  • Page 1: Table Of Contents

    Table of Contents Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems How to get going AM/FM stereo with CD AM/FM stereo with in-dash six CD Auxiliary input jack Rear seat controls Climate Controls Manual heating and air conditioning Rear window defroster Lights Headlamps...
  • Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction Control™/AdvanceTrac Air suspension Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch...
  • Page 3 Ford Motor Company. Ford may change the contents without notice and without incurring obligation. Copyright © 2006 Ford Motor Company...

  • Page 4: Introduction

    California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
  • Page 5 Introduction Warning symbols on your vehicle When you see this symbol, it is imperative that you consult the relevant section of this guide before touching or attempting adjustment of any kind. Protecting the environment We must all play our part in protecting the environment.
  • Page 6 • where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
  • Page 7 Introduction Using your vehicle with a snowplow Do not use this vehicle for snowplowing. Your vehicle is not equipped with a snowplowing package. Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles.
  • Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Airbag - Front Airbag - Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor...
  • Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...

  • Page 10: Instrument Cluster

    Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
  • Page 11 Instrument Cluster Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Powertrain malfunction/reduced power (RTT) (if equipped): Displays when the engine has defaulted to a ’limp-home’ operation. Report the fault to a dealer at the earliest opportunity.
  • Page 12 Instrument Cluster Safety belt: Reminds you to fasten your safety belt. A BeltMinder chime will also sound to remind you to fasten your safety belt. Refer to the Seating and safety restraints chapter to activate/deactivate the BeltMinder chime feature. Charging system (RTT): Displays when the battery is not charging properly.
  • Page 13 Instrument Cluster not turn ON or begins to flash, have the system inspected by your authorized dealer. For more information on this system, refer to Understanding Your Tire Pressure Monitoring System in the Tires, Wheels and Loading chapter. Low fuel (RTT) (if equipped): Displays when the fuel level in the fuel tank is at or near empty (refer to Fuel gauge in this chapter).
  • Page 14 Instrument Cluster Four wheel drive low (RTT) (if equipped): Displays when four-wheel drive low is engaged. If the light fails to illuminate when the ignition is turned ON, or remains on, have the system serviced immediately by your authorized dealer. Four wheel drive (RTT) (if equipped): Displays when four-wheel drive is engaged.

  • Page 15: Gauges

    Instrument Cluster Parking brake ON warning chime: Sounds when the parking brake is set, the engine is running and the vehicle is driven more than 3 mph (5 km/h). Turn signal chime: Sounds when the turn signal lever has been activated to signal a turn and not turned off after the vehicle is driven more than 1.5 miles (2.4 km).
  • Page 16 Instrument Cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
  • Page 17 Instrument Cluster Battery voltage gauge: Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked by your authorized dealer as soon as possible.

  • Page 18: Entertainment Systems

    Entertainment Systems AUDIO SYSTEMS Quick start — How to get going Listening to the radio 1. If the audio system is off, press VOL-PUSH to turn the radio on. Turn VOL-PUSH to adjust the volume. Note: The system may take a few moments to turn on.
  • Page 19 Entertainment Systems 2. Press AUX repeatedly to cycle through auxiliary audio sources. Select SAT1, SAT2 or SAT3 to listen to satellite radio. 3. Press SEEK, SEEK access the previous or next satellite channel. You may also seek by music category. For further information, refer to CATEGORY listing under the MENU control on your specific audio system.
  • Page 20 Entertainment Systems For an in-dash six CD system, if a disc is not already loaded, press LOAD. Select a slot number using memory presets 1–6. When the display reads LOAD CD#, load the desired disc, label side up. If you do not choose a slot within 5 seconds, the system will choose for you.
  • Page 21 Entertainment Systems random play will begin when the current track is finished playing. CD SHUF will appear in the display. To disengage, press SHUFFLE again. SHUFFLE OFF will appear in the display. Note: In track mode, all tracks on the current disc will shuffle in random order.

  • Page 22: Am/Fm Stereo With Cd

    Entertainment Systems AM/FM single CD/MP3 satellite compatible sound system (if equipped) Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.
  • Page 23 Entertainment Systems 3. MENU: Press repeatedly to access the following settings: CATEGORY (satellite radio if equipped): Press MENU until the currently active category appears in the display (CATEGORY MODE). In CATEGORY MODE, press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.) Once you have selected a category, use SEEK...
  • Page 24 Entertainment Systems BASS: Press MENU to reach the bass setting. Use SEEK, SEEK to adjust. TREB (Treble): Press MENU to reach the treble setting. SEEK, SEEK to adjust. BAL (Balance): Press MENU to reach the balance setting. SEEK, SEEK to adjust the audio between the left (L) and right (R) speakers.
  • Page 25 Entertainment Systems SINGLE PLAY / DUAL PLAY: If Single Play is ON, press Dual Play. For further information on Single Play/Dual Play, refer to Rear seat controls later in this chapter. FES (FULL/LOCKED): Your vehicle is equipped with a Family Entertainment DVD system.
  • Page 26 Entertainment Systems 7. SHUFFLE: In CD/MP3 mode, press SHUFFLE to engage shuffle mode. SHUFFLE ON will appear in the display. If you wish to engage shuffle mode right away, press SEEK to begin random play. Otherwise, random play will begin when the current track is finished playing.
  • Page 27 Entertainment Systems 13. TEXT/SCAN: In radio and CD/MP3 mode, press and hold for a brief sampling of radio stations or CD tracks. Press again to stop. In CD/MP3 mode, press and release to display track title, artist name, and disc title. In TEXT MODE sometimes the display requires additional text to be displayed.

  • Page 28: Am/Fm Stereo With In-Dash Six Cd

    Entertainment Systems 18. CD slot: Insert a CD label side Premium/Audiophile AM/FM in-dash six CD/MP3 satellite compatible sound system (if equipped) Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches, radio and moon roof (if equipped) may be used for up to ten minutes after the ignition is turned off or until either front door is opened.
  • Page 29 Entertainment Systems 2. MUTE/ : Press to mute the playing media. Press again to return to the playing media. 3. MENU: Press repeatedly to access to the following settings: CATEGORY (satellite radio if equipped): Press MENU until the currently active category appears in the display (CATEGORY MODE). In CATEGORY MODE, press to scroll through the list of available SIRIUS channel Categories (Pop, Rock, News, etc.) Press...
  • Page 30 Entertainment Systems To view the station name or type: When the desired category appears in the display, press TEXT/SCAN to toggle between displaying the station type (COUNTRY, ROCK, etc.) or the station name (WYCD, WXYZ, etc.). BASS: Press MENU to reach the bass setting. Use SEEK, SEEK to adjust.
  • Page 31 Entertainment Systems COMPRESS (Compression): Available only in CD/MP3 mode. Press MENU until COMPRESS ON/OFF appears in the display. Use SEEK, SEEK to toggle ON/OFF. When COMPRESS is ON, the system will bring soft and loud CD passages together for a more consistent listening level.
  • Page 32 Entertainment Systems (Play/Pause): This control is operational in CD and DVD mode (if equipped). When a CD or DVD is playing in the FES system, press this control to play or pause the current CD/DVD. The CD/DVD status will display in the radio display. If your vehicle is equipped with a Family Entertainment System (FES) please refer to the DVD supplement for further information.
  • Page 33 Entertainment Systems memory presets, tune to the desired channel then press and hold a preset control until sound returns. Satellite radio is available only with a valid SIRIUS subscription. Check with your authorized dealer for availability. 13. TEXT/SCAN: In radio and CD/MP3 mode, press and hold to hear a brief sampling of radio stations or CD tracks.
  • Page 34 Entertainment Systems 17. LOAD: To load a disc into the system, press LOAD. Select a slot number using memory presets 1–6. When the display reads LOAD CD#, load the desired disc, label side up. If you do not choose a slot within 5 seconds, the system will choose for you.

  • Page 35: Auxiliary Input Jack

    Entertainment Systems Auxiliary input jack Your vehicle is equipped with an Auxiliary Input Jack (AIJ). The Auxiliary Input Jack provides a way to connect your portable music player to the in-vehicle audio system. This allows the audio from a portable music player to be played through the vehicle speakers with high fidelity.

