ASSEMBLY
INSTRUCTIONS
YOU SHOULD HAVE ONE PACKAGE:
•
1 cardboard package
TOOLS REQUIRED:
•
Battery or electric drill
•
3.3mm (1/8th inch) drill bit
•
Screwdriver or riveter
•
Tape measure
•
Ladder
•
Non-slip gloves, good
shoes and goggles
•
A set of helping hands
Some parts have sharp edges and should
be handled very carefully. We recommend
the use of protective gloves and footwear
when assembling.
DO NOT attempt to erect this shed in windy
weather. All dimensions are approximate.
GVO 1508
SLOPING ROOF SHED
1530mm wide x 780mm deep x 1830mm - 1770mm high
PACKED BY:
Please quote this code for any
correspondence back to the supplier
CALL 0508 454 873
for an installer near you
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Galvo Shed GVO 1508
Summary of Contents for Galvo Shed GVO 1508
- Page 1 GVO 1508 SLOPING ROOF SHED 1530mm wide x 780mm deep x 1830mm - 1770mm high ASSEMBLY PACKED BY: INSTRUCTIONS YOU SHOULD HAVE ONE PACKAGE: • 1 cardboard package TOOLS REQUIRED: Please quote this code for any • Battery or electric drill correspondence back to the supplier •...
-
Page 2: Components Checklist
COMPONENTS CHECKLIST Please check all components carefully and advise your supplier immediately if any discrepancies. Remember to quote the code on the front page. 1 x 1770 x 780mm door sheet 1 x narrow 1830 x 715mm sheet 2 x 1770 x 780mm sheets for back wall for front wall, beside door 2 x 980mm x 780mm sheets for roof 2 x 1830 - 1770mm sloping sheets... -
Page 3: Door Assembly
STEP 1 DOOR ASSEMBLY YOU WILL NEED 1 x 1770 x 780mm door sheet Attach the 780mm 'U' channels to the top and bottom of the door sheet 2 x 1770mm 'U' channels for door sides at the centre ribs only. Attach the 1770mm 'U' channels to the door sheet 2 x 780mm 'U' channels (door top through the top and bottom channels... -
Page 4: Front Wall
STEP 3 FRONT WALL YOU WILL NEED 2 x 1515mm 'U' channels Lay out the door with the sheet attached and the corner door jamb with the 'U' channel 2 x 793mm door spacers attached (as shown below). Cap the sheets with the 1515mm channels . - Page 5 STEP 4 BACK WALL YOU WILL NEED 2 x 1770 x 780mm sheets Join the two sheets together with 2 fixings through the overlapping 2 x 1515mm 'U' channels ribs, making sure the ends of the sheets are flush. Cap the sheeting with the 1515mm 'U' channels Fix the channels through the end ribs and every second rib in between.
- Page 6 STEP 6 END WALLS YOU WILL NEED 2 x 1830mm - 1770mm sidewalls Cap the sloping sheets with the 735mm 'U' channels 2 x 735mm 'U' channels per side Fix the channels through the end ribs and every second rib in between. Make sure you put at least two fixings up through the underside of the channel into the pan of the sheet.
-
Page 7: Step 8 Installation
STEP 8 INSTALLATION BUILDING YOUR SHED SIDE WALL ASSEMBLY • Stand up the back wall and as your helping hand is holding it up, bring the left end wall The basic task is to join the sheets in to meet it at the left corner (diagram 1) overlapping the corners (diagram 2). Drill and fix together to form your panels, and fix at approximately 100mm down from the top and up from the bottom, drilling and fixing channels to the top and bottom of... - Page 8 e.g.
