IFP70 Series
Commercial Touch Display
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website. "Antes de operar su equipo lea cu idadosamente las instrucciones en este manual"
migliori offerte di Monitor LCD
Model No. VS17729/VS17710
P/N: IFP6570/IFP8670
ViewSonic IFP8670

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic VS17729

Summary of Contents for ViewSonic VS17729

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
  • Page 2 As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.

  • Page 3: Safety Precautions

    Do not place any heavy objects on the device or connection cables. • If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •...
  • Page 4 • Only use attachments/accessories specified by the manufacturer. • When a cart is used, use with caution when moving the cart/equipment combination to avoid injury from tipping over. • Disconnect the power plug from the AC outlet if the device is not being used for a long period of time.

  • Page 5: Table Of Contents

    Contents Safety Precautions ............3 Introduction .............. 10 Package Contents ....................10 Wall Mount Kit Specifications (VESA) ..............11 Product Overview ....................12 Control Panel ......................12 I/O Panel ........................ 14 Smart Pen and Charger ..................16 Charger ......................16 Button Functions of the Smart Pen ..............16 Charging ......................
  • Page 6 Using Your ViewBoard ..........34 Powering On/Off your ViewBoard ................34 Initial Launch Setup ....................35 vLauncher - Customizable Welcome Screen............37 Tool Bar ........................38 ViewBoard On-Screen Display (OSD) Menu ............44 General Settings ....................45 Detailed Settings ....................47 Audio Settings ....................47 Screen Settings ....................
  • Page 7 Startup Channel ..................67 Built-in PC Startup Option ................. 67 Standby Mode ................... 68 Black Screen After Startup ................. 69 Close Power Off Reminder ................ 69 Password for Screen Lock ................70 Input Setting ....................71 Input Alias Switch ..................71 Wake on Active Source ................
  • Page 8 Embedded Applications and Settings ......85 Embedded Digital Whiteboard App ..............85 myViewBoard ......................85 Floating Bar ....................... 85 Toolbar ......................85 ViewBoard Cast ....................87 Cast Sender from Windows-based Devices, Macbook, and Chrome devices..88 Cast Sender from Mobile Devices: iOS-based (iPhone, iPad) and Android OS based phone/tablet.
  • Page 9 RS-232 Protocol ............109 Description ......................109 RS-232 Hardware Specification ................109 LAN Hardware Specification ................110 RS232 Communication Setting ................110 LAN Communication Setting ................110 Command Message Reference ................110 Protocol ......................111 Set-Function Listing ..................... 111 Get-Function Listing .................... 117 Remote Control Pass-through Mode ..............

  • Page 10: Introduction

    • Smart Pen Charger & Receiver • Screw x 6 • Sensor hub • USB cable (3m) ViewSonic Corporation (US/Canada/Latin America) : www.viewsonic.com/support/product-registration : 14035 Pipeline Ave. Chino, CA 91710, USA : 909-468-1240 United States Latin America 1-800-688-6688 http://www.viewsonic.com/la/ service.us@viewsonic.com soporte@viewsonic.com...

  • Page 11: Wall Mount Kit Specifications (Vesa)

    Wall Mount Kit Specifications (VTSA) NOTE: Please follow the instructions in the wall mount installation guide to install your wall mount or mobile mount bracket. If attaching to other building materials, please contact your nearest dealer. Model VTSA Spec. (A x B) Standard Screw (C x D) Quantity IFP6570 - 65”...

  • Page 12: Product Overview

    Product Overview Control Panel...
  • Page 13 Number Item Description Sensor hub to monitor temperature, humidity, luminosity, and PIR (motion sensor) Camera Microphone Smart Pen and Charger Windows button Source select Decrease the Volume Increase the Volume Speaker Mute Microphone Mute Turn on/off the device Tap to enter Energy Saving mode Press and hold for at least two (2) seconds to enter Standby mode Remote control receiver...

  • Page 14: I/O Panel

    I/O Panel Lower Right Side DP IN Bottom Right Bottom Left...
  • Page 15 Number Port Description Charging support up to 60W, OTG, data transmission, USB Type-C network signal output, and an extension for audio and video. Connect to devices with HDMI input function. HDMI OUT High definition input; connect to PC with HDMI HDMI IN output, set-top box, or other video device.

  • Page 16: Smart Pen And Charger

    Smart Pen and Charger Charger The charger is magnetically attached to the lower right side of the ViewBoard. Connect the charger to the USB 3.0 port on the side of the panel. Button Functions of the Smart Pen Number Description Eraser Previous Page Next Page...

  • Page 17: Charging

    Pairing/Unpairing To pair/unpair the Smart Pen with the ViewBoard: 1. Go to: Settings > Personal > Smart Pen Setting. 2. To Pair: Press the 2 and 4 button on the Smart Pen at the same time. The LED indicator will go from solid white to flashing orange, and finally off when paired. 3.

