Summary of Contents for Eyedro E5B-EW-E3
- Page 1 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS Revision: 230608...
-
Page 2: Table Of Contents
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS CONTENTS Important Safety Information for Eyedro Monitoring Products ..............5 Additional Safety Information for Electricity Monitoring Products ..............6 Box Contents (By Product)..........................7 Eyedro Business Electricity Monitors ......................7 Hardware Installation ............................ 8 Install Current Sensors .......................... - Page 3 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS Materials You Will Need........................23 Tools You Will Need ..........................23 Procedure (Wi-Fi Devices Only) ......................23 Tips ..............................24 Software Configuration ..........................25 MyEyedro.com ............................25 Specifications .............................. 26 Hardware Specifications .......................... 26 Sensor Specifications ..........................
- Page 4 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS If you have any questions about using your Eyedro Electricity Monitoring System please visit eyedro.com for information, documentation, videos, and answers to frequently asked questions. PLEASE READ ALL ENCLOSED INSTRUCTIONS PRIOR TO THE INSTALLATION.
-
Page 5: Important Safety Information For Eyedro Monitoring Products
SERVICEABLE. Please contact The Eyedro Monitoring products (and all components) are Eyedro Green Solutions Inc. if any component appears damaged or faulty. DO NOT open the case of the unit or tamper with any of the internal or external components. -
Page 6: Additional Safety Information For Electricity Monitoring Products
It is important that you observe some simple safety precautions when installing Eyedro Electricity Monitoring products. The Eyedro Electricity Monitor was designed to be non-intrusive and easy to install. Typically, there is no need to disconnect any electrical cabling during the installation. However, there are several safety issues that should be considered when installing and using the system. -
Page 7: Box Contents (By Product)
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS BOX CONTENTS (BY PRODUCT) EYEDRO BUSINESS ELECTRICITY MONITORS Ethernet Mesh Description + Wi-Fi Eyedro Ethernet/Wi-Fi Electricity Module (EMx.ENWI.*E) Eyedro Mesh Electricity Module (EMx.NODE.*E) Eyedro Mesh Gateway Module 0 - 1 (EMx.GATE.0N) Current Sensors (200A sensors shown... -
Page 8: Hardware Installation
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS HARDWARE INSTALLATION DO NOT CONTINUE WITH THE INSTALLATION OF THE EYEDRO ELECTRICITY MONITORING SYSTEM UNTIL YOU HAVE READ THE SAFETY SECTION OF THIS GUIDE. ©2011-2023 Eyedro Green Solutions Inc. P a g e... -
Page 9: Install Current Sensors
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS INSTALL CURRENT SENSORS MATERIALS YOU WILL NEED • Eyedro Current Sensors • Approved bushing or connector (not included) • Labels (optional – not included) TOOLS YOU WILL NEED • Flashlight • Screwdriver • Pliers PROCEDURE Current sensors are installed on the individual line (/live/hot) conductors only. -
Page 10: Parallel Feeders
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS PARALLEL FEEDERS High ampacity services and feeders are often installed with conductors in parallel to reduce pulling tensions and for easier handling. Parallel feeders are conductors of the same length, same material, same circular mil area, same insulation, and terminated in the same manner. -
Page 11: Common Circuit Types
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS COMMON CIRCUIT TYPES The most common application of Eyedro Electricity Monitoring products is for monitoring of the electrical service entrance of a building. However, there are other common applications where Eyedro Electricity Monitoring products are often used. The following sub-sections provide a brief overview of some of the common and less common applications. - Page 12 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS 3-PHASE DELTA MONITORING Note: The sensor position is the same for Delta, High-Leg Delta or Corner Grounded Delta systems. ©2011-2023 Eyedro Green Solutions Inc. P a g e | 12...
- Page 13 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS SPLIT (SINGLE) PHASE MONITORING ©2011-2023 Eyedro Green Solutions Inc. P a g e | 13...
- Page 14 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS SINGLE PHASE BRANCH CIRCUIT MONITORING Branch circuits are commonly used for lighting and receptacles throughout the building. These circuits can be identified by a single-pole breaker in the electrical panel. Cabling typically consists of black (line) and white (neutral) conductors with a bare copper (or green) ground conductor.
- Page 15 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS BALANCED BRANCH CIRCUIT MONITORING Balanced branch circuits are commonly used for electric heaters/baseboards, electric water heaters, air conditioners, heat pumps, pool pumps, etc. These circuits can be identified by a double-pole breaker in the electrical panel. Cabling typically consists of black (line 1) and red (line 2) conductors with a bare copper (or green) ground conductor.
- Page 16 PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS UNBALANCED BRANCH CIRCUIT MONITORING Unbalanced branch circuits are commonly used for large loads with multiple voltage requirements, split receptacles, and sub-panel feeders throughout the building. These circuits can be identified by a double-pole breaker in the electrical panel. Cabling typically consists of black (line 1), red (line 2), and white (neutral) conductors with a bare copper (or green) ground conductor.
