- Page 1 VOKKERO VARSITY II User Guide Version 1.0 212224 VOGO NA (North America) VOGO VOKKERO 25 Main Street, 3rd Floor, 895 Rue de la Vieille Poste Tuckahoe, NY 10707 Parc Majoria-Pompignane www.vokkerousa.com Immeuble LA LÓNA, 34000 Montpellier, France www.vokkero.com...
- Page 2 VOKKERO VARSITY II | User Guide V1.0 PREAMBLE • This guide describes the functionality of the system Vokkero® VARSITY II, options and accessories. It explainshow to configure it to allow a conference-type communication between multiple users. Web www.VOKKERO.com VOGO NA (North America) 25 Main Street, 3rd Floor Tuckahoe, NY 10707 www.vokkerousa.com VOGO (Headquarters) 895 Rue de la Vieille Poste Parc Majoria-Pompignane Immeuble LA LÓNA, 34000 Montpellier, France www.vokkero.com 2 / 16...
-
Page 3: Table Of Contents
VOKKERO VARSITY II | User Guide V1.0 Table des matières PRÉAMBULE / PREAMBLE / PRÄAMBEL / PREAMBOLO ENGLISH INFORMATIONS DISCLAIMER TECHNICAL SUPPORT INTRODUCTION ENVIRONMENTAL RECOMMENDATIONS WARNINGS DISPOSAL OF WASTE BY USERS IN PRIVATE HOUSEHOLDS RECOMMANDATIONS REGARDING USE FOR VO8363AAAA SYSTEM INSTALLATION PROCEDURE SYSTEM DESCRIPTION 2.1. VOKKERO VARSITY II Terminal 2.1.1. Description of product interface 2.1.2. General characteristics 2.2. VOKKERO VARSITY II Charger 2.2.1. Description of product interface 2.2.2. General Technical Specifications QUICK START OF THE CONFERENCE 3.1. Setting up Audio Conference 3.2. Description of the terminal 3.3. Connecting a headset 3.3.1. Plugging in a headset... -
Page 4: English
VOKKERO VARSITY II | User Guide V1.0 ENGLISH 4 / 16... -
Page 5: Informations
VOKKERO VARSITY II | User Guide V1.0 INFORMATIONS Document Information Title VOKKERO VARSITY II Subtitle VARSITY II Document type User Guide Version Version 1.0 This document applies to the following products: Name Reference VOK-VARSITY II-US From : VO8364VAA VOK-ELITE-CHARGER From : VO8363AA DISCLAIMER This document and the use of any information contained therein, is subject to the acceptance of the VOKKERO terms and conditions. They can be downloaded from www.vokkero.com VOKKERO makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. - Page 6 VOKKERO VARSITY II | User Guide V1.0 USE of VOKKERO VARSITY II in US USAGE RESTRICTIONS The table below lists the channels available in the VOKKERO VARSITY II system and specify the associated potential usage restrictions. Channels Frequency (MHz) 927,4 921,8 Inside the stadium, a spectrum referent may be available to assist in frequency allocation. For the use of VARSITY II outside United States, please contact customer support: “www.vokkero.com/Support/Technical Support”. In the VOKKERO HELPDESK space, log in with your identifiers (or sign up to create your account) to access the support. The device complies with the requirements of human exposure to radio frequency fields produced by wireless communica- tions devices worn close to the body. The equipment must be attached to the arm via the armband provided by Vokkero. 6 / 16...
