USER MANUAL
Enjoy peace of mind.
Register your appliance today.
Stay updated on better living services, safety notices and
shop for accessories.
1. Open the camera app on your smartphone and
point at the QR code to scan
Product Registration QR code is located on the
front of your appliance or inside the door rim*.
2. Tap the notification or link to open the registration form
3. Complete your details and enjoy peace of mind
*Exact location of QR code may vary depending on oven model
ELECTRIC BUILT-IN OVENS
WVE6313, WVE6314

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WVE6313 and is the answer not in the manual?

Questions and answers

Related Manuals for Westinghouse WVE6313

Summary of Contents for Westinghouse WVE6313

  • Page 1 2. Tap the notification or link to open the registration form 3. Complete your details and enjoy peace of mind *Exact location of QR code may vary depending on oven model ELECTRIC BUILT-IN OVENS WVE6313, WVE6314...

  • Page 2: Table Of Contents

    Failure to strictly adhere to the requirements in this manual may result in personal injury, property damage and affect your ability to make a claim under the Westinghouse manufacturer’s warranty provided with your product. Products must be used, installed and operated in accordance with this manual.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Please read the user manual carefully and store in a handy Steam can be released. There is a risk of skin burns. place for later reference. There is a risk that steam causes moisture damage to cabinets. •...
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING CAUTION Read the following carefully to avoid damage to the appliance. • Do not place thick portions of food under the grill. Foods may curl, catch and ignite. • Do not use the door as a shelf. •...

  • Page 5: Installing Your Appliance

    WIRe SeCTION mODeL DImeNSIONS RATING POWeR RATING CURReNT RATING (mm²) (H X W X D) mm WVE6313/ 597 x 596 x 569 2.3kW 9.6A WVE6314 Note: Electrical connection is 230-240 volts AC 50Hz. Wiring minimum temperature rating 75°C. INSTALLING yOUR APPLIANCe...
  • Page 6 INSTALLING YOUR APPLIANCE (CONTINUED) Fig. B 16mm 568mm 553mm 8mm min clearance Infill Proud fit panel Cupboard door Oven 600mm Levelling oven Place a level in the oven as below, making sure the level sits on the front and rear forms. Cabinet construction for your appliance For the best integration within a kitchen, install the appliance in a standard 600mm wide cupboard that gives...
  • Page 7 Refer to cooktop installation instructions for required clearance between cooktop and oven. WVE6313, WVE6314 models come with 10A power cord for ‘Plug & Play’. 10A powerpoint is needed. NOTE: If a powerpoint is fitted it must be...

  • Page 8: Product Description

    PRODUCT DESCRIPTION WVE6313/WVE6314 Function selector Temperature selector Oven/grill indicator light Electronic Clock PRODUCT DeSCRIPTION...

  • Page 9: Before First Use

    BEFORE FIRST USE INSTALLING YOUR OVEN ACCESSORIES Preparing your appliance for the first time Side racks • Please remove all internal boxes and bags from the • The side racks attach to each side of your oven. oven before operation. There is a left hand and right hand version (see image •...

  • Page 10: Using Your Oven

    USING YOUR OVEN Understanding your oven functions Fan & Grill Your oven will have the following functions. “Fan & Grill” offers you the benefits of both “Bake” and traditional “Grill” functions. The grill element turns on and off to maintain the set temperature while the fan Fan Forced circulates the heated air.
  • Page 11 Operating your oven temperature selector TIPS & INFORMATION IMPORTANT A thermostat controls the temperature in your appliance. The temperature can be selected within the specified Cooling/Venting fan range. To set the temperature, turn the temperature selector in a clockwise direction to the desired setting. An This appliance is fitted with a cooling fan.
  • Page 12 USING YOUR OVEN (CONTINUED) Cooking with your timer • Make sure dishes will fit into the oven before you switch it on. • Keep edges of baking dishes at least 40mm from the WARNING CAUTION side of the oven. This allows free circulation of heat and ensures even cooking.
  • Page 13 ReCOmmeNDeD mINUTeS meAT ReSULT TemPeRATURe PeR KG Rare 35 - 40 Beef Medium 45 - 50 Well done 55 - 60 Medium Lamb Well done Veal Well done Pork Well done Roasting poultry and fish • Place the poultry or fish in an oven set at a moderate temperature of 180°C.

