IFP62 Series
Commercial Touch Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.
Model No. VS18622 | VS18623 | VS18624
P/N: IFP6562 | IFP7562 | IFP8662
Advertisement
Table of Contents
Related Manuals for ViewSonic ViewBoard IFP8662
Summary of Contents for ViewSonic ViewBoard IFP8662
- Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
- Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
-
Page 3: Safety Precautions
Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •... - Page 4 • Only use attachments/accessories specified by the manufacturer. • When a cart is used, use with caution when moving the cart/equipment combination to avoid injury from tipping over. • Disconnect the power plug from the AC outlet if the device is not being used for a long period of time.
-
Page 5: Table Of Contents
Contents Safety Precautions ............3 Introduction .............. 10 Package Contents ....................10 Wall Mount Kit Specifications (VESA) ..............11 Product Overview ....................12 Front Control Panel ....................12 I/O Panel ........................ 13 Remote Control ..................... 14 Using Gestures ...................... 17 Making Connections ..........19 Connecting External Devices and Touch Connection ...........19 Type C Connection .................... - Page 6 Using Your ViewBoard ..........25 Powering On/Off your ViewBoard ................25 Initial Launch Setup ....................26 vLauncher - Customizable Welcome Screen............28 vLauncher Message ....................28 Applications ......................29 Toolbar .........................31 On-Screen Display (OSD) Menu ................37 General Settings ....................38 Input Settings ......................39 Widget ........................
- Page 7 Embedded Applications and Settings ......81 Air Class ........................81 Voter ........................83 Judge ........................85 Responder ......................87 Selector ......................... 88 Grouping........................ 89 Message ........................ 89 Manager ........................ 89 Exit ......................... 89 myViewBoard Display ...................90 myViewBoard Live ....................91 myViewBoard Manager ..................92 myViewBoard Record ...................93 myViewBoard Whiteboard ...................94 ViewBoard Cast ....................97...
- Page 8 RS-232 Protocol ............107 Description ......................107 RS232 Hardware Specification ................107 LAN Hardware Specification ................108 RS232 Communication Setting ................108 LAN Communication Setting ................108 Command Message Reference ................108 Protocol ......................109 Set-Function Listing ..................... 109 Get-Function Listing .................... 115 Remote Control Pass-through Mode ..............
- Page 9 Regulatory and Service Information ......131 Compliance Information ..................131 FCC Compliance Statement ................. 131 Industry Canada Statement ................. 131 CE Conformity for European Countries ............... 131 Declaration of RoHS2 Compliance............... 132 ENERGY STAR Statement ..................133 Indian Restriction of Hazardous Substances ............133 Product Disposal at End of Product Life ..............
-
Page 10: Introduction
Introduction Package Contents • HDMI cable • Stylus pen x 2 • Power cable x 4 • Quick start guide • Remote control • RS-232 adapter • AAA battery x 2 • Clamp x 5 • USB cable • Webcam Plate •... -
Page 11: Wall Mount Kit Specifications (Vesa)
Wall Mount Kit Specifications (VESA) NOTE: Please follow the instructions in the wall mount installation guide to install your wall mount or mobile mount bracket. If attaching to other building materials, please contact your nearest dealer. Model VESA Spec. (A x B) Standard Screw (C x D) Quantity IFP6562 - 65”... -
Page 12: Product Overview
Product Overview Front Control Panel HDMI IN TOUCH OUT Number Item Description • Power indicator light • Press to turn on the device • Press to turn off/on the display backlight only • Press and hold to turn off the device Remote control receiver Ambient light sensor •... -
Page 13: I/O Panel
I/O Panel HDMI IN TOUCH OUT AUDIO OUT AUDIO IN SPDIF RS232 12 13 Number Port Description HDMI OUT Extend content out to another display device • USB Type A input USB 3.0 • Connect USB devices such as hard disks, keyboard, mouse, etc. -
Page 14: Remote Control
Remote Control Number Description Power on/off Screen capture [PC¹] Windows button Startup writing Back to the Embedded player Home Screen Back / Return to previous page Increase / Decrease volume Numeric Keypad Information Input source selection Media control buttons: ͫ Red - Play / Pause ͫ... - Page 15 Inserting Remote Control Batteries To insert batteries into the remote control: 1. Remove the cover on the rear of the remote control. 2. Insert two “AAA” batteries, ensuring the “+” symbol on the battery matches the “+” on the battery post. 3.
