Sony CDX-4000X Product Manual

2000 MOBILE PRODUCT GUIDE – PART 1
• X-tal Lock SSIR-EXA Tuner
• 18FM + 12AM Presets, Station Memo
• 8X Oversampling, 1-Bit, CD-R Playback
• Telephone Attenuator
• Flip-Down Detachable Faceplate, Red Key Illum.
General
Output lead
Tone Controls
Power Requirements
Dimensions (w/h/d)
Mounting Dimensions (w/h/d)
Weight
Supplied Accessories
Optional Accessories
Tuner Section
FM
Tuning Range
Antenna Terminal
Intermediate Frequency
Usable Sensitivity
Selectivity
Signal-to-Noise Ratio
Harmonic Distortion @ 1 kHz
Separation
Frequency Response
CD Player Section
Mechanism Type
Optical Pickup Name
System
Frequency Response
Signal-to-Noise Ratio
Wow and Flutter
Preamplifier Section
Line Outputs
Line Output Impedance
Bus Input Impedance
Max Line Output Level
Power Amplifier Section
Speaker Outputs
Speaker Impedance
Maximum Power Output
RMS Power Output
Distortion
14
CDX-4000X
CD Receiver
, BTM ™
† , CD TEXT
Power Antenna Relay Control, Power Amplifier Control, Telephone ATT Control Lead
Bass ±9 dB at 100 Hz; Treble ±9 dB at 10 kHz
12VDC Car Battery (negative ground)
Approx. 188 x 58 x 183 mm (7
Approx. 182 x 53 x 162 mm (7
Approx. 1.2 kg (2 lb. 10 oz.)
Parts for Installation and Connections (1 set), Front Panel Case (1)
Wired Rotary Commander (RM-X4S)
87.5-107.9 MHz
External Antenna Connector
10.7 MHz
8 dBf
75 dB at 400 kHz
66 dB (stereo); 72 dB (mono)
0.6% (stereo); 0.3% (mono)
35 dB (@ 1 kHz)
30-15,000 Hz
MG-383Z-121//K
KSS-720A
Compact Disc Digital Audio System
10-20,000 Hz
90 dB
Below measurable limit
Rear (RCA) (1), Front (RCA) (1)
10k ohms
N/A
2.1 Volts, < 1.0% THD
Front/Rear (sure seal connectors)
4-8 ohms
50 W x 4 (@ 4 ohms)
19 W x 4 (20-20kHz, 4 ohms)
1% THD
Design and specifications subject to change without notice.
• D-Bass w/Auto Level Adjust
• 13-seg, White/2-Color Negative LCD
• Xplo - d 50 W x 4 Design, F/R Preouts
• Rotary Encoder w/Cross Key
• Optional Rotary Remote
1 / x 2 3 / x 7 1 / in.) (including trim)
2 8 4
1 / x 2 1 / x 6 1 / in.)
4 8 2
AM
Tuning Range
Antenna Terminal
Intermediate Frequency
Sensitivity
Harness Plug Configuration
Plug shown with wires facing viewer
Pin Number Wire Color
1 White
2 Green
3 Violet
4 Grey
5 Blue/White
6 Blue
7 Red
8 Black
9 White/Black
10 Green/Black
11 Violet/Black
12 Grey/Black
13 Sky Blue
14 N/C
15 N/C
16 Yellow
530-1,710 kHz
External Antenna Connector
450 kHz
30 µV
Description
Left Front Positive
Left Rear Positive
Right Rear Positive
Right Front Positive
Amp Remote
Antenna Remote
Accessory +12 VDC
Ground
Left Front Negative
Left Rear Negative
Right Rear Negative
Right Front Negative
Telephone Attenuate
Constant +12 VDC
