  • Page 1 USER’S MANUAL BCO-1000-J1900 Series Basic Fanless Embedded System...
  • Page 2 l User’s Manual BCO-1000-J1900 Please note, the BCO-1000 is now referred to as “BCO-1000-J1900" due to a model name change. All product features and functionality remain the same. If any questions, please contact us for more information. Name Change Guide: LEGACY Model Name NEW Model Name BCO-1000...

  • Page 3: Table Of Contents

    l User’s Manual BCO-1000-J1900 Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….………..04 Disclaimer ………………………………………………………..…….…….………………………….………………..04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….…………..05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………07 Ordering Information …………………………………….……………………………………….……….…………...
  • Page 4 l User’s Manual BCO-1000-J1900 Chapter 4 BIOS Setup …………………………………………………………………………… 47 BIOS Introduction …….……….……………………………………..….…….…..….…………...48 Main Setup ……..……….………………….…………………………..…….….………………..49 4.2.1 System Date …….……………………………………………..……..……………………..49 Advanced Setup ………………………………………………………..…………………………….. 50 4.3.1 Trusted Computing ………………………………………………………………………… 50 4.3.2 ACPI Settings ……..…………………………………………………………..……………….51 4.3.3 Super IO Configuration …………………………….………..…………………..……... 52 4.3.4 Hardware Monitor ………………………………………….………………………..…..56 4.3.5 Serial Port Console Redirection …………………………………..……..……..56 4.3.6 CPU Configuration ……………………………..……………….………….….…….…..

  • Page 5: Prefaces

    l User’s Manual BCO-1000-J1900 Prefaces Revision Revision Description Date Manual Released 2018/01/15 Added WDT and GPIO Sample Code 2018/02/09 Model Name and Installation Instruction Update 2020/07/09 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T Solution Inc.

  • Page 6: Safety Precautions

    l User’s Manual Preface BCO-1000-J1900 Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. ⚫...

  • Page 7: Technical Support And Assistance

    l User’s Manual Preface BCO-1000-J1900 Technical Support and Assistance Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ⚫ Model name and serial number ⚫...

  • Page 8: Package Contents

    l User’s Manual Preface BCO-1000-J1900 Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty BCO-1000 Series Embedded System Utility DVD Driver Accessory Kit DVI to VGA Adapter Ordering Information Model No.

  • Page 9: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 10: Overview

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.1 Overview BCO-1000 series powered by Intel® Celeron® Processor J1900 2.0GHz SoC, which delivers increased performance by up to 150% compared to previous Atom® platforms and low power consumption. The BCO-1000 series is compatible for applications that need a basic and simple but dependable solution.

  • Page 11: Hardware Specification

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.2 Hardware Specification Processor System • Intel® Celeron® Processor J1900, Quad Core, 2MB Cache, Digital Input & Output 2.0 GHz with AMI 64Mbit SPI BIOS. (Except BCO-1000, BCO-1010, BCO-1010B, BCO-1010U, BCO-1020D) • 4x Digital Input (Source Type) Memory - Input Voltage (Dry Contact): •...

  • Page 12: System I/O

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.3 System I/O 1.3.1 BCO-1000 Front Panel SIM card ATX power on/off switch Used to insert a SIM card Press to power-on or power-off the system LAN port AT/ATX mode select switch Used to connect the system to a local area Used to select AT or ATX power mode network...
  • Page 13 l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 Rear Panel COM port DC IN COM1 ~ COM2 support RS232/422/485 serial Used to plug a DC power input with terminal device block Antenna hole DVI-I port Used to connect an antenna for optional Mini- Used to connect a DVI monitor or connect PCIe WiFi module optional split cable for dual display mode...

  • Page 14: Bco-1010 / Bco-1010A / Bco-1010B / Bco-1010U

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.3.2 BCO-1010 / BCO-1010A / BCO-1010B / BCO-1010U Front Panel SIM card ATX power on/off switch Used to insert a SIM card Press to power-on or power-off the system LAN port AT/ATX mode select switch Used to connect the system to a local area Used to select AT or ATX power mode network...
  • Page 15 l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 Digital I/O Terminal Block Rear Panel The Digital I/O terminal block supports 4 digital DC IN input and 4 digital output (BCO-1010A Only) Used to plug a DC power input with terminal block COM port COM1 ~ COM2 support RS232/422/485 serial...

