ANBAUANLEITUNG
mounting instructions • instructions de montage • instrucciones de montaje • istruzioni di montaggio
ADV.23.017.76000
beinhaltet • contains • contient • contiene • contiene
SBL.23.017.10000/B
MSS.23.017.10000/B
HPR.00.220.85202/B
HPR.00.220.20000/B
STP.23.176.10000/B
STP.11.176.10700/B

Advertisement

loading
Need help?

Need help?

Do you have a question about the ADV.23.017.76000 and is the answer not in the manual?

Questions and answers

Related Manuals for SW-Motech ADV.23.017.76000

Summary of Contents for SW-Motech ADV.23.017.76000

  • Page 1 ANBAUANLEITUNG mounting instructions • instructions de montage • instrucciones de montaje • istruzioni di montaggio ADV.23.017.76000 beinhaltet • contains • contient • contiene • contiene SBL.23.017.10000/B MSS.23.017.10000/B HPR.00.220.85202/B HPR.00.220.20000/B STP.23.176.10000/B STP.11.176.10700/B...

  • Page 2: Safety Warning Symbol

    ~ 1.5 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Page 3 Use thread locker: Indicates that a thread must be coated with liquid thread locker. H (HIGH): high strength; M (MEDIUM): medium strength; L (LOW): low strength. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 4 Ø 12 / ø 8.4 / h 15 US.ST.130.02.125 DB.00.250.125.015.01 MU.ST.12.01.985.08 SC.ST.06.040.02.912.088 US.ST.064.02.125 DB.ST.120.084.015.01 M6 x 16; DIN 912 M6; DIN 985 SC.ST.06.016.02.912.088 MU.ST.06.01.985.08 KES.RD.260.0270.02.GL SBL.00.051.005/B The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 5  WARNING: Always use suitable tools! Loosen the screws shown and push the fairing slightly outwards. Remove the coolant reservoir from the vehicle frame. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 6 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Loosen the screws and remove the fairing shown from the left-hand side of the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 7 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Loosen the screws and remove the fairing shown from the right-hand side of the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 8 Now reassemble the fairing parts and coolant reservoir and mount them onto the vehicle. Tighten the screws according to the manufacturer's instructions. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 9 Do not tighten the screws yet. × × 75 Nm × × × × × × × 75 Nm The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 10 Do not tighten the screws yet. × × 75 Nm × × × × × × × 75 Nm × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 11 Finally, insert the plastic plugs (26) and end caps (27) into the openings on the × crash bars on both sides. × × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 12 TÜV regulations. After installation, parts subject to registration should be entered in the vehicle documents by your test center. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 13 ~ 1 h. EASY DIFFICULT ENGLISH ·Thank you for choosing this premium product from SW-MOTECH. PREPARATION: Read the mounting instructions carefully and make sure Visit our online shop for more information (e.g. model assignments). Required that all parts on the parts list are available.
  • Page 14 Indicates the tightening torque of a part specified by SW- strength; M (MEDIUM): medium strength; L (LOW): MOTECH or the vehicle manufacturer (OEM). low strength. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 15 M6 x 25; DIN 7991 M6; DIN 6927 M6 x 35; DIN 7991 Ø16 / Ø6.2 / h5 SC.ST.06.025.02.7991.088 SE.00.064.02 MU.ST.06.02.6927.08 SC.ST.06.035.02.7991.088 DB.00.160.062.005.01 The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 16 Insert the rubber grommets (2) into the openings of the engine guard (1). Then press the spacers (3) into the openings of the rubber grommets (2). × × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 17 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Remove the original engine guard from the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 18 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Remove the original mounting bracket from the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 19 Screw mounting brackets (4) and (5) to the vehicle. ×  WARNING: Use a liquid threadlocker! Do not tighten the screws yet. × × × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 20 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Remove the original engine guard and horn from the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 21 MOUNTING STEP · READ AND KEEP MOUNTING INSTRUCTIONS! Remove the original mounting bracket from the vehicle. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 22  WARNING: Use a liquid threadlocker! Do not tighten the screws yet. × × × × × × × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 23 When all components are loosely attached, tighten all screws as specified in the mounting instructions. 8 Nm × × × 8 Nm × The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
  • Page 24 TÜV regulations. After installation, parts subject to registration should be entered in the vehicle documents by your test center. The content translation is automated. Errors and omissions excepted © SW-MOTECH GmbH & Co. KG Subject to technical and design changes.
