INSTRUCTION MANUAL • MANUEL D'INSTRUCTIONS
SLD03TVBL
Adjustable shower post system • Système de barre murale réglable
Store/Magasin
1 2
3 4
1 844 666-0155
DO NOT RETURN THIS PRODUCT TO STORE, CONTACT US. We're there if you need help.
NE RETOURNEZ PAS CE PRODUIT AU MAGASIN, CONTACTEZ-NOUS.
Nous sommes là si vous avez besoin d'aide.
1 844 666-0155 • question@dimex360.com
2022-03
Advertisement
Related Manuals for Akuaplus SLD03TVBL
Summary of Contents for Akuaplus SLD03TVBL
- Page 1 INSTRUCTION MANUAL • MANUEL D’INSTRUCTIONS SLD03TVBL Adjustable shower post system • Système de barre murale réglable Store/Magasin 1 844 666-0155 DO NOT RETURN THIS PRODUCT TO STORE, CONTACT US. We’re there if you need help. NE RETOURNEZ PAS CE PRODUIT AU MAGASIN, CONTACTEZ-NOUS.
- Page 2 We recommend that you hire a professional plumber to install and repair this product. Refer to the regulations stipulated in the Canadian Plumb- ing Code and inquire about your municipality’s requirements before proceeding to the installation. The Canadian Plumbing Code requires the installation of a water-hammer arrester to dampen water hammer in pipes.
- Page 3 Suggested installation/Installation suggéré Ceiling/Plafond 5” (127mm) MIN 78” (198 cm) MIN 82” (208 cm) MAX Shower-bath Bain-douche 32” (81 cm) MIN 48” (122 cm) MAX 1 Stainless steel shower rail Barre en acier inoxydable 2 Hand shower Douchette 3a Top wall bracket Attache murale supérieure 3b Bottom wall bracket Attache murale inférieure...
- Page 4 La protection contre les coups de bélier est nécessaire. Ne découpez pas plus grand que le gabarit. Protection against water hammer is necessary. Do not cut larger than the template. The valve must be installed in order to have the cut guide even with the ceramic. If you remove the cut guide keep the Not included plastic protection on parts #5 and #10...
- Page 5 You can also shut off the water from the hot water shutoff valves and the cold water on either side of the valve. Vous pouvez aussi fermer l’eau à partir des soupapes d’arrêt de l’eau chaude et de l’eau l’eau froide qui se trouve de chaque côté...
- Page 6 This akuaplus® product has been designed to meet high-quality standards and comes with a limited lifetime warranty on Ce produit akuaplus® a été conçu pour répondre à des normes de haute qualité très strictes et est assorti d’une garantie à vie cartridges and a 1-year warranty against a manufacturing defect after the date of purchase.
