Trion Herrmidifier G100 Technical  Engineering  Specification

Trion Herrmidifier G100 Technical Engineering Specification

Power flow-thru humidifier

Advertisement

G100
Power Flow-Thru Humidifier
T E C H N I C A L
Form No. H-G100-1008
A i r P u r i f i c a t i o n S y s t e m s
E N G I N E E R I N G

Performance:

Save on Energy Costs and Improve Comfort.
Increasing a Home's Relative Humidity Makes it Feel More
Comfortable at 68ºf / 20ºc than it does at 73ºf / 23ºc at a Low
Relative Humidity Level.
Lower Thermostat Settings Deliver Substantial Savings on Monthly
Energy Bills.
Evaporative Supply Capacity Distributes up to 19 Gallons per day
at 120ºf
Ideal for Heat-Pump Applications

Features:

Self-Piercing Saddle Valve and a 24v Brass Solenoid Valve Makes
Installation Easy
High Capacity Unit Distributes 19 Gallons per day at 120º F
Built-In Fan Motor Helps Deliver Maximum Humidity
2" Evaporator Pad Expands the Evaporative Area for Water Supply
and Increases Performance
Flexible Humidity Control – The Wall or Duct-Mounted Humidistat
Adjusts from 20% to 80% Relative Humidity

How Humidifiers Work:

Evaporative humidifier is installed onto the supply duct, where warm,
dry air is forced across a moistened evaporator pad (wetted through the
home's water supply), creating a superfine mist that is released into the
indoor air. The adjustable, precision-made humidistat allows the user to
choose the optimum level of relative humidity for indoor comfort.

Warranty:

2-year Limited Warranty
S P E C I F I C A T I O N
w w w. t r i o n i n c . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Herrmidifier G100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Trion Herrmidifier G100

  • Page 1 Power Flow-Thru Humidifier T E C H N I C A L Form No. H-G100-1008 A i r P u r i f i c a t i o n S y s t e m s E N G I N E E R I N G...
  • Page 2 24.0 (90.8) (28.4) 19.0 (71.9) 30.5 (115.5) (37.9) 23.5 (88.9) 37.5 (141.9) (54.9) 33.0 (124.9) 51.5 (194.9) - Engineered Humidification Solutions Trion ® reserves the right to revise or modify products and/or specifications without notice ® G100 Power Flow-Thru Humidifier Installation Options Downflow Counterflow Upflow Bottom Return Upflow Side Return Horizontal and Herrmidifier are registered trademarks ® ® Form No. H-G100-1008...
