Elson EPS LEAD FREE Installation Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EPS PEX
EPS LEAD FREE CRIMP
EPS LEAD FREE CRIMP
LF
99.9% Lead Free
< 0.1% Pb
EPS WATER
PEX PLUMBING SYSTEM
MANUAL
TM
TM
WaterMark
WaterMark
WMKA21276
WMKA21274
Standard AS/NZS 2537.2
Standard AS 2492
Version 2.4
* Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

Advertisement

Table of Contents
loading

Related Manuals for Elson EPS LEAD FREE

Summary of Contents for Elson EPS LEAD FREE

  • Page 1 < 0.1% Pb EPS WATER PEX PLUMBING SYSTEM MANUAL WaterMark WaterMark WMKA21276 WMKA21274 Standard AS/NZS 2537.2 Standard AS 2492 Version 2.4 * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 2 9001 certified factory. Elson set a higher quality benchmark by introducing 99.9% Lead Free DR Brass plumbing products in 2016 with the launch of elson LEAD FREE PRESS fittings and we have continued to expand our Lead Free range to include Water Meter Ball Valves, PRV Boundary Valves, Hot Water Valves – PRVs, PLVs & Non- Return Isolating Valves, Press Ball Valves, Dual Check Valves, BUSHPEX Ball Valves, elson innovative Union Ball Valves, and Elson EPS LEAD FREE* CRIMP WATER &...
  • Page 3 • Lead free brass can be recycled maintaining the environmental benefits. Elson EPS LEAD FREE CRIMP Water & Gas Dual Pex plumbing system has been designed with high strength pex pipe for hot and cold water applications & pex-al pipe for gas applications.

  • Page 4: Table Of Contents

    Contents EPS LEAD FREE CRIMP WATER & GAS SYSTEM ................EPS LEAD FREE CRIMP WATER & GAS DUAL PEX Fittings ..............EPS LF CRIMP WATER - EPS CRIMP Pex Water Pipe ................. - Installation Requirements .................. - Technical Information ..................

  • Page 5: Crimp Water & Gas System

    EPS PEX 99.9% Lead Free < 0.1% Pb EPS PEX The EPS LEAD FREE* Crimp Water & Gas Dual PEX Plumbing System. Suitable for both Water & Gas applications. 99.9% LEAD FREE Crimp fittings have been designed to be dual purpose for both water and gas applications.

  • Page 6: Crimp Water & Gas Dual Pex Fittings

    Number. Lead Free Identification stamping also appears on the brass fitting where possible or it will display the letters “LF”. Elson EPS Crimp water & gas dual fittings have been tested and approved in accordance with the Australian and New Zealand Standard AS/NZS 2537.2 with watermark certificate WMKA 21276.
  • Page 7 Never expose EPS plumbing system to a naked flame. Replace all pipe and fittings that have been compromised due to direct or radiant heat. Always follow required installation procedure as per AS/NZS 3500. * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 8: Installation Requirements

    INSTALLATION REQUIREMENT CARE & HANDLING EPS LEAD FREE* CRIMP Pipe & fittings. Must be protected from damage through all stages of the process from transport to storage and installation in accordance with AS/NZS3500. Provision for pipe and fittings protection includes but is not limited to the following: •...
  • Page 9 Refer to Pipe Specification Chart for spacing. Pipe Size Horizontal Vertical 16mm 600mm 1200mm 20mm 700mm 1400mm 25mm 750mm 1500mm 32mm 850mm 1700mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 10 The potential threat of electrocution and death must be recognised if an earth line is disconnected by cutting metal pipes. ALWAYS check with a licenced electrician prior to proceeding. * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 11 C @ 1090kPa Temp / Opera�ng Pressure C @ 1190kPa C @ 1190kPa C @ 1190kPa C @ 1190kPa * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight. March 2023...

