READ ALL INSTRUCTIONS BEFORE USING IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
IMPORTANT SAFETY INSTRUCTIONS INDICATES THAT FAILURE TO FOLLOW THE INSTRUCTION MAY CAUTION CAUSE BODY INJURY OR PROPERTY DAMAGE. 1. Do not install or use the product in wet places such as a steam room, etc. 2. It is recommended to use a water-proof electrical outlet, which should be installed in a dry and safe place where it is not easy to get wet. 3.
Page 4
INSTRUCTIONS SMART TOILET ONE PIECE TANKLESS Installation Manual: (Pages 01 - 09) Toilet User Manual: (Pages 10 - 20) Remote Control User Manual: (Pages 21 - 26) MODEL# ST3W Main Unit Installation Manual Remote Components Installation Cardboard NPT 1/2 Sealing Flange...
Page 5
1. The product drawing is for reference only, and we reserve the right to modify the appearance of the product. 2. If the appearance of the product is changed, the actual product shall prevail.
Page 6
TOILET INSTALLATION PRECAUTION BEFORE INSTALLING Minimum dynamic working water pressure: 0.18+ MPa (5.81+ gal/min or 22+ L/min), failure to meet this pressure will not achieve the best flushing effect. Remark: Apply the methods below if you don’t have water pressure testing device. Hose in the package Angle valve in...
Page 7
STEP #2 Installation Method 1: Installation Method 2: Installation of mating angle valve Draw drain outlet centerline on the floor, NPT 1/2 Install angle valve at proper position on wall according to dimension of toilet. Mating angle valve Line Drain outlet Note: 1.
STEP #5 Mounting bracket Mounting bracket installation Washer Bolt Assemble the mounting bracket with bolts and then secure them to the pre-installed flange on the ground and tighten with nuts. STEP #6 STEP #7 Ceramic toilet installation Screw installation Put the screw through the fixing sleeve and Install sealing flange on drain outlet;...
AFTER INSTALLATION 1. Turn on the angle valve 2. Power Connection Check thread connection, make sure no Insert power line leakage protection plug into leakage is found,unscrew angle valve the power socket, press the reset switch, plug anticlockwise to maximum opening. indicator lights on indicating that the power is (Tips: When opening for the first time, the angle valve handle has a larger torque)
Page 10
TOILET USER MANUAL (PAGES 10 TO 20) READ ALL INSTRUCTIONS BEFORE USING IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed,including the following: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Page 11
IMPORTANT SAFETY INSTRUCTIONS INDICATES THAT FAILURE TO FOLLOW THE INSTRUCTION MAY CAUTION CAUSE BODY INJURY OR PROPERTY DAMAGE. 1. Do not install or use the product in wet places such as a steam room, etc. 2. It is recommended to use a water-proof electrical outlet, which should be installed in a dry and safe place where it is not easy to get wet. 3.
Technical specification Model ST3W Rated voltage 110V-120V,50/60Hz Rated power 1200-1400W Main Unit Overall unit Waterproof IPX4 Electrical wire length is about 1.8m Flush volume 1.28Gpf (4.8Lpf) Flushing mode Siphonic jet Rough-in distance 305mm Toilet Outlet outside diameter Drainage method Down-drain 0.18 MPa (dynamic pressure, flow rate of...
Page 13
ST3W Model Thermal fuse, Water temperature senor, Ground Cleaning Safety device protection, Thermostat, Over temperature device protection, Leakage protection plug Warm air volume Over 0.2m /min Warm wind temperature 6 different level adjustment Drying device Heating power 250W GROUNDING INSTRUCTIONS...
PARTS IDENTIFICATION Bumper Indicator light Button Seat Ceramic toilet Clearning baffle Drying baffle Rear cleaning Front Remote cleaning sensing window Spray nozzle Use the foot to touch the sensing area to achieve half flushing...
DAILY MAINTENANCE Main Unit Care And Maintenace Spray Nozzle Maintenance And Care 1. Shut off power supply before doing 1. Nozzle self-cleaning maintenance. While not sitting on the unit, short press the “ REAR/MOVE ” Button on the main unit, the spray nozzle will extend outward and water will flow out.
EMERGENCY TROUBLESHOOTING No water supply Maintenance of filter net Time for maintenance: It is under Put around 2.1Gal (8L) of water into a bucket and flush the bowl. normal water pressure but poor flush performance occurs. Note: Avoid water spilling from bowl. 1.
EMERGENCY TROUBLESHOOTING Battery replacement When the product is left unused for long time 1. Unplug DC connector and remove the battery box. Especially in winter when no one at home for a long time, please drain out the water 2. Install new batteries. inside tank and pipe to prevent freezing.
Page 18
DESCRIPTION OF THE BUTTON FUNCTION The illustration of main unit buttons Press and hold the “Stop” button (for about) 3son the unit, the unit enters the shutdown mode (red light off), press the “stop” button again, the unit returns to the working mode (lights red).
Page 19
DESCRIPTION OF INDICATOR LIGHT 1. When the unit starts up, it displays water temperature information by default. Temperature display light, water temperature indicator and separator are all on; Seat temperature indicator is 50% on. 2. When water temperature is in a non-neutral state, and there is a seat temperature adjustment. After 5 seconds of adjustment, it automatically switches to the water temperature display: Water temperature indicator, separator and temperature display light are all on;...
TROUBLESHOOTING GUIDE Problem Cause Solution Water inlet hose bent to cause Solve the problem of bending of water inlet hose blocking No Water from Inlet valve is off Turn on the inlet valve Nozzle Water supply is cut off Connect water supply and wait for the water Water inlet hose bent to cause Solve the problem of bending of water inlet partial blocking...
Page 21
REMOTE CONTROL USER MANUAL (PAGES 21 TO 26) Drying/ Dryer temperature Rear washing/ moving washing Front washing/ moving washing Indicator light Nozzle moving forward Water reducing Water increasing Stop/Energy saver Nozzle moving backward Water Seat temperature temperature Flush Night light...
REMOTE CONTROL INSTALLATION Remote control hanger installation 1: 1. Drill a 6 mm diameter hole in the wall to a depth of about 35 mm. 2. Tear off the double-sided adhesive sticker on the back of the hanger. 3. Install the expansion pipe into the wall hole, and align it with the hanger hole. Attach the double-sided adhesive sticker on the back of the hanger to the wall,lock the screw, and tear off the double-sided adhesive sticker on the back of the patch and stick it on.
USAGE INSTRUCTION NOTICE: · The body should touch the seat and the buzzer rings “CLICK”, which means functions of front washing, rear washing and drying are in operation. · Please stay backward when sitting on the seat. So that the washing position can be easily aligned and there will be no splash.
DRY|DRYER TEMP ①Press the " " button, the indicator light will light up, showing the current air temperature range. It will stop drying automatically after a cycle or after DRY DRYER TEMP. the human body leaves the seat. ②In the process of drying, press the " "...
Water temperature adjustment Short press the " " button to adjust the water temperature. The indicator will show the water temperature level if it’s on. When the indicator is off, the water level is 0. Short press this button to adjust water temperature level from 0 to 5 in cycle.
User code · IR remote control ① Plug in the toilet. It will execute self-inspection. When finished, it beeps once. ② First press " " button, then press " " button, the indicator light will flash. ③ Press the Pressure " + " or " - " button to select user 1-9 (as shown the figure below). The indicator light displays the corresponding user code and flashes.