  • Page 16: Bco-1020C / Bco-1020D

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.3.2 BCO-1020C / BCO-1020D Front Panel SIM card ATX power on/off switch Used to insert a SIM card Press to power-on or power-off the system LAN port AT/ATX mode select switch Used to connect the system to a local area Used to select AT or ATX power mode network Power LED...
  • Page 17 l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 Rear Panel Digital I/O Terminal Block The Digital I/O terminal block supports 4 digital DC IN input and 4 digital output Used to plug a DC power input with terminal block COM port COM1 ~ COM4 support RS232/422/485 serial DVI-I port device...

  • Page 18: Bco-1030

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.3.2 BCO-1030 Front Panel SIM card Used to insert a SIM card ATX power on/off switch Press to power-on or power-off the system LAN port Used to connect the system to a local area AT/ATX mode select switch network Used to select AT or ATX power mode...
  • Page 19 l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 Rear Panel Digital I/O Terminal Block DC IN The Digital I/O terminal block supports 4 digital Used to plug a DC power input with terminal input and 4 digital output block COM port DVI-I port COM1 ~ COM6 support RS232/422/485 serial Used to connect a DVI monitor or connect...

  • Page 20: Mechanical Dimension

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.4 Mechanical Dimensions 1.4.1 BCO-1000 Unit: mm...

  • Page 21: Rco-1010 / Rco-1010A / Rco-1010B / Bco-1010U

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.4.2 BCO-1010 / BCO-1010A / BCO-1010B / BCO-1010U Unit: mm...

  • Page 22: Rco-1020C / Rco-1020D

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.4.3 BCO-1020C / BCO-1020D Unit: mm...

  • Page 23: Rco-1030

    l User’s Manual Chapter 1: Product Introductions BCO-1000-J1900 1.4.4 BCO-1030 Unit: mm...

  • Page 24: Chapter 2 Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 25: Switch And Connector Locations

    l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 2.1 Switch and Connector Locations 2.1.1 Top View COM2 COM1 DVI-I DC IN BAT1 SODIMM1 PWR_SW1 MIC-IN LINE-OUT LAN 1 LAN 2 USB 3 USB 2 USB 2 USB 2 PWR_LED1 HDD_LED1...

  • Page 26: Bottom View

    l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 2.1.2 Bottom View SATA1 CLR_COMS1 AT_ATX1 RESET1 WDT_LED1 2.1.3 Daughter board view...

  • Page 27: Connector / Switch Definition

    l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch PWR_SW1 Power Switch PWR_LED1 Power LED Status HDD_LED1 HDD Access LED Status WDT_LED1...

  • Page 28: Switch Definitions

    l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 2.3 Switches Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Right) ATX Power Mode（Default） 2-3 (Left) AT Power Mode CLR_CMOS1: Clear BIOS Switch Switch Definition Normal Status (Default) Clear BIOS 2.4 Connectors Definitions PWR_SW1: Power Button...
  • Page 29 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 USB3_1: USB 3.0 Connector, Type A Definition Definition USB3_RX+ USB2_DATA1- USB2_DATA1+ USB3_TX- USB3_TX+ USB3_RX- LAN1: RJ45 with LEDs Port Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N Link LED Status Definition Act LED Status Definition...
  • Page 30 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 LINE_OUT1 : Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC_IN1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L RESET1 : Reset Button Definition RESET DC_IN1: DC Power Input Connector (+9~30V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition...
  • Page 31 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ DDC_CLOCK DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC COM1_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex...
  • Page 32 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 COM2_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD2 TX2- DATA2- RxD2 TX2+ DATA2+ TxD2 RX2+ DTR2 RX2- DSR2...
  • Page 33 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 CN2: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD4 (DCD6) TX4- (TX6-) DATA4- (DATA6-) RxD4 (RxD6) TX4+ (TX6+) DATA4+ (DATA6+) TxD4 (TxD6)
  • Page 34 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900...
  • Page 35 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 MINIPCIE1: Mini PCI-Express Socket Definition Definition Definition WAKE# +3.3V +3.3V USB_DP1 +3.3V MINIPCIE RST# MINIPCIE_RXN1 +3.3V +1.5V +3.3V CLKREQ1# MINIPCIE_RXP1 +1.5V MINIPCIE_CLKN1 SMB_CLK +1.5V MINIPCIE_CLKP1 MINIPCIE_TXN1 SMB_DATA MINIPCIE_TXP1 +3.3V USB_DN1 CN3: Mini PCI-Express / mSATA Socket Definition Definition Definition...
  • Page 36 l User’s Manual Chapter 2: Switches and Connectors BCO-1000-J1900 SATA1: SATA with Power Connector Definition Definition SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 +3.3V +3.3V +12V +3.3V +12V +12V...

