced Settings Adjust the preferred boot up mode and set/reset a password. Item Description Normal Mode The embedded screen sharing Apps will run normally. Secured Mode The embedded screen sharing Apps will be removed. The system will automatically reboot, and then the Disable Embedded OS Embedded OS will not appear.
Page 72: Startup & Shutdown
Startup & Shutdown Set the Startup Input, Standby Mode, EnergyStar Mode, Black Screen After Startup, Power off Reminder timer and Schedule settings. Item Description Startup Input Adjust the Startup Input preference. Decide what happens when you press the Power button while Standby Mode the ViewBoard is On.
Page 73: Toolbar Setting
Toolbar Setting Adjust the Side toolbar settings.
Page 74: Input Source
Input Source Adjust the input source names and settings, as well as the side toolbar settings.
Page 75: Label Input Source
Label Input Source Set labels for each input source that will be easily recognized when displayed.
Page 76: Source
Source Toggle Wake up by active HDMI input and HDMI CEC and select Auto switch input ports. Item Description Wake up by Active The screen will turn on automatically after plugging in an HDMI input HDMI cable when the screen is off. The original signal will automatically switch to a new cable Auto switch input ports after it’s plugged in.
Page 77: Apps
Apps The user can view application information and force stop, uninstall, move to USB storage, clear data, clear cache, and clear defaults. NOTE: • Pre-loaded apps cannot be uninstalled. • Not all apps support the move to USB storage feature. •...
Page 78 Apps View any running or installed applications. Tap on them for more detailed information and options. • By tapping on a running application, you can see more information, stop, or report the application.
Page 79 • Selecting All will list all installed applications. • Tapping on any application will display further information and options.
Page 80 • Selecting Download will list all installed applications that can be uninstalled. • Tapping on any application will display further information about the application.
Page 81: System
System View and adjust Storage, Clone to USB, Display ID, Security, System Update, and About device settings.
Page 82: Clone To Usb
Clone to USB Copy settings to an external USB drive.
Page 83: Display Id
Display ID Assign a number to remote control the display by RS-232/LAN. • To assign or change the Display ID, tap Change and input a number. NOTE: The Display ID is for RS-232 users, and the range is 01~99.
Page 84: Security
Security Review Certificate, Trusted Credential storage, and Unknown sources install settings. • Tap on Install certificate from storage to add additional certificates.
Page 85 • Selecting Clear Credentials will remove all manually installed credentials. NOTE: Pre-loaded credentials cannot be cleared. • Under Trusted Credentials view and edit all trusted and installed CA certificates. • Tapping on a credential will provide more detailed information.
Page 86 • Allow the installation of applications from unknown sources by selecting the box under Unknown source security. NOTE: Applications from unknown sources may not be compatible or work properly.
Page 87: System Update
System Update The ViewBoard automatically searches for software updates whenever connected to the Internet (OTA). With just one click, users can update their version of ViewBoard software. Item Description Online Update Manually check online for a new software version. Local Update Update the software manually with a local file.
Page 88: About Device
About Device Display Embedded Player information, Legal information, and Asset Tagging. • By selecting Edit, the asset information can be adjusted. • Tap on Legal information to check open source licenses.
Page 89: Pre-Installed Applications And Settings
Pre-installed Applications and Settings myViewBoard Display Wirelessly mirror screens to a larger display. To share a screen to a ViewBoard with myViewBoard Display: 1. Open myViewBoard Display on the ViewBoard you want to share your screen to. 2. On the device you want to share the screen from, go to: https://myviewboard.
Page 90: Myviewboard Manager
Manager Remotely manage multiple installations of ViewSonic devices. Once devices are set up and have myViewBoard Manager installed, they can be added to the entity and managed remotely from the Manager web application. NOTE: Only available to Entity Admins from myviewboard.com after signing in.
Page 91: Myviewboard Whiteboard
myViewBoard Whiteboard A digital whiteboarding application. NOTE: To learn more about myViewBoard Whiteboard, visit: https://wiki. myviewboard.com/Whiteboard_for_Android. Floating Toolbar Item Description Move Move the Floating Toolbar. Present Mode Switch between presentation and preparation modes. Paste from Insert the current clipboard content onto the canvas. Clipboard Go to the previous page (if the canvas has multiple Previous Page...