  • Page 18: Sensor Hub

    Sensor Hub Once installed, and WCD mode is activated, the sensor hub will collect environmental data (Temperature, Humidity, luminosity, and PIR) and display it on- screen. Installation To install the sensor hub: 1. Insert the prongs on the bottom of the sensor into the top, upper left of the ViewBoard.
  • Page 19 3. When WCD mode is turned on, the environmental data will be displayed on- screen. 4. Touching the environmental data will launch a more detailed overview of the collected data. NOTE: When powered off/the backlight is off (standby mode), if the PIR sensors detect movement after standing by for 20 seconds it will turn on automatically.

  • Page 20: Camera

    Camera The camera is magnetically attached to the top middle of the ViewBoard. Connect the camera to the USB 3.0 port on the side of the panel as shown below. NOTE: A USB cable of at least two (2) meters should be used.

  • Page 21: Remote Control

    Remote Control...
  • Page 22 Number Item Description Power on/off Mute/Unmute SLEEP Sleep Mode DISPLAY For Non-Android sources; display current input source information P.MODE Blank Screen S.MODE Freeze Screen Numeric input buttons ALT+TAB Slot-in computer space bar Alt+Tab -/-- ALT+F4 Slot-in computer, close program window INPUT Input source selection ASPECT...
  • Page 23 Number Item Description EPG/BACK Return button FAV/SPACE PC [Space] button CH.+/PGUP/ CH+: PC previous page CH.-/PGDN CH-: PC next page VOL+/VOL- Increase/Decrease volume F1-F12 Built-in computer F1 - F12 function button NOTE: All computer-related function keys are not available without a slot-in computer.
  • Page 24 Inserting Remote Control Batteries To insert batteries into the remote control: 1. Remove the cover on the rear of the remote control. 2. Insert two “AAA” batteries, ensuring the “+” symbol on the battery matches the “+” on the battery post. 3.
  • Page 25 Remote Control Receiver Range The working range of the remote control is shown here. It has an effective range of ° 8 meters, 30 degrees left and right. Ensure there is nothing obstructing the remote control’s signal to the receiver.

  • Page 26: Using Gestures

    Using Gestures Touch gestures allow the user to use pre-determined commands without using a keyboard or mouse. Using gestures on the ViewBoard, the user can select/deselect objects, change the location of an object, access settings, erase digital ink, and much more. Select and Deselect an Nbject (Clicking) Press and release the ViewBoard to select/deselect options or objects.

  • Page 27: Moving An Object

    Moving an Object Press and hold the object on the ViewBoard and slowly drag it with your finger to your desired location. Erasing Digital Ink Use your flattened hand, palm, or fist on the ViewBoard and move your hand across the area which you wish to erase. Swipe Up for Neneral Settings Swipe up from the bottom of the ViewBoard to launch the General...

  • Page 28: Making Connections

    Making Connections Connecting Txternal Devices and Oouch Connection Your external device(s) can be connected in any of the following configurations: Oype C Connection To connect via Type C: 1. Connect a Type C cable from your external device to the Type C port on the ViewBoard.

  • Page 29: Rs-232 Connection

    RS-232 Connection When you use a RS-232 serial port cable to connect your display to an external computer certain functions can be controlled remotely by the PC, including Power On/Off, Volume adjustment, Input select, Brightness, and more.

  • Page 30: Usb And Networking Connections

    USB and etworking Connections Just like any PC, it is easy to connect various USB devices and other peripherals to your ViewBoard. USB Peripherals Plug the USB device cable into the USB port. Networking and Modem cables Plug the router cable into the LAN port.

  • Page 31: Media Player Connection

    Media Player Connection To connect to a media player: 1. Connect the HDMI cable to the HDMI ports on your ViewBoard and peripheral device. Plug in the power cord of your ViewBoard, and turn on the power supply switch. Press the Power button on the right-hand side of the ViewBoard to turn the screen on.

  • Page 32: Spdif Connection

    SPDIF Connection To connect to an external sound system: 1. Connect an optical cable from the SPDIF port to your sound system’s optical connector. Plug in the power cord of your ViewBoard, and turn on the rear-panel power supply switch. Power button on the right-hand side of the ViewBoard to turn the Press the screen on.

  • Page 33: Video Output Connection

    Video Nutput Connection To output video via a display device: 1. Connect an HDMI cable to the HDMI IN port of your display device, and the other end to the HDMI OUT port of your ViewBoard. Plug in the power cord of your ViewBoard, and turn on the power supply switch. Power button on the right-hand side of the ViewBoard to turn the Press the screen on.