- Page 16 Remote Control Receiver Range The working range of the remote control is shown here. It has an effective range of ° 8 meters, 30 degrees left and right. Ensure there is nothing obstructing the remote control’s signal to the receiver. 30°...
-
Page 17: Using Gestures
Using Gestures Touch gestures allow the user to use pre-determined commands without using a keyboard or mouse. Using gestures on the ViewBoard, the user can select/deselect objects, change the location of an object, access settings, erase digital ink, and much more. Select and Deselect an Object (Clicking) Press and release the ViewBoard to select/deselect options or objects. - Page 18 Moving an Object Press and hold the object on the ViewBoard and slowly drag it with your finger to your desired location. Erasing Digital Ink Use your flattened hand, palm, or fist on the ViewBoard and move your hand across the area which you wish to erase.
-
Page 19: Making Connections
Making Connections Connecting External Devices and Touch Connection Type C Cable Type C USB Cable TOUCH HDMI Cable HDMI Computer USB Cable TOUCH VGA Cable Your external device(s) can be connected in any of the following configurations: Type C Connection To connect via Type C: Connect a Type C cable from your external device to the Type C port on the ViewBoard. -
Page 20: Rs-232 Connection
RS-232 Connection Serial Port Cable RS-232 Computer When you use a RS-232 serial port cable to connect your display to an external computer certain functions can be controlled remotely by the PC, including Power On/Off, Volume adjustment, Input select, Brightness, and more. -
Page 21: Usb And Networking Connections
USB and Networking Connections Just like any PC, it is easy to connect various USB devices and other peripherals to your ViewBoard. USB Peripherals Plug the USB device cable into a USB port. USB Cable USB Device Networking and Modem cables Plug the network cable into a LAN port. -
Page 22: Media Player Connection
Media Player Connection HDMI IN HDMI Cable To connect to a media player: 1. Connect the HDMI cable to the HDMI IN port on your ViewBoard and peripheral device. Plug in the power cord of your ViewBoard, and turn on the power supply switch. Press the Power button on the right-hand side of the ViewBoard to turn the screen on. -
Page 23: Spdif Connection
SPDIF Connection Optical Cable SPDIF Power amplifier / Stereo equipment To connect to an external sound system: 1. Connect an optical cable from the SPDIF port to your sound system’s optical connector. Plug in the power cord of your ViewBoard, and turn on the rear-panel power supply switch. -
Page 24: Video Output Connection
Video Output Connection HDMI Cable HDMI OUT Projector To output video via a display device: 1. Connect an HDMI cable to the HDMI IN port of your display device, and the other end to the HDMI OUT port of your ViewBoard. Plug in the power cord of your ViewBoard, and turn on the power supply switch. -
Page 25: Using Your Viewboard
Using Your ViewBoard Powering On/Off your ViewBoard 1. Ensure the power cord is connected, plugged into a power outlet, and the power switch is in the “On” position. The AC Power input and switch are located at the bottom of the unit. 2. -
Page 26: Initial Launch Setup
Initial Launch Setup When you first turn on your ViewBoard, an initial setup wizard will launch. 1. Select your Language. 2. Setup and verify your LAN connection. - Page 27 3. Select your Time Zone to set the Date and Time. 4. Select your preferred System Mode. 5. Accept or Decline the Privacy and Copyright Protection Terms.
-
Page 28: Vlauncher - Customizable Welcome Screen
vLauncher - Customizable Welcome Screen vLauncher Message Both the vLauncher Title and Subtitle can be customized by tapping on them. Additionally, a password can be set by tapping on Set Password. -
Page 29: Applications
Applications Installed applications can all be found on the welcome screen. To view all applications tap on the Down Arrow. To hide the application drawer tap the Up Arrow. To add a shortcut to an application, tap, hold, and drag up the icon. - Page 30 To remove an application shortcut, tap, hold, and drag the icon down.
-
Page 31: Toolbar
Toolbar Toolbar trigger icons are on the edge of the ViewBoard launcher providing access to your tools. To launch a tool: 1. Tap a Toolbar trigger icon. 2. Tap on your desired tool icon. NOTE: The default toolbar setting is to be available for all input sources; however, users can go to: Settings >... - Page 32 Description Icon Return to the previous operation screen. NOTE: Only for the Embedded Player source. Back Return to the Home Screen of the Embedded Player. Home Display all embedded applications that are currently being used. Recent View all installed applications. Apps Launch the whiteboarding software.
