- Page 1 OWNER’S MANUAL WATER HEATERS CAUTION: READ INSTRUCTIONS BEFORE OPERATING APPLIANCE. MODEL: F600, F650, F750, F1100, F1150, F1200, F1250, H2000, H2050, H2200, H2250, H2850, HF2000, HF2050, HF2200, HF2250, S600, S650, S700, S750, S1100, S1150, S1200, S1250, S1800, S1900 75545 Rev. C...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING When using electrical appliances, basic safety precautions to reduce the risk of fire, electrical shock, or injury to persons should be followed, including: 1. READ ALL INSTRUCTIONS BEFORE USING THIS WATER HEATER. 2. This water heater must be grounded. Connect only to properly grounded source. See "GROUNDING INSTRUCTIONS"... - Page 4 CAUTION Hydrogen gas can be produced in a hot water system served by these heaters that have not been used for a long period of time (generally 2 weeks or more). Hydrogen gas is extremely flammable. To reduce the risk of injury under these conditions, it is recommended that the hot water faucet be opened for several minutes at the kitchen sink before using any electrical appliance connected to the hot water system.
- Page 5 NOTICE This temperature / pressure valve may weep during initial operation. This is normal. The valve will seat itself with use. A drain hose should be installed at this valve and directed overboard. If the boat is connected to the dockside water system, make sure to turn off the system at the dock when not attended.
-
Page 6: Installation
• Turn power off at main power panel or remote switch • Remove wiring access cover • Depress red button on high temperature limit switch • Replace cover and turn power on • If temperature limit switch reactivates, contact a Whale-Seaward Authorized service center. - Page 7 WIRING DIAGRAM FOR 120V WIRING DIAGRAM FOR 240V...
- Page 8 Winterizing your fresh water system is an essential procedure that will maintain the life and longevity of your Whale Heat water heater and fresh water tanks. To ensure that your fresh water system has adequate protection for winter storage, use the following recommended winterizing procedure.
- Page 9 6. Fill fresh water tanks to 100% capacity. NOTICE Whale Heat recommends that while filling the fresh water storage tanks that a small amount of common household bleach be added to the fresh water system to control the possible growth of algae. If an algae condition starts it is very difficult to control.
- Page 10 PARTS LIST MODELS S300W ITEM MODEL NO. PART NO. DESCRIPTION ALL MODELS 80727 TANK ASSEMBLY ALL MODELS 73127 TEMPERATURE/PRESSURE VALVE ALL MODELS 73124 GASKET, HEATING ELEMENT S300W 75586 1250W HEATING ELEMENT S300W 74563 HIGH LIMIT SWITCH, 120V ALL MODELS 73129 THERMOSTAT S300W 73148...
- Page 12 ITEM MODEL NO. PART NO. DESCRIPTION H2000 / H2050 / H2200 / H2250 80355 TANK ASSEMBLY H2000E / H2050E / H2200E /H2250E E80355E TANK ASSEMBLY ELECTRIC ONLY HF2000 / HF2050 / HF2200 /HF2250 80351 TANK ASSEMBLY ALL MODELS 73127 TEMPERATURE/PRESSURE VALVE ALL MODELS 73124 GASKET, HEATING ELEMENT...
- Page 13 PARTS LIST MODELS H2850EW-3000, H2850EW-4500, H2850ES-3000, H2850ES-4500 ITEM MODEL NO. PART NO. DESCRIPTION H2850ES-3000, H2850ES-4500 80491 TANK ASSEMBLY H2850EW-3000, H2850EW-4500 80491 TANK ASSEMBLY ALL MODELS 73127 TEMPERATURE/PRESSURE VALVE ALL MODELS 73124 GASKET, HEATING ELEMENT H2850ES-3000, H2850EW-3000 74715 3000W HEATING ELEMENT H2850ES-4500, H2850EW-4500 75086 4500W HEATING ELEMENT...
- Page 15 ITEM MODEL NO. PART NO. DESCRIPTION ALL MODELS 80263 TANK ASSEMBLY ALL MODELS 73127 TEMPERATURE/PRESSURE VALVE ALL MODELS 73124 GASKET, HEATING ELEMENT S1800 / S1900 74031 1500W HEATING ELEMENT 120V S1850 / S1950 74032 1500W HEATING ELEMENT 240V S1800 / S1900 74563 HIGH LIMIT SWITCH 120V S1850 / S1950...
- Page 17 ITEM MODEL NO. PART NO. DESCRIPTION ALL MODELS 80263E TANK ASSEMBLY ALL MODELS 73127 TEMPERATURE/PRESSURE VALVE ALL MODELS 73124 GASKET, HEATING ELEMENT S1800E / S1900E 74031 1500W HEATING ELEMENT 120V S1850E / S1950E 74032 1500W HEATING ELEMENT 240V S1800E / S1900E 74563 HIGH LIMIT SWITCH 120V S1850E / S1950E...
- Page 18 PARTS LIST MODELS S600, S650, S700, S750, F600, F650, F700, F750 S1100, S1150, S1200, S1250, F1100, F1150, F1200, F1250 ITEM MODEL NO. PART NO. DESCRIPTION ITEM MODEL NO. PART NO. DESCRIPTION S600 / S700 80253 S600 / S650 80648 FRONT PANEL, GALVANIZE...
-
Page 19: Limited Two-Year Warranty
B. Will meet applicable specifications and descriptions at time of delivery to BUYER. The obligation of WHALE HEAT under this warranty is limited to the repair, rework, or replacement at WHALE HEAT’S option, any part or component thereof, which examination discloses to our satisfaction to have been nonconforming or defective. - Page 20 NOTES...
