Related Manuals for Lithionics Battery 12V130A-G31-LRBM8
Summary of Contents for Lithionics Battery 12V130A-G31-LRBM8
- Page 1 Part Number: 74-505 12V130A-G31-LRBM8 User Guide NeverDie® Compact Series 100 Internal BMS MiniBMS ® ® TECHNOLOGY...
-
Page 2: Table Of Contents
Notice of Copyright 12V130A-G31-LRBM8 User Guide Copyright © 2021 all rights reserved. No part of this document may be reproduced in any form without the express consent of Lithionics Battery, Clearwater, FL 33765 USA. Lithionics Battery reserves the right to revise this document and make periodic changes to the contents without obligation or organization of such changes and revisions. -
Page 3: Battery Installation
CAUTION: Improper terminal connection or lug stacking may cause battery damage that is not covered under warranty. LITHIONICS BATTERY, CLEARWATER, FL 33765 USA PH: 727.726.4204 | FAX: 727.797.8046 | WEB: LITHIONICSBATTERY.COM Page 3 of 11... -
Page 4: First Power-Up
WARNING - If the reserve energy is used and the battery module is left in a deeply discharged state without immediate charging, the battery module may become permanently damaged. LITHIONICS BATTERY, CLEARWATER, FL 33765 USA PH: 727.726.4204 | FAX: 727.797.8046 | WEB: LITHIONICSBATTERY.COM... -
Page 5: Battery Charging
Maximum Absorb Cycle Time 60 Minutes your charger is suitable for charging your battery, contact Recommend Float Voltage 13.4V Lithionics Battery® or your dealer to confirm charger Maximum Float Voltage 13.6V compatibility, or to purchase compatible charger. Equalization Mode Disabled... -
Page 6: Power Button With Status Light
4. Every 6 months charge the battery to 100% state-of-charge, then discharge the battery to LVC, then charge it back to 50% ±10% state-of-charge. LITHIONICS BATTERY, CLEARWATER, FL 33765 USA PH: 727.726.4204 | FAX: 727.797.8046 | WEB: LITHIONICSBATTERY.COM Page 6 of 11... -
Page 7: Bluetooth App
1) The battery must be in the ON position. 2) Bluetooth must be enabled on your device. 3) Open the Lithionics Battery® Monitor App and accept location permissions. 4) Under the Device List, select the battery you would like to monitor (the device name is identified by the battery serial number). - Page 8 The log files can be found under the settings menu and can be easily shared from the app for troubleshooting or analyzing battery history. LITHIONICS BATTERY, CLEARWATER, FL 33765 USA PH: 727.726.4204 | FAX: 727.797.8046 | WEB: LITHIONICSBATTERY.COM Page 8 of 11...
-
Page 9: Bms Functions
Even when the BMS detects the short circuit and tries to protect, the BMS may be damaged under such a large current. Make sure that the battery connection is always properly fused and does not rely on the BMS alone for short circuit protection! LITHIONICS BATTERY, CLEARWATER, FL 33765 USA PH: 727.726.4204 | FAX: 727.797.8046 | WEB: LITHIONICSBATTERY.COM... -
Page 10: Battery Specifications
Additionally, the battery needs at least one charge & discharge cycle every six months. Self-discharge rate Residual capacity ≤3% per month; ≤15% per year Reversible capacity ≤1.5%per month; ≤8% per year LITHIONICS BATTERY, CLEARWATER, FL 33765 USA PH: 727.726.4204 | FAX: 727.797.8046 | WEB: LITHIONICSBATTERY.COM Page 10 of 11... -
Page 11: Troubleshooting & Faq
Troubleshooting & FAQ When troubleshooting your battery, one of the most helpful tools is the battery Status Code feature of the Lithionics Battery Monitor App. If the battery shuts down due to a protective BMS feature, please have the Bluetooth app available when resetting the battery to identify the battery info and status code.