- Page 33 Description Icon Access the pen, highlighter, clear, and save options. Highlighter Eraser Undo Redo Clean Save Exit Annotate the overlay of any input source with black, white, yellow, orange, red, pink, green, or blue ink. NOTE: The default pen setting supports up to 10-point writing. Highlighter Mark and highlight with yellow, grey, gold, orange, red, pink, green or blue ink.
- Page 34 Description Icon View more applications within the ViewBoard tool bar. Screen Freeze Spotlight Stopwatch Timer Air Class Screen Capture Hide/Unhide Screen Freeze Convert the currently displayed content into a still image; then you can zoom in, zoom out, go back to full screen, and exit. Zoom in Zoom out Full Screen...
- Page 35 Description Icon Stopwatch Tapping Start will initiate the stopwatch. At any time, the stopwatch can be paused, resumed, split, or reset. More Timer Access the countdown timer with an optional alarm setting. Touch and swipe to adjust the numeric values, then click Start. At any time, the countdown timer can be paused, resumed, or reset.
- Page 36 Description Icon Air Class Interactive teaching tool for classroom usage. Screen Capture Take a screenshot of the current screen. More Hide/Unhide Hide or unhide the Toolbar trigger icons. Access the General Settings. Settings...
-
Page 37: On-Screen Display (Osd) Menu
On-Screen Display (OSD) Menu Access General Settings and Input Settings through the OSD Menu. ViewBoard has two options for opening the OSD Menu: Option 1 Long press anywhere in the vLauncher background. 30° 30° Option 2 Press the INPUT button on the remote control. -
Page 38: General Settings
General Settings To adjust the Backlight and enable/disable Auto Brightness and Eye Care: Press INPUT on the remote control or long press the vLauncher background and touch General on-screen (if needed) to display the General Settings menu. Drag the brightness slider directly to adjust the backlight value, and/or touch On or Off to enable/disable the function. -
Page 39: Input Settings
Input Settings To select an Input Source: Press INPUT on the remote control, press the setting button on the front panel, or press the setting icon from the toolbar to display the Input Settings menu. Press to select the input source you want. q/p/t/u NOTE: ... -
Page 40: Widget
Widget NOTE: Only available for the Embedded Player source. To add a widget to the vLauncher welcome screen: 1. Long press the vLancher background via touch to launch the OSD Menu. 2. Select Widget. 3. Touch and hold the desired widget. 4. -
Page 41: Settings - Hdmi & Vga Input Source
Settings - HDMI & VGA Input Source Press MENU on the remote control or select the setting icon next to the input source in Input Settings to launch the Settings menu. Settings include: Audio, Screen, Display, and Adjust. Audio Settings 1. -
Page 42: Screen Settings
Screen Settings 1. Press q on the remote control and select the Screen menu. 2. Press q/p/t/u on the remote control or directly touch the option to select it. 3. Adjust your preference by touching each value directly, or with the remote control by pressing ENTER. -
Page 43: Display Settings
Display Settings 1. Press q on the remote control and select the Display menu. 2. Press q/p/t/u on the remote control or directly touch the option to select it. 3. Adjust the Brightness, Contrast, Hue, and Sharpness directly by touching and adjusting each value, or with the remote control by pressing ENTER to adjust the option. -
Page 44: Low Blue Light Filter And Eye Health
Low Blue Light Filter and Eye Health The Blue Light Filter blocks high-energy blue light for a more comfortable viewing experience. NOTE: To meet TÜV Rheinland low blue light certification, the Display Settings must be: • Mode: Standard (Brightness and Contrast are 50) •... - Page 45 Eye and Neck Exercises Eye Exercises Eye exercises can help minimize eye strain. Slowly roll your eyes to the left, right, up, and down. Repeat as many times as needed. Exercises for the eyes (1) Keep the body and the (2) Move the eyes le and (3) Move the eyes to look head upright.
-
Page 46: Adjust Settings - (Vga Only)
Adjust Settings - (VGA Only) 1. Press q on the remote control and select the Adjust menu. 2. Press q/p/t/u on the remote control or directly touch the option to select it. 3. Adjust your preference by touching each value directly, or with the remote control by pressing ENTER. -
Page 47: Settings - Embedded Player
Settings - Embedded Player When the ViewBoard is in the Embedded Player input source, press MENU on the remote control or tap the setting icon next to the input source in the On-Screen Display (OSD) Menu’s Input Settings to enter the Settings menu. Network &... - Page 48 Wi-Fi Setup and manage wireless access points. • Tap the toggle button to turn Wi-Fi On or Off. • Once On, you can: Add a Network, view Saved Networks, Refresh the network list, or view Advanced settings. • In Advanced settings, you can toggle Network notifications On or Off and view Network card info.
