- Page 1 COMFORTSTEAM READ AND SAVE THESE INSTRUCTIONS CFS20 & CFS22 UNITS NOT FOR COMMERCIAL USE Humidification System Series T R I O N | w w w . t r i o n i a q . c o m ®...
-
Page 2: Table Of Contents
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l TABLE OF CONTENTS SECTION I WARRANTY Preface ................................3... -
Page 3: Section I Warranty
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION I WARRANTY Warranty 1. TRION warrants to the buyer or any user during the This Warranty gives you specific legal rights, and you duration of the Warranty that the humidifier described... -
Page 4: Section Ii Unit Operation
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION II UNIT OPERATION Basic Operation Overview to the cylinder full level. -
Page 5: Key Features
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Key Features Faults: Adjustable Setpoints (See Figure 13, Page 13) -
Page 6: Engineering & Application
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Engineering and Application The CFS20/22 series steam humidifiers can be applied in a variety of applications. -
Page 7: Section Iii Installation Instructions
The cabinet is designed to safely contain the working components To make the necessary connections for water fill and drain, the of the TRION CFS 20/22 series humidifier and dissipate heat following steps are required. (Refer to Figure 4 for locations.) to protect the electronics. -
Page 8: Steam Distribution
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Steam Distribution Distributor Mounting Instructions TRION supplies a stainless steel duct distributor for injecting Sheetmetal Duct: pure steam into the duct. This can be installed in the side Make a 1-1/4”... -
Page 9: Wiring
2.66 TERMINALS Control Circuit Connections WARNING! Do NOT install any controls inside the TRION CFS 20/22 cabinet. Installations of any extraneous devices inside the electrical compartment may cause erratic behavior of the circuitry and will VOID the warranty. The humidifier is turned on by applying 24VAC across positions #3 and #4 of the terminal strip shown in Figure 8. -
Page 10: Installation Checklist
The TRION CFS20/22 Humidifier checklist is provided to help the installer ensure a successful installation. If further assistance is needed from the TRION representative or the factory, the checklist is expected to be completed. If a job site visit is required from the TRION representative or the factory, and the checklist has not been accurately completed, additional charges may be applied by the individual(s) representing TRION. -
Page 11: Start-Up Instructions
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION IV OPERATING INSTRUCTIONS to “cylinder full”... -
Page 12: Maintenance
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Maintenance To maintain output, the water level in the cylinder will slowly move cylinder. -
Page 13: Section V Troubleshooting Guide
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l SECTION V TROUBLESHOOTING GUIDE Test Points All TRION CFS 20/22 series humidifiers are manufactured under Each circuit board (see Figure 13) features three test points to strict quality control and are subjected to a complete operational aid in the troubleshooting process. -
Page 14: Unit Detected Faults: (Red Service Light On)
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Unit Detected Faults (Red Service Light is ON) Problem / Symptom Probable Cause... -
Page 15: Non-Fault Activated Problems
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Non-Fault Activated Problems Humidifier turned ON but will not Check power supply. - Page 16 I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Problem/Symptom Reason - Correction Water “foaming”...
-
Page 17: Wiring Diagrams
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l CFS20 Wiring Diagram CFS22 Wiring Diagram w w w. -
Page 18: Exploded View
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l EST-596 FILL SUB-ASSEMBLY EST-207... -
Page 19: Parts List
I n s t a l l a t i o n , O p e r a t i o n , & M a i n t e n a n c e M a n u a l Parts List 1095 Hose clamp SS... - Page 20 TRION ® 101 McNeill Rd. | Sanford, NC 27330 P: 800.884.0002 | F: 800.458.2379 | www.trioniaq.com | customerservice@trioniaq.com Form No. 267949-002 Rev. 12/17 © TRION 2017. All Rights Reserved.