  • Page 36: Rear Seat Controls

    Entertainment Systems Troubleshooting: 1. Do not connect the audio input jack to a line level output. Line level outputs are intended for connection to a home stereo and are not compatible with the AIJ. The AIJ will only work correctly with devices that have a headphone output with a volume control.
  • Page 37 Entertainment Systems 2. VOLUME: Press to increase ( ) or decrease ( ) the volume level in the headphones. From the rear seat controls, volume control can be set no higher than the current radio setting unless the speakers are turned off. : In radio mode, press and release to advance through memory presets.
  • Page 38 Entertainment Systems • Use the other controls to make adjustments to the playing media. • Dual Play mode may also be activated by pressing memory presets 2 and 4 simultaneously on the front audio controls. The rear speakers mute and rear seat passengers have audio (for their selected media) available through their headphones.
  • Page 39 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
  • Page 40 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
  • Page 41 Entertainment Systems Audio system warranty and service Refer to the Warranty Guide for audio system warranty information. If service is necessary, see your dealer or qualified technician. MP3 track and folder structure Your MP3 system recognizes MP3 individual tracks and folder structure as follows: •...
  • Page 42 Entertainment Systems Sample MP3 structure If you are burning your own MP3 discs, it is important to understand how the system will read the structures you create. While various .mp3 files may be present, (files with .mp3 extensions other than mp3), only files with the .mp3 extension will be .mp3 played.

  • Page 43: Climate Controls

    Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control.
  • Page 44 Climate Controls Dual zone manual heating and air conditioning system with rear passenger compartment climate control (if equipped) 1. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. MAX A/C: Distributes recirculated air through the instrument panel vents only to cool the vehicle.
  • Page 45 Climate Controls will be warmer or cooler than the driver airflow temperature setting when more than one rear temperature light ( REAR ) is illuminated. Rear defroster: Press to activate/deactivate rear window defroster. Refer to Rear window defroster later in this chapter for more information.
  • Page 46 Climate Controls 2. Select A/C. 3. Adjust the temperature control to maintain comfort. 4. Set the fan speed to the highest setting. 5. Direct the outer instrument panel vents towards the side windows. To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.
  • Page 47 Climate Controls Rear defroster: Press to activate/deactivate the rear window defroster. Refer to Rear window defroster later in this chapter for more information. 5. R Rear fan speed control: Press to enable the auxiliary system or to adjust the rear fan speed from the front control. The rear fan speed settings available are 4, 3, 2, 1 and O (OFF).
  • Page 48 Climate Controls 17. EXT: Press to display the outside temperature. Press again to display the cabin temperature settings. 18. REAR: Press to enable the control located in the rear seat. Press again to turn the auxiliary system off. Dual automatic temperature control with heated and cooled seats and rear passenger compartment climate control (if equipped) Defrost: Distributes outside air through the windshield defroster vents.
  • Page 49 Climate Controls Passenger heated seat control: Press once to activate the high heat setting (2 indicator lights). Press again to activate the low heat setting (1 indicator light). Press again to deactivate the passenger heated seat. Passenger cooled seat control: Press once to activate the high cool setting (2 indicator lights).
  • Page 50 Climate Controls 16. A/C: Press to activate/deactivate air conditioning. Use with recirculated air to improve cooling performance and efficiency. Engages automatically in AUTO, , and 17. EXT: Press to display the outside temperature. Press again to display cabin temperature settings. Recirculated air: Press to activate/deactivate air recirculation in the vehicle cabin.

  • Page 51: Rear Window Defroster

    Climate Controls Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. AUXILIARY CLIMATE CONTROL (IF EQUIPPED) 1. Fan speed: Turn to select the desired fan speed. 2. Temperature/mode selection: The distribution of air from the overhead and floor registers is based on the temperature selected.

  • Page 52: Lights

    Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to turn on the headlamps. Autolamp control The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control.
  • Page 53 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the foglamps on at full intensity output. To activate: •...
  • Page 54 Lights PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel and all applicable switches in the vehicle during headlamp and parklamp operation. Move the control to the full upright position, past detent, to turn on the interior lamps. Move the control to the full down position, past detent, to prevent the interior lights from illuminating...

  • Page 55: Turn Signal Control

    Lights 4. On the wall or screen you will observe a light pattern with a distinct horizontal edge towards the right. If this edge is not at the horizontal reference line, the beam will need to be adjusted so the edge is at the same height as the horizontal reference line.
  • Page 56 Lights INTERIOR LAMPS Front row map lamps (if equipped) To turn on the map lamps, press the outer edge of the clear lens. The front row map lamp lights when: • any door is opened. • the instrument panel dimmer switch is rotated until the courtesy lamps come on.

  • Page 57: Bulb Replacement

    Lights Rear cargo lamp The dome lamp lights when: • any door is opened, and the switch is in the middle position. • the instrument panel dimmer switch is rotated until the courtesy lamps come on. • any of the remote entry controls are pressed and ignition is OFF (and switch is in the middle position).
  • Page 58 To replace all instrument panel lights - see your authorized dealer * To obtain replacement approach lamp assembly bulbs, see your authorized dealer and reference Ford part no. 2L1Z–13B374–BB for the passenger side mirror and 2L1Z–13B375–BB for the driver side mirror.
  • Page 59 Lights 3. At the back of the headlamp, remove the two headlamp assembly retainer bolts. 4. Slide headlamp assembly forward and off the retaining tab to expose the back of the bulb and electrical connector. 5. Disconnect the electrical connector. 6.
  • Page 60 Lights 3. At the back of the headlamp, remove the two headlamp assembly retainer bolts. 4. Slide headlamp assembly forward and off the retaining tab to expose the back of the headlamp assembly. 5. Rotate the bulb socket counterclockwise and remove from the lamp assembly.
  • Page 61 Lights 6. Install the bulb socket into the lamp assembly and rotate clockwise. 7. Carefully install the tail lamp assembly on the vehicle by securing the lamp assembly with two screws. High-mount brakelamp To change the high-mount brakelamp bulbs: 1. Remove the two screws holding the lamp assembly in place.
  • Page 62 Lights Replacing license plate lamp bulb The license plate bulbs are located in the license plate housing assembly on the liftgate. To change the license plate bulbs: 1. Make sure the headlamp switch is in the OFF position. 2. Remove the license lamp screw from the assembly.
  • Page 63 Lights Approach lamp bulb removal (if equipped) To change the bulbs: 1. Make sure that all the doors are closed and the interior lights have automatically turned off or the opposite mirror approach lamp has turned off. 2. With a small flat tipped screwdriver, insert the tip into the approach light module slot located on the outboard corner of the lens...

  • Page 64: Driver Controls

    Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Speed dependent wipers: When the wiper control is on, the speed of the wipers will automatically adjust with the vehicle speed.

  • Page 65: Steering Wheel Adjustment

    Driver Controls For rear wash cycle, rotate (and hold as desired) the rear wiper/washer control to either position. From either position, the control will automatically return to the INT 2 or OFF position. TILT STEERING WHEEL 1. Pull and hold the steering wheel release control toward you.
  • Page 66 Driver Controls OVERHEAD CONSOLE The appearance of your vehicle’s overhead console will vary according to your option package. Forward storage bin (if equipped) The storage compartment may be used to store a pair of sunglasses. Press the release area on the rear edge of the bin door to open the storage compartment.
  • Page 67 Driver Controls Power quarter rear windows (if equipped) Press the portion of the control to open the power rear quarter windows. Press the left portion of the control to close the power rear quarter windows. Do not leave children unattended in the vehicle and do not let children play with the power rear quarter windows.
  • Page 68 Driver Controls The auxiliary power point is located on the instrument panel. Do not use the power point for operating the cigarette lighter element (if equipped). To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of 12 VDC/180W.

  • Page 69: Power Windows

    Driver Controls Not equipped with rear climate control Cigar/Cigarette lighter (if equipped) Do not plug optional electrical accessories into the cigarette lighter socket. Do not hold the lighter in with your hand while it is heating, this will damage the lighter element and socket. The lighter will be released from its heating position when it is ready to be used.
  • Page 70 Driver Controls Press and pull the window switches to open and close windows. • Push down (to the first detent) and hold the switch to open. • Pull up and hold the switch to close. Rear Window Buffeting: When one or both of the rear windows are open, the vehicle may demonstrate a wind throb or buffeting noise;...

  • Page 71: Mirrors

    Driver Controls AUTOMATIC DIMMING INSIDE REAR VIEW MIRROR (IF EQUIPPED) Your vehicle may be equipped with an inside rear view mirror with an auto-dimming function. The electronic day/night mirror will change from the normal (high reflective) state to the non-glare (darkened) state when bright lights (glare) reach the mirror.
  • Page 72 Driver Controls Powerfold mirrors (if equipped) Rotate the 4–way adjustment switch to the center position. Press the switch down to auto fold in and down again to auto fold back to design position. Powerfold the side mirrors in carefully when driving through a narrow space, like an automatic car wash.
  • Page 73 Driver Controls Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place. These actions could cause damage to the glass and mirrors. Signal indicator mirrors (if equipped) When the turn signal is activated, the lower portion of the mirror housing will blink.

