CD Automation srl
RELATIVE COOLING GAIN
(available only with PID or PI - CntF <> onoF (group miSC of configuration))
Upper display
Lower display
Range
0.20 ↔ 1.00
When selftune is actve and rCEn = On the range become
PAL = AIr
0.85 ↔ 1.00
PAL = OIL
0.80 ↔ 0.90
PAL = H2O
0.30 ↔ 0.60
DEAD BAND/OVERLAP TRA HEATING/COOLING OUTPUT
(available only with PID or PI - CntF <> onoF (group miSC of configuration)) e con
o2Fn = Cool)
Upper display
Lower display
Negative value indicates the dead band, positive value indicates the overlap.
Range
-20 ↔ 50
14.9 Group PAL2 (Pallet 2 control parameters)
See gruop 1
14.10 Group PAL3 (Pallet 3 control parameters)
See gruop 1
rC1
Actual Value
oLAP1
Actual Value
pag. 49 di 122