  • Page 34: Using Your Viewboard

    Using Your ViewBoard Powering Nn/Nff your ViewBoard 1. Ensure the power cord is connected, plugged into a power outlet, and the power switch is in the “On” position. The AC Power input and switch are located at the bottom of the unit. 2.

  • Page 35: Initial Launch Setup

    Initial Launch Setup When you first turn on your ViewBoard, an initial setup wizard will launch. 1. Select your Language: 2. Setup and verify your LAN connection: 35 35...
  • Page 36 3. Select your Time Zone to set the Date and Time: 4. Select your preferred System Mode: 5. Select your preferred vLauncher mode: 36 36...

  • Page 37: Vlauncher - Customizable Welcome Screen

    vLauncher - Customizable Welcome Screen Icon Description myViewBoard annotation application Wireless screen sharing application, vCastReceiver Switch to slot-in PC source Open web browser Open cloud meeting Application list NOTE: ViewBoard offers two background themes, Corporate and Education. 37 37...

  • Page 38: Tool Bar

    Tool Bar Tool bar trigger icons are on the edge of the ViewBoard launcher providing access to your tools. To launch a tool: 1. Tap a Tool bar trigger icon. 2. Tap on your desired tool icon. NOTE: The default tool bar setting is to be available for all input sources; however, users can go to: Settings >...
  • Page 39 Description Icon Return to the previous operation screen NOTE: Only for the Embed Player source Return to the home screen of the Embedded Player Display all embedded applications that are being used Launch the myViewBoard software 39 39...
  • Page 40 Description Icon Access the pen, highlighter, clear, and save options 1. Digital Pen Annotate the overlay of any input source with red, black, blue, or green ink. NOTE: The default digital pen setting supports up to 10-point writing. 2. Digital Highlighter Mark and highlight with four colors: yellow, orange, blue, and green.
  • Page 41 Description Icon Convert the currently displayed content into a still image; then you can zoom in or zoom out NOTE: The ViewBoard will take a few seconds to reduce the screen resolution to 1080p. 1. Zoom In Enlarge the captured image. NOTE: The screen resolution will be reduced after zooming in.
  • Page 42 Description Icon Countdown Access the countdown timer with an optional alarm setting. Touch and swipe to adjust the numeric values, then click Start. At any time, the countdown timer can be paused, resumed, or reset. The timer will reduce in size and move to the lower-center of the screen automatically when the user touches another area.
  • Page 43 Description Icon Stopwatch Tapping Start will initiate the stopwatch. At any time, the stopwatch can be paused, resumed, split, or reset. The stopwatch will reduce in size and move to the lower-center of the screen automatically when the user touches another area. Touching the stopwatch again will return it to its normal size and original location.

  • Page 44: Viewboard On-Screen Display (Osd) Menu

    ViewBoard Nn-Screen Display (NSD) Menu ViewBoard has two options for opening the OSD Menu: Nption 1 Swipe up from the bottom of the screen. Nption 2 Press the INPUT button on the remote control. 44 44...

  • Page 45: General Settings

    Neneral Settings To select an Input Source: Press INPUT on the remote control to display the General Setting menu, then press to enter the Input Source menu. Press to select the input source you want. q/p/t/u Press ENTER on the remote control, or touch the input source. Press EPG/BACK on the remote control, or touch a blank area outside of the menu to exit.
  • Page 46 To adjust the Volume: Press INPUT on the remote control to display the General Setting menu. Drag the volume slider directly to adjust the value. (Mute) Press on the remote control to enable or disable the mute function. Press EPG/BACK on the remote control, or touch a blank area outside of the menu to exit.

  • Page 47: Detailed Settings

    Detailed Settings Press MENU on the remote control or select the icon on the General Setting menu to launch the Detailed Settings menu. Detailed Settings include: Audio, Screen, and Display. NOTE: For non-Android inputs only. Audio Settings 1. Press u on the remote control and select the Audio menu. 2.

  • Page 48: Screen Settings

    Screen Settings 1. Press u on the remote control and select the Screen menu. 2. Press q/p/t/u on the remote control or directly touch the option to select it. 3. Adjust your preference by touching each value directly, or with the remote control by pressing ENTER.

  • Page 49: Display Settings

    Display Settings 1. Press u on the remote control and select the Display menu. 2. Press q/p/t/u on the remote control or directly touch the option to select it. 3. Adjust the Brightness, Contrast, Hue, and Sharpness directly by touching and adjusting each value, or with the remote control by pressing ENTER and using t/u to adjust the option.

  • Page 50: Advanced Settings

    Advanced Settings When the ViewBoard is in the Embed Player source, tap the icon in the On- Screen Display (OSD) Menu to enter the Advanced Settings Menu. Wireless & Networks Check current network connection status, Wi-Fi, BT, and establish a Wireless hotspot.