- Page 7 VOKKERO VARSITY II | User Guide V1.0 COMPLIANCE TO FCC US/CAN This device complies with part 15 of the FCC rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1). this device may not cause Harmful interference, and (2). This device must accept any interference received, including interference that may cause undesired opera- tion of the device. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential instal- lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to radiocommunication. However, there is no guarantee that inter- ference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and receiver • Connect the quipment into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by VOGO could void the user’sauthority to operate the equipment. This device is limited to operating the frequencies authorized by Part 15 and cannot be configured by end users or profes- sional installers to operate outside the authorized bands. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lower) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be chosen so that the equivalent isotropically radiated power (e.i.r.p.) is not superior than necessary for successful communication. Ce dispositif est conforme aux règles de la FCC part 15 and à la norme CNR-247 d’Industrie Canada applicable aux appa- reils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas pro- duire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
- Page 8 VOKKERO VARSITY II | User Guide V1.0 FOR PORTABLE DEVICE USAGE (<20cm from body/SAR needed): Radiation Exposure Statement: This device complies with the FCC and ISED portable RF exposure limit set forth for an uncontrolled environment and is safe for intended operation as described in this manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or set the device to lower output power if such function is available. This portable equipment with its antenna complies with FCC’s and ISED RF radiation exposure limits set forth for an uncontrolled environment. To maintain compliance follow the instructions below: 1. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2.Avoid direct contact with the antenna, or keep it to a minimum while using this equipment. The SAR limit adopted by USA and Canada is 1.6 W/kg averaged over 1 gram of tissue. The highest SAR value reported to FCC and ISED for this device complies with this limit. Déclaration d’exposition aux radiations: Le produit est conforme aux limites d’exposition FCC (Etats-Unis) et ISED (CANADA) pour les appareils portables RF établies pour un environnement non contrôlé.
-
Page 9: Introduction
VOKKERO VARSITY II | User Guide V1.0 INTRODUCTION All rights to this manual are the exclusive property of VOKKERO. All rights reserved. Copying this manual (without writ- ten permission from the owner) via printing, copying, recording or by any other means, translating this manual (in full or partially) into any other language, including all programming languages, using any electrical, mechanical, magnetic or optical devices, manually or any by other methods, is prohibited. VOKKERO reserves the right to change the technical specifications or functions of its products, or to cease manufac- turing any of its products, or to cease technical support for one of its products without notice in writing and urges its customers to make sure that the information they have is valid. VOKKERO configuration software and programs are available free of charge in a non-modifiable version. VOKKERO can make no guarantees, including guarantees concerning suitability and applicability for a certain type of application. Under no circumstances can the manufacturer, or the distributor of an VOKKERO program, be held liable for any damage caused by the use of the aforesaid program. Program names, as well as all copyright relating to programs, are the exclusive property of VOKKERO. Any transfer, granting of licences to a third party, leasing, hire, transport, copying, editing, translation, modification into another programming language or reverse engineering are prohibited without VOKKERO’s prior written authorisation and consent. ENVIRONMENTAL RECOMMENDATIONS All superfluous packaging materials have been eliminated. We have done everything possible to make it easy to sepa- rate the packaging into three types of materials: cardboard (box), expanded polystyrene (filler material) and polyethy- lene (packets, foam protective sheets). Your device is composed of materials that can be recycled and reused if it is dismantled by a specialist company. Please observe local regulations concerning the manner in which waste packaging material, used batteries and your obsolete equipment are disposed of. -
Page 10: Disposal Of Waste By Users In Private Households
VOKKERO VARSITY II | User Guide V1.0 DISPOSAL OF WASTE BY USERS IN PRIVATE HOUSEHOLDS This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste by taking it to a collection point designated for the recycling of electrical and electronic appliances. Separate collection and recycling of your waste at the time of disposal will contribute to conserving natural resources and guarantee recycling that respects the environment and human health. For further information concerning your nearest recycling centre, please contact your nearest local authority/town hall offices, your household waste collection company or the shop where you bought the product Warning: If the charger is used with any other batteries or products whatsoever, there is a risk of an explosion. After use, the batteries must be disposed of at an appropriate recycling centre. They must not be thrown away to degrade in the environment. When batteries are replaced, the device must be corectly implemented. Warning for Switzerland : the annex 4.10 of SR 814.013 Standad must be applied for batteries. This symbol on the devode or its packaging means the use of a DC voltage. -
