USER MANUAL
Enjoy peace of mind.
Register your appliance today.
Stay updated on better living services, safety notices and
shop for accessories.
1. Open the camera app on your smartphone and
point at the QR code to scan
Product Registration QR code is located on the
front of your appliance or inside the door rim*.
2. Tap the notification or link to open the registration form
3. Complete your details and enjoy peace of mind
*Exact location of QR code may vary depending on oven model
Timer
Clock
Cook Time
MODE
GAS BUILT-IN OVENS
WVG6565SD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Westinghouse WVG6565SD
Summary of Contents for Westinghouse WVG6565SD
- Page 1 2. Tap the notification or link to open the registration form 3. Complete your details and enjoy peace of mind *Exact location of QR code may vary depending on oven model Timer Clock Cook Time MODE GAS BUILT-IN OVENS WVG6565SD...
-
Page 2: Table Of Contents
Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Westinghouse manufacturer’s warranty in the event that your product fault is due to failure to adhere this manual. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Always keep the appliance clean. Ensure fats and oils Please read the user manual carefully and store in a handy do not accumulate around elements, burners or fans. place for later reference. • Care must be taken when wiping exposed stainless steel edges.…they can be sharp! TIPS &... - Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING CAUTION Read the following carefully to avoid damage to the appliance. • The grill door must be left fully open whilst grilling in a separate grill wall oven and a separate grill underbench oven. • The grill tray must be fully inserted whilst grilling. •...
-
Page 5: Installing Your Appliance
INSTALLING YOUR APPLIANCE • This appliance must be mounted on a flat surface for the full width and depth of the product. WARNING WARNING To avoid any potential hazard, you must follow our • To avoid overheating, the appliance must not instructions when you install your appliance. - Page 6 INSTALLING YOUR APPLIANCE (CONTINUED) Levelling oven Place a level in the oven as below making sure the level sits on the front and rear forms. ✓ INSTALLING YOUR APPLIANCE...
- Page 7 Separate grill wall oven use black installation screws supplied mounting holes use black installation screws with plastic spacers provided Recommended 650mm min. carry handle 8 min. clearance 1.7m flexible gas hose (supplied unfitted) 1.5m electrical service cord D Gas connection - 150mm from right hand side GAS TYPE - 220mm from bottom...
- Page 8 INSTALLING YOUR APPLIANCE (CONTINUED) Recommended cabinet design NOTE: Powerpoint connection must be accessible with the appliance installed. Front View Area for mounting of powerpoint. Supporting shelf 8mm below door line to give perfect alignment of cooker & cupboard (kick panel notched to suit).
-
Page 9: Gas Installation Information
GAS INSTALLATION INFORMATION Gas Connection to brace the inlet against the action of wrenching when connecting the hose to the appliance gas inlet. The appliance is preset for natural gas use. If LPG is to be Failure to do so may damage the appliance. used, see Conversion to LPG section. - Page 10 GAS INSTALLATION INFORMATION (CONTINUED) Check the operating pressure (refer table above). SUPPLY NOMINAL OVEN For LPG Cookers: Adjust the regulator if necessary PRESSURE TEST POINT INJECTOR GAS TYPE (this may be remote from the cooker). (KPA) PRESSURE (KPA) For NG Cookers: The outlet pressure should not vary from the nominal outlet pressure of 1.00kPa by more NG &...
- Page 11 Converting your appliance for use with LPG Install all the removed parts in the reverse order of disassembly. The appliance is preset for natural gas use but can be Attach the supplied LPG sticker to the cooker, near converted for use with LPG. the gas supply inlet.
-
Page 12: Product Description
PRODUCT DESCRIPTION WVG6565SD Function selector Oven temperature selector Electronic Clock Grill temperature selector PRODUCT DESCRIPTION... -
Page 13: Before First Use
BEFORE FIRST USE Setting the time WARNING CAUTION If you have purchased a model fitted with an electronic • Do not line the oven with foil as it will damage clock, you must set the time of day before you can the enamel. -
Page 14: Installing Oven Accessories
INSTALLING YOUR OVEN ACCESSORIES Side racks The side racks attached to each side of your oven. There is a left hand and right hand version (see image below for details). • Insert the rear peg into the rear access hole provided, ensuring that the peg is fully inserted. -
Page 15: Using Your Oven
USING YOUR OVEN Separate grill Understanding your oven functions Your oven will have a selection of the following functions. The “grill” directs radiant heat from the powerful upper Refer to “Description of your appliance” to confirm what element onto the food. You can use the “grill” function for functions are available to you. - Page 16 USING YOUR OVEN (CONTINUED) Operating your oven temperature selector General features A thermostat controls the temperature in your appliance. The oven is equipped with an electronic clock that can be The temperature can be selected within the specified used to turn the oven off automatically. The range.