  • Page 51: Wi-Fi

    Wi-Fi Tap On to toggle Wi-Fi on or off. Tap the settings icon to: Add Network, view Saved Networks, Refresh the network list, or view Advanced settings. In Advanced settings, you can set Proxy and IP settings. 51 51...

  • Page 52: Ethernet

    Ethernet Tap On to toggle Ethernet on or off. You can adjust Static IP and Proxy settings as well. Tap the setting icon to view Advanced settings. 52 52...

  • Page 53: Hotspot & Tethering

    Hotspot & Tethering Tap Portable Wi-Fi hotspot to turn it on or off. Tap Set up Wi-Fi hotspot to set Network name, Security, and Password. 53 53...
  • Page 54 Tap On to toggle BT on or off. Once On, select a listed device to pair and connect to. Tap the more settings icon to: Refresh, Rename the device, and Show received files. 54 54...

  • Page 55: Vpn

    To create a VPN profile: 1. Go to: Settings > Wireless & networks > More > VPN and tap the “+” icon to add a VPN. 2. Key in the desired name. 55 55...
  • Page 56 3. Select the VPN Type. 4. Choose to enable/disable PPP encryption (MPPE) and/or show advanced options. 56 56...

  • Page 57: Share

    Share The SAMBA Service provides file sharing via LAN. When the SAMBA Service is enabled, the user can explore the ViewBoard file system with a PC or mobile equipment. To access, go to: Settings > Share > SAMBA Service. 1. Tap the box or name to enable the SAMBA Service, then set a password if needed.
  • Page 58 4. Key in the user name and password, then select OK (if necessary). 5. After a successful log in, the ViewBoard files will be available. 58 58...

  • Page 59: Device

    Device Adjust the Theme, Display, Storage, and Sound settings. Theme Users can change their home launcher theme. NOTE: vLauncher cannot be removed. Display Adjust the Wallpaper, HDMI Out Encryption setting, and Burn-in Protection Interval. 59 59...

  • Page 60: Wallpaper

    Wallpaper Users can change their wallpaper with default images, or use their own by tapping My photos and selecting the image file. 60 60...

  • Page 61: Hdmi Out Resolution Setting

    HDMI Nut Resolution Setting Users can adjust their HDMI Out resolution preference. 61 61...

  • Page 62: Burn-In Protection Interval

    Burn-in Protection Interval This setting allows the user to program the time between movements of the picture in minutes. NOTE: Burn-in Protection must be enabled in the OSD Menu first. Storage Users can check the storage status of their ViewBoard. Sound Users can enable/disable touch sounds, and adjust output settings.

  • Page 63: Personal

    Personal View and adjust Security, Startup & Shutdown, Language & Input, Smart Pen Setting, Password for screen lock, Input Setting, and Other Settings. Security Review Credential storage and Unknown sources install settings. Orusted Credentials Show and edit all trusted CA certificates that have been installed on the ViewBoard. 63 63...

  • Page 64: Clear Credentials

    Clear Credentials Clear any previously installed credentials. NOTE: Pre-loaded credentials cannot be cleared. Unknown Sources Enable the installation of apps from unknown sources. NOTE: Apps from unknown sources may not be compatible or work properly. 64 64...

  • Page 65: Language & Input

    Language & Input Adjust the Language and Input method(s) of the Embedded Player. Languages Choose from the available languages. 65 65...

  • Page 66: Current Keyboard

    Current Keyboard Enable/disable the virtual keyboard and/or change the default input method. Virtual Keyboard View and adjust advanced entry settings. Physical Keyboard View and adjust advanced entry settings. 66 66...

  • Page 67: Startup And Shutdown

    Startup and Shutdown Set the Startup Channel, Standby Mode, Black Screen After Startup, and adjust Timer settings. Startup Channel Adjust the startup channel preference. Built-in PC Startup Nption Adjust the slot-in PC startup preference. NOTE: Only available when the slot-in PC is connected. 67 67...

  • Page 68: Standby Mode

    To enable Sleep mode: 1. The user needs to provide their ViewBoard’s serial number (S/N) to ViewSonic. The S/N label is located near the I/O side. 2. ViewSonic will then provide the KEY (FakePowerOff) file to the user.

  • Page 69: Black Screen After Startup

    Black Screen After Startup When enabled, the ViewBoard will turn off the backlight automatically after booting Close Power Nff Reminder When enabled, the ViewBoard will turn off the directory without any reminder after the scheduled off time. To add a task: 1.

  • Page 70: Password For Screen Lock

    Password for Screen Lock Set a screen lock password by selecting Set, inputting a password, and selecting OK. 70 70...

  • Page 71: Input Setting

    Input Setting Enable/disable Input Alias Switch, Wake on Active Source, Channel Auto Switch, Auto Search, and set No Signal Power off. Input Alias Switch Once enabled, the user can edit input aliases and when the Display button is pressed the source information (located in the upper left side) will also be changed. Users can also choose to “Display”...

