6. DIAGRAM & DIMENSIONAL SKETCH, EXAMPLE - AKVA LUX II TDv
DHW
DCW
DH
Supply
DH
Return
8
DKDHR
Akva Lux II TDv
145X2085 / AQ428255318526en-010101
2. Plate heat exchanger DHW
4. Differential pressure controller AVPL
5. Strainer
38. DHW controller PTC2+P
40. Danfoss FJVR for bypass/circ.
52. Zone valve RA-C DN15
Danfoss District Energy
HE
Supply
HE
Return
