WINEGARD
ConnecT
2.0
®
™
WF2-435
LONG RANGE, HIGH PERFORMANCE 4G LTE + WIFI EXTENDER
WF2-335
LONG RANGE, HIGH PERFORMANCE WIFI EXTENDER
Installation / Operation Manual
Register your product at winegard.com/myantenna
For help, email help@winegard.com
or call 1-800-320-9992
Place label here
www.winegard.com/connect
Manuel disponible en français au www.winegard.com/connect
2452399
Rev0 10/17
Advertisement
Table of Contents
Related Manuals for Winegard ConnecT 2.0 WF2-435
Summary of Contents for Winegard ConnecT 2.0 WF2-435
- Page 1 LONG RANGE, HIGH PERFORMANCE 4G LTE + WIFI EXTENDER WF2-335 LONG RANGE, HIGH PERFORMANCE WIFI EXTENDER Installation / Operation Manual Register your product at winegard.com/myantenna For help, email help@winegard.com or call 1-800-320-9992 Place label here www.winegard.com/connect Manuel disponible en français au www.winegard.com/connect 2452399 Rev0 10/17...
-
Page 2: Parts List
Mounting Screw (20) Barrel Crimp Splice • Do not paint any portion of the Winegard ConnecT. Painting the system could damage the system and will void the warranty. • When first setting up the Winegard ConnecT 2.0 it is recommended to 20’... -
Page 3: Installing The Power Switch
EXTERIOR INSTALLATION (cont) Clean the roof area where the base feet will attach to the roof; do not Front of Vehicle erase your marks. Check with your vehicle manufacturer for approved sealant, and put approved sealant in the areas marked for the base feet. Place the base feet on top of the sealant. -
Page 4: Operation
Then click SELECT. See figure 2. If you have available data to use, the INTERNET STATUS should display Connected to 4G/LTE “Winegard ConnecT Data Plan”. If you do not have any available data the Figure 3 field will not display Connected. You will have to add data in order to use the 4G connection. -
Page 5: Operation (Cont)
(AES). Other options are available on this screen. Guest Network The Winegard ConnecT 2.0 provides a simple way to set up an extra network that doesn’t have access to the Status Screen. This allows you to provide guests with an easy login process to use when accessing your network while you still maintain a secure system. -
Page 6: Advanced Settings
Winegard ConnecT 2.0. Change Network Address WARNING: DO NOT CHANGE THE NETWORK ADDRESS UNLESS INSTRUCTED BY WINEGARD TECH SUPPORT. DOING SO MAY CAUSE YOUR SYSTEM TO NOT FUNCTION PROPERLY. Change Administration Password It is not necessary to change the administration password, however, to change the password click on CHANGE PASSWORD to bring up the new password screen. -
Page 7: Updating The Software
UPDATING THE SOFTWARE When first setting up the Winegard ConnecT 2.0 it is recommended to Figure 8 check for software updates the first time the system is connected to an Internet signal. It is also recommended to check for updates every couple months for fixes and added features. - Page 8 Unlike some other hotspot data plans, the firmware with the correct Carriers Network Winegard plan allows you to decide what data plan is right for you in a given Settings you will need an internet connection.
- Page 9 PROVIDER field and then enter the correct APN that your cellular provider provided you when you requested your SIM card in the CELLULAR APN field. Also, be sure that the Winegard APN check box is NOT checked. See Figure 11.
-
Page 10: Troubleshooting
One of several things has happened. The first thing to check is the WiFi signal that your device is up the login screen? connected to. If this is not the Winegard ConnecT SSID, this address isn’t valid. If you are indeed connected to the correct network, the address may have been changed. To resolve this, perform a factory reset. - Page 11 Scanning The Winegard ConnecT 2.0 unit is looking for WiFi signals in range. This can take a few minutes. Once the unit is able to identify all of the signals, they will be listed and you will be able to choose one.
-
Page 12: Fcc Statement
Winegard is a registered trademark of Winegard Company. Disclaimer: Although every effort has been made to ensure that the information in this manual is correct and complete, no company shall be held liable for any errors or omissions in this manual. Information provided in this manual was accurate at time of printing. If the antenna does not function as expected, please contact Winegard Co.