  • Page 72: Wake On Active Source

    Wake on Active Source The ViewBoard will detect HDMI signals in Standby mode. If HDMI has a signal output, the ViewBoard will power on automatically. Auto Search When enabled, if the current source does not have a signal, the ViewBoard will automatically search the input sources one time.

  • Page 73: Other Settings

    Nther Settings Adjust Side Tool bar Channel and Eco Mode settings. Side Tool bar Channel Adjust the side tool bar availability. ECO Mode When enabled, the ViewBoard will turn off automatically after sixty (60) minutes of Embedded Player source being idle or after five (5) minutes of other input sources not having a signal.

  • Page 74: System

    System View and adjust Date & Time, System Settings, About Device, and Advanced Settings. Date & Time Set the system time and format. Automatic Date & Oime When enabled, the ViewBoard will automatically synchronize the date and time via the Internet. NOTE: Ethernet or Wi-Fi connection is needed.
  • Page 75 Set Date Adjust the values then select OK when finished. Set Time Adjust the values then select OK when finished. 75 75...
  • Page 76 Select Time Zone Choose from the available time zones. Select Time Format Choose from 12 hour and 24 hour time format. Simply toggle 24-hour format on/ off. Choose Date Format Select from the available date formats. 76 76...

  • Page 77: About Device

    About Device Display Embedded Player information, System Updates, Display ID Setting, and Asset Tag. System Update The ViewBoard automatically searches for software updates whenever connected to the Internet (OTA). With just one click, users can update their version of ViewBoard software. 77 77...
  • Page 78 Legal Information Check open source and System WebView licenses. Display ID Change the Display ID. NOTE: The Display ID is for RS-232 users, and the range is 01~98. Asset Tag Key in the asset information. 78 78...

  • Page 79: System Settings

    System Settings Adjust WCD, Wake on Active Source, Channel Auto Switch, and No Signal Power Off. When activated, WCD mode will display the environmental data (Temperature, Humidity, and PIR) on-screen. Wake Nn Active Source Toggle on/off. Channel Auto Switch Choose your preference. 79 79...
  • Page 80 o Signal Power Nff Select the time for power off. 80 80...

  • Page 81: Advanced

    Advanced Set the Mode, check Apps, modify Passwords, and enable/disable USB disk connection. Mode • Normal Mode: The embedded screen sharing apps will run normally. • Security Mode: The embedded screen sharing apps will be removed. • Disable Embedded OS: The system will automatically reboot, and then the Embedded OS will not appear.

  • Page 82: Applications

    Applications The user can view App information and force stop, uninstall, move to USB storage, clear data, clear cache, and clear defaults. NOTE: • Pre-loaded apps cannot be uninstalled. • Not all apps support the move to USB storage feature. •...
  • Page 83 3. Selecting the information icon ( ) will provide further options. 4. Select the right upper icon for additional options. 83 83...

  • Page 84: Advanced Mode Password

    Advanced Mode Password Modify the Advanced setting entry password. USB Disk Enable Enable/disable USB disk connection. Privacy Set the interval for local file storage access. ͫ Never: Local storage will be cleaned, and no longer able to save files. ͫ 1 Hour: Files saved to local storage will be deleted after 1 hour. ͫ...

  • Page 85: Embedded Applications And Settings

    Tmbedded Applications and Settings Embedded Digital Whiteboard App Within ViewBoard, ViewSonic offers the embedded digital whiteboarding app, myViewBoard. myViewBoard Floating Bar Move the Floating Bar. Switch between presentation and preparation modes. Paste from the clipboard onto the canvas. Click to open the web browser Go to the previous canvas.
  • Page 86 Text Box Creates a Text box. Undo Button Undo previous actions. Redo Button Redo previous actions. Page Toggle Select pages, sort pages, delete pages. Button Show or hide the current host information. Whiteboard background management menu. 86 86...

  • Page 87: Viewboard Cast

    ViewBoard Cast Working with ViewBoard® Cast software, the vCastReceiver app, will allow the ViewBoard® to receive vCastSender laptop screens (Windows/Mac/Chrome) and mobile (iOS/Android) users’ screens, photos, videos, annotations, and camera(s). etwork Information • ViewBoard® Cast software, laptops, and mobile devices can connect to both the same subnet and across the subnet network.

  • Page 88: Cast Sender From Windows-Based Devices, Macbook, And Chrome Devices

    Cast Sender from Windows-based Devices, Macbook, and Chrome devices. Mac, Windows, Chrome Devices: 1. Make sure your device is connected to the same network as the ViewBoard. 2. Visit the address that is shown on the ViewBoard to download the application. 3.

