Summary of Contents for Anzzi BA-LMDFX017AL
- Page 3 PRODUCT SIZE CHART BA-LMDFX017AL 32" * 24" 32"[813mm] MOUNTING DIMENSIONS 30.1" [765mm] 1.44" [36.5mm]...
- Page 4 For the style of LED Mirror shown below Please read carefully and save these instructio Don’t discard any of the packaging until you are sure that you have all of the parts and the fittings. DANGER Make sure power to the junction box or outlet is off before commencing installation. Always unplug the mirror from the outlet or turn off the switch before cleaning or servicing to reduce the risk of electric shock.
- Page 5 Do not use attachments that are not recommended by the manufacturer. guide. Statement: ANZZI does not assume any Make sure that the electricity is turned off at the power source before proceeding with the responsibility for the losses caused by the installation or cleaning.
- Page 6 INSTALLATION INSTRUCTIONS SCREW WAL L PLUG Hook Twist-cap Connector (x6) (x6) (x2) (x3) Make sure the holes of template matches the hanging Position Template x1 holes of the mirror. deck surface Measure the distance "h" from the Position Template According to the height "H" of the product, place the to the top of the product.
- Page 7 INSTALLATION INSTRUCTIONS Hook The LED mirror is provided with a power supply cord. For the plug-in connection, hang the mirror to the Hooks If drilling into wood, drill a 1/8” hole at each marked as shown. Then plug the power supply cord into the location (figure A) and secure Hooks with screws.
- Page 8 OPERATION Turn on the power supply before you use the mirror. Press this key to turn the LED light on or off. The defogger operates when the LED light is turned on. Press and hold to change the color temperature from 2700-6500k. It will change gradually(2700-6500k).