  • Page 74: Speed Control

    Driver Controls SPEED CONTROL With speed control set, you can maintain a speed of 30 mph (48 km/h) or more without keeping your foot on the accelerator pedal. Speed control does not work at speeds below 30 mph (48 km/h). Do not use the speed control in heavy traffic or on roads that are winding, slippery or unpaved.
  • Page 75 Driver Controls Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 30 mph (48 km/h). Increasing speed while using speed control There are two ways to set a higher speed:...
  • Page 76 Driver Controls Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed. • Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.
  • Page 77 Driver Controls In AM, FM1, or FM2 mode: • Press SEEK select preset stations within the selected radio band or press and hold to select the next/previous radio frequency. In Satellite radio mode (if equipped): • Press SEEK advance through preset channels or subscribed channels. In CD mode: •...

  • Page 78: Moon Roof

    Driver Controls Press FAN + or - to adjust fan speed. MOON ROOF (IF EQUIPPED) The moon roof control is located on the overhead console. Do not let children play with the moon roof or leave children unattended in the vehicle. They may seriously hurt themselves. When closing the moon roof, you should verify that it is free of obstructions and ensure that children and/or pets are not in the proximity of the moon roof opening.
  • Page 79 Driver Controls The moon roof has a built-in sliding shade that can be manually opened or closed when the glass panel is shut. To close the shade, pull it toward the front of the vehicle. HOMELINK WIRELESS CONTROL SYSTEM (IF EQUIPPED) The HomeLink Wireless Control System, located on the driver’s visor, provides a convenient way to...
  • Page 80 Driver Controls 1. Press and hold the two outside buttons releasing only when the indicator light begins to flash after 20 seconds. Do not repeat Step 1 to program additional hand-held transmitters to the remaining two HomeLink buttons. This will erase previously programmed hand-held transmitter signals into HomeLink .
  • Page 81 Driver Controls 6. Firmly press and release the “learn” or “smart” button. (The name and color of the button may vary by manufacturer.) Note: There are 30 seconds in which to initiate Step 7. 7. Return to the vehicle and firmly press, hold for two seconds and release the programmed HomeLink button.
  • Page 82 Driver Controls Operating the HomeLink Wireless Control System To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
  • Page 83 Driver Controls ELECTRONIC COMPASS/TEMPERATURE DISPLAY WITHOUT MESSAGE CENTER (IF EQUIPPED) Outside air temperature In vehicles without Dual Electronic Automatic Temperature Control (DATC), the outside temperature display is contained in the instrument cluster and displays all the time. In vehicles with DATC, the temperature displays in the climate control display.
  • Page 84 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Turn ignition to the ON position. 3. Start the engine. 7 8 9 1011 4. Locate the reset button on the compass sensor mounted on the base of mirror.

  • Page 85: Message Center

    Driver Controls MESSAGE CENTER With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status preceded by a brief indicator chime.
  • Page 86 Driver Controls Outside air temperature (if equipped) Press and hold the INFO button for 2 seconds to display the outside temperature. To switch from a blank display to the temperature display, hold the INFO button for 2 seconds until the temperature is seen in the display.
  • Page 87 Driver Controls 5. Press and release the RESET until the message center displays a selection to change the current zone setting. 6. Press and release the RESET control until the message center display changes to show the current zone setting (XX). 7.
  • Page 88 Driver Controls Distance to empty (DTE) Selecting this function from the INFO menu estimates approximately how far you can drive with the fuel remaining in your tank under normal driving conditions. Remember to turn the ignition OFF when refueling to allow this feature to correctly detect the added fuel. The DTE function will display XXX MILES TO E FUEL LEVEL and sound a tone for one second when you have approximately 50 miles (80 km) to empty.
  • Page 89 Driver Controls Instantaneous fuel economy Press INFO until the menu displays “MPG”. This will display your fuel economy as a Bar Graph ranging from poor economy to excellent economy. Your vehicle must be moving to calculate instantaneous fuel economy. When your vehicle is not moving, this function shows one or no bars illuminated.
  • Page 90 Driver Controls Reset to English (if in another language) When entering the SETUP MENU and a non-English language has been selected, “HOLD RESET FOR ENGLISH” will be displayed to change back to English. Press and hold the RESET control to set the language choice. Easy entry/exit (if equipped) This feature automatically moves the drivers seat backwards for easy exit from the vehicle.
  • Page 91 Driver Controls Autolock This feature automatically locks all vehicle doors when the vehicle is shifted into any gear, putting the vehicle in motion. 1. To disable/enable the autolock feature, select this function from the SETUP control for the current display mode. 2.
  • Page 92 Driver Controls Units (English/Metric) 1. Select this function from the SETUP menu for the current units to be displayed. 2. Press the RESET control to change from English to Metric. System check Selecting this function from the SETUP menu causes the message center to cycle through each of the systems being monitored.
  • Page 93 Driver Controls the message center after you acknowledge the warning by pressing the RESET control and clearing the warning message. Warning messages that have been reset are divided into three categories: • They cannot be cleared until the condition is corrected. •...
  • Page 94 Driver Controls Warning display Status Check brake system Warning can be reset. Will return after 10 minutes. If within the 10 minutes, the condition is cleared and set again, XXX miles (km) to empty fuel it will not return until the initial 10 level low minutes is up.
  • Page 95 Driver Controls TIRE PRESSURE MONITOR FAULT. Displayed when the Tire Pressure Monitoring System is malfunctioning. If the warning stays on or continues to come on, have the system inspected by your authorized dealer. TIRE PRESSURE SENSOR FAULT. Displayed when a tire pressure sensor is malfunctioning, or your spare tire is in use.
  • Page 96 Driver Controls PARK AID <ON> OFF (if equipped). Displayed when the transmission is in R (Reverse). Refer to Reverse Sensing System in this section to enable. OIL CHANGE REQUIRED/CHANGE OIL SOON. Displayed when the engine oil life remaining is 5 percent or less. When oil life left is between 5% and 0%, the CHANGE OIL SOON message will be displayed.
  • Page 97 Driver Controls Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.
  • Page 98 Driver Controls To open the liftgate from the Instrument panel: Press the button once to open the liftgate, press it again to close. To open the liftgate with the Key fob: Refer to Remote Entry System in the Locks and security chapter. To open the liftgate with outside release handle (manual actuation):...
  • Page 99 Driver Controls Warning, keep clear of the liftgate when activating the rear switch. To manually operate the liftgate: 1. Disable the liftgate power function, refer to the Message Center in this chapter. 2. Open and close the liftgate as you would a standard liftgate. Note: In case of operation in extreme cold -40°...
  • Page 100 Driver Controls Liftgate ajar signal If the liftgate or liftgate glass are not fully latched, you will receive a “LIFTGATE or LIFTGLASS AJAR” message on the instrument panel. If you see this message, check both the liftgate glass and liftgate door to insure they are fully latched.
  • Page 101 Driver Controls Make sure the liftgate is closed to prevent exhaust fumes from being drawn into the vehicle. If you must drive with the liftgate open, keep the vents open so outside air comes into the vehicle. CARGO MANAGEMENT SYSTEM (IF EQUIPPED) The cargo management system consists of a storage compartment located in the floor of the rear cargo...
  • Page 102 Driver Controls To move the shelf to the divider position, pull up and pivot the shelf over the channels on the side trim panels and snap vertically in place. Do not load any objects on the shelf that may obstruct your vision or strike occupants of the vehicle in the case of a sudden stop or collision.
  • Page 103 Always ensure that the load is secure before traveling. Ford Motor Company recommends loading the roof rack only when equipped with (optional) crossbars, to avoid unintended damage to the roof panel.

  • Page 104: Locks And Security

    Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your authorized dealer supplied keys, replacement keys are available through your authorized dealer.
  • Page 105 Locks and Security The autolock feature repeats when: • any door is opened then closed while the ignition is in the 3 (ON) position and the vehicle speed is 9 mph (15 km/h) or lower, and • the vehicle attains a speed greater than 12 mph (20 km/h). Deactivating/activating autolock Your vehicle comes with the autolock feature enabled.
  • Page 106 Locks and Security Keyless entry key pad procedure 1. Turn the ignition to the 1 (OFF/LOCK) position. 2. Close all doors, the liftgate and liftgate window. 3. Enter 5–digit entry code 4. Press and hold the 3 • 4. While holding the 3 • 4 press the 7 • 8. 5.
  • Page 107 Locks and Security Power door unlock/lock procedure You must complete Steps 1-5 within 30 seconds or the procedure will have to be repeated. If the procedure needs to be repeated, you must wait 30 seconds. Note: All doors must be closed and remain closed throughout the configuration process.