- Page 49 Ethernet Set the local network and proxy. • Tap the drop down menu to connect/disconnect the Ethernet. • You can adjust Local network and Proxy settings as well. • Tap Advanced to view Network card info and toggle Network auto reconnect.
- Page 50 Wireless Hotspot Set and share my internet connection with other devices. • Tap the toggle button to turn Wireless hotspot On or Off. • Tap Set up to set the Network name, Security, and Password.
- Page 51 Bluetooth Manage connections, set the device name and discoverability. • Tap the toggle button to turn Bluetooth On or Off. Once On, users can select a listed device to pair and connect to, rename their device, remove a device, or receive files.
- Page 52 Setup and manage Virtual Private Networks. To create a VPN profile: 1. Go to: Settings > Wireless & Network > VPN and tap Add VPN. 2. Key in the Name.
- Page 53 3. Select the VPN Type. 4. Choose to enable/disable PPP encryption (MPPE) and/or show Advanced options.
-
Page 54: Share
Share SAMBA The SAMBA Service provides file sharing via LAN. When the SAMBA Service is enabled, the user can explore the ViewBoard file system with a PC or mobile equipment. 1. Go to: Settings > Share > SAMBA. 2. Tap the toggle button to enable the SAMBA Service, then set a password if needed. - Page 55 5. Key in the user name and password, then select OK (if applicable). 6. After a successful log in, the ViewBoard files will be available.
-
Page 56: Display
Display Adjust the Wallpaper, Theme, Display ID, Protection, and HDMI Out settings. - Page 57 Wallpaper Users can change their wallpaper with default images (both still and live), or use their own by tapping My Photo and selecting the image file.
- Page 58 Protection Toggle HDCP & Copyright and set a Password for Screen Lock. • To set up a password for screen lock, tap Set Password and enter the desired password.
- Page 59 HDMI Out Adjust the HDMI Out Resolution setting and mute/unmute the display speaker when connected via HDMI Out. NOTE: The mute/unmute option box is unchecked by default.
-
Page 60: Preference
Preference View and adjust Touch, Language, Keyboard & Input, Date & Time, Boot Mode & Advanced, Start up & Shut down, and Toolbar settings. - Page 61 Touch Adjust Touch Settings and toggle Touch Sounds and Windows Ink On/Off. Language Adjust and choose the preferred language from the available languages.
- Page 62 Keyboard & Input Method Enable/disable the visual keyboard and/or change the default input method. • Tap on Settings to adjust the advanced keyboard settings.
- Page 63 Date & Time Set the system time and format. Item Description Automatic Date & When enabled, the ViewBoard will automatically synchronize Time the date and time via the Internet. Time Zone Select the appropriate time zone. Choose from 12-hour or 24-hour time format. Simply toggle 24- Time Format hour format On/Off.
- Page 64 Boot Mode Adjust the preferred boot up mode and set/reset a password. Item Description Normal Mode The embedded screen sharing Apps will run normally. Secured Mode The embedded screen sharing Apps will be removed. The system will automatically reboot, and then the Disable Embedded OS Embedded OS will not appear.
- Page 65 Startup & Shutdown Set the Startup Input, Standby Mode, EnergyStar Mode, Black Screen After Startup, Power off Reminder timer and Schedule settings. Item Description Startup Input Adjust the Startup Input preference. Display Setting when Decide what happens to the display when there is no signal for No Signal HDMI, PC, or VGA sources.
- Page 66 Item Description Black Screen After When enabled, the ViewBoard will turn off the backlight Startup automatically after booting up. Time Switch When enabled, the ViewBoard will turn off without any reminder after the scheduled off time. Power Off Reminder Schedule Schedule a Boot and Shut off time.
-
Page 67: Input Source
Input Source Adjust the input source names and settings, as well as the side toolbar settings. - Page 68 Rename Input Source Set labels for each input source that will be easily recognized when displayed.
- Page 69 Source Toggle Wake up by active source, Signal auto search, and HDMI CEC and select Input port auto switch. Item Description Wake up by Active The screen will turn on automatically after plugging in an Source HDMI cable when the screen is off. When enabled, if the current source does not have a signal, Signal Auto Search the ViewBoard will automatically search for an input source.