Page 92 Main Toolbar Item Description Screen Screenshot, video, and audio recording. Capture Select and hold to move the toolbar to the left side, right Move side, or bottom of the screen. File Open, save, export, and print whiteboard files. Import resources (image, video, audio, etc.) to the Magic Box whiteboard.
Page 93 Background Management Item Description Sign In Sign in to a myViewBoard account. Background Change the canvas background. Management FollowMe Display custom images uploaded to a cloud storage Setting account. Color Palette Choose from solid or gradient colors as the background. Choose backgrounds that come pre-installed with Pre-installed Whiteboard.
Page 94: Vcast
vCast Working with ViewBoard® Cast software (vCast, vCast Pro, and vCastSender), the vCast application will allow the ViewBoard to receive laptop screens (Windows/ Mac/Chrome) and mobile (iOS/Android) users’ screens, photos, videos, annotations, and camera(s) that are using the vCastSender application.
Page 95 ͫ UDP 48689, 25123 (Device searching and broadcast & client device audio transfer) ͫ UDP 5353 (Multicast search device protocol) • Port and DNS for Activation: ͫ Port: 443 ͫ DNS: https://vcastactivate.viewsonic.com • OTA Service ͫ Server Port: TCP 443 ͫ Server FQDN Name: https://vcastupdate.viewsonic.com...
Page 96: Display Group Settings
Display Group Settings To adjust the Display Group Settings, select the Display Group icon ( ) located in the lower-right corner of the screen. 1. Toggle the “Turn On/Off Display Group” ON to enable the Display Group feature. NOTE: Other preinstalled ViewBoard Cast devices in the same network will be listed.
Page 97 3. If you frequently connect to the same device, you can select the Star icon ( next to the device to add it to your frequently connected devices list, “My List of Devices in Group”, for easier Display Group setup and management.
Page 98: Synchronized Group Screen All The Time
Synchronized Group Screen All the Time When the “Synchronized group screen all the time” function is toggled ON, it will display a synchronized group screen continuously. If it is toggled OFF, it will work on vCast mirroring only. NOTE: Select the devices to group first, then toggle the “Synchronized group screen all the time”...
Page 99: Moderator Mode
Moderator Mode Moderator Mode allows the moderator to take control of the devices connected to the ViewBoard or display. To enter Moderator Mode, select the Moderator Mode icon ( ) located in the lower-right corner of the screen. When enabled, the moderator can view a list of all connected screens in the left floating window and can preview each participant’s screen and then select any of participant’s screen and cast to the ViewBoard’s or display’s main screen for presentation.
Page 100: Broadcast
Broadcast When enabled, the ViewBoard’s screen will be broadcasted to all of the participant’s connected screens simultaneously. The participants can only view the presentation contents until the moderator disables the Broadcast function. Multiple Screen Sharing By default, vCast is set to allow multiple screen sharing, but can also be set to single screen sharing.
Page 101: Casting From Windows, Macbook, And Chrome Devices
Casting from Windows, MacBook, and Chrome Devices 1. Ensure the client device (e.g., laptop) is connected to the same network as the ViewBoard. NOTE: The network name can be found under Room Network. 2. On the client device, visit the address that is shown on the ViewBoard to download and install the vCastSender application.
Page 102 4. To connect to the ViewBoard, input the PIN code and click OK. NOTE: The PIN code can be found as highlighted below: 5. Additionally, you can connect to the ViewBoard by clicking Device List then the Device Name listed. NOTE: ...
Page 103: Casting From Android Devices
Casting from Android Devices 1. Ensure the client device (e.g., Android phone or tablet) is connected to the same network as the ViewBoard. NOTE: The network name can be found under Room Network. 2. On the Android client device, scan the QR code shown on the ViewBoard to directly download the vCastSender application, or download the application from the Google Play Store.
Page 104 3. After installing, launch the vCastSender application. 4. To connect to the ViewBoard, input the PIN code and select OK. NOTE: The PIN code can be found as highlighted below: 5. You can also connect to the ViewBoard by selecting Device List then the Device Name listed.