  • Page 89: Cast Sender From Mobile Devices: Ios-Based (Iphone, Ipad) And Android Os Based Phone/Tablet

    Cast Sender from Mobile DevicesE iNS-based (iPhone, iPad) and Android NS based phone/tablet. Android: 1. Make sure your device is connected to the same network as the ViewBoard. 2. Scan the QR Code that is shown on the ViewBoard, or key in the web address provided, to download the application.

  • Page 90: Cast Out From A Mobile Device That Supports Annotation

    Cast Nut from a Mobile Device that Supports Annotation Item Description Toggle Click to hide or display tool bar Home Click to return to home interface Return Click to return to previous operation interface Folder Click to view or open mobile device internal file Screen Click to share screen sharing...

  • Page 91: Air Class

    Air Class Display quiz questions on the ViewBoard and allow up to 30 mobile users to submit answers remotely. Whether deploying single or multiple choice questions, the ViewBoard will record the results for each device being used. etwork Information • PC (Windows/Mac/Chromebook) and tablet/mobile (iOS/Android) devices, as well as the ViewBoard need to be linked to the same LAN network subnet.
  • Page 92 To launch Air Class: 1. Tap the tool bar trigger icon and select the more tools icon ( ). Then select the Air Class icon ( 2. Select “Enter the class”. 3. Choose from the available interactive functions at the bottom of the screen. Item Description Voter...

  • Page 93: Voter

    Voter 1. Select the Single choice or Multiple choice icon to select the preferred answer type. 2. Tap BEGIN VOTING to let the participants start. 3. After the participants are finished and press OK, the ViewBoard will show the participant‘s name on screen. 4.
  • Page 94 6. Choose the right answer to show the correct rate. 7. Click the Explain icon ( ) to further analyze the topic. 94 94...

  • Page 95: Judge

    Judge 1. Tap BEGIN VOTING to let the participants start a True/False questionnaire. 2. After the participants are finished and press OK, the ViewBoard will show the participant‘s name on screen. 3. Tap FINISH VOTING to close the quiz. 4. Then the participants’ “Answer Statistics” will be displayed. 5.

  • Page 96: Responder

    6. Click the Explain icon ( ) to further analyze the topic. Responder Participants race to select their answer and tap OK to submit their answer. 96 96...

  • Page 97: Selector

    Selector 1. Select the “Selector’ icon. 2. Set the number of participants to be selected. NOTE: The number of participants that can be selected will be based on the total number of participants. 3. Tap START to start the random selection. 4.

  • Page 98: Message

    Message To allow messaging: 1. Tap the “Message” icon to enable the function. 2. Participants select “Message” to change to the message interface. 3. Participants key in their message then select SEND. 98 98...

  • Page 99: Manager

    4. The message will scroll across the top of the ViewBoard. Manager Select the icon to let more participants join the class. Exit Select to exit the Air Class interface. 99 99...

  • Page 100: Other Default Applications

    Nther Default Applications Zoom Select to launch the Zoom application for video conferencing. 1. Select Sign In. Enter your email and password or sign in with your Google, Facebook, or SSO account. 2. If you do not have a Zoom account, you will need to select Sign Up or Join a Meeting.

  • Page 101: Join A Meeting

    Join a Meeting 1. Select Join a Meeting. 2. Enter the Meeting ID of the meeting you want to join, and enter a name. 3. Select Join Meeting.

  • Page 102: Start An Instant Meeting

    Start an Instant Meeting 1. Once signed in, you can: Start, Join, or Schedule a meeting. 2. To start an instant meeting, select Start meeting. 3. Choose the meeting options: ͫ Choose to have Video On or Off. ͫ Choose to Use Personal Meeting ID (PMI) or a unique meeting ID. 4.
  • Page 103 6. Select Invite at the bottom of the Participants screen. 7. Choose participants by using the contact method you prefer.

  • Page 104: Vsweeper

    vSweeper Select the icon to clear unnecessary data and unwanted files. Advanced Settings can also be customized to the user’s needs.
  • Page 105 Screen Lock Select the icon to set a screen lock password and enable screen lock. NOTE: If the user forgets the password, use the remote control and press INPUT 0214 to restore the password to default. To set a screen lock password: 1.

  • Page 106: Chromium

    Chromium Web browser for surfing the Internet. WPS Nffice Create, edit, and view Documents, Memos, Presentations, and Spreadsheets.

  • Page 107: Folders

    Folders 1. Storage Device Display Select the appropriate storage device. 2. Icons Item Description Click to exit. Exit Click to sort file. Sort Click to display file by thumbnail mode. Thumbnail Click to display file by list mode. List Click to select file. Select Click to add folder.
  • Page 108 3. File Type Menu Item Description All types OFFICE files Image stored by myViewBoard, Side Tool Note Bar, and remote control Screen Capture button. Picture Image files Media Audio and Video files 4. File Information Preview the image, show the image’s name, size, resolution, and creation date. 5.