  • Page 108: Anti-Theft System

    Locks and Security CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
  • Page 109 Locks and Security Unlocking the doors/liftgate Press this control to unlock the driver’s door. The interior lamps will illuminate with the ignition is in the 1 (OFF/LOCK) position. Press the control a second time within three seconds to unlock all doors and liftgate.
  • Page 110 Locks and Security Sounding a panic alarm Press this control to activate the alarm. The personal panic alarm will cycle the horn and parking lamps on/off. To deactivate the alarm, press the control again or turn the ignition to the 2 (ACCESSORY) or 3 (ON) position.
  • Page 111 Locks and Security Deactivating the memory seat feature To deactivate this feature: 1. Press the SET control on the driver’s door panel. 2. Within 5 five seconds, press any control on the remote transmitter which you would like to deactivate and then press the SET control on the driver’s door panel.
  • Page 112 Locks and Security Note: Replacement of the battery will not cause the remote transmitter to become deprogrammed from your vehicle. The remote transmitter should operate normally after battery replacement. Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: •...
  • Page 113 Locks and Security Illuminated entry The lamps illuminate when the remote entry system is used to unlock the door(s). The system automatically turns off after 25 seconds or when the ignition is turned to the 2 (ACCESSORY) or 3 (ON) position. The dome lamp control must not be set to the off position for the illuminated entry system to operate.
  • Page 114 The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. 2007 Expedition (exd)
  • Page 115 Locks and Security Theft indicator The theft indicator is located in the instrument cluster. • When the ignition is in the 1 (OFF/LOCK) position, the indicator will flash once every 2 seconds to indicate the SecuriLock system is functioning as a theft deterrent. •...
  • Page 116 Check to make sure the coded key is an approved Ford coded key. If your keys are lost or stolen you will need to do the following: •...
  • Page 117 Locks and Security 1. Insert the first previously programmed coded key into the ignition and turn the ignition from the 1 (OFF/LOCK) to the 3 (ON) position [maintain ignition in 3 (ON) for at least three seconds, but no more than ten seconds]. 2.

  • Page 118: Seating And Safety Restraints

    Seating and Safety Restraints SEATING Front row adjustable head restraints Your vehicle’s seats are equipped with two-way adjustable head restraints. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
  • Page 119 Seating and Safety Restraints Lift handle to move seat forward or backward. Manual seat recliner (if equipped) Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
  • Page 120 Seating and Safety Restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support (if equipped) The lumbar support control is located on the outboard side of the seat. Turn the lumbar support control clockwise for more support.
  • Page 121 Seating and Safety Restraints Using the power lumbar support (if equipped) The power lumbar control is located on the outboard side of the seat. Press the forward side of the control for additional support. Press the rear side of the control to reduce support.
  • Page 122 Seating and Safety Restraints Move the switch in the direction of the arrows to raise or lower the rear portion of the seat cushion. Press the switch in the direction of the arrows to move the seat forward, backward, up or down. Press the control to recline the seatback forward or rearward.
  • Page 123 Seating and Safety Restraints Memory seats/power mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, power mirrors, and adjustable pedals to two programmable positions. The memory seat control is located on the outboard side of the seat cushion.
  • Page 124 Seating and Safety Restraints Climate controlled seats air filter replacement (if equipped) The climate controlled seat system includes air filters that must be replaced periodically. Refer to the Scheduled Maintenance Guide for more information. • There is a filter located under each front seat.
  • Page 125 Seating and Safety Restraints To install a filter: • First, position the filter in it’s housing making sure that the far forward end is all the way up in the housing. Then push in on the center of the outside edge of the filter and rotate up into the housing until it clips into position.
  • Page 126 Seating and Safety Restraints 2. Locate handle on the side of the seat cushion by the door. 3. Pull up on the handle and push the seatback forward toward the front of the vehicle. To return the seat to the upright position: 1.
  • Page 127 Seating and Safety Restraints Placing the 2nd row outboard 40% seats in cargo mode Use caution when folding the seatback to the flat back position as the system will move forward when you lift the release handle. The 2nd row seats can be placed in a kneel down load floor position to allow more cargo space.
  • Page 128 Seating and Safety Restraints Adjusting the 2nd row outboard 40% seat for E-Z Entry The E-Z entry seat allows for easier entry and exit to and from the 3rd row seat. To enter the 3rd row seat: 1. Fold down the 2nd row seat and release the handle. 2.
  • Page 129 Seating and Safety Restraints Exiting the 3rd row 1. Pull the strap located at the bottom outboard of the seat back to release the seat from the floor, and rotate the seat up towards the front seat. 2. Follow the directions above to return the seat from the E-Z entry and to the upright position.
  • Page 130 Seating and Safety Restraints To prevent possible damage to the seat or safety belts, ensure that the safety belts are not buckled when moving the seat to the load floor position. 2. With the latch released the seatback can be lowered into the load floor position.
  • Page 131 Seating and Safety Restraints Adjusting the 2nd row center 20% seat (if equipped) Lift the handle to move the seat forward or backward. Note: This seat can be moved forward to keep a child in a child restraint close to the front seat occupants. The seat should be moved to the full rearward position when it is occupied by older children or adults.
  • Page 132 Seating and Safety Restraints Pull up on the handle located behind the seatback while pushing the seatback forward and down into the seat cushion. To return the seatback to its original position lift the seatback until it latches into place. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback.

  • Page 133: Safety Restraints

    Seating and Safety Restraints Push the bottom portion of the control button to lower the desired seatback. Push the top of the control button to return the seatback to its original position. The power fold down seats will operate for 30 minutes after the ignition switch is in Off.
  • Page 134 Seating and Safety Restraints Your vehicle’s Personal Safety System consists of: • Driver and passenger dual-stage airbag supplemental restraints. • Front safety belts with pretensioners, energy management retractors, and safety belt usage sensors. • Driver’s seat position sensor. • Front crash severity sensor. •...
  • Page 135 Seating and Safety Restraints allows your Personal Safety System to distinguish between different levels of crash severity and modify the deployment strategy of the dual-stage airbags and safety belt pretensioners. Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System tailor the deployment level of the driver dual-stage airbag based on seat position.
  • Page 136 Seating and Safety Restraints safety belt pretensioners, front safety belt buckle sensors, and the driver seat position sensor. In addition, the RCM also monitors the restraints warning light in the instrument cluster. A difficulty with the system is indicated by one or more of the following: •...
  • Page 137 Seating and Safety Restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
  • Page 138 Seating and Safety Restraints 2. To unfasten, push the release button and remove the tongue from the buckle. • Front and rear seats All safety restraints in the vehicle are combination lap and shoulder belts except for the front row center lap belt (if equipped). Front center lap belt To fasten the front center lap belt, insert the tongue into the center...
  • Page 139 Seating and Safety Restraints Automatic locking mode In this mode, the shoulder belt is pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to use the automatic locking mode •...
  • Page 140 Seating and Safety Restraints After any vehicle collision, the combination lap and shoulder belt system at all passenger seating positions must be checked by an authorized dealer to verify that the “automatic locking retractor” feature for child seats is still functioning properly, in addition to other checks for proper safety belt system function.
  • Page 141 Seating and Safety Restraints Safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and right front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, squeeze the side release buttons with your thumb and finger and slide the height adjuster down.
  • Page 142 Seating and Safety Restraints To adjust the comfort guide: 1. Slip the shoulder belt into the belt guide. (The portion of the belt between the latch tongue and the D-ring, not the portion where the belt exits from the quarter trim panel.) 2.
  • Page 143 (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
  • Page 144 Seating and Safety Restraints BeltMinder The BeltMinder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders to the driver that the driver’s safety belt is unbuckled by intermittently sounding a chime and illuminating the safety belt warning lamp in the instrument cluster.
  • Page 145 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given... Consider... “Crashes are rare events” 36 700 crashes occur every day. The more we drive, the more we are exposed to “rare”...
  • Page 146 Seating and Safety Restraints Reasons given... Consider... “I have an airbag” Airbags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. “I’d rather be thrown clear” Not a good idea. People who are ejected are 40 times more likely to DIE.