-
Page 17: Wireless Mesh Best Practices (Mesh Products Only)
6. Keep the area around the Eyedro module free from metallic objects. 7. Do not mount the Eyedro module on the metal electrical panel - if unavoidable, put an insulating material, like wood or foam, between the Eyedro module and the metal. -
Page 18: Mount Eyedro Device(S)
The serial number will be in the format "123 - 45678" 2. Find a clear area on the wall beside the electrical panel (or router in the case this is the Eyedro Wireless Gateway Module). Make sure all cables will easily reach the module before securing. -
Page 19: Procedure (Horizontal Mount)
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS PROCEDURE (HORIZONTAL MOUNT) Mounting is not required for horizontal installations (i.e., on a desktop or shelf). If added security is desired, follow instructions for vertical mounting using screws or double-sided tape. ©2011-2023 Eyedro Green Solutions Inc. -
Page 20: Connect Cabling
3. Connect the other end of the Ethernet cable to the router (or Internet access point). 4. Connect the appropriate end of the low-voltage power adapter to the Eyedro module. Electricity monitoring devices (with sensors) use a power supply with a 6V AC output. -
Page 21: Procedure (Wi-Fi Installations)
2. Connect the other end of the Ethernet cable to the router (or Internet access point). 3. Connect the appropriate end of the low-voltage power adapter to the Eyedro Gateway module. Gateway devices use a power supply with a 5VDC output. -
Page 22: Internet Connection
A good test would be to plug a laptop or computer into the same Ethernet port that you intend to use for your (wired) Eyedro product, or, if installing a Eyedro Wi-Fi product, provision it to connect to the same Wi-Fi network – if you can open a browser and navigate the web no additional configuration is likely needed. -
Page 23: Provisioning Eyedro Wi-Fi
2. Using the same phone/tablet/computer, search for available Wi-Fi networks and connect to the Wi-Fi network created by your Eyedro device. The name of the created network will be “Eyedro[xxx-yyyyy]” where xxx-yyyyy matches the serial number of the device. 3. Open a browser and go to eyedro.com/setup. -
Page 24: Tips
Device is connected to the provisioned network and should appear as ‘Active’ in MyEyedro. If the status lights are still not green (connected) after following the procedure, cycle power to the Eyedro device and try the procedure again – carefully following all instructions and notes. -
Page 25: Software Configuration
(or login if you have an existing account). 2. From the system configuration screen, enter the serial number of your Eyedro Module(s) – found on the back of the device(s). For more information on MyEyedro and complete instructions for adding devices, refer to the online documentation and user guide found at http://eyedro.com/support... -
Page 26: Specifications
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS SPECIFICATIONS HARDWARE SPECIFICATIONS Ethernet + Wi-Fi Mesh Class 2 Power Supply Input: 120Vac, 60Hz (North America/Type A) Power Supply Input: 240Vac, 50Hz (Europe/Type C) Output: 6Vac, 0-350mA 0°C to 50°C Ambient Operating (32°F to 122°F) -
Page 27: Sensor Specifications (Available Substitutes)
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS SENSOR SPECIFICATIONS (AVAILABLE SUBSTITUTES) Cable Sensor Input Output Accuracy Core Opening Length 0 to 5Aac 250V 50/60Hz (XH-SCT-T06-5) 0 to 10Aac (XH-SCT-T06- 250V 50/60Hz 10A) 0 to 15Aac (XH-SCT-T06- 250V 50/60Hz 15A) 0 to 20Aac 6.0 mm... -
Page 28: Compliance
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS COMPLIANCE This product has been tested and found in compliance to: Safety Requirements for Electrical Equipment For Measurement, Control, And Laboratory Use - Part 1: General Requirements [UL 61010-1:2012 Ed.3+R:19Jul2019] Safety Requirements for Electrical Equipment For Measurement, Control, And Laboratory Use –... -
Page 29: Warranty
WARRANTY LIMITED ONE YEAR WARRANTY Eyedro Green Solutions Inc. shall provide warranty for all defects in material and workmanship for a period of one year from the original date of purchase. Defective parts may be repaired or replaced, at the discretion of the manufacturer, free of charge during this period. -
Page 30: Troubleshooting
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS TROUBLESHOOTING Device installation is simple and non-invasive but occasionally problems do arise. Before contacting support, please refer to our online troubleshooting resources. Troubleshooting: eyedro.com/support-troubleshooting ©2011-2023 Eyedro Green Solutions Inc. P a g e | 30... -
Page 31: Contact Information
PRODUCT GUIDE: EYEDRO ELECTRICITY MONITORING PRODUCTS CONTACT INFORMATION If you have any questions about using your Eyedro Electricity Monitoring System please visit our website for documentation, videos, frequently asked questions, and contact forms. Website: eyedro.com Support: eyedro.com/support Eyedro Green Solutions Inc.
