- Page 1 Hanshow Nebular Plus Plus-266 Product Manual V2.0.4 HS-ESL-EPDN001 For more information, visit our website at: https://www.hanshow.com...
- Page 2 Hanshow. Offenders will be liable for any and all damages caused by their offence hereof and will be subject to all remedies that Hanshow is entitled to seek under applicable laws.
- Page 3 TARGET USERS This document provides engineers with necessary data and related guidelines of Nebular Plus series. Users have to master the basic knowledge on communication and network and so on. This manual is applicable for the below engineers: Testing Engineer ...
- Page 4 Hanshow Nebular Plus Series Product Manual SYMBOL DESCRIPTION Icon Description Information indicated with this icon should be paid special attention and attached great importance by the reader. Information indicated with this icon is the explanation on the formal text for the readers to comprehend the text better.
-
Page 5: Table Of Contents
6.2 Precautions for use ......................... 12 7 FCC ID warning ............................. 14 7.1 Warning for nameplate ........................14 7.2 Warning for product manual ......................14 8 IC statement ............................15 9 UKCA statement ........................... 16 Hanshow Copyright Reserved © Hanshow Technology Co., Ltd. -
Page 6: Overview
(ESLs). They adopt e-ink screen to achieve page switching, light flashing, pricing and so on based on 2.4GHz wireless communication. With ultra-thin, extended life and high- definition visual effects, the Nebular Plus series widely serves traditional retail, new retail, department stores and fashion, pharmacies, culture, and entertainment. -
Page 7: Features
Hanshow Nebular Plus Series Product Manual 1.2 Features The features of Nebular Plus series are as follows: Nebular Plus ESLs come in 1 ESL sizes: 2.66” Display colors include: BWRY (Black-White-Red-Yellow). Operating frequency band: 2402MHz ~ 2480MHz. -
Page 8: Product View
Hanshow Nebular Plus Series Product Manual 2 Product view This chapter describes Nebular Plus series’ appearance and composition. 2.1 Product appearance Figure 2-1 shows Nebular Plus. Figure 2-1 Nebular Plus Hanshow Copyright Reserved © Hanshow Technology Co., Ltd. - Page 9 Hanshow Nebular Plus Series Product Manual Each section of Nebular Plus and its relative description is shown in Figure 2-2 Table 2-1. Figure 2-2 Key area of Nebular Plus Table 2-1 Each area description of Nebular Plus Name Description LED indicator Supports 7-color flashing.
-
Page 10: Dimensions
Hanshow Nebular Plus Series Product Manual 2.2 Dimensions This section covers the dimensions of Nebular Plus series. Figure 2-3 2.66” dimension Hanshow Copyright Reserved © Hanshow Technology Co., Ltd. -
Page 11: Hardware Performance
Hanshow Nebular Plus Series Product Manual 3 Hardware performance This chapter consists of: Specifications 错误 未找到引用源。 Product nameplate 3.1 Specifications Table 3-1 lists the Nebular Plus specifications. Table 3-1 Nebular Plus specifications Name 2.66” Dimensions 82.3*40.3*7.8 (mm*mm*mm) - Page 12 Hanshow Nebular Plus Series Product Manual Name 2.66” Display color BWRY Viewing angle Nearly 180 degrees Battery life [3-2] 10 years Page switch 8 pages Protection level IP68 Operating 0 ~ 40 temperature [3-3] Storage 0 ~ 40 temperature [3-3]...
-
Page 13: Product Nameplate
Hanshow Nebular Plus Series Product Manual 3.2 Product nameplate Taking Nebular Plus-266R-N as an example, Figure 3-1 shows the nameplate of Nebular Plus. Figure 3-1 Nameplate of Nebular Plus Note: Each ESL has a unique S/N number. The above is for reference only, actual label information might vary. -
Page 14: Packaging And Accessories
Hanshow Nebular Plus Series Product Manual 4 Packaging and accessories This chapter describes Nebular Plus series’ packaging and required accessories. 4.1 Packaging Nebular Plus family packaging and the specific ESL quantity is shown in Figure 4-1. Figure 4-1 Nebular Plus family packaging Hanshow Copyright Reserved ©... -
Page 15: Product Accessories
Hanshow Nebular Plus Series Product Manual 4.2 Product accessories Common accessories of Nebular Plus series are shown in Table 4-1. Table 4-1 Common accessories of Nebular Plus series Rail Table stand T-hook Basket clip Hanshow Copyright Reserved © Hanshow Technology Co., Ltd. -
Page 16: Application Scenarios
Hanshow Nebular Plus Series Product Manual 5 Application scenarios Nebular Plus series are available to various zones and shelves of hypermarket, supermarket and retail stores. The ESLs are applicable to areas with different fixtures: Shelves Hooks Fences ... -
Page 17: Precautions
Hanshow Nebular Plus Series Product Manual 6 Precautions During transportation and usage of Nebular Plus series, please note the following precautions. 6.1 Transportation considerations Avoid the following considerations during transport: Water leakage or heavy moisture Heavy stacking High heat conditions above 40℃... - Page 18 Hanshow Nebular Plus Series Product Manual Avoid direct sunlight or incandescent light on ESLs. Do not install ESLs in a strong magnetic environment. Do not place ESLs near or in a fire. Do not place ESLs near kitchen appliances such as a stove, a microwave oven.
-
Page 19: Fcc Id Warning
Hanshow Nebular Plus Series Product Manual 7 FCC ID warning 7.1 Warning for nameplate This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. -
Page 20: Ic Statement
Hanshow Nebular Plus Series Product Manual 8 IC statement This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. -
Page 21: Ukca Statement
Hanshow Nebular Plus Series Product Manual 9 UKCA statement All products of the Nebular Plus series comply with UK Conformity Assessed (UKCA) standards. Nebular Plus products include 1.54”, 2.0”, 2.13”, 2.66”, 2.9”, 3.46”, 3.5”, 4.2”, 5.83”, 7.5”, 2.13” Freezer, 2.66” Freezer, and 3.5” Freezer.