  • Page 147: Airbags

    Seating and Safety Restraints 2. Wait until the safety belt warning light turns off. (Approximately 1 minute) • Step 3 must be completed within 50 seconds after the safety belt warning light turns off. 3. At a moderate speed, buckle then unbuckle the safety belt 9 times, ending in the unbuckled state.
  • Page 148 Seating and Safety Restraints Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
  • Page 149 Seating and Safety Restraints Do not attempt to service, repair, or modify the airbag supplemental restraint systems or its fuses. See your authorized dealer. The front passenger airbag is not designed to offer protection to an occupant in the center front seating position. Modifying or adding equipment to the front end of the vehicle (including frame, bumper, front end body structure and tow hooks) may affect the performance of the airbag system, increasing the...
  • Page 150 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates airbag inflation. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
  • Page 151 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the airbag has deployed, the airbag will not function again and must be replaced immediately. If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 152 Seating and Safety Restraints Seat-mounted side airbag system (if equipped) Do not place objects or mount equipment on or near the airbag cover on the side of the seatbacks of the front seats or in front seat areas that may come into contact with a deploying airbag. Failure to follow these instructions may increase the risk of personal injury in the event of a collision.
  • Page 153 Seating and Safety Restraints The side airbag system consists of the following: • An inflatable nylon bag (airbag) with an inflator concealed behind the outboard bolster of the driver and front passenger seatbacks. • A special seat cover designed to allow airbag deployment.
  • Page 154 Seating and Safety Restraints If the side airbag has deployed, the airbag will not function again. The side airbag system (including the seat) must be inspected and serviced by an authorized dealer . If the airbag is not replaced, the unrepaired area will increase the risk of injury in a collision.
  • Page 155 Seating and Safety Restraints How does the Safety Canopy system work? The design and development of the Safety Canopy system included recommended testing procedures that were developed by a group of automotive safety experts known as the Side Airbag Technical Working Group.
  • Page 156 Seating and Safety Restraints The Safety Canopy is mounted to roof side-rail sheet metal, behind the headliner, along the entire side of the vehicle. In certain lateral collisions or rollover events, the Safety Canopy system will be activated, regardless of which seats are occupied. The Safety Canopy is designed to inflate between the side window area and occupants to further enhance protection provided in side impact collisions and rollover events.

  • Page 157: Child Restraints

    Seating and Safety Restraints • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired. If any of these things happen, even intermittently, have the SRS serviced at authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision or rollover event.
  • Page 158 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
  • Page 159 Seating and Safety Restraints • Is the shoulder belt centered on the shoulder and chest? • Can the child stay seated like this for the whole trip? Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder...
  • Page 160 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
  • Page 161 Seating and Safety Restraints Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child.
  • Page 162 80 pounds (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors.
  • Page 163 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
  • Page 164 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is pulled out and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
  • Page 165 Seating and Safety Restraints Installing child safety seats in the center front seating position (if equipped) Always transport children 12 years old and under in the rear seats and always properly use appropriate child restraints. It is safer to install child safety seats in seating positions that have child seat anchors.
  • Page 166 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): • Second row bench seat • Second row bucket seats Attach the tether strap only to the appropriate tether anchor as shown.
  • Page 167 Seating and Safety Restraints • center seating position (if equipped) 3. Route the child safety seat tether strap under the head restraint (outboard seats) and over the back of the seat. 4. Grasp the tether strap and position it to the seat frame. 5.
  • Page 168 Seating and Safety Restraints 6. Rotate the tether strap clip. 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions. Third row seating position 1. Position the child safety seat on the center of the seat cushion. 2.
  • Page 169 Seating and Safety Restraints 4. Clip the tether strap through the anchor loop as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 5. Install the child safety seat tightly using the LATCH anchors or safety belts.
  • Page 170 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol: Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
  • Page 171 Seating and Safety Restraints Attach LATCH lower attachments of the child seat only to the anchors shown. If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the vehicle seat cushion when the child is seated in it.

  • Page 172: Tires, Wheels And Loading

    Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
  • Page 173 Tires, Wheels and Loading Power is supplied to all four wheels through a transfer case or power transfer unit. 4WD vehicles allow you to select different drive modes as necessary. Information on transfer case operation and shifting procedures can be found in the Driving chapter.

  • Page 174: Tire Information

    10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
  • Page 175 Tires, Wheels and Loading Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
  • Page 176 Tires, Wheels and Loading TIRES Tires are designed to give many thousands of miles of service, but they must be maintained in order to get the maximum benefit from them. Glossary of tire terminology • Tire label: A label showing the OE (Original Equipment) tire sizes, recommended inflation pressure and the maximum weight the vehicle can carry.

  • Page 177: Tire Inflation

    (if equipped), at least monthly and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate. Ford recommends the use of a digital or dial-type tire pressure gauge rather than a stick-type tire pressure gauge.
  • Page 178 Tires, Wheels and Loading Label which is located on the B-Pillar or the edge of the driver’s door. The cold inflation pressure should never be set lower than the recommended pressure on the Safety Compliance Certification Label or Tire Label. When weather temperature changes occur, tire inflation pressures also change.
  • Page 179 Tires, Wheels and Loading TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves. Check for holes or cuts that may permit air leakage from the tire and make necessary repairs.
  • Page 180 Tires, Wheels and Loading Tires degrade over time depending on many factors such as weather, storage conditions, and conditions of use (load, speed, inflation pressure, etc.) the tires experience throughout their lives. In general, tires should be replaced after six years regardless of tread wear.
  • Page 181 Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door. If this information is not found on these labels then you should consult your Ford dealer. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
  • Page 182 The tire pressure sensors mounted in the wheels (originally installed on your vehicle) are not designed to be used in aftermarket wheels. The use of wheels or tires not recommended by Ford Motor Company may affect the operation of your Tire Pressure Monitoring System.
  • Page 183 Tires, Wheels and Loading Tire and wheel alignment A bad jolt from hitting a curb or pothole can cause the front end of your vehicle to become misaligned or cause damage to your tires. If your vehicle seems to pull to one side when you’re driving, the wheels may be out of alignment.
  • Page 184 Tires, Wheels and Loading Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation. Note: Your vehicle may be equipped with a dissimilar spare tire/wheel. A dissimilar spare tire/wheel is defined as a spare tire and/or wheel that is different in brand, size or appearance from the road tires and wheels.
  • Page 185 Tires, Wheels and Loading 4. R: Indicates a “radial” type tire. 5. 15: Indicates the wheel or rim diameter in inches. If you change your wheel size, you will have to purchase new tires to match the new wheel diameter. 6.
  • Page 186 Tires, Wheels and Loading 8. U.S. DOT Tire Identification Number (TIN): This begins with the letters “DOT” and indicates that the tire meets all federal standards. The next two numbers or letters are the plant code designating where it was manufactured, the next two are the tire size code and the last four numbers represent the week and year the tire was built.
  • Page 187 Tires, Wheels and Loading 13. Maximum Permissible Inflation Pressure: Indicates the tire manufacturers’ maximum permissible pressure and/or the pressure at which the maximum load can be carried by the tire. This pressure is normally higher than the manufacturer’s recommended cold inflation pressure which can be found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
  • Page 188 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.

  • Page 189: Tire Pressure Monitoring System (Tpms)

    Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
  • Page 190 Tires, Wheels and Loading Changing tires with TPMS Each road tire is equipped with a tire pressure sensor fastened to the inside rim of the wheel. The pressure sensor is covered by the tire and is not visible unless the tire is removed. The pressure sensor is located opposite (180 degrees) from the valve stem.
  • Page 191 Tires, Wheels and Loading When you believe your system is not operating properly The main function of the Tire Pressure Monitoring System is to warn you when your tires need air. It can also warn you in the event the system is no longer capable of functioning as intended.
  • Page 192 Tires, Wheels and Loading Low Tire Pressure Possible cause Customer Action Required Warning Light Flashing Warning Spare tire in use Your temporary spare tire is in Light use. Repair the damaged road wheel and re-mount it on the vehicle to restore system functionality.

  • Page 193: Vehicle Loading

    Follow these guidelines when using snow tires and chains: • Use only cable type chains or chains offered by Ford as an accessory or equivalent. Other conventional link type chains may contact and cause damage to the vehicle’s wheel house and/or body.
  • Page 194 Tires, Wheels and Loading your vehicle, familiarize yourself with the following terms for determining your vehicle’s weight ratings, with or without a trailer, from the vehicle’s Tire Label or Safety Compliance Certification Label: Base Curb Weight – is the weight of the vehicle including a full tank of fuel and all standard equipment.
  • Page 195 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
  • Page 196 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
  • Page 197 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
  • Page 198 Tires, Wheels and Loading Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the originals do not increase the GVWR and GAWR limitations. Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury.
  • Page 199 Tires, Wheels and Loading • A final example for your vehicle with 1400 lb. (635 kg) of cargo and luggage capacity. You and one of your friends decide to pick up cement from the local home improvement store to finish that patio you have been planning for the past 2 years.

