With Universal Dock for iPod
www.proform.com
Model No. PFTL49908.0
Serial No.
Write the serial number in the space
above for future reference.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
DO NOT CONTACT THE STORE;
please contact Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
1-888-533-1333
CALL TOLL-FREE:
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–4 p.m. MT
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
All manuals and user guides at all-guides.com
®
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFTL49908.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Pro-Form PFTL49908.0

Summary of Contents for Pro-Form PFTL49908.0

  • Page 1 All manuals and user guides at all-guides.com With Universal Dock for iPod ® www.proform.com USER'S MANUAL Model No. PFTL49908.0 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete cus- tomer satisfaction.

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    All manuals and user guides at all-guides.com IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and in- structions in this manual and all warnings on your treadmill before using your treadmill. ICON as- sumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 4 All manuals and user guides at all-guides.com 19. Never leave the treadmill unattended while it 23. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and switch the reset/off cir- cuit breaker to the off position when the Always unplug the power treadmill is not in use.

  • Page 5: Before You Begin

    All manuals and user guides at all-guides.com BEFORE YOU BEGIN Thank you for selecting the new PROFORM 580 LT ual. To help us assist you, please note the product ® treadmill with Universal Dock for iPod . The 580 LT model number and serial number before contacting us.

  • Page 6: Assembly

    All manuals and user guides at all-guides.com ASSEMBLY To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
  • Page 7 All manuals and user guides at all-guides.com 1. Make sure that the power cord is unplugged. With the help of a second person, carefully tip the treadmill onto its left side. Partially fold the Frame (56) so that the treadmill is more stable; do not fully fold the Frame yet.
  • Page 8 All manuals and user guides at all-guides.com 4. Identify the Right Upright (89) and the Right Long Upright Spacer (91), which are marked with stickers. Insert the Wire Harness (88) through the Right Upright Spacer (91) as shown. Then, set the Right Upright Spacer on the Base (95).
  • Page 9 All manuals and user guides at all-guides.com 7. With the help of a second person, carefully tip the treadmill onto its right side. Partially fold the Frame (56) so that the treadmill is more stable; do not fully fold the Frame yet. Remove and discard the two indicated bolts (B) and the shipping bracket (C).
  • Page 10 All manuals and user guides at all-guides.com 10. Set the Console (105) face down on a soft sur- face to avoid scratching the Console. Remove the ties securing the Pulse Support (111) to the Console. Lift off the Pulse Support (111). 11.
  • Page 11 All manuals and user guides at all-guides.com 13. Have a second person hold the console assem- bly near the Right Upright (89). Console Assembly Connect the Wire Harness (88) to the console wire. See the inset drawing. The connectors should slide together easily and snap into place.
  • Page 12 All manuals and user guides at all-guides.com 15. Raise the Frame (56) to the position shown. Have a second person hold the Frame until this step is completed. Orient the Storage Latch (60) so that the large barrel and the Latch Knob (61) are in the posi- tions shown.

  • Page 13: Operation And Adjustment

    All manuals and user guides at all-guides.com OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT tric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. Plug the power cord into a surge suppressor, Your treadmill features a walking belt coated with high- performance lubricant.
  • Page 14 All manuals and user guides at all-guides.com CONSOLE DIAGRAM Integrated Universal Dock for iPod Clip FEATURES OF THE CONSOLE certified by the developer to meet Apple performance standards. The treadmill console offers an impressive array of To turn on the power, see page 15. To use the man- features designed to make your workouts more effec- ual mode, see page 15.
  • Page 15 All manuals and user guides at all-guides.com HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power.
  • Page 16 All manuals and user guides at all-guides.com 4. Change the incline of the treadmill as desired. 6. Measure your heart rate if desired. Note: If you use the handgrip pulse sensor and To change the incline of the treadmill, press the the optional chest pulse sensor at the same Incline increase or decrease button.
  • Page 17 All manuals and user guides at all-guides.com HOW TO USE THE WEIGHT LOSS CENTER buttons; however, when the next segment be- gins, the treadmill will automatically adjust to 1. Insert the key into the console. the speed and incline settings for the next seg- ment.
  • Page 18 All manuals and user guides at all-guides.com HOW TO USE A CLASSIC WORKOUT incline setting will flash in the display for a moment to alert you. The treadmill will then automatically 1. Insert the key into the console. adjust to the speed and incline settings for the sec- ond segment.
  • Page 19 All manuals and user guides at all-guides.com HOW TO USE THE STEREO SOUND SYSTEM The display will show the total number of This product has been designed specifically to work hours the treadmill has with iPod and has been certified by the developer to been used.

  • Page 20: How To Fold And Move The Treadmill

    All manuals and user guides at all-guides.com HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it.
  • Page 21 All manuals and user guides at all-guides.com HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. It may be nec- essary to push the frame forward as you pull the knob to Frame the left.

  • Page 22: Troubleshooting

    All manuals and user guides at all-guides.com TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 23 All manuals and user guides at all-guides.com Remove the three M4.2 x 19mm Hood Screws (12) and carefully pivot the Hood (67) off. Locate the Reed Switch (70) and the Magnet (51) on the left side of the Pulley (53). Turn the Pulley until the Magnet is aligned with the Reed Switch.
  • Page 24 All manuals and user guides at all-guides.com PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...

  • Page 25: Exercise Guidelines

    All manuals and user guides at all-guides.com EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 26: Part List

    All manuals and user guides at all-guides.com PART LIST—Model No. PFTL49908.0 R1008A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description M4.2 x 19mm Screw...
  • Page 27 All manuals and user guides at all-guides.com Key No. Qty. Description Key No. Qty. Description Right Handrail Pulse Support 15 1/2" Cable Tie Console Ground Wire Console Base Access Door Left Accessory Tray Key Plate Console Audio Wire Right Accessory Tray –...

  • Page 28: Exploded Drawing

    All manuals and user guides at all-guides.com EXPLODED DRAWING A—Model No. PFTL49908.0 R1008A...
  • Page 29 All manuals and user guides at all-guides.com EXPLODED DRAWING B—Model No. PFTL49908.0 R1008A...
  • Page 30 All manuals and user guides at all-guides.com EXPLODED DRAWING C—Model No. PFTL49908.0 R1008A...
  • Page 31 All manuals and user guides at all-guides.com EXPLODED DRAWING D—Model No. PFTL49908.0 R1008A...

  • Page 32: Ordering Replacement Parts

    All manuals and user guides at all-guides.com ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
