- Page 1 4G LTE + WIFI EXTENDER with TV/AM/FM ANTENNA WF2-85B, WF2-685 WIFI EXTENDER with TV/AM/FM ANTENNA OEM Installation / Operation Manual DOWNLOAD Winegard Connected App FREE DOWNLOAD For help, email help@winegard.com or call 1-800-320-9992 www.winegard.com/connect Register your product at winegard.com/login Place label here 2452403 Rev4-22...
-
Page 2: Table Of Contents
Changes and technological advances are continuously being made in the wireless market. Information provided in this manual was accurate at time of printing. If the ConnecT 2.0 + antenna does not function as expected, please contact Winegard Company at... -
Page 3: Connect 2.0 + Installation
EXTERIOR INSTALLATION Choosing a Location for the Antenna & Power Supply Before mounting the antenna, determine a location for the wall plate/power supply. Front of Vehicle Keep in mind the following: • A coaxial cable will have to run from the power supply to the antenna and from the power supply to each television (up to 4 TVs if using the WP2-600). - Page 4 EXTERIOR INSTALLATION (cont) Option A ConnecT 2.0 + with WP2-600 Wall Plate (cont) Step 13 – You can wire up to 4 TVs with this wall plate. ConnecT each TV to the TV outputs as labeled below. VEHICLE'S ROOF Vehicle's Roof + 12V DC TO PWR + +12V DC TO PWR+ GROUND TO GND-...
- Page 5 Step 7 – Run the coax cable from the ConnecT to the ANT IN input on the standard Winegard wall plate/power supply. Step 8 – There is an option to run a cable to an outside receptacle. If doing so, connect that cable to the PARK CABLE IN input.
-
Page 6: Wifi/4G Operation
Then click SELECT. See figure 2. If you have available data to use, the INTERNET STATUS should display Connected to 4G/LTE “Winegard ConnecT Data Plan”. If you do not have any available data the Figure 3 field will not display Connected. You will have to add data in order to use the 4G connection. -
Page 7: Operating Features
Figure 6 Guest Network The Winegard ConnecT 2.0 + provides a simple way to set up an extra network that doesn’t have access to the Status Screen. This allows you to provide guests with an easy login process to use when accessing your network while you still maintain a secure system. - Page 8 Change Network Address Figure 7 WARNING: DO NOT CHANGE THE NETWORK ADDRESS UNLESS INSTRUCTED BY WINEGARD TECH SUPPORT. DOING SO MAY CAUSE YOUR SYSTEM TO NOT FUNCTION PROPERLY. Change Administration Password It is not necessary to change the administration password, however, to change the password click on CHANGE PASSWORD to bring up the new password screen.
- Page 9 UPDATING THE SOFTWARE When first setting up the Winegard ConnecT 2.0 + it is recommended to Figure 8 check for software updates the first time the system is connected to an Internet signal. It is also recommended to check for updates every couple months for fixes and added features.
-
Page 10: Swapping The Sim
Unlike some other hotspot data plans, the firmware with the correct Carriers Network Winegard plan allows you to decide what data plan is right for you in a given Settings you will need an internet connection. - Page 11 SIM card in the CELLULAR APN field. Also, be sure that the Winegard APN check box is NOT checked. See figure 11. Figure 12 CELLULAR PROVIDER APN (ACCESS POINT NAME) AT&T...
-
Page 12: All About The App
Let Winegard keep you connected to the Internet ® while on the road and on the water using our Connected app for Winegard Internet products. Installation and setup of your ConnecT system is quick and easy when using our app. -
Page 13: Over The Air Antenna Operation
Connected to WiFi XXXX are unable to connect to the internet, the source signal may have a problem. The Winegard ConnecT 2.0 + unit is looking for WiFi signals in range. This can take a few minutes. Scanning Once the unit is able to identify all of the signals, they will be listed and you will be able to choose one. - Page 14 One of several things has happened. The first thing to check is the WiFi signal that your device is the login screen? connected to. If this is not the Winegard ConnecT SSID, this address isn’t valid. If you are indeed connected to the correct network, the address may have been changed. To resolve this, perform a factory reset.
-
Page 15: Fcc Statement And Warranty Statement
This equipment uses and can radiate radio dated sales receipt for the Winegard product to verify the product is under warranty. If the date of purchase cannot be verified, the warranty period shall be considered to begin thirty (30) days after the date of manufacture. - Page 16 Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. Google Play and the Google Play logo are trademarks of Google LLC. Winegard is a registered trademark of Winegard Company. Disclaimer: Although every effort has been made to ensure that the information in this manual is correct and complete, no company shall be held liable for any errors or omissions in this manual.
