- Page 1 Churchwell Installation Manual Model: 51199 Matte Silver 51200 Noble Bronze Fan weight ±2 lbs: 26.7 lbs (12.1 kg) ©2020 Hunter Fan Co. PG3962 r110520...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for those Hunter Pro Tip: parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
-
Page 4: Choosing The Right Installation Location
A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit. -
Page 5: Installing The Ceiling Bracket
You have two options for installation. Pick which one works best for your location. Remove any existing Hunter Pro Tip: bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. The machine screws are the ones that came with your outlet box. -
Page 6: Hanging The Fan
1886 Hanging the Fan NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Place the downrod ball into the slot in the ceiling bracket. Progress Check: Your fan should look like this. Note: Fan style may vary. - Page 7 If you are unfamiliar with wiring or uncomfortable doing it yourself, please contact a qualifi ed electrician. You are going to need these: Hunter Pro Tip: Here is how to connect the wires: 4 Wire Nuts (these are in the...
- Page 8 Insert the two canopy screws found in the hardware bag. Canopy Screw Lift the canopy into place so that Hunter Pro Tip: NOTICE the screw holes are aligned. Let the tool do the work! A magnetic screwdriver will If screw holes do not align...
- Page 9 1886 Assembling the Light 2 of 6 1 of 6 Light Kit Screw Light Kit Screw Insert a third screw, found in the Feed the wire plug through the center hardware bag, into place and hole of the upper switch housing, then tighten all three screws.
- Page 10 1886 Installing the Pull Chains Light Pull Chain Fan Pull Chain Remove and discard the plastic connectors from the ends of the pull chains (if necessary), then connect the appropriate pull chain pendant to each of the short chains coming from the switch housing.
-
Page 11: Troubleshooting
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,... - Page 12 1886 Downrod If you need a different downrod length follow these steps: Follow steps 1-5 to remove standard downrod pipe Follow steps 6-10 to reassemble with new downrod WARNING FAN FALL HAZARD To prevent SERIOUS INJURY or DEATH: • ALWAYS follow the downrod assembly instructions exactly.