Page 105 6. Additionally, you can connect to the ViewBoard or by selecting Scan then placing the on-screen QR code into the box to automatically connect.
Page 106: Casting From Apple Ios Devices
Casting from Apple iOS Devices Apple AirPlay® is compatible with vCast for screen mirroring and content streaming under the same subnet environment only. An “AirPlay Password” will be generated on-screen for connection when using AirPlay to cast to a ViewBoard. 1.
Page 107 2. On the iOS client device, directly open AirPlay and select the Device Name of the ViewBoard to connect. NOTE: The Device Name can be found as highlighted below: 3. Input the generated on-screen AirPlay Password on the client device to connect. NOTE: ...
Page 108 4. You can also connect to the ViewBoard by selecting Scan then placing the on- screen QR code into the box to automatically connect.
Page 109: Connecting To A Viewboard From A Mobile Device
Connecting to a ViewBoard from a Mobile Device Once connected, select Receive. The ViewBoard will appear on the mobile device with an on-screen toolbar. Users can interact with the ViewBoard with annotations, file sharing, etc. Item Description Toggle Hide or display the toolbar. Home Return to the Home interface.
Page 110: Casting With Chromecast
Casting with Chromecast vCast supports native Chromecast screen sharing via the Chrome browser casting when the Chromecast feature is enabled. NOTE: Chromecast does not support password protection or multiple-screen casting. 1. Ensure the client device (e.g., laptop) is connected to the same network as the ViewBoard.
Page 111 3. In the Chrome browser, go to: Settings > Save and share > Cast... > Select the screen to cast to.
Page 112: Casting With Miracast
Casting with Miracast vCast supports native Miracast to cast content from Windows and Android devices to a ViewBoard when the Miracast feature is enabled. NOTE: • Miracast does not support password protection or multiple-screen casting. • Miracast sharing is only available over Wi-Fi. •...
Page 113 3. Please follow the below steps to cast: For Windows devices: 1. On the Windows device, press Win + K and select the display to cast to. 2. Select the checkbox “Allow mouse, keyboard, touch, and pen input from the device”...
Page 114: Rs-232 Protocol
RS-232 Protocol This document describes the hardware interface and software protocols of RS-232 interface communication between the ViewSonic LED Display and computers or other control units with RS-232 protocol. The protocol contains three command sections: • Set-Function • Get-Function • Remote control pass-through mode NOTE: ...
Page 115: Lan Hardware Specification
LAN Hardware Specification ViewSonic LFD communication port on the rear side: 1. Connector type: 8P8C RJ45 2. Pin Assignment: Pin # Signal Remark Output from Display Output from Display Input to Display BI_D3+ For 1G case BI_D3- For 1G case...
Page 116: Protocol
Protocol Set-Function Listing The PC can control the Display for specific actions. The Set-Function command allows you to control the Display behavior at a remote site through the RS-232 port. The Set-Function packet format consists of 9 bytes. Set-Function Description: Length: Total Byte of Message excluding “CR”...
Page 117 Example 1: Set Brightness at 76 for Display (#02) and this command is valid Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38 0x73 0x24 0x30 0x37 0x36 0x0D 0x32 Reply (Hex Format) Name Length Command Type 0x30 0x34 0x2B...
Page 118 Set-Function Table A. Basic Function Set Function Length ID Command Command Value Range Comments Code Code Type (ASCII) (Three ASCII bytes) (ASCII) (Hex) 1. The Power-on via LAN control may work only under specific modes. See display UG Power ON 000: STBY *3.2.1 for details.
Page 119 Set Function Length ID Command Command Value Range Comments Number 000~009 *3.1.1 000: UP 001: DOWN 002: LEFT 003: RIGHT Key Pad *3.1.1 004: ENTER 005: INPUT 006: MENU/(EXIT) 007: EXIT Disable: RCU will have no function Enabled: RCU controls normally 000: Disable Remote...
Page 120 NOTE: 1. Behavior at Lock Modes Lock Mode Behavior 1. Lock all buttons on the front panel and RCU, except for “Power” Button Lock 2. All the SET functions should be workable via RS-232, even the ones with according hot key in RCU like Mute,…etc. 1.
