ICP DAS USA ZT-2024 Quick Start Manual

1
What's in the Shipping Package?
The shipping package showed contain the following items:
ZT‐2024 Device
If any of these items are missing or damaged, please contact your local distributor
for more information. Save the shipping materials and cartons in case you need to
ship the module in the future.
2
Preparing the Device
Refer to Section 4. for details of how to configure the DIP switches of the
1.
ZT-2000 I/O device.
Install the ZT Configuration Utility on your Host PC to configure the ZT-2000
2.
coordinator. The utility can be founded on the CD in the
\Napdos\ZigBee\ZT_Series\Utility folder, or downloaded from:
http://ftp.icpdas.com/pub/cd/usbcd/napdos/zigbee/zt_series/utility
Power Supply: Connect a power supply using a voltage range of +10 ~ +30
3.
V
DC
ICP DAS, ZT‐2024 Quick Star, Version 1.0.0
Copyright
ZT‐2024
ANT‐124‐05
+Vs GND
©
2014 by ICP DAS Co., Ltd. All Rights Reserved.
Quick Start
Quick Start
+Vs GND
Page 1
CD