-
Page 70: App
The user can view application information and force stop, uninstall, move to USB storage, clear data, clear cache, and clear defaults. NOTE: • Pre-loaded apps cannot be uninstalled. • Not all apps support the move to USB storage feature. • Not all apps support Clear Defaults. - Page 71 View any running or installed applications. Tap on them for more detailed information and options. • By tapping on a running application, you can see more information, stop, or report the application.
- Page 72 • Selecting All, Download, or USB storage will list all installed applications. • Tapping on any application will display further information and options.
-
Page 73: System
System View and adjust Clone to USB, Display ID, Security, System Update, and About device settings. - Page 74 Clone to USB Copy settings to an external USB drive.
- Page 75 Display ID Assign a number to remote control the display by RS-232/LAN. • To assign or change the Display ID, tap Change and input a number. NOTE: The Display ID is for RS-232 users, and the range is 01~99.
- Page 76 Security Review Certificate, Trusted Credential storage, and Unknown sources install settings. • Tap on Install certificate from storage to add additional certificates.
- Page 77 • Selecting Clear Credentials will remove all manually installed credentials. NOTE: Pre-loaded credentials cannot be cleared. • Under Trusted Credentials view and edit all trusted and installed CA certificates. • Tapping on a credential will provide more detailed information.
- Page 78 • Allow the installation of applications from unknown sources by selecting the box under Unknown source security. NOTE: Applications from unknown sources may not be compatible or work properly.
- Page 79 System Update The ViewBoard automatically searches for software updates whenever connected to the Internet (OTA). With just one click, users can update their version of ViewBoard software. Item Description When the display is off, the system will automatically check for a new version. If a new version is found, the system will Auto Update automatically update.
- Page 80 About Device Display Embedded Player information, Legal information, and Asset Tagging. • By selecting Edit, the asset information can be adjusted. • Tap on Legal information to check open source licenses.
-
Page 81: Embedded Applications And Settings
Embedded Applications and Settings Air Class Display quiz questions on the ViewBoard and allow up to 30 mobile users to submit answers remotely. Whether deploying single or multiple choice questions, the ViewBoard will record the results for each device being used. Network Information •... - Page 82 To launch Air Class: 1. Tap the tool bar trigger icon and select the more tools icon. Then select the Air Class icon. 2. Select Enter the class. 3. Choose from the available interactive functions at the bottom of the screen. Item Description Voter...
-
Page 83: Voter
Voter 1. Select the Single choice or Multiple choice icon to choose the preferred answer type. 2. Tap BEGIN VOTING to let the Participants start. 3. After the Participants are finished and press OK, the ViewBoard will show the Participant‘s name on screen. 4. - Page 84 6. Choose the right answer to show the correct rate. 7. Click the Explain icon ( ) to further analyze the topic.
-
Page 85: Judge
Judge 1. Tap BEGIN VOTING to let the Participants start a True/False questionnaire. 2. After the Participants are finished and press OK, the ViewBoard will show the Participant‘s name on screen. 3. Tap FINISH VOTING to close the quiz. 4. Then the Participants’ “Answer Statistics” will be displayed. - Page 86 5. Choose the right answer to show the correct rate. 6. Click the Explain icon ( ) to further analyze the topic.