Page 121 B. Optional Function Set Function Length ID Command Command Value Range Comments Code Type (ASCII) Code (Hex) (Three ASCII bytes) (ASCII) Inputs in cycle Input Select: “ loop depend on Cycle *3.3.1 display itself Contrast 000 ~ 100 Sharpness 000 ~ 100 Color &...
Page 122 Set Function Length ID Command Command Value Range Comments 000: TV 001: AV 002: S-Video 003: YPbPr 004: HDMI1 014: HDMI2 024: HDMI3 034: HDMI4 005: DVI Value range is 006: VGA1 PIP-Input same as SET- *2.9 016: VGA2 Input select 026: VGA3 007: Slot-in PC (OPS/SDM)/HDBT...
Page 123 Set Function Length ID Command Command Value Range Comments 001: Backlight OFF 101: Backlight ON 002: Freeze OFF Function On_Off 102: Freeze ON *3.3.2 003: Touch OFF 103: Touch ON NOTE: 1. Tiling definition of H Monitors, V Monitors, and Position 2.
Page 124: Get-Function Listing
Get-Function Listing The PC can interrogate the LFD for specific information. The Get-Function packet format consists of 9 bytes which is similar to the Set-Function packet structure. Note that the “Value” byte is always = 000. Get-Function Description: Length: Total Byte of Message excluding “CR”. TV/DS ID Identification for each of TV/DS (01~98;...
Page 125 Example 1: Get Brightness from TV-05 and this command is valid. The Brightness value is 67. Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38 0x67 0x62 0x30 0x30 0x30 0x0D 0x35 Reply (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38...
Page 126 Get-Function Table A. Basic Function Response Get Function Length ID Command Command Comments Range Code Code (Three ASCII Type (ASCII) (ASCII) (Hex) bytes) Get-Brightness 000 ~ 100 1. For Android platform whose main mode is controlled by backlight and the other sources 000 ~ 100 Get-Backlight *3.2.0...
Page 127 Response Get Function Length ID Command Command Comments Range (for the models with LAN) Get-MAC address Reply in new 32-byte format *3.2.0 (for the models with LAN) Get-IP address *3.2.0 Reply in new 32-byte format *3.2.0 Reply in new 32-byte Get-Serial number format *3.2.0...
Page 128 NOTE: 1. Get Operation Hour example Assumed the accumulated operation hour is 123,456 hrs Send: 0x 38 30 31 67 31 30 30 30 0D (Get Operation hour) Reply: 0x 32 30 31 72 31 31 32 33 34 35 36 00 00 … 00 00 0D 2.
Page 129 B. Optional Function Response Get Function Length ID Command Command Comments Range Code Type (ASCII) Code (Hex) (Three ASCII bytes) (ASCII) Get-Contrast 000 ~ 100 Get-Sharpness 000 ~ 100 Get-Color 000 ~ 100 Get-Tint 000 ~ 100 Keep both “Backlight On_Off” Get-Backlight On_ 000: OFF and “Function On_...
Page 130 Response Get Function Length ID Command Command Comments Range 001: Backlight OFF 101: Backlight ON Get-Function On_ 002: Freeze OFF 102: Freeze ON *3.3.2 003: Touch OFF 103: Touch ON NOTE: 1. Get Date example Assumed the current date of display#01 as below: Date: 2017-3/15 Send: 0x 38 30 31 67 32 59 30 30 0D (Get Date:Year)
Page 131 C. Auto Reply *3.2.1 The display will send out the updated data/status automatically without GET query from the host whenever the following data/status is changed by the user through any of the available ways like: remote control unit, front control panel keys, or touch screen.
Page 132: Remote Control Pass-Through Mode
Remote Control Pass-through Mode When the PC sets the Display to Remote Control Pass through mode, the Display will send a 7-byte packet (followed by “CR”) in response to remote control unit (RCU) button activation. In this mode the RCU will have no effect on the Display function. For example: “Volume+”...
