5. MAIN COMPONENTS / CONNECTIONS- AKVA LUX II TDv
2. Plate heat exchanger DHW
4. Differential pressure controller AVPL
5. Strainer
38. PTC2+P Controller
40. Danfoss FJVR thermostat for bypass/circulation
52. Zone valve RA-C
145H4156
Accessories
Cover, white painted H410 x W310 x D210
Circulation set for mounting on site
Ball valve set for ECO, 2 pc. DVGW, 4 pc. heating (76 mm
x ¾" ET/IT)
Safety set for mounting underneath substation
Actuator TWA-Q for zone valve
Supplement for stainless steel HEX XB 06H-1 26StS (26 pl)
Supplement for stainless steel HEX XB 06H-1 40StS (40 pl)
145H3001
Danfoss District Energy
Akva Lux II TDv
Code No.
145H4156
145H4746
145H4015
145H3001
145X2085 / AQ428255318526en-010101
5
4
2
52
145H4746
Akva Lux II TDv with ball valve set 145H4015
38
40
7 7
