SERVICE MANUAL
CD player section
System
Compact disc digital audio
system
Signal-to-noise ratio
90 dB
Frequency response
10 - 20,000 Hz
Wow and flutter
Below measurable limit
Tuner section
FM
Tuning range
FM tuning interval:
50 kHz/200 kHz switchable
87.5 - 108.0 MHz
(at 50 kHz step)
87.5 - 107.9 MHz
(at 200 kHz step)
Antenna terminal
External antenna connector
Intermediate frequency
10.7 MHz
Usable sensitivity
8 dBf
Selectivity
75 dB at 400 kHz
Signal-to-noise ratio
65 dB (stereo),
68 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation
35 dB at 1 kHz
Frequency response
30 - 15,000 Hz
Capture ratio
2 dB
AM
Tuning range
AM tuning interval:
9 kHz/10 kHz switchable
531 - 1,602 kHz
(at 9 kHz step)
530 - 1,710 kHz
(at 10 kHz step)
Antenna terminal
External antenna connector
Intermediate frequency
10.71 MHz/450 kHz
30 µV
Sensitivity
MICROFILM
CDX-4480ESP

SPECIFICATIONS

Power amplifier section
Outputs
Speaker impedance
Maximum power output
General
Outputs
Tone controls
Power requirements
Dimensions
Mounting dimensions
Mass
Supplied accessories
Design and specifications are subject to change without
notice.
FM/AM COMPACT DISC PLAYER
– 1 –
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
Speaker outputs
(sure seal connectors)
4 - 8 ohms
40 W × 4 (at 4 ohms)
Line outputs (2)
Power antenna relay
control lead
Power amplifier control
lead
Telephone ATT control
lead
Bass ± 10 dB at 100 Hz
Treble ± 10 dB at 10 kHz
12 V DC car battery
(negative ground)
Approx. 178 × 50 × 185 mm
(w/h/d)
Approx. 182 × 53 × 162 mm
(w/h/d)
Approx. 1.2 kg
Parts for installation and
connections (1 set)
Front panel case (1)
E Model
NEW
MG-363W-121
KSS-520A
