ASSEMBLY
INSTRUCTIONS
YOU SHOULD HAVE TWO PACKAGES:
•
1 cardboard package
•
1 channel pack
TOOLS REQUIRED:
•
Battery or electric drill
•
3.3mm (1/8th inch) drill bit
•
Pop riveter
•
Tape measure
•
Ladder
•
Non-slip gloves, good
shoes and goggles
•
A set of helping hands
Some parts have sharp edges and should
be handled very carefully. We recommend
the use of protective gloves and footwear
when assembling.
DO NOT attempt to erect this shed in windy
weather. All dimensions are approximate.
GVO 3023
GABLE ROOF SHED
3030mm wide x 2280mm deep x 1830-2025mm high
PACKED BY:
Please quote this code for any
correspondence back to the supplier
CALL 0508 454 873
for an installer near you
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Galvo Shed GVO 3023
Summary of Contents for Galvo Shed GVO 3023
- Page 1 GVO 3023 GABLE ROOF SHED 3030mm wide x 2280mm deep x 1830-2025mm high ASSEMBLY PACKED BY: INSTRUCTIONS YOU SHOULD HAVE TWO PACKAGES: • 1 cardboard package • 1 channel pack Please quote this code for any TOOLS REQUIRED: correspondence back to the supplier •...
- Page 2 ASSEMBLY OVERVIEW These instructions are designed to guide you though the Rivets are fitted by drilling through outside of the channel into process of building your new garden shed. It is a simple the ribs of the sheet, usually at every second rib. It is also process of joining sheets together before adding top and important to fit at least one rivet per sheet from the inside of bottom channels to form a shed panel.
- Page 3 STEP 1 BACK WALL YOU WILL NEED 4 x 1830mm x 780mm sheets Join the 4 sheets together with 2 fixings through the overlapping ribs, making 2 x 3000mm 'U' channels with ends cut sure the ends of the sheets are flush. Cap the sheeting with the 3000mm 'U' channels Fix the channels through the end ribs and every second rib in between.
- Page 4 STEP 3 END WALLS YOU WILL NEED 4 x 1960mm angle cut sheets & 2 x together as with previous panels to create a gable 2025mm gable cut sheets (end walls) Join the sloping sheets end wall as shown. Make a cut in the centre (1145mm) of the 2290mm top channel 2 x 2255mm 'U' channels (bottom) and cap the three sheets.
- Page 5 STEP 5 DOOR BRACES YOU WILL NEED 2 x 'Z' Door braces The door braces can be fitted now. Tuck one end of the 'Z' between Fixings the bottom channel of the inside of the door and the sheet in the corner.
- Page 6 STEP 7 FRONT WALL YOU WILL NEED 2 x 3000mm 'U' channels with ends cut Lay down the doors with the sheets attached. Cap the sheets with the 3000mm 2 x 1586mm door spacers channels . Use the door spacers to make sure the door fits the gap (they sit 3 x padbolts on top of the 'Z' door jambs...
- Page 7 STEP 8 INSTALLATION BUILDING YOUR SHED SIDE WALL ASSEMBLY • Stand up the back wall and as your helping hand is holding it up, bring the left end wall The basic task is to join the sheets in to meet it at the left corner (diagram 1) overlapping the corners (diagram 2). Drill and fix together to form your panels, and fix at approximately 100mm down from the top and up from the bottom, drilling and fixing channels to the top and bottom of...
- Page 8 e.g.