  • Page 200: Trailer Towing

    Tires, Wheels and Loading TRAILER TOWING Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires, and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing. Follow these guidelines to ensure safe towing procedure: •...
  • Page 201 Tires, Wheels and Loading Note: Before towing a trailer, make sure the trailer brakes (if equipped) and lamps are properly connected and functional. Electronic trailer brakes (if equipped) refer to the instructions provided by the aftermarket electronic brake controller manufacture for determining trailer brake functionality.
  • Page 202 Tires, Wheels and Loading Trailer weight Rear axle Maximum GCWR - Engine range (0 - ratio lb. (kg) maximum) lb. (kg) Expedition EL (U.S. Only) Expedition Max (Canada Only) 4x2 5.4L with standard 12200 (5534) 0–6000 (0–2721) trailer tow package 5.4L with optional 15000 (6804)
  • Page 203 Tires, Wheels and Loading Integrated hitch rating The standard integrated hitch has two ratings depending on mode of operation: • Weight carrying - requires a draw bar and hitch ball. The draw bar supports all the vertical tongue load of the trailer. •...
  • Page 204 Tires, Wheels and Loading 2. Turn the air suspension (if equipped) control to OFF. 3. Measure the height of a reference point on the front and rear bumpers at the center of the vehicle. 4. Attach the trailer to the vehicle and adjust the hitch equalizers so that the front bumper height is within a ⁄...
  • Page 205 Tires, Wheels and Loading Driving while you tow When towing a trailer: • Keep your speed no faster than 70 mph (112 km/h) during the first 500 miles (800 km) of towing a trailer, and don’t make full throttle starts. •...

  • Page 206: Recreational Towing

    Tires, Wheels and Loading • If you will be towing a trailer frequently in hot weather, hilly conditions, at GCWR, or any combination of these factors, consider refilling your rear axle with synthetic gear lube if not already so equipped. Refer to the Maintenance and Specifications chapter for the lubricant specification.
  • Page 207 If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, the drive shaft will have to be removed before the vehicle is towed. Ford recommends the driveshaft be removed/installed only by a qualified technician at an authorized dealer. See your authorized dealer for driveshaft removal/installation.

  • Page 208: Driving

    Driving STARTING Positions of the ignition 1. OFF/LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 3. ON, all electrical circuits operational.
  • Page 209 Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions A computer system controls the engine’s idle revolutions per minute (RPM). When the engine starts, the idle RPM runs higher than normal in order to warm the engine.
  • Page 210 Driving 4. Make sure the parking brake is set. 5. Turn the key to 3 (ON) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights.
  • Page 211 Driving 3. After idling for a few seconds, apply the brake, shift into gear and drive. Note: If the engine does not start within five seconds on the first try, turn the key to OFF, wait 10 seconds and try again. If the engine still fails to start, press the accelerator to the floor and try again;...

  • Page 212: Brakes

    Driving a 110 volt grounded outlet. Be sure to re-attach the cap onto the plug when the heater is not in use. To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters.
  • Page 213 Driving The ABS operates by detecting the onset of wheel lockup during brake applications and compensates for this tendency. The wheels are prevented from locking even when the brakes are firmly applied. Using ABS • In an emergency or when maximum efficiency from the four-wheel ABS is required, apply continuous force on the brake.
  • Page 214 Driving Parking brake Apply the parking brake whenever the vehicle is parked. To set the parking brake, press the parking brake pedal down until the pedal stops. The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the parking brake is released.

  • Page 215: Traction Control™/Advancetrac

    Driving Pull the release lever to release the brake. Driving with the parking brake on will cause the brakes to wear out quickly and reduce fuel economy. ADVANCETRAC WITH ROLL STABILITY CONTROL (RSC) STABILITY ENHANCEMENT SYSTEM (IF EQUIPPED) The AdvanceTrac with RSC system provides stability enhancement features such as Roll Stability Control (RSC), Electronic Stability Control (ESC) and Traction Control (TCS) for certain driving situations.
  • Page 216 Driving If your vehicle should become stuck in deep snow or mud, try switching the AdvanceTrac with RSC system off by pressing the AdvanceTrac with RSC button momentarily. This will allow your tires to “dig” for traction. If the AdvanceTrac with RSC system is activated excessively in a short period of time, the brake portion of the system will disable to allow the brakes to cool down.
  • Page 217 Driving • Driving on slick surfaces. • Cornering while towing a heavily loaded trailer (refer to Trailer towing in the Tires, Wheels and Loading chapter.) Roll Stability Control (RSC) The RSC system works in conjunction with the AdvanceTrac system to help maintain roll stability of the vehicle during aggressive maneuvers by applying brake force to one or more wheels.
  • Page 218 Driving If the vehicle is above 25 mph (40 km/h), momentarily pressing the AdvanceTrac with RSC button will steadily illuminate the “sliding car” icon, however, the AdvanceTrac with RSC system will remain enabled until the vehicle speed drops below 25 mph. If the vehicle speed decreases below 25 mph (40 km/h), the system will become deactivated, but if the vehicle speed subsequently increases to above 25 mph (40 km/h), the system will again become active.
  • Page 219 Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of a AdvanceTrac with RSC event is an indication that at least some of the tires have exceeded their ability to grip the road;...

  • Page 220: Air Suspension

    Driving • Wheels out of alignment • Loose or worn suspension components Variable assist steering Your vehicle is equipped with variable assist power steering. At low engine RPM, steering assist will adjust to reduce efforts and improve low speed maneuverability. At high engine RPM, the assist will adjust to improve steering feel at high speeds.
  • Page 221 Driving LIMITED-SLIP AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface. Under normal conditions, the limited slip axle functions like a standard rear axle. Extended use of other than the manufacturer’s specified size tires on a limited slip rear axle could result in a permanent reduction in effectiveness.

  • Page 222: Transmission Operation

    Driving Use extra caution while becoming familiar with your vehicle. Know the capabilities and limitations of both you as a driver and your vehicle. AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock – column-shift transmission This vehicle is equipped with a park/brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed.
  • Page 223 Driving Do not drive your vehicle until you verify that the brakelamps are working. Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
  • Page 224 Driving 5. Start the vehicle and release the parking brake. Do not drive your vehicle until you verify that the brakelamps are working. Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle.
  • Page 225 Driving • Move the gearshift lever into the desired gear. If your vehicle is equipped with a floor-shift transmission, press the gearshift lever release button (on the front of the lever) while shifting into the desired gear. To put your vehicle in P (Park): •...
  • Page 226 Driving • Floor-shift transmission Transmission operates in gears one through four except in 4L where transmission operates in gears two through six. • This position allows for all forward gears, 1–4; 5th and 6th gear are not available. • Provides engine braking. •...
  • Page 227 Driving 1 (First) • Transmission operates in 1st gear only. • Provides maximum engine braking. • Allows upshifts by moving gearshift lever. • Will not downshift into 1 (First) at high speeds; allows for 1 (First) when vehicle reaches slower speeds. Forced downshifts •...
  • Page 228 Driving This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting objects to avoid damaging the vehicle. The system may not detect smaller objects, particularly those close to the ground.
  • Page 229 Driving Audible Warnings Distance to Object Warning Speed above 2.5 mph (4 km/h) up to 1.6 feet (.5 meters) Solid 1.6 feet (.5 meters) to 3.1 feet (1 meter) Fast beep 3.1 feet (1 meter) to 5.7 feet (1.8 meters) Medium/fast beep 5.7 feet (1.8 meters) to 9 feet (2.8 meters) Medium beep...
  • Page 230 Driving CONTROL TRAC FOUR-WHEEL DRIVE (4X4) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. If equipped with the Control Trac 4x4 System, and 4L (4x4 LOW) is selected while the vehicle is moving, the system will not engage.
  • Page 231 Driving Positions of the Control Trac system The Control Trac system functions in four modes: • 2H (2WD) delivers power to the rear wheels only. This is appropriate for normal on-road driving on dry pavement. • 4A (4X4 AUTO) provides electronic control four-wheel drive with power delivered to all four wheels, as required, for...
  • Page 232 Driving Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions. Avoid sharp turns or abrupt maneuvers in these vehicles.
  • Page 233 Driving The AdvanceTrac with RSC stability enhancement system can be turned off manually by pressing the AdvanceTrac with RSC button (refer to AdvanceTrac with Roll Stability Control (RSC) Stability Enhancement System in this chapter) while operating in 2H, 4A or 4H while driving in deep sand, very deep snow or more strenuous off-road maneuvers.
  • Page 234 Driving • It often may be less risky to strike small objects, such as highway reflectors, with minor damage to your vehicle rather than attempt a sudden return to the pavement which could cause the vehicle to slide sideways out of control or roll over. Remember, your safety and the safety of others should be your primary concern.
  • Page 235 Driving Emergency maneuvers • In an unavoidable emergency situation where a sudden sharp turn must be made, remember to avoid “over-driving” your vehicle, i.e., turn the steering wheel only as rapidly and as far as required to avoid the emergency. Excessive steering will result in less vehicle control, not more.
  • Page 236 Driving Normal characteristics On some four–wheel drive models, the initial shift from two-wheel drive to four–wheel drive while the vehicle is moving can cause some momentary clunk and ratcheting sounds. This is the front drivetrain coming up to speed and engaging the front wheels, and is not cause for concern.
  • Page 237 Ford Motor Company joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
  • Page 238 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral; instead, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
  • Page 239 Ford Motor Company recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).