  • Page 109: Rs-232 Protocol

    RS-232 Protocol This document describes the hardware interface spec and software protocols of RS- 232 interface communication between ViewSonic LFD and PC or other control units with RS-232 protocol. The protocol contains three command sections: • Set-Function • Get-Function • Remote control pass-through mode NOTE: Below, “PC”...

  • Page 110: Lan Hardware Specification

    LA Hardware Specification ViewSonic LFD communcation port on the rear side: 1. Connector type: 8P8C RJ45 2. Pin Assignment: Pin # Signal Remark Output from Display Output from Display Input to Display BI_D3+ For 1G case BI_D3- For 1G case...

  • Page 111: Protocol

    Protocol Set-Function Listing The PC can control the Display for specific actions. The Set-Function command allows you to control the Display behavior at a remote site through the RS-232 port. The Set-Function packet format consists of 9 bytes. Set-Function DescriptionE Length: Total Byte of Message excluding “CR”...
  • Page 112 Txample 1E Set Brightness as 76 for Display (#02) and this command is valid Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x38 0x30 0x73 0x24 0x30 0x37 0x36 0x0D 0x32 Reply (Hex Format) Name Length Command Type 0x34 0x30 0x2B...
  • Page 113 Set-Function Oable A. Basic Function Set Function Length ID Command Command Value Range Comments Type (ASCII) Code Code (Three ASCII (ASCII) (Hex) bytes) Power on/ off 000: STBY 1. The Power-on (standby) 001: ON via LAN control may works only under specific mode.
  • Page 114 Button lock 000: Unlock *See note in details 001: Lock Menu lock > 000: Unlock *See note in details 001: Lock Number 000~009 *3.1.1 Key Pad 000: UP *3.1.1 001: DOWN 002: LEFT 003: RIGHT 004: ENTER 005: INPUT 006: MENU/(EXIT) 007: EXIT Remote 000: Disable...
  • Page 115 B. Nptional Function Set Function Length ID Command Command Value Range Comments Type (ASCII) Code Code (Hex) (Three ASCII bytes) (ASCII) Contrast 000 ~ 100 Sharpness 000 ~ 100 Color & 000 ~ 100 Tint ‘ 000 ~ 100 Backlight On_Off 000: Off 001: On Color mode...
  • Page 116 Tiling-Mode 000: OFF (for video wall) 001: ON Tiling-Compen- 000: OFF (for video wall) sation 001: ON Bezel width com- pensation Tiling-H by V 01x~09x: H (for video wall) Monitors 0x1~0x9: V 1. 2nd digital for H monitors 2. 3rd digital for V monitors Tiling-Position 001~025...

  • Page 117: Get-Function Listing

    Net-Function Listing The PC can interrogate the LFD for specific information. The Get-Function packet format consists of 9 bytes which is similar to the Set-Function packet structure. Note that the “Value” byte is always = 000. Net-Function DescriptionE Length: Total Byte of Message excluding “CR”. TV/DS ID Identification for each of TV/DS (01~98;...
  • Page 118 Example 1: Get Brightness from TV-05 and this command is valid. The Brightness value is 67. Send (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x38 0x30 0x67 0x62 0x30 0x30 0x30 0x0D 0x35 Reply (Hex Format) Name Length Command Type Command Value1 Value2 Value3 0x38 0x30...
  • Page 119 Net-Function Oable A. Basic Function Net Function Length ID Command Command Response Comments Range Type (ASCII) Code Code (Three ASCII (ASCII) (Hex) bytes) Get-Brightness 000 ~ 100 000 ~ 100 1. For Android Get-Backlight *3.2.0 platform whose main mode is controlled by backlight and the other sources are controlled by bright-...
  • Page 120 Get-MAC address (for the model with LAN) Reply in new 32-byte format *3.2.0 Get-IP address (for the model with *3.2.0 LAN) Reply in new 32-byte format*3.2.0 Get-Serial number Reply in new 32-byte *3.2.0 format *3.2.0 Get-FW version Reply in new 32-byte *3.2.0 format *3.2.0 NOTE:...
  • Page 121 6. Get FW version example Assumed the FW version is 3.02.001 Send: 0x 38 30 31 67 38 30 30 30 0D (Get FW version) Reply: 0x 32 30 31 72 38 33 2E 30 32 2E 30 30 31 00 00…00 00 0D...
  • Page 122 B. Nptional Function Net Function Length ID Command Command Response Comments Range Type (ASCII) Code Code (Hex) (Three ASCII bytes) (ASCII) Get-Contrast 000 ~ 100 Get-Sharpness 000 ~ 100 Get-Color 000 ~ 100 Get-Tint 000 ~ 100 Get-Backlight 000: Off On_Off 001: On Get-PIP mode...
  • Page 123 2. Get Time example Assumed the current time of display#01 as below: Time: 16:27:59 Send: 0x 38 30 31 67 33 48 30 30 0D (Get Time:Hour) Reply: 0x 38 30 31 72 33 48 31 36 0D (“H16”) Send: 0x 38 30 31 67 33 4D 30 30 0D (Get Time:Min) Reply: 0x 38 30 31 72 33 4D 32 37 0D (“M27”)
  • Page 124 C. Auto Reply *3.2.1 The display will send out the updated data/status automatically without getting a query from the host whenever the following data/status is changed by the user through any of the available ways like: remote control unit, front keys, or touch screen.

