Description of the appliance and control panel
Cup shelf
Control panel (see
description below)
Boiler outlet/
Infusion assembly
Water tank seat
Water tank lid
Water tank with
water lter seat
OK steam light
Control Panel
OK co ee/
hot water light
Co ee delivery
"STOP"/hot water function position
Steam function
Indicator for
drip tray
maximum
water level
Water low
level indicator
3
General switch
ON/OFF
Power supply
cable
connector
Steam/
hot water
selector
Hot water/
Cappuccino
steam nozzle
nozzle
Stand-by/energy save light
ON/Stand-by Button
Function selector
Cup tray
Drip tray
