What's in the Shipping Package?
The shipping package showed contain the following items:
ZT-2018/S
Device
If any of these items are missing or damaged, please contact your local distributor for more
information. Save the shipping materials and cartons in case you need to ship the module in the
future.
2
Preparing the Device
Refer to Section 4. for details of how to configure the DIP switches of the ZT-2000 I/O
1.
device.
Install the ZT Configuration Utility on your Host PC to configure the ZT-2000
2.
coordinator. The utility can be founded on the CD in the
\Napdos\ZigBee\ZT_Series\Utility folder, or downloaded from:
http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/utility
Power Supply: Connect a power supply using a voltage range of +10 ~ +30 V
3.
ICP DAS, ZT-2018/S Quick Start, Version 1.0.0
Copyright
ZT-2018/S
ANT-124-05
+Vs
GND
©
2013 by ICP DAS Co., Ltd. All Rights Reserved.
Quick Start
CN-1824
Quick Start
+Vs
DC
GND
Page 1
