- Page 1 183 / 5786 158 / 4927 173 / 8735 Max mattress weight: 50kg 161 / 6644 184 / 5226 157 / 4580 144 / 4799 171 / 7811 171 / 9682 (Small If you need help or have damaged or missing parts, call the Customer Helpline on 01992 450 333...
- Page 3 on 01992 450 333. Tick boxes provided to check the components (Cannot compress by hand alone. It must be attached to the frame with a mattress on top for it to compress). Long support leg x 2 x 28 ( 4ft ) x 28 (4ft6) Slats x 30 ( 5ft )
- Page 4 on 01992 450 333. Tick boxes provided to check the components Metal Support Block x 4 Frame Support x 1 (These clips are very small, please keep them in a safe place until required in assembly.) 5/16” Washer x 8 Metal Clip x 4 Plastic Foot Adjuster x 2 1/4”...
- Page 5 Tick boxes provided to check the components 5/16” 45mm 5/16” 25mm 1/4” 15mm Bolt Bolt Bolt M4 45mm 1/4” 38mm 1/4” 19mm Wood screw Bolt Bolt (not supplied)
- Page 6 legs Attach 2x legs to the underside of the headboard using screws as shown. Repeat on the underside of the footboard 20mm Aim to screw in the wooden screw roughly 20mm for the edge. 20mm Aim to screw in the wooden screw roughly 20mm for the...
- Page 7 Assemble footboard a: Attach the frame support to the foot- board using bolts and washers as shown. b: Attach the metal support blocks to the footboard & headboard as shown using m4 screws...
- Page 8 Step 3 Attaching side rails Loosely attach the bolts to the headboard and footboard then hook on the side rails & . Securely tighten the bolts Do not over tighten. Footboard Headboard...
- Page 9 Step 4 Assemble base a: Attach the short support legs to the underside of the bottom central rail using 2x bolts Insert cap b: Attach the bottom centre rail to the headboard and foot- board using washers & bolts as shown. c: Attach the support rails to the side rails Place bolts in to...
- Page 10 Step 5 Insert base panels...
- Page 11 Step 6 IMPORTANT: The gas struts will not compress by hand alone. The gas struts will only compress once the frame is assembled Attaching hinges with the weight of the mattress on top. a: Attach the hinges to the side rails &...
- Page 12 Identify the rails then lay them down on the oor to secure Step 7 together. Frame assembly Attach belt to the front frame rail before xing the rails together. Connect the side rails back frame rail front rail , and centre rail using bolts and washers...
- Page 13 Note: Be careful not to block or damage the support legs Step 9 with any items stored underneath the frame. Ensure there Support legs assembly is enough space for the legs when the frame is lowered. Attach the long support legs to the underside of the frame using bolts...
- Page 14 Step 10 Attach frame The weight of the mattress Attach the assembled will help lower the frame. frame to the hinges as shown, by inserting Mattress weight limit is 50kg. bolts through the upper arm of the hinge and into the side rails Step 11 Insert bolt...
- Page 15 Step 12 Contact customer service if you have any damaged slats or are missing slats or caps on 01992 450 333. Place Slats Note: The frame may not push down until the mattress has a: Slot the bed slats been placed on top. If so, attach the slats rst whilst frame is in into the end the upright position, place mattress on top of frame and pull central slat caps...