Page 133 Code (HEX) Basic Optional *3.1.1 *3.1.1 RECALL (LAST) INFO (DISPLAY) ASPECT (ZOOM, SIZE) VOLUME UP (+) VOLUME DOWN (-) MUTE CHANNEL/PAGE UP (+)/ BRIGHTNESS+ CHANNEL/PAGE DOWN (-)/ BRIGHTNESS- POWER SOURCES (INPUTS) SLEEP MENU DOWN LEFT (-) RIGHT (+) OK (ENTER, SET) EXIT...
Page 134 Code (HEX) Basic Optional *3.1.1 *3.1.1 (F1) ■ GREEN (F2) ■ YELLOW (F3) ■ BLUE (F4) ■ NOTE: 1. This IR-pass-through code is different from the RCU key code. 2. Special control sequence for POWER key under IR-pass through mode. 2-1.
Page 135: Appendix
Appendix Specifications Item Category Specifications IFP110 Model VS19822 Size 110” Display Area 2436.48 (H) × 1370.52 (V) mm Surface LCD Panel Hard Coating (9H) Treatment Brightness 400 nits (Typical) Native Resolution 3840 x 2160 (UHD) Type Infrared Touch Windows: 40 points...
Page 136 Item Category Specifications ≤ 5,000 m Altitude 16,404.2 ft Operating Relative Humidity 20%~80% non-condensing Conditions 0° C to 40° C Temperature 32° F to 104° F 0~3,658 m Altitude 0~12,001.3 ft Storage Relative Humidity 10%~80% non-condensing Conditions -10° C to 60° C Temperature 14°...
Page 137: Display Modes
Display Modes DisplayPort Resolution Refresh Rate (@) 640 x 480 60, 67, 72 Hz 800 x 600 56, 60, 72, 75 Hz 832 x 624 75 Hz 1024 x 768 60, 70, 75 Hz 1152 x 864 75 Hz 1152 x 870 75 Hz 1280 x 720 60 Hz...
Page 138: Usb Type C
USB Type C Resolution Refresh Rate (@) 640 x 480 60, 67, 72 Hz 800 x 600 56, 60, 72, 75 Hz 832 x 624 75 Hz 1024 x 768 60, 70, 75 Hz 1152 x 864 75 Hz 1152 x 870 75 Hz 1280 x 720 60 Hz...
Page 139: Hdmi Out
HDMI Out Resolution Refresh Rate (@) 720 x 480 60 Hz 1920 x 1080 60 Hz 3840 x 2160 60 Hz...
Page 140: Troubleshooting
Troubleshooting This section describes some common problems that you may experience when using the ViewBoard. Problem or Issue Possible Solutions 1. Check whether something is obstructing the display’s remote control receiver. Remote Control is not 2. Check whether the batteries in the remote control working are installed correctly.
Page 141 Touch Function Problem or Issue Possible Solutions 1. Check that drivers are installed correctly. 2. Reinstall driver(s). Touch function does not work 3. Check setup and align it. 4. Check whether the touch pen is working properly. Video Not Working Properly Problem or Issue Possible Solutions 1.
Page 142: Maintenance
Some chemical cleaners have been reported to damage the screen and/or case of the device. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. NOTE: If condensation appears between the glass and the panel, keep the...
Page 143: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 144: Declaration Of Rohs2 Compliance
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
Page 145: Energy Star Statement
U.S. Environmental Protection Agency. As an ENERGY STAR Partner, ViewSonic is determined to meet the Energy star Guidelines and mark all certified models with the ENERGY STAR logo.
Page 146: Indian Restriction Of Hazardous Substances
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...
Page 147: Copyright Information
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic® and the three birds logo are registered trademarks of ViewSonic® Corporation. VESA is a registered trademark of the Video Electronics Standards Association.
Page 148: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/...
Page 149: Limited Warranty
ViewSonic® Smart White Board What the warranty covers: ViewSonic® warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, and as your sole remedy, repair or replace the product with a similar product.
Page 150 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
Page 151 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
Page 152: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
Page 153 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
Page 154 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.

This manual is also suitable for:

Vs19822

ViewSonic IFP110 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for ViewSonic IFP110

Summary of Contents for ViewSonic IFP110

This manual is also suitable for:

Table of Contents
