- Page 1 Whittington Installation Manual Model: 51182 Noble Bronze 51183 Matte Silver Fan weight ±2 lbs: 27.8 lbs (12.6 kg) ©2020 Hunter Fan Co. PG3937 r100820...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Wood Screws
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Installing the Downrod Tighten the setscrew with pliers. DO NOT Lower the adapter cover until it rests flush HAND TIGHTEN. against the motor housing. WARNING FAN FALL HAZARD To prevent SERIOUS INJURY or DEATH: • ALWAYS tighten setscrew with pliers. •... -
Page 7: Wiring The Fan
If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualified electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the... -
Page 8: Installing The Canopy
1886 Installing the Canopy Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that the screw holes are aligned. Installing the Blades: Secure each blade to a blade iron as shown using the blade nuts, found in the hardware bag, and the blade assembly screws, found in the hardware bag. -
Page 9: Assembling The Light Fixture
1886 Assembling the Light Fixture 2 of 3 Light Kit Screw Partially install two light kit assembly screws, found Feed the wire plugs through the center in the hardware bag, halfway into the motor hole of the upper switch housing, then housing as shown. -
Page 10: Preparing The Remote
1886 Preparing the Remote The remote control is already paired for use. For your convenience, a remote To access the battery Remote Function Guide compartment, remove the function card is packed in Key Press Function small Phillips head screw that with your remote. -
Page 11: Troubleshooting
Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. provide maintenance to the fan, or acts of God (e.g. flood). - Page 12 Follow the onscreen prompts to set up your fan. (fan style may vary). Hunter Pro Tip: Need to install the app later? When ready, turn the wall switch off and then on.