-
Page 87: Responder
Responder Participants race to select their answer and tap OK to submit their answer. -
Page 88: Selector
Selector 1. Select the “Selector’ icon. 2. Set the number of Participants to be selected. NOTE: The number of Participants that can be selected will be based on the total number of Participants. 3. Tap START to start the random selection. 4. -
Page 89: Grouping
Grouping Select the icon to assign Participants to groups. Message To allow messaging: 1. Tap the “Message” icon to enable the function. 2. Participants select Message to change to the message interface. 3. Participants key in their message then select SEND. 4. -
Page 90: Myviewboard Display
myViewBoard Display Wirelessly mirror screens to a larger display. To share a screen to a ViewBoard with myViewBoard Display: 1. Open myViewBoard Display on the ViewBoard you want to share your screen to. 2. On the device you want to share the screen from, go to: https://myviewboard. -
Page 91: Myviewboard Live
myViewBoard Live Stream whiteboarding sessions. A Stream URL and a Stream Key are needed to begin live streaming. The Stream URL is automatically shown after selecting the streaming service in myViewBoard Live. NOTE: The Stream Key will come from the streaming service chosen. On myViewBoard Live: 1. -
Page 92: Myviewboard Manager
Manager Remotely manage multiple installations of ViewSonic devices. Once devices are set up and have myViewBoard Manager installed, they can be added to the entity and managed remotely from the Manager web application. NOTE: Only available to Entity Admins from myviewboard.com after signing in. -
Page 93: Myviewboard Record
myViewBoard Record Capture everything that is displayed on screen in a video format. To launch the screen recording application: 1. Select the myViewBoard Record icon in the application drawer. 2. Select the preferred recording configurations. 3. Tap the check mark and a three (3) second countdown will begin. Screen recording will begin immediately after the countdown. -
Page 94: Myviewboard Whiteboard
myViewBoard Whiteboard A digital whiteboarding application. NOTE: To learn more about myViewBoard Whiteboard, visit: https://wiki. myviewboard.com/Whiteboard_for_Android. Floating Toolbar Item Description Move Move the Floating Toolbar. Present Mode Switch between presentation and preparation modes. Paste from Insert the current clipboard content onto the canvas. Clipboard Go to the previous page (if the canvas has multiple Previous Page... - Page 95 Main Toolbar Item Description Screen Screenshot, video, and audio recording. Capture Select and hold to move the toolbar to the left side, right Move side, or bottom of the screen. File Open, save, export, and print whiteboard files. Import resources (image, video, audio, etc.) to the Magic Box whiteboard.
- Page 96 Background Management Item Description Sign In Sign in to a myViewBoard account. Background Change the canvas background. Management FollowMe Display custom images uploaded to a cloud storage Setting account. Color Palette Choose from solid or gradient colors as the background. Choose backgrounds that come pre-installed with Pre-installed Whiteboard.
-
Page 97: Viewboard Cast
ViewBoard Cast Working with ViewBoard® Cast software, the vCastReceiver application, will allow the ViewBoard® to receive vCastSender laptop screens (Windows/Mac/ Chrome) and mobile (iOS/Android) users’ screens, photos, videos, annotations, and camera(s). Network Information • ViewBoard® Cast software, laptops, and mobile devices can connect to both the same subnet and across the subnet network. -
Page 98: Cast Sender From Windows-Based, Macbook, And Chrome Devices
Cast Sender from Windows-based, Macbook, and Chrome devices. Mac, Windows, Chrome Devices: 1. Make sure your device is connected to the same network as the ViewBoard. 2. Visit the address that is shown on the ViewBoard to download the application. 3. -
Page 99: Cast Sender From Mobile Devices: Ios-Based (Iphone, Ipad) And Android Os Based Phone/Tablet
Cast Sender from Mobile Devices: iOS-based (iPhone, iPad) and Android OS based phone/tablet. Android/iOS: 1. Make sure your device is connected to the same network as the ViewBoard. 2. Scan the QR Code that is shown on the ViewBoard to download directly from the server, or download from the Google Play Store or the Apple Store. -
Page 100: Cast Out From A Mobile Device That Supports Annotation
Cast Out from a Mobile Device that Supports Annotation Item Description Toggle Hide or display the toolbar. Home Return to the Home interface. Return Return to the previous operation interface. Folder View or open the mobile device’s internal file. Screen Share the screen. -
Page 101: Other Default Applications
Other Default Applications Chromium Web browser for surfing the Internet. -
Page 102: Folders
Folders 1. Storage Device Display Select the appropriate storage device. 2. Icons Item Description Exit Exit Folders Sort Sort the files Thumbnail Display files by thumbnail view List Display files by list view Select Select a file Add folder Add a folder Copy Copy a file Paste... - Page 103 3. File Type Menu Item Description All types Office files Images stored by myViewBoard, Side Tool Note Bar, and remote control Screen Capture button. Picture Image files Media Audio and Video files 4. File Information Preview the file, show the file’s name, size, resolution, and creation date. 5.
-
Page 104: Officesuite
OfficeSuite Create, edit, and view Documents, Spreadsheets, Presentations, and PDFs. - Page 105 Screen Lock Set a screen lock password and enable screen lock. NOTE: If the user forgets the password, use the remote control and press INPUT-0-2-1-4 to restore the password to default. To set a screen lock password: 1. Go to: Settings > Display > Password for screen lock, or select the Screen Lock icon in the applications list.
