DIS344 Voltage Dual-Axis Inclination Switch Introduction Designed by Bewis Sensing Technology LLC, The DIS342 series is a dual-axis inclination switch, with a measuring range of ±90°. When the measured inclination angle exceeds the alarm threshold, the output line becomes closed (disconnected is also available). If the measured inclination does not exceed the alarm threshold, the output line is normally open (also normally closed).
DIS344 Voltage Dual-Axis Inclination Switch Specifications Electrical Specifications Product number DIS344 Typical Power Supply (V) Conditions Non-loaded Operating current(mA) 40(DC12V) Operating temperature(°C) +100 Store temperature(℃) <±90 Measuring range(°) dynamic 2°/ Static 0.1° Accuracy(°) 0.01 Resolution(°) Measuring axis X、Y Alarm axis X、Y Zero temperature ±0.01...
Page 4
DIS344 Voltage Dual-Axis Inclination Switch Mechanical Characteristic Metal connector(standard cable is 1.5m) Connector Protection level IP67 Magnesium alloy anodizing Shell material Installation Three M4 screws Package size Product Size:L103.8*W55.4*H26(mm) Aviation connector:116 Metal connector:105 Top view Bare plate product size Product size: L69*W49*H12(mm) Note: ±1mm error for length and width dimensions, please refer to actual size.
DIS344 Voltage Dual-Axis Inclination Switch Installation direction The correct installation method can avoid measurement error. The following points should be made when installing the sensor: First of all, to ensure that the sensor mounting surface and the measured surface completely close, the measured surface should be as horizontal as possible, can not have the angle shown in Figure A and Figure C, the correct installation is shown in Figure B and Figure D.
DIS344 Voltage Dual-Axis Inclination Switch Electrical Connections Electrical interfaces WHITE ORANGE BLACK PURPLE BEOWN Cable color YELLOW GREEN & Function +X OUT -Y OUT -X OUT +Y OUT DC 9-35V 9~35V BROWN +X OUT ORANGE -X OUT GREEN YELLOW WHITE +Y OUT BLACK PURPLE...
Page 7
DIS344 Voltage Dual-Axis Inclination Switch Debug software Users can directly download serial assistant on official website (Supports-Download). You can also use more convenient and intuitive PC software. DIS344 supporting serial debugging software can be connected to the inclinometer on the computer for angle display.
Page 8
DIS344 Voltage Dual-Axis Inclination Switch Protocol 1 Data Frame Format: (8 data bits,1 stop bit,No parity check,default baud rate 9600) Identifier Data Frame Length Command Address Code Checksum (1byte) (1byte) (1byte) (1byte) (Nbyte) (1byte) 0x77 Data Format: Hexadecimal Identifier: Fixed to 77(partly 68) Frame Length: Length from Frame Length to Checksum(included)...
DIS344 Voltage Dual-Axis Inclination Switch Ordering Information Package condition Product number Way of communication RS232 DIS344-232 IP67 Package/Metal Connector DIS344-TTL IP67 Package/Metal Connector Executive standard ● Enterprise Quality System Standard: ISO9001:2008 Standard (Certificate No.:10114Q16846ROS) ● CE certification (certificate number: 3854210814) ●...
