General Information - airmaster AM 1000 Mounting

1.

General Information

Scope of Delivery:
The Airmaster air handling unit is packed on one pallet.
The delivery depends on the costumers order.
Please check the delivery before installation. The most
important parts are shown below. The scope of delivery
can be seen from the delivery note.
1. Airmaster air handling unit (4 sections)
2. Wall-/ceiling bracket
3. 4-split service cover
4. Panel set (a set consists of one to three long panels
and double that number of short panels)
5. Control panel
Airlinq Viva
6. Roof penetration set (optional)
7. Wall grilles (optional)
8. Room Cooling (RC 1000) (Optional)
RC 1000 is an option that is intended to be connected
to the AM 1000. The RC 1000 is both mechanically and
electrically connected to the AM 1000, which means that
these two appliances together is considered as one unit.
The function of the RC 1000 is to cool down the supply air
coming from the AM 1000.
9. Operation & Maintenance manual (for program-
ming), Mounting manual, and Installation manual
(for installation);
To be handed over to the owner!