-
Page 106: Vsweeper
vSweeper Clear unnecessary data and unwanted files. Advanced Settings can also be customized to the user’s needs. -
Page 107: Rs-232 Protocol
RS-232 Protocol This document describes the hardware interface spec and software protocols of RS232 interface communication between ViewSonic LFD and PC or other control units with RS232 protocol. The protocol contains three command sections: • Set-Function • Get-Function • Remote control pass-through mode NOTE: ... -
Page 108: Lan Hardware Specification
LAN Hardware Specification ViewSonic LFD communication port on the rear side: 1. Connector type: 8P8C RJ45 2. Pin Assignment: Pin # Signal Remark Output from Display Output from Display Input to Display BI_D3+ For 1G case BI_D3- For 1G case... -
Page 109: Protocol
Protocol Set-Function Listing The PC can control the Display for specific actions. The Set-Function command allows you to control the Display behavior at a remote site through the RS232 port. The Set-Function packet format consists of 9 bytes. Set-Function Description: Length: Total Byte of Message excluding “CR”... - Page 110 Example 1: Set Brightness as 76 for Display (#02) and this command is valid Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38 0x73 0x24 0x30 0x37 0x36 0x0D 0x32 Reply (Hex Format) Name Length Command Type 0x30 0x34 0x2B...
- Page 111 Set-Function Table A. Basic Function Set Function Length ID Command Command Value Range Comments Code Code (Three ASCII Type (ASCII) (ASCII) (Hex) bytes) 1. The Power-on via LAN control may works only under specific mode. To Power on/ off 000: STBY see display UG for (standby) 001: ON...
- Page 112 000: Unlock Button lock *See note in details 001: Lock 000: Unlock Menu lock > *See note in details 001: Lock Number 000~009 *3.1.1 000: UP 001: DOWN 002: LEFT 003: RIGHT Key Pad *3.1.1 004: ENTER 005: INPUT 006: MENU/(EXIT) 007: EXIT Disable: RCU will be no function...
- Page 113 B. Optional Function Set Function Length ID Command Command Value Range Comments Code Type (ASCII) Code (Hex) (Three ASCII bytes) (ASCII) Contrast 000 ~ 100 Sharpness 000 ~ 100 Color & 000 ~ 100 Tint ‘ 000 ~ 100 000: Off Backlight On_Off 001: On 000: Normal...
- Page 114 000: OFF Tiling-Mode 001: ON (for video wall) 000: OFF (for video wall) Tiling-Compen- 001: ON Bezel width com- sation pensation (for video wall) 01x~09x: H 1. 2nd digital for H Tiling-H by V 0x1~0x9: V monitors Monitors 2. 3rd digital for V monitors (for Video wall) Copy the screen...
-
Page 115: Get-Function Listing
Get-Function Listing The PC can interrogate the LFD for specific information. The Get-Function packet format consists of 9 bytes which is similar to the Set-Function packet structure. Note that the “Value” byte is always = 000. Get-Function Description: Length: Total Byte of Message excluding “CR”. TV/DS ID Identification for each of TV/DS (01~98;... - Page 116 Example 1: Get Brightness from TV-05 and this command is valid. The Brightness value is 67. Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38 0x67 0x62 0x30 0x30 0x30 0x0D 0x35 Reply (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x30 0x38...
- Page 117 Get-Function Table A. Basic Function Response Get Function Length ID Command Command Comments Range Code Code (Three ASCII Type (ASCII) (ASCII) (Hex) bytes) Get-Brightness 000 ~ 100 1. For Android platform whose main mode is controlled by backlight and the other sources are 000 ~ 100 Get-Backlight...
- Page 118 (for the model with LAN) Get-MAC address Reply in new 32-byte format *3.2.0 (for the model with LAN) Get-IP address *3.2.0 Reply in new 32-byte format*3.2.0 Reply in new 32-byte Get-Serial number format *3.2.0 *3.2.0 Reply in new 32-byte Get-FW version *3.2.0 format *3.2.0 NOTE: ...
- Page 119 6. Get FW version example Assumed the FW version is 3.02.001 Send: 0x 38 30 31 67 38 30 30 30 0D (Get FW version) Reply: 0x 32 30 31 72 38 33 2E 30 32 2E 30 30 31 00 00…00 00 0D...