  • Page 37: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 38: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source. 3.2 Removing chassis bottom cover 1.

  • Page 39: Installing Sodimm

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.3 Installing SODIMM 1. Unscrew three screws on the chassis: one screw on front panel, one screw on system left side, and one screw on system right side. 2. Hold the chassis top cover. Pull the system main body following the below direction so the top cover can be separated from it.
  • Page 40 l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3. System main body and top cover separated. 4. Insert memory module from 45 degree direction. 5. Press the memory module vertically downward until you hear the “click” sound. Make sure the memory module is firmly in place.

  • Page 41: Installing Sata Hdd/Ssd

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.4 Installing SATA HDD/SSD 1. Remove HDD bracket by unscrewing the four screws. 2. Lock the 2.5” HDD with HDD bracket using four screws.
  • Page 42 l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3. Insert the entire bracket following the below direction so the SATA connector is firmly plugged into the HDD. 4. Fasten the four screws to lock the HDD bracket in place.

  • Page 43: Installing Mini Pcie Card / Msata

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.5 Installing Mini PCIe card / mSATA 1. Place the system body upside down so you can see the 2x mini card socket. Mini PCIe 2 (CN3) can support mSATA. Mini PCIe 1 Mini PCIe 2 / mSATA 2.

  • Page 44: Installing Antenna

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.6 Installing antenna 1. Remove antenna hole cover on the system panel. 2. Have antenna jack penetrate through the hole.
  • Page 45 l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the cable-end onto the communication module.

  • Page 46: Assemble Chassis Bottom Cover

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.7 Assemble chassis bottom cover 1. Place the bottom cover according to the below direction. 2. Lock the bottom cover with the four screws.

  • Page 47: Installing Sim Card

    l User’s Manual Chapter 3: System Setup BCO-1000-J1900 3.8 Installing SIM card 1. SIM card socket is located on the front panel of the system. 2. Now you can insert SIM card into the socket. 3. To uninstall SIM card, simply press the installed SIM card and then the card will be pushed out.

  • Page 48: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 49: Bios Introduction

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.1 BIOS Introduction The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del> immediately allows you to enter the setup screens.

  • Page 50: Main Setup

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. 4.2.1 System Date Set the system date.

  • Page 51: Advanced Setup

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3 Advanced Setup 4.3.1 Trusted Computing ■ Security Device Support Enable or disable TPM function...

  • Page 52: Acpi Settings

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.2 ACPI Settings ■ Enable ACPI Auto Configuration This item allows you to enable or disable BIOS ACPI Auto Configuration. ■ Enable Hibernation This item allows you to enable or disable system ability to hibernate. ■...

  • Page 53: Super Io Configuration

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.3 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ❑ Serial Port This item allows you to enable or disable serial port.
  • Page 54 l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 ■ Serial Port 2 Configuration ❑ Serial Port This item allows you to enable or disable serial port. ❑ Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ❑...
  • Page 55 l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 ■ Serial Port 4 Configuration ❑ Serial Port This item allows you to enable or disable serial port. ❑ Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ❑...
  • Page 56 l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 ■ Serial Port 6 Configuration ❑ Serial Port This item allows you to enable or disable serial port. ❑ Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ❑...

  • Page 57: Hardware Monitor

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.4 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. 4.3.5 Serial Port Console Redirection ■ Console Redirection These items allows you to enable or disable COM1 console redirection.

  • Page 58: Cpu Configuration

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.6 CPU Configuration ■ Intel Virtualization Technology Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple Virtual systems. ■...

  • Page 59: Ppm Configuration

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.7 PPM Configuration ■ CPU C state Report Enables or disables support for CPU's power-saving functions. ■ Enhanced C state Enables or disables Intel CPU Enhanced Halt (C1E) function, a CPU power-saving function in system halt state.

  • Page 60: Sata Configuration

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.8 SATA Configuration ■ SATA Speed Support Change the SATA Speed. Select <Gen1> or <Gen2> speed. ■ SATA Mode This item allows you to select IDE or AHCI Mode. ■ Mini Serial – ATA Port 0 This item allows you to enable or disable Serial-ATA Port 0.

  • Page 61: Network Stack Configuration

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.10 Network Stack Configuration ■ Network Stack Enable/Disable UEFI Network Stack.