Page 11: System Installation Procedure
VOKKERO VARSITY II | User Guide V1.0 The operations described below allow you to rapidly and easily implement your VOKKERO VARSITY II communication system. All the operations described are valid for all the VOKKERO VARSITY II terminals listed below: VOK-VARSITY II-US : REF VO8364VAA Note: Your product reference is given on the label on the back of the terminal housing. The VOKKERO VARSITY II is a ready-to-use system with the following two main elements: • Terminals: VO8364VAA • Optional Charger: VOK-ELITE-CHARGER : VO8363AA 1. SYSTEM INSTALLATION PROCEDURE • Connect the power unit to the end charger (if several are connected in a row). • Connect the power unit to the mains. • Connect the VOKKERO VARSITY II terminals as shown below. Note: the order and position of the terminals on the charger(s) are not of importance. Power supply connector Charger Up to 4 chargers can be chained 11 / 16... -
Page 12: System Description
VOKKERO VARSITY II | User Guide V1.0 2. SYSTEM DESCRIPTION 2.1. VOKKERO VARSITY II Terminal 2.1.1. Description of product interface On/Off button Turns the terminal On/Off Gives battery life (led colour from green to orange and then to red) Headset connector Connect to a VOKKERO headset. LED Screen Gives indication on terminal role, network reception, channel… + and – buttons Adjust the audio volume 2.1.2. General characteristics General Specifications Value Supply voltage 3.7V nominal... -
Page 13: Vokkero Varsity Ii Charger
VOKKERO VARSITY II | User Guide V1.0 2.2. VOKKERO VARSITY II Charger 2.2.1. Description of product interface System installation procedure VOKKERO VARSITY II: • Connect the power supply to the charger • Connect the power supply to the mains • Connect the VARSITY II terminals as shown below. Place the terminals in the locations intended for this purpose (4 per charger). Insert them vertically so as not to damage the connector. • When the terminal is detected, charging begins. If the corresponding LED does not come on, check that the terminal has been correctly positioned. • To remove the terminals from the charger, pull them up. Note: when the terminals are removed from the charger, they turn off automatically, so they must be turned on again to use them. Be careful to use the power supply provided by Vokkero when your VARSITY II kit is delivered. 2.2.2. General Technical Specifications Specifications Value... -
Page 14: Quick Start Of The Conference
VOKKERO VARSITY II | User Guide V1.0 3. QUICK START OF THE CONFERENCE 3.1. Setting up Audio Conference The terminals are delivered pre-configured and ready-to-use. The first step consists in turning on the terminals and in particular the Master role terminal. This role is used to synchronize the other terminals. You can recognize the Master terminal thanks to its orange icon number 1. In case no terminal show the orange icon number 1 or if several terminals shows this orange icon number 1 , that means that you have no Master or several Master roles in the network. In that case, the audio conference won’t work properly. The «modification of the role number» function makes it possible to remedy this situation by offering the possibility of modifying the role number of a terminal by assigning it the role n°1 (see paragraph 3.5). 3.2. Description of the terminal Press the On/Off button to turn on the terminal. Press the On/Off for 3 secondes to turn off the terminal. Note 1: all settings, including volume, remain unchanged when the terminal is turned off (i.e., will be identical when the terminal is turned again). The LCD screen will light up indicating a number with an associated color. This number indicates the role of your device in the conference. • Icone 1 (orange) : Master •... -
Page 15: Adjust Volume
VOKKERO VARSITY II | User Guide V1.0 3.4. Adjust Volume Push + to increase the audio volume Push – to decrease audio volume 5 steps of volume are available. A vocal synthesis (heard in the headset) indicates the step (volume 1 to volume 5). A vocal synthesis indicates that “Minimum volume” is reached, another vocal synthesis indicates that “Maximum volume” is reached. To avoid possible hearing damage, do not listen at high volume for a long time. 3.5. Modification of the role number To function correctly, the audio conference must have a terminal with the role number 1. Your VARSITY kit is deliver ready-to-use and no configuration is needed. However, if this terminal is missing (eg: power problem or malfunction), the conference is no longer possible. The «modification of the role number» function makes it possible to remedy this situation by offering the possibility of modifying the role number of a terminal by assigning it role n ° 1. IMPORTANT : The role numbers must be unique for the proper functioning of the conference (only one n ° 1, only one n ° 2, etc ...) Procedure : • Push + on the terminal for 5 seconds. • Your terminal screen will then display your number flashing. • You can switch the number by pressing + or - • To confirm the change of terminal role, press the “On / Off” button on the terminal. • After confirmation, the LCD returns to the main screen displaying the role number in a fixed way.