- Page 120 B. Optional Function Response Get Function Length ID Command Command Comments Range Code Type (ASCII) Code (Hex) (Three ASCII bytes) (ASCII) Get-Contrast 000 ~ 100 Get-Sharpness 000 ~ 100 Get-Color 000 ~ 100 Get-Tint 000 ~ 100 000: Off Get-Backlight 001: On On_Off 000: OFF...
- Page 121 2. Get Time example Assumed the current time of display#01 as below: Time: 16:27:59 Send: 0x 38 30 31 67 33 48 30 30 0D (Get Time:Hour) Reply: 0x 38 30 31 72 33 48 31 36 0D (“H16”) Send: 0x 38 30 31 67 33 4D 30 30 0D (Get Time:Min) Reply: 0x 38 30 31 72 33 4D 32 37 0D (“M27”)
- Page 122 C. Auto Reply *3.2.1 The display will send out the updated data/status automatically without getting a query from the host whenever the following data/status is changed by the user through any of the available ways like: remote control unit, front keys, or touch screen.
-
Page 123: Remote Control Pass-Through Mode
Remote Control Pass-through Mode When the PC sets the Display to Remote Control Pass through mode, the Display shall send a 7-byte packet (followed by “CR”) in response to remote control unit (RCU) button activation. In this mode the remote control shall have no effect on the Display function. - Page 124 VOLUME DOWN (-) MUTE CHANNEL/PAGE UP (+)/ BRIGHTNESS+ CHANNEL/PAGE DOWN (-)/ BRIGHTNESS- POWER SOURCES (INPUTS) SLEEP MENU DOWN LEFT (-) RIGHT (+) OK (ENTER, SET) EXIT (F1) ■ GREEN (F2) ■ YELLOW (F3) ■ BLUE (F4) ■ NOTE: This IR-pass-through code is different from the RCU key code. Special control sequence for POWER key under IR-pass through mode.
- Page 125 2-2. When Display is ON and receives the IR POWER code: Display will forward the POWER code to the host via RS232, then turn off itself. 2-3. When SET-POWER LOCK is enabled, the Display will not respond to POWER key pressing. The VOLUME UP and VOLUME DOWN code will repeatedly output when you press and hold the keys.
-
Page 126: Appendix
Appendix Specifications Item Category Specifications Model IFP6562 IFP7562 IFP8662 Screen Size 64.5” 74.5” 85.6” 4 x HDMI (v. 2.0) 1 x USB Type C (DP v. 1.4; PD 65W; 100M Ethernet) 1 x VGA Input Signal 1 x Audio In 1 x USB Type A (2.0) 5 x USB Type A (3.0) 1 x HDMI... -
Page 127: Display Modes
Display Modes VGA Mode Resolution Refresh Rate (@) 640 x 480 60Hz, 72Hz, 75Hz 720 x 400 70Hz 800 x 600 56Hz, 60Hz, 72Hz, 75Hz 832 x 624 75Hz 1024 x 768 60Hz, 70Hz, 75Hz 1152 x 864 60Hz, 75Hz 1152 x 870 75Hz 1280 x 768... -
Page 128: Troubleshooting
Troubleshooting This section describes some common problems that you may experience when using the ViewBoard. Problem or Issue Possible Solutions 1. Check whether something is obstructing the display’s remote control receiver. Remote Control is not 2. Check whether the batteries in the remote control working are installed correctly. - Page 129 Touch Function Problem or Issue Possible Solutions 1. Check that drivers are installed correctly. 2. Reinstall driver(s). Touch function does not work 3. Check setup and align it. 4. Check whether the touch pen is working properly. Video Not Working Properly Problem or Issue Possible Solutions 1.
-
Page 130: Maintenance
Some chemical cleaners have been reported to damage the screen and/or case of the device. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. NOTE: If condensation appears between the glass and the panel, keep the... -
Page 131: Regulatory And Service Information
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 132: Declaration Of Rohs2 Compliance
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law. -
Page 133: Energy Star Statement
U.S. Environmental Protection Agency. As an ENERGY STAR Partner, ViewSonic is determined to meet the Energy star Guidelines and mark all certified models with the ENERGY STAR logo. -
Page 134: Copyright Information
VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 135: Customer Service
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn 香港 (繁體中文) www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/... -
Page 136: Limited Warranty
ViewSonic® Smart White Board What the warranty covers: ViewSonic® warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, and as your sole remedy, repair or replace the product with a similar product. - Page 137 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
- Page 138 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
-
Page 139: Mexico Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &... - Page 140 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
- Page 141 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