  • Page 62: Csm Configuration

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.3.11 CSM Configuration ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter This item allows you to select which type of operating system to boot. UEFI and Legacy: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.

  • Page 63: Usb Configuration

    Chapter 4: BIOS Setup l User’s Manual BCO-1000-J1900 4.3.12 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support.

  • Page 64: Chipset

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.4 Chipset 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options.
  • Page 65 Chapter 4: BIOS Setup l User’s Manual BCO-1000-J1900 ■ Intel IGD Configuration This section provides onboard graphics-related configuration options. ❑ IGD Turbo Enable This item allows you to enable or disable IGD Turbo. ❑ GFX Boost This item allows you to enable or disable GFX Boost. ❑...

  • Page 66: South Bridge

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azaliadevice. ❑ Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ❑ XHCI Mode This item allows you to enable or disable the USB XHCI controller.
  • Page 67 l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 ■ PCI Express Configuration ❑ PCI Express Port 1 (mPCIE1) This item allows you to enable or disable PCI Express Port 1 (mPCIE1) in the Chipset. ❑ Speed ❑ Change the PCIe Port Speed. Select <AUTO> ,<Gen 2> or <Gen 1> ❑...

  • Page 68: Security

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.5 Security Security menu allow you to change administrator password and user password settings. 4.5.1 Administrator Password This item allows you to set Administrator Password. 4.5.2 User Password This item allows you to set User Password.
  • Page 69 l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 ■ Security Boot Item Options Description Secure Boot Disabled [Default] , Secure Boot feature is Active if Enabled Secure Boot is Enabled,Platform Key(PK) is enrolled and the System is in User mode. The mode change requires platform reset Secure Boot...
  • Page 70 l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 ■ Key Management Item Options Description Provision Disabled [Default] , Install factory default Secure Boot Factory Default Enabled keys after the platform reset and while the System is in Setup mode...

  • Page 71: Boot

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.6 Boot This menu allows you to setup the system boot options. 4.6.1 Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State This item selects the keyboard NumLock state.

  • Page 72: Save & Exit

    l User’s Manual Chapter 4: BIOS Setup BCO-1000-J1900 4.7 Save & Exit This setting allows you to configure the boot settings. 4.7.1 Save Changes and Reset This item allows you reset the system after saving the changes. 4.7.2 Discard Changes and Reset Select this option to quit Setup without making any permanent changes to the system configuration.

  • Page 73: Appendix Wdt & Gpio

    l User’s Manual Appendix – WDT & GPIO BCO-1000-J1900 WDT Sample Code WDT Setting // IO Address 0xA16 is time value // IO Address 0xA15 is WDT enable and configuration Example, Set 0xA16=-0x03, 0xA15=0x31, it will reset after 3 seconds #define TimePort 0xA16 #define TimeEnablePort...

  • Page 74: Gpio Sample Code

    l User’s Manual Appendix – WDT & GPIO BCO-1000-J1900 GPIO Sample Code GPIO Setting IO_DO4 I/O 0xA02h Bit3 IO_DO3 I/O 0xA02h Bit2 IO_DO2 I/O 0xA02h Bit1 IO_DO1 I/O 0xA02h Bit0 IO_DI4 I/O 0xA03h Bit7 IO_DI3 I/O 0xA03h Bit6 IO_DI2 I/O 0xA03h Bit5 IO_DI1 I/O 0xA03h Bit4 #define GPI_ADDR 0xA03...
  • Page 75 Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).
  • Page 76 l User’s Manual Appendix – WDT & GPIO BCO-1000-J1900 WDT Sample Code SIO_INDEX_Port equ 04Eh SIO_DATA_Port equ 04Fh SIO_UnLock_Value equ 087h SIO_Lock_Value equ 0AAh WatchDog_LDN equ 007h WDT_UNIT equ 60h ;60h=second, 68h=minute, 40h=Disabled Watchdog timer WDT_Timer equ 30 ;ex. 30 seconds Sample code: ;Enable config mode dx, SIO_INDEX_Port...
  • Page 77 l User’s Manual Appendix – WDT & GPIO BCO-1000-J1900 GPIO Sample Code ⚫ GPI 0 ~ GPI 3 GPI 0 GPI 1 GPI 2 GPI 3 IO Address 0xA03h 0xA03h 0xA03h 0xA03h Sample code ⚫ GPO 0 ~ GPO 3 GPO 0 GPO 1 GPO 2...
