- Page 1 INSTALLATION INSTRUCTIONS ONE PIECE HIGH EFFICIENCY TOILET MODEL# MOTB17...
-
Page 2: Important Safeguards
READ ALL INSTRUCTIONS BEFORE USING IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS INDICATES THAT FAILURE TO FOLLOW THE INSTRUCTION MAY CAUTION CAUSE BODY INJURY OR PROPERTY DAMAGE. 1. Do not install or use the product in wet places such as a steam room, etc. 2. It is recommended to use a water-proof electrical outlet, which should be installed in a dry and safe place where it is not easy to get wet. 3. - Page 4 TOILET COMPONENTS During unpacking of the product, and prior to installation, inspect your new product for any damages or missing parts Do not attempt to install or operate the product if the product is damaged. ONE PIECE TOILET WITH SOFT-CLOSE TOILET SEAT X1 WAX RING X1 2X NUTS...
-
Page 5: Dimensions/Technical Data
DIMENSIONS/TECHNICAL DATA 15 3/4’’ (400) 12 1/16’’ (305) 18 11/16’’ 14 7/16’’ (475) (367) 6 1/8’’ (155) 5 11/16’’ (145) 1. The product drawing is for reference only, and we reserve the right to modify the appearance of the product. 2. - Page 6 INSTALLATION INSTRUCTIONS CARE AND MAINTENANCE To ensure this product is installed properly, please read these instructions carefully before you begin. ( Certain installations may require professional help.) Also be sure your installation conforns to lacal codes. HANDLE WITH CARE. VITREOUS CHINAWARE FRAGILE CAUTION WITH SHARP EDGES IF BROKEN.
- Page 7 STEP #2 Roughing-in dimensions NOTE: DISTANCE FROM WALL TO CLOSET FLANGE CENTER LINE MUST BE AS LISTED ON CHART: STEP #3 STEP #4 Install closet bolts Install wax ring Insert floor bolts into flange channel Turn toilet bowl down onto a towel or with bolt head down use plastic cushioned surface.
- Page 8 STEP #5 Position toilet bowl on flange a. Unplug floor waste opening, gently place the bowl in position with the floor bolts protruding up through the hole in the base. b. Press down with slight twisting motion on the top center of bowl to compress the wax ring creating a water-tight seal.
