Morphy Richards MRICE12SS Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Compact Ice Maker
Model: MRICE12SS
INSTRUCTION MANUAL
Read these instructions carefully before
using this appliance for the first time.
STORE THESE INSTRUCTIONS CAREFULLY
For product hints and tips plus more join us at
www.morphyrichards.com.au
facebook.com/MorphyRichardsAUS
instagram.com/morphyrichardsau

Advertisement

Table of Contents
loading

Related Manuals for Morphy Richards MRICE12SS

Summary of Contents for Morphy Richards MRICE12SS

  • Page 1 Compact Ice Maker Model: MRICE12SS INSTRUCTION MANUAL Read these instructions carefully before using this appliance for the first time. STORE THESE INSTRUCTIONS CAREFULLY For product hints and tips plus more join us at www.morphyrichards.com.au facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE To reduce the risk of fire, electric shock, injury to persons or damage to property, follow basic precautions including the following: WARNING: Misuse of appliance could cause personal injury. • Check your ice maker to ensure it is in good condition and that •...
  • Page 3 WARNING: Do not store explosive substances such as aerosol • cans with a flammable propellant in this appliance. WARNING: Keep ventilation openings, in the appliance • enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means •...
  • Page 4 If the refrigerant circuit should be damaged: Avoid opening flames and sources of ignition. • Thoroughly ventilate the room in which the appliance is • situated. Location Before using the Ice Maker for the first time, please wait 2 hours •...
  • Page 5 Remove the plug from the socket, grasp the plug and pull out • the power cord, do not pull on the cord directly. Do not let the cord hang over the edge of a table or counter and • keep it away from any hot surfaces. Do not let the cord run across an open space e.g.

  • Page 6: Specifications

    SPECIFICATIONS Model: MRICE12SS Colour: Stainless Steel / Black Rated Power: 150W Rated Voltage & Frequency: 220-240V~ 50Hz Water Tank Capacity: 1.8L Ice Bin Capacity: 0.8 kg Refrigerant/Refrigerant Amount: R600a/24g Foaming Agent: Dimensions (W x D x H): 228 x 336 x 292mm Net Weight: 7.7kg...

  • Page 7: Control Panel

    CONTROL PANEL 66.0 C01005白色 ON/OFF Button - Starts or Stops the appliance. POWER Indicator - In standby mode the POWER indicator will PANTONE BLACK C blink. During operation the POWER indicator will be solid. 透光区 ICE FULL Indicator - When the ice reaches the maximum amount of ice in the ice tray, the ICE FULL indicator will illuminate.

  • Page 8: Before First Use

    BEFORE FIRST USE Remove all packaging materials and read all instructions. Check that all accessories are complete and the appliance is not damaged. Clean all parts to remove any dust or manufacturing residue. Clean the water storage tank and ice collecting tray with clean water.

  • Page 9: Using Your Ice Maker

    USING YOUR ICE MAKER Ensure the drainage plug at the bottom of the water tank is closed securely. Plug the ice maker into a wall outlet, the POWER indicator will blink. NOTE: The appliance should be rested for 30 minutes before plugging into a wall outlet, if it has been moved.

  • Page 10: Care And Cleaning

    USING YOUR ICE MAKER The ADD WATER indicator will light up when the water tank is out of water and the ice making cycle will stop automatically. Remove the ice basket and add water to the water tank, and then press the ON/OFF button again to restart the ice making cycle.
  • Page 11 CARE & CLEANING Remove the ice basket and clean the ice maker interior with a • soft cloth soaked with warm water and vinegar, then rinse with clean water and drain all the water. Replace the drainage plug securely in position. Wash the ice •...

  • Page 12: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS ADD WATER indicator 1. Low water level or lack 1. Stop making ice, refill illuminates. of water. water and then press “ON/ 2. The water screen at the OFF” button to restart ice bottom of water reservoir is making cycle.
  • Page 13 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS Poor ice making result. 1. Poor heat dissipation. 1. Leave a 15cm clearance 2. The water temperature is on all sides of the ice maker too high. for proper ventilation. 3. The ambient temperature 2.
  • Page 14 TIPS FOR YOUR ICE MAKER Opening the lid for long periods can cause a significant • increase of the temperature in the compartments of the appliance. If the appliance is left empty for long periods, switch off, • defrost, clean, dry, and leave the lid open to prevent mould developing within the appliance.

  • Page 15: Maintenance

    MAINTENANCE If the unit fails to operate efficiently, is broken or other problems arise, unplug and do not operate. Ask for advice by calling your local after sales service agent or the Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
  • Page 16 Recycling: Do not dispose of electrical appliances as unsorted municipal waste. Use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the ground water, polluting the food chain and damaging health and wellbeing.