  • Page 240: Roadside Emergencies

    36,000 miles (60,000 km), whichever occurs first on Ford and Mercury vehicles, and four years or 50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start •...

  • Page 241: Hazard Flasher Switch

    1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1–800–241–3673;...

  • Page 242: Fuel Pump Shut-Off Switch

    Roadside Emergencies FUEL FUEL PUMP SHUT-OFF SWITCH RESET The fuel pump shut-off switch is a device intended to stop the electric fuel pump when your vehicle has been involved in a substantial jolt. After a collision, if the engine cranks but does not start, the fuel pump shut-off switch may have been activated.

  • Page 243: Fuses And Relays

    Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
  • Page 244 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located under the right-hand side of the instrument panel. To remove the trim panel for access to the fuse box, pull the panel toward you and swing it out away from the side and remove it.
  • Page 245 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Smart window #1 Driver side module, CHMSL brake on/off Smart window #2 Keypad illumination, 3rd row seat enable, Brake Shift Interlock (BSI), SPDJB, TPMS initiators Turn signals Low beam headlamps (left) Low beam headlamps (right) Interior lights Backlighting, Cargo lamps, Puddle...
  • Page 246 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Horn relay Demand lamps Instrument panel cluster Ignition switch Radio Instrument panel cluster Not used (Spare) Compass, Automatic dimming rear view mirror Restraints control module Ebrake Not used (spare) Rear park assist, 4x4 PATS transceiver Climate control...
  • Page 247 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
  • Page 248 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — Not used 40A** Heated/cooled seats 60A** ABS (pump) 20A** Rear console power point 30A** Auxiliary blower 25A* Trailer tow connector (park lamps) 30A * Trailer tow connector (battery charge) —...
  • Page 249 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 25A* Trailer tow connector (stop/turn lamps) 20A* 4x4 module 10A* Powertrain Control Module (PCM) – Keep alive power, Canister vent 15A* Transmission B+ 30A** Third row seats (passenger side) 50A** Air suspension pump 30A**...

  • Page 250: Changing Tires

    Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — A/C clutch diode — Fuel pump diode 15A* Trailer tow connector (back-up lamp) — Not used 10A* Air suspension logic — Not used 10A* Blower coil — Not used 30A* Run/Start –...
  • Page 251 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
  • Page 252 Roadside Emergencies Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs •...
  • Page 253 Roadside Emergencies Spare tire information Note: If your vehicle is equipped with the tire pressure monitoring system (TPMS), the system indicator light will illuminate when the spare is in use. To restore the full functionality of the TPMS system, all road wheels equipped with the tire pressure monitoring sensors must be mounted on the vehicle If your vehicle is equipped with TPMS, have a flat tire serviced by an...
  • Page 254 Roadside Emergencies Removing the spare tire 1. Fold the rear seat down. Refer to Rear seats in the Seating and safety restraints chapter. 2. Remove the jack handle and winch extension from the tray and assemble them. 3. Open the spare tire winch access plug in the bottom of the compartment located behind the 3rd row seat, very close to the jack and...
  • Page 255 Roadside Emergencies 1. Park on a level surface, activate hazard flashers and set the parking brake. 2. Place gearshift lever in P (Park), turn engine OFF and block the wheels (both front or both rear) on the opposite end of the vehicle from the wheel being changed.
  • Page 256 Roadside Emergencies 6. Position the jack according to the jack locator arrows found on the frame and turn the jack handle and extension tool assembly clockwise. Note: Use the frame rail as the jacking location point, NOT the control arm. 7.
  • Page 257 Roadside Emergencies To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire. •...
  • Page 258 Roadside Emergencies Stowing the spare tire 1. Lay the tire on the ground, near the rear of the vehicle, with the valve stem side facing up. 2. Slide the wheel partially under the vehicle and install the retainer through the wheel center. If equipped, you may have to remove the wheel center cap prior to pushing the retainer through the...

  • Page 259: Lug Nut Torque

    M14 x 2.0 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
  • Page 260 Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the automatic transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
  • Page 261 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2007 Expedition (exd) Owners Guide (post-2002-fmt) USA (fus)
  • Page 262 Roadside Emergencies 4. Make the final connection of the negative (-) cable to the jump starting stud located in the rear of the engine compartment, behind the battery. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
  • Page 263 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the jump starting stud. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2007 Expedition (exd) Owners Guide (post-2002-fmt) USA (fus)
  • Page 264 Roadside Emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 2007 Expedition (exd) Owners Guide (post-2002-fmt) USA (fus)
  • Page 265 Roadside Emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.

  • Page 266: Wrecker Towing

    It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. Also, wrecker towing the vehicle by the frame-mounted tow hooks is not recommended or advised.
  • Page 267 • Do not exceed a distance of 50 miles (80 km). • Do not exceed 35 mph (56 km/h) vehicle speed. Ford Motor Company produces a towing manual for all authorized tow truck operators. Have your tow truck operator refer to this manual for proper hook-up and towing procedures for your vehicle.

  • Page 268: Customer Assistance

    Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
  • Page 269 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
  • Page 270 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
  • Page 271 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
  • Page 272 (CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
  • Page 273 Customer Assistance If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your authorized dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.

  • Page 274: Reporting Safety Defects (U.s. Only)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. 2007 Expedition (exd)

  • Page 275: Reporting Safety Defects (Canada Only)

    Customer Assistance To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153); go to http://www.safercar.gov; or write to: Administrator NHTSA 400 Seventh Street, SW Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from http://www.safercar.gov.

  • Page 276: Cleaning

    Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
  • Page 277 Cleaning WAXING Applying Motorcraft Paint Sealant (ZC-45) to your vehicle every six months will assist in reducing minor scratches and paint damage. • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
  • Page 278 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
  • Page 279 Cleaning WINDOWS AND WIPER BLADES The windshield, rear and side windows and the wiper blades should be cleaned regularly. If the wipers do not wipe properly, substances on the vehicle’s glass or the wiper blades may be the cause. These may include hot wax treatments used by commercial car washes, water repellant coatings, tree sap, or other organic contamination;...
  • Page 280 Cleaning Do not use chemical solvents or strong detergents when cleaning the steering wheel or instrument panel to avoid contamination of the airbag system. • Be certain to wash or wipe your hands clean if you have been in contact with certain products such as insect repellent and suntan lotion in order to avoid possible damage to the interior painted surfaces.
  • Page 281 Cleaning For King Ranch Expedition leather seats, refer to separate section in this chapter. • To clean, use a soft cloth with Motorcraft Deluxe Leather and Vinyl Cleaner (ZC-11–A). Dry the area with a soft cloth. • To help maintain its resiliency and color, use the Motorcraft Deluxe Leather Care Kit (ZC-11–D), available from your authorized dealer.
  • Page 282 FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
  • Page 283 Cleaning and appearance of your vehicle. Each product is made from high quality materials that meet or exceed rigid specifications. For best results, use the following products or products of equivalent quality: Motorcraft Bug and Tar Remover (ZC-42) Motorcraft Car Care Kit (ZC-26) Motorcraft Car Wash (Canada only) (CXC-21) Motorcraft Custom Bright Metal Cleaner (ZC-15) Motorcraft Custom Clear Coat Polish (ZC–8–A)

  • Page 284: Maintenance And Specifications

    Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide/Owner Information Guide to find out which parts and services are covered.