  • Page 14: Cooking Guide

    COOKING GUIDE Choosing the best oven settings The following table is intended as a guide and experience may show some variation in cooking times necessary to meet individual requirements. It may be necessary to change some cooking times and temperatures from your previous oven.

  • Page 15: Grilling Guide

    GRILLING GUIDE Grilling hints Guide to better grilling WARNING WARNING TIPS & INFORMATION IMPORTANT Always clean the grill/oven dish after every use. Excessive Definite times can not be given for grilling as it is fat build up may cause a fire. dependant on the size of the food and your own tastes.

  • Page 16: Dealing With Cooking Problems

    DEALING WITH COOKING PROBLEMS PROBLem CAUSeS RemeDy Uneven cooking • Incorrect shelf position • Select shelf suitable for cooking function. See cooking function tables in cooking guide • Oven tray too large • Experiment with other trays or dishes • Trays not centralised •...

  • Page 17: Getting To Know The Oven

    GETTING TO KNOW THE OVEN CARE AND CLEANING Get to know the oven with this ‘Simple Test Cake’ WARNING WARNING Although we strive for a perfect performing oven, it’s Ensure the oven is electrically isolated before cleaning. possible that there will be some variation in colour This can be done by switching off the appliance via when baking.
  • Page 18 CARE AND CLEANING (CONTINUED) WARNING WARNING The door glass on this appliance is made from a tough, durable material that withstands heating and cooling without breaking. As a precaution however, do not put cold water on hot glass. Should you have any questions about the glass in your new appliance, please contact the customer care centre by dialling 1300 363 640.
  • Page 19 Removing the oven door WARNING WARNING Make sure the appliance is turned off before you remove TIPS & INFORMATION IMPORTANT or replace parts, to avoid the possibility of electric shock. Your oven is equipped with a door that can be disassembled in order to clean all the panes of glass.
  • Page 20 CARE AND CLEANING (CONTINUED) • Grasp the oven door with a hand each side of the Removing the door glass panels door and remove it from the oven by pulling it towards you. WARNING CAUTION Rough handling, especially around the edges can cause the glass to break.
  • Page 21 Re-assembling the top door trim Fitting the oven door • Take hold of the top door trim at each side and • Take hold of the oven door with a hand on each side position it to the inside edge of the glass. and with the door at an angle of 45 , position the recesses at the bottom of the door onto the hinge...

  • Page 22: Troubleshooting

    TROUBLESHOOTING Faults If there is a problem with the oven, please: • Check the points listed below before calling for service. It may be possible to avoid a call by fixing the problem yourself – and so continue cooking. • For cooking problems refer to “Dealing with cooking problems”.
  • Page 23 TROUBLESHOOTING (CONTINUED) Oven PROBLem POSSIBLe CAUSe Oven or grill • Time of day not set. not working • Power not turned on. • Controls are incorrectly set. • Oven is in ‘Demo’ mode, refer to Using your oven section. • Household fuse has blown or power supply is off. NOTE: If the household fuse continues to blow, call the Customer Care Centre.
  • Page 24 NOTES NOTES...
  • Page 25 NOTES NOTES...
  • Page 26 NOTES NOTES...

  • Page 27: Warranty

    (c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004...
  • Page 28 0800 225 088 westinghouse.co.nz email: customercare@electrolux.co.nz web: westinghouse.co.nz and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license by Electrolux Home Products Pty Ltd. All Rights Reserved. © 2023 Electrolux Home Products Pty Ltd. ABN 51 004 762 341 W_MAN_WVE6313_WVE6314_A26334001_A4_April2023...