  • Page 12: Technical Information

    Flow Rate (L/s) Only reliable for water at 15.5 degrees celcius with velocity flow less than 10 feet/s or 3.048 m/s * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 13: Frequently Asked Questions

    • Inspect the tool to ensure if functions properly. • Inspect the jaws to ensure they’re clean, dry, and free of dirt. * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 14 Do I need to check every crimp joint has been compressed properly? – you should check every crimp joint has been Compressed properly by testing with the crimp gauge. * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 15: Jointing Instructions

    Make sure you are aware of the operating features and functions. • Ensure that only Elson compatible jaws are used to match the tool. Check the jaw matches the diameter of the Elson Eps Crimp Water and Gas Dual Plumbing System requirements.
  • Page 16 • Pressure test the installation in accordance with AS/NZS 3500. * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 17: Fittings

    No.2 Straight Connector 20mm x 20mm FI LF21070 No.2 Straight Connector 25mm x 25mm FI LF21072 No.2 Straight Connector 32mm x 25mm FI * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 18 NO.12 ELBOW LEAD FREE BRASS Code Description LF21080 No.12 Elbow 16mm LF21082 No.12 Elbow 20mm LF21084 No.12 Elbow 25mm LF21086 No.12 Elbow 32mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 19 No.19BP Elbow 20mm x 15mm MI 95mm Long LF21152 No.19BP Elbow 20mm x 15mm MI 200mm Long LF21158 No.19BP Elbow 20mm x 20mm MI 200mm Long * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 20 No.27 Tee Reduced 20 x 16 x 16mm (16mm Centre+16mm End) LF21384 No.27 Tee Reduced 25 x 20 x 20mm (20mm Centre+ 20mm End) * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 21 FLARED COMPRESSION UNION LEAD FREE BRASS Code Description LF21220 Flared Compression Union 16mm x G1/2 FL LF21222 Flared Compression Union 20mm x G3/4 FL * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 22 Connecting Barb Female 25mm CONNECTING BARB MALE LEAD FREE BRASS Code Description LF21450 Connecting Barb Male 16mm LF21452 Connecting Barb Male 20mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 23 Adaptor Water SDR7.4 Pex 20mm x EPS LF Crimp 20mm REVERSION UNION Code Description LF21500 Reversion Union 16mm LF21502 Reversion Union 20mm LF21504 Reversion Union 25mm LF21506 Reversion Union 32mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 24: Water Pipe

    Recycled Water Pipe (Lilac) 5m Length 16mm 21738 Recycled Water Pipe (Lilac) 5m Length 20mm 21739 Recycled Water Pipe (Lilac) 5m Length 25mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 25 Hot Water Pipe (Red) 50m Coil 16mm 21758 Hot Water Pipe (Red) 50m Coil 20mm 21753 Hot Water Pipe (Red) 50m Coil 25mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 26: Tools & Accessories

    NOVOPRESS BATTERY Code Description 23864 Novopress Battery 1.5AH LI-LON 12V NOVOPRESS BATTERY CHARGER Code Description 23866 Novopress Battery Charger 12V 230V AUS * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 27 EPS PEX PIPE CUTTER Code Description 21936 PEX PIPE & PEX/AL/PEX PIPE 16mm-32mm RING REPAIR TOOL Code Description 21934 Ring Repair Tool 16mm-25mm * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 28 CLIP METAL SCREW Code Description 23820 Open Clip 16mm Metal Screw 23822 Open Clip 20mm Metal Screw 23824 Open Clip 25mm Metal Screw * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.
  • Page 29 PEX Profile Bend Bracket W/Spring 90 Degree 25mm PROFILE BEND Code Description 23838 PEX Profile Bend Bracket 90 Deg x 25mm PA6 * Elson Lead Free copper alloy products are 99.9% Lead Free and contain less than 0.1% Lead by weight.

  • Page 30: Warranty

    To the extent of the Law, Elson shall not be liable for any consequential loss or damage of any kind caused by any product faulty or defective in workmanship or manufacture.
  • Page 32 Distributed by Disclaimer: The informa�on provided within this Product Informa�on and Installa�on Manual is designed as a guide only and is believed to be accurate at the �me of prin�ng. Elson Australasia Pty Ltd and its employees take no responsibility in regard to any specific installa�on. Installa�on must always require supervision and consulta�on from a licenced Plumber.