  • Page 125: Remote Control Pass-Through Mode

    Remote Control Pass-through Mode When the PC sets the Display to Remote Control Pass through mode, the Display shall send a 7-byte packet (followed by “CR”) in response to remote control unit (RCU) button activation. In this mode the remote control shall have no effect on the Display function.
  • Page 126 VOLUME DOWN (-) MUTE CHANNEL/PAGE UP (+)/ BRIGHTNESS+ CHANNEL/PAGE DOWN (-)/ BRIGHTNESS- POWER SOURCES (INPUTS) SLEEP MENU DOWN LEFT (-) RIGHT (+) OK (ENTER, SET) EXIT (F1) ■ GREEN (F2) ■ YELLOW (F3) ■ BLUE (F4) ■ NOTE: This IR-pass-through code is different from the RCU key code. Special control sequence for POWER key under IR-pass through mode.
  • Page 127 2-2. When Display is ON and receives the IR POWER code: Display will forward the POWER code to the host via RS-232, then turn off itself. 2-3. When SET-POWER LOCK is enabled, the Display will not respond to POWER key pressing. The VOLUME UP and VOLUME DOWN code will repeatedly output when you press and hold the keys.

  • Page 128: Appendix

    Appendix Specifications Item Category Specifications Model IFP6570 IFP8670 Screen Size 64.5” 85.6” Input Signal 1 x Type C 1 x HDMI 1 x DisplayPort 1 x PC audio 1 x RJ45 Output Signal 1 x HDMI 1 x Earphone 1 x SPDIF Speaker Output 10W x 2, 15W Subwoofer x 1 RS-232...

  • Page 129: Display Modes

    Display Modes VGA Mode Resolution Refresh Rate (@) 640 x 480 60Hz, 72Hz, 75Hz 720 x 400 70Hz 800 x 600 56Hz, 60Hz, 72Hz, 75Hz 832 x 624 75Hz 1024 x 768 60Hz, 70Hz, 75Hz 1152 x 864 60Hz, 75Hz 1152 x 870 75Hz 1280 x 768...

  • Page 130: Troubleshooting

    Oroubleshooting This section describes some common problems that you may experience when using the ViewBoard. Problem or Issue Possible Solutions 1. Check whether something is obstructing the display’s Remote Control is not working remote control receiver. 2. Check whether the batteries in the remote control are installed correctly.
  • Page 131 Oouch Function Problem or Issue Possible Solutions 1. Check that drivers are installed correctly. Touch function does not work 2. Reinstall driver(s). 3. Check setup and align it. 4. Check whether the touch pen is working properly. Video Not Working Properly Problem or Issue Possible Solutions 1.

  • Page 132: Maintenance

    Some chemical cleaners have been reported to damage the screen and/or case of the device. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners. NOTE: If condensation appears between the glass and the panel, keep the...

  • Page 133: Regulatory And Service Information

    Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 134: Declaration Of Rohs2 Compliance

    Ohe following information is only for TU-member statesE The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.

  • Page 135: Energy Star® Statement

    U.S. Environmental Protection Agency. As an ENERGY STAR® Partner, ViewSonic is determined to meet the ENERGY STAR® Guidelines and mark all certified models with the ENERGY STAR® logo.

  • Page 136: Copyright Information

    VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.

  • Page 137: Customer Service

    For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) www.viewsonic.com.cn www.viewsonic.com/hk/ 香港 (繁體中文) Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/...

  • Page 138: Limited Warranty

    ViewSonic® Smart White Board What the warranty covers: ViewSonic® warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, and as your sole remedy, repair or replace the product with a similar product.
  • Page 139 (e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warrantiesE...
  • Page 140 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...

  • Page 141: Mexico Limited Warranty

    If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 142 Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
  • Page 143 Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Distribuciones y Servicios Computacionales SA de CV.
  • Page 144 C0 M91 Y72 K24 Process Color C0 M0 Y0 K100 Process Color C0 M91 Y72 K24 Process Color Pantone Black C Spot Color Pantone 187 C Spot Color...

This manual is also suitable for:

Ifp6570Ifp8670Ifp70 seriesVs17710

Table of Contents