  • Page 285: Engine Compartment

    Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom of the instrument panel. 2. Go to the front of the vehicle and release the auxiliary latch that is located under the front center of the hood.
  • Page 286 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
  • Page 287 Maintenance and Specifications CHANGING THE WIPER BLADES It is recommended that wiper blades are renewed before winter. To replace the wiper blades: 1. Fold back the wiper arm and position the wiper blade at right angles to the wiper arm. 2.

  • Page 288: Engine Oil

    Maintenance and Specifications ENGINE OIL Checking the engine oil Refer to the scheduled maintenance information for the appropriate intervals for checking the engine oil. 1. Make sure the vehicle is on level ground. 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan.
  • Page 289 Maintenance and Specifications • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. • Do not overfill the engine with oil. Oil levels above this mark may cause engine damage. If the engine is overfilled, some oil must be removed from the engine by an authorized dealer.
  • Page 290 Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.

  • Page 291: Battery

    Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
  • Page 292 Maintenance and Specifications Keep batteries out of reach of children. Batteries contain sulfuric acid. Avoid contact with skin, eyes or clothing. Shield your eyes when working near the battery to protect against possible splashing of acid solution. In case of acid contact with skin or eyes, flush immediately with water for a minimum of 15 minutes and get prompt medical attention.

  • Page 293: Engine Coolant

    Maintenance and Specifications 7. Drive the vehicle to complete the relearning process. • The vehicle may need to be driven 10 miles (16 km) or more to relearn the idle and fuel trim strategy. • If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned.
  • Page 294 Maintenance and Specifications • Enables calibrated gauges to work properly. When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
  • Page 295 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine Coolant or any orange-colored extended life product with your factory filled coolant can result in degraded corrosion protection.
  • Page 296 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
  • Page 297 Maintenance and Specifications Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Maintenance product specifications and capacities in this chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this section. Severe climates If you drive in extremely cold climates (less than –34°...
  • Page 298 Maintenance and Specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The symbol will illuminate. • The indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.

  • Page 299: Fuel Information

    Maintenance and Specifications FUEL FILTER For fuel filter replacement, see your authorized dealer. Refer to scheduled maintenance information for the appropriate intervals for changing the fuel filter. Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used.
  • Page 300 Maintenance and Specifications • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury. If fuel is swallowed, call a physician immediately, even if no symptoms are immediately apparent.
  • Page 301 Maintenance and Specifications Refueling Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
  • Page 302 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
  • Page 303 Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the Right Fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
  • Page 304 Maintenance and Specifications If you have run out of fuel: • You may need to cycle the ignition from OFF to ON several times after refueling to allow the fuel system to pump the fuel from the tank to the engine. On restarting, cranking time will take a few seconds longer than normal.
  • Page 305 Maintenance and Specifications • Use the same filling rate setting (low — medium — high) each time the tank is filled. • Allow no more than two automatic click-offs when filling. • Always use fuel with the recommended octane rating. •...
  • Page 306 Maintenance and Specifications • Idling for long periods of time (greater than one minute) may waste fuel. • Anticipate stopping; slowing down may eliminate the need to stop. • Sudden or hard accelerations may reduce fuel economy. • Slow down gradually. •...
  • Page 307 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
  • Page 308 Maintenance and Specifications Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Illumination of the indicator, charging system warning light or the temperature warning light, fluid leaks, strange odors, smoke or loss of engine power could indicate that the emission control system is not working properly.
  • Page 309 Maintenance and Specifications These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel, properly tightening the fuel cap or letting the electrical system dry out. After three driving cycles without these or any other temporary malfunctions present, the indicator should stay off the next time the engine is started.
  • Page 310 Maintenance and Specifications Allow the vehicle to sit for at least eight hours without starting the engine. Then, start the engine and complete the above driving cycle. The engine must warm up to its normal operating temperature. Once started, do not turn off the engine until the above driving cycle is complete. If the vehicle is still not ready for I/M testing, the above driving cycle will have to be repeated.

  • Page 311: Air Filter(S)

    Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid The automatic transmission does not have a transmission fluid dipstick. Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, (i.e., if the transmission slips or shifts slowly) or if you notice some sign of fluid leakage.
  • Page 312 Maintenance and Specifications 2. Reposition the locking clip on the connector (connector shown from below for clarity), squeeze the connector and pull it off of the air outlet tube. 3. Clean the area around the air tube to air cover connection to prevent debris from entering the system and then loosen the bolt on the air tube clamp so the clamp is...
  • Page 313 Maintenance and Specifications 6. Remove the air filter element from the air filter housing. 7. Install a new air filter element. 8. Replace the air filter housing cover and secure the clamps. Be careful not to crimp the filter element edges between the air filter housing and cover and ensure that the tabs on the edge are properly aligned into the slots.

  • Page 314: Part Numbers

    PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.

  • Page 315: Maintenance Product Specifications And Capacities

    Maintenance and Specifications 2007 Expedition (exd) Owners Guide (post-2002-fmt) USA (fus)
  • Page 316 Maintenance and Specifications 2007 Expedition (exd) Owners Guide (post-2002-fmt) USA (fus)
  • Page 317 Maintenance and Specifications 2007 Expedition (exd) Owners Guide (post-2002-fmt) USA (fus)

  • Page 318: Engine Data

    Maintenance and Specifications ENGINE DATA Engine 5.4L V8 engine Cubic inches Required fuel 87 octane Firing order 1-3-7-2-6-5-4-8 Ignition system Coil on plug Spark plug gap 0.040–0.050 inch (1.02–1.27 mm) Compression ratio 9.85:1 Spark plug gap not adjustable Engine drivebelt routing •...
  • Page 319 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure (B-Pillar) by the trailing edge of the driver’s...
  • Page 320 Maintenance and Specifications The Vehicle Identification Number (VIN) contains the following information: 1. World manufacturer identifier 2. Brake system / Gross Vehicle Weight Rating (GVWR) / Restraint System 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6.

  • Page 321: Accessories

    GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
  • Page 322 Accessories Lifestyle Ash cup / smoker’s package Cargo organization and management Cross bars Towing mirrors Trailer hitches, wiring harnesses and accessories Peace of mind Mobile-Ease hands-free communication system Remote start Vehicle security systems Wheel locks Not all accessories are available for all models. For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...

  • Page 323: Index

    Index refill capacities ......315 ABS (see Brakes) .....212 Accessory delay ......70 Battery ........291 AdvanceTrac ......215 acid, treating emergencies ..291 jumping a disabled battery ..259 Air cleaner filter ....311, 314 maintenance-free ....291 Air suspension ......220 replacement, specifications ...314 description ......220 servicing ........291 Airbag supplemental restraint BeltMinder .......144 system ....147–148, 152, 154...
  • Page 324 ....291 (see Speed control) ....74 lubrication specifications ..315 Customer Assistance ....240 refill capacities ......315 Ford Extended Service Plan ...272 service points ......285 Getting assistance outside starting after a collision ..242 the U.S. and Canada ....273 Engine block heater ....211 Getting roadside assistance ...240...
  • Page 325 Index refill capacities ......315 Gas mileage specifications ......315 (see Fuel economy) ....304 Exhaust fumes ......211 Gauges .........15 Fail safe cooling ......297 Hazard flashers ......241 Floor mats ........96 Headlamps ........52 Fluid capacities ......315 aiming ........54 Foglamps ........52 autolamp system .......52 Four-Wheel Drive vehicles ..230 bulb specifications ....57 control trac ......230 daytime running lights .....53...
  • Page 326 Index Locks autolock ......104, 106 childproof ........108 Jack ..........250 doors ........104 positioning .......250 Lubricant specifications ...315 storage ........250 Lug nuts ........259 Jump-starting your vehicle ..259 Lumbar support, seats ..120–121 Keyless entry system Message center ......85 autolock ......104, 106 english/metric button ....92 keypad ........113 system check button ....92 locking and unlocking doors ..114...
  • Page 327 Index Pedals (see Power adjustable Safety belts (see Safety restraints) ..133, 136–139, 141 foot pedals) .........73 Safety Canopy ......154 Power adjustable foot pedals ..73 Safety defects, reporting ..274–275 Power distribution box (see Fuses) .......244, 247 Safety restraints ..133, 136–141 BeltMinder ......144 Power door locks ......104 extension assembly ....142...
  • Page 328 Index Speed control ......74 wrecker ........266 Starting your vehicle ..208–210 Transmission ......222 jump starting ......259 brake-shift interlock Steering wheel (BSI) ........222–223 controls ........76 fluid, checking and adding tilting .........65 (automatic) ......311 fluid, refill capacities ....315 lubricant specifications ..315 Tilt steering wheel ......65 Trunk .........109 Tire Pressure Monitoring Turn signal ........55...

Table of Contents

Save PDF
