Summary of Contents for BW SENSING LIS344
- Page 1 LIS344 Serials Voltage Dual-Axis Inclination Switch Technical Manual...
- Page 2 Voltage Dual-Axis Inclination Switch Introduction Designed by Bewis Sensing Technology LLC, The LIS344 series is a dual-axis inclination switch, with a measuring range of ±90°. When the measured inclination angle exceeds the alarm threshold, the output line becomes closed (disconnected is also available). If the measured inclination does not exceed the alarm threshold, the output line is normally open (also normally closed).
-
Page 3: Electrical Specifications
LIS344 Voltage Dual-Axis Inclination Switch Specifications Electrical Specifications LIS344 Product number Typical Power Supply (V) Conditions Non-loaded Operating current(mA) 40(DC12V) Operating temperature(°C) +100 Store temperature(℃) <±90 Measuring range(°) 0.1(<±80) ; 0.2(±80-90); Accuracy(°) 0.01 Resolution(°) Measuring axis X、Y Alarm axis X、Y Zero temperature ±0.01... - Page 4 LIS344 Voltage Dual-Axis Inclination Switch Mechanical Characteristic Metal connector（standard cable is 1.5m） Connector Protection level IP67 Magnesium alloy anodizing Shell material Installation Four M4 screws Package size Product Size：L90*W40.5*H26（mm） 4.5 通孔 Bare plate product size Product size: L47*W36*H15(mm) Note: ±1mm error for length and width dimensions, please refer to actual size.
-
Page 5: Installation Direction
LIS344 Voltage Dual-Axis Inclination Switch Installation direction The correct installation method can avoid measurement error. The following points should be made when installing the sensor: First of all, to ensure that the sensor mounting surface and the measured surface completely close, the measured surface should be as horizontal as possible, can not have the angle shown in Figure A and Figure C, the correct installation is shown in Figure B and Figure D. -
Page 6: Electrical Connections
LIS344 Voltage Dual-Axis Inclination Switch Electrical Connections Electrical interfaces WHITE ORANGE BLACK PURPLE BEOWN Cable color YELLOW GREEN & Function +X OUT -X OUT -Y OUT +Y OUT DC 9-35V 9~35V BROWN +X OUT ORANGE -X OUT GREEN YELLOW WHITE... - Page 7 Users can directly download serial assistant on official website (Supports-Download). You can also use more convenient and intuitive PC software. LIS344 supporting serial debugging software can be connected to the inclinometer on the computer for angle display. The software debugging interface is as shown in the figure below. Using the debug software, it can conveniently display the current X-direction tilt angle, and you can also modify and set other parameters by yourself.
- Page 8 LIS344 Voltage Dual-Axis Inclination Switch Protocol 1 Data Frame Format： （8 data bits，1 stop bit，No parity check，default baud rate 9600） Identifier Data Frame Length Command Address Code Checksum (1byte) （1byte） （1byte） （1byte） （Nbyte） （1byte） 0x77 Data Format: Hexadecimal Identifier: Fixed to 77(partly 68) Frame Length: Length from Frame Length to Checksum（included）...
- Page 9 LIS344 Voltage Dual-Axis Inclination Switch 2.3 Read angle of X,Y axis Command：77 04 00 04 08 Identifier Data Frame Length Checksum Address Code Command (1byte) （0byte） （1byte） （1byte） （1byte） （1byte） 0x77 0x08 0x04 0x04 Command response： Data Identifier Frame Length...
- Page 10 LIS344 Voltage Dual-Axis Inclination Switch 2.4 Set address module Command: 77 05 00 0F 01 15 Frame Length Command Identifier Address Code Data Checksum （1byte） (1byte) （1byte） （1byte） （1byte） （1byte） 0xXX 0x05 0x77 0xYY 0x0F Command response： Address Code Command...
- Page 11 LIS344 Voltage Dual-Axis Inclination Switch 2.7 Set the zero type Command：77 05 00 05 01 0B Identifier Data Frame Length Address Code Checksum Command （1byte） （1byte） （1byte） （1byte） （1byte） （1byte） 0x00: absolute zero 0x77 0x05 0x05 0x01: relative zero Command response：...
- Page 12 LIS344 Voltage Dual-Axis Inclination Switch 2.10 Quer y alarm angle Command： 77 05 00 21 00 26 Data Identifier Address Code Command Frame Length Checksum （1byte） (1byte) （1byte） （1byte） （1byte） （1byte） 0x00:+X 0x01:+Y 0x77 0x05 0x21 0X02:-X 0X03:-Y Response command：...
- Page 13 LIS344 Voltage Dual-Axis Inclination Switch 2.13 Set alarm delay off time Command： 77 07 00 23 01 05 00 30 Data Identifier Address Code Frame Length Checksum Command (1byte) （1byte） （3byte） （1byte） （1byte） （1byte） 0x77 0x07 0x23 DXXYY Response command：...
-
Page 14: Ordering Information
LIS344 Voltage Dual-Axis Inclination Switch Ordering Information Package condition Product number Way of communication RS232 LIS344-232 IP67 Package/Metal Connector LIS344-TTL IP67 Package/Metal Connector Executive standard ● Enterprise Quality System Standard: ISO9001:2008 Standard (Certificate No.:10114Q16846ROS) ● CE certification (certificate number: 3854210814) ●... - Page 15 LIS344 Voltage Dual-Axis Inclination Switch Wuxi Bewis Sensing Technology LLC Address: Building 30, No. 58 Xiuxi Road, Binhu District, Wuxi City Hotline: 400-618-0510 Tel: +86 510 85737178-801 Email: sales@bwsensing.com Website: www.bwsensing.com...