- Page 17 Setting the cooking duration Ignition and response to ignition failure The electronic controller attempts to ignite the flame Select the desired oven when an oven function and temperature is selected (the The oven indicator light will appear and the heating thermostat indicator light changes from off to on).
- Page 18 USING YOUR OVEN (CONTINUED) Power failure Oven shelf location In the event of an interruption to mains power, the The oven has 5 positions for shelves (as shown in the restoration of power will not cause the burner to re-ignite diagram below).
- Page 19 Roasting poultry and fish • Place the poultry or fish in an oven set at a moderate temperature of 180°C. • Place a layer of foil over the fish for about three quarters of the cooking time. The table shows temperatures and cooking times for different kinds of fish and poultry.
-
Page 20: Cooking Guide
COOKING GUIDE Choosing the best oven settings The following table is intended as a guide and experience may show some variation in cooking times necessary to meet individual requirements. It may be necessary to change some cooking times and temperatures from your previous oven. -
Page 21: Grilling Guide
GRILLING GUIDE Grilling hints Do not place aluminium foil under the food as this prevents fats and oils from draining away, which could result in a fire. WARNING WARNING Baste the food during cooking with butter, olive oil Always clean the grill/oven dish after every use. Excessive or marinade. -
Page 22: Dealing With Cooking Problems
DEALING WITH COOKING PROBLEMS PROBLEM CAUSES REMEDY Uneven cooking Incorrect shelf position Select shelf that places food in the centre of the oven Baked products too brown on top Experiment with other trays or dishes Trays not centralised Centre trays Air flow in oven uneven Rotate food during cooking Grill dish affecting thermostat... -
Page 23: Getting To Know Your Oven
GETTING TO KNOW THE OVEN Get to know the oven with this ‘Simple Test Cake’ Although we strive for a perfect performing oven, it’s possible that there will be some variation in colour when baking. Therefore, we suggest this simple, easy and delicious to make Simple Test Cake, it can help you understand your new oven. -
Page 24: Cleaning Your Appliance
CLEANING YOUR APPLIANCE WARNING WARNING WARNING WARNING • Ensure the oven is electrically isolated before • The door glass on this appliance is made from a cleaning. This can be done by switching off tough, durable material that withstands heating and the appliance via the powerpoint or isolating switch cooling without breaking. - Page 25 RELEASING THE GRILL ELEMENT Cleaning your oven accessories Removing the trays and shelves from your appliance WARNING WARNING • Slide the dish and shelves towards you until they Make sure the appliance is turned off before you remove reach the front stop. or replace parts, to avoid the possibility of electric shock.
- Page 26 CLEANING YOUR APPLIANCE (CONTINUED) Retaining clips models - The upper grill element is Cleaning the oven door secured with 2 clips which can be removed to help clean the oven cavity ceiling. To disengage the clips, push the edge of WARNING CAUTION the clip towards back of the oven as shown below.
- Page 27 • Grasp the oven door with a hand each side of the Removing the door glass panels door and remove it from the oven by pulling it towards you. WARNING CAUTION Rough handling, especially around the edges can cause the glass to break. •...
- Page 28 CLEANING YOUR APPLIANCE (CONTINUED) Cleaning the door glass panels Re-assembling the top door trim • Take hold of the top door trim at each side and WARNING CAUTION position it to the inside edge of the glass. Do not to use harsh abrasives on the glass panes as the •...
- Page 29 Re-assembling the top door trim • Take hold of the oven door with a hand on each side and with the door at an angle of 45º, position the recesses at the bottom of the door onto the hinge arms of the oven. Let the door slide down the hinge arms as far as it will go.
-
Page 30: Troubleshooting
TROUBLESHOOTING Faults PROBLEM POSSIBLE CAUSE If there is a problem with the oven and/or Oven not • Foil or trays on bottom of oven. grill, please: heating enough • Timer is in “AUTO” mode. (Refer to • Check the points listed below before calling timer operating instructions) for service. -
Page 31: Warranty
(c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004... - Page 32 NEW ZEALAND phone: 0800 10 66 10 email: customercare@electrolux.co.nz web: westinghouse.co.nz and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license. All Rights Reserved. © 2023 Electrolux Home Products Pty Ltd. ABN 51 004 762 341 WMAN_WVG6565SD/WD_A26334701_Mar2023...
