- Page 1 THE BRAND PLUMBERS TRUST elson PULL-ON PEX PLUMBING SYSTEM WaterMark Product information and installation manual WMKA21276 Standard AS/NZS 2537.2 WaterMark WMKA21274 Version 3.1 Standard AS 2492...
- Page 2 BUSHPEX Pull-On Plumbing Systems are a cost effective alternative to other plumbing systems. The elson BUSHPEX Pull-On PEX system is fast and easy to install, usually with fewer fittings. The flexible pipe is light weight and resists corrosion and incrustation. Water flow noise is low in PE-X pipe and water hammer is significantly reduced.
-
Page 3: Table Of Contents
- Pipes....................- Fittings.................... - Pipe Specification Chart..............- Pipe and fitting protection and care during handling and installation..- Underground Installation..............- Fire Certification for elson BUSHPEX Water Pipe........- elson BUSHPEX Pull-On Tools............. System Testing................... Warranty..................Frequently asked Questions.............. -
Page 4: Features And Benefits
• 25 year product warranty against manufacturing defect when installed according to detailed requirements. • elson BUSHPEX pipe manufactured to AS 2492 and fittings to AS/NZS 2537.2 standard within our ISO9001 accredited manufacturing facility with all Watermark Certification by SAI Global. -
Page 5: Technical Information
BUSHPEX Pipe elson BUSHPEX pipe is manufactured from PE-Xa raw material to exceed the performance requirements of AS 2492. The flexible elson BUSHPEX pipe is the perfect choice for hot and cold potable water and recycled water applications. PE-Xa crosslinked polyethylene is polyethylene (PE) which has undergone a change in molecular structure... - Page 6 BUSHPEX Pull-On is a complete plumbing system comprising of PE-Xa pipe in sizes 16, 20, 25 and 32mm plus a comprehensive range of DR Brass fittings with hightensile brass sleeves. Manual and battery tooling options for jointing the pipe and fittings completes the system.
-
Page 7: Pipe Specification Chart
Temp / Opera�ng Pressure C @ 1330kPa C @ 1330kPa C @ 1330kPa C @ 1330kPa Temp / Opera�ng Pressure C @ 1500kPa C @ 1500kPa C @ 1500kPa C @ 1500kPa April 2023 elson BUSHPEX Pull-On V3.1 Apr 2023... -
Page 8: Pipes
Pipe & Fitting Protection and Care during Handling and Installation elson BUSHPEX pipe and Pull-On fittings must be protected from damage through all stages of the process from transport to storage and installation in accordance with AS/NZS 3500. Provision for pipe and fitting protection therefore includes but is not limited to the following: •... -
Page 9: Underground Installation
(Technical Information Section) Elson BUSHPEX Water PEX pipe is certified for wall and floor penetrations in accordance with Australian Standard 1530: Part4 : 2005. The elson BUSHPEX water pipe was tested in connection with the Promat Passive Fire Protection collars. -
Page 10: Elson Bushpex Pull-On Tools
BUSHPEX Pull-On Tools are specifically designed to be used with the elson BUSHPEX Pull-On PEX Pipe and fitting System and may not be compatible with other systems. elson BUSHPEX Pull-On Tools are manufactured to precise specifications and require care, regular maintenance and regular inspection to ensure accurate and consistent operation. - Page 11 • Water quality - Australian city potable water reticulation systems as defined in the Australian Drinking Water Guidelines. ELECTROCUTION WARNING! The potential threat of electrocution and death must be recognised if an earth line is disconnected by cutting metal pipes. ALWAYS check with a licenced electrician prior to proceeding. elson BUSHPEX Pull-On V3.1 Apr 2023...
-
Page 12: System Testing
WMKA 21274), elson BUSHPEX Pull-On fittings (watermark certificate WMKA 21276) and elson BUSHPEX approved tooling. Elson Australasia Pty Ltd undertakes to repair or replace product which is found to be faulty or defective in workmanship or manufacture according to the warranty conditions. The benefits provided to the consumer by this warranty are in addition to other rights and remedies available to the consumer under the law. - Page 13 To the extent of the Law, Elson shall not be liable for any consequential loss or damage of any kind caused by any product faulty or defective in workmanship or manufacture.
-
Page 14: Frequently Asked Questions
Can braze-on adaptors be installed after crimping elson BUSHPEX Pipe? NO – Brazing must only ever be done prior to the jointing of the elson BUSHPEX pipe to the fitting. Alternatively use elson PRESS Pull-On fittings from copper to elson BUSHPEX Pull-On. -
Page 15: Elson Bushpex Pull-On Jointing Instruction
Pressure test the installation in accordance with off. AS/NZS 3500. Immediately insert the expanded pipe end into the fitting until it reaches the last and largest ridge. Note the pipe contracts over time due to the PEX memory effect. elson BUSHPEX Pull-On V3.1 Apr 2023... -
Page 16: Product Listings
No.3 Straight Connector 16mm x 20mm MI 23042 No.3 Straight Connector 20mm x 15mm MI 23044 No.3 Straight Connector 20mm x 20mm MI 23048 No.3 Straight Connector 20mm x 25mm MI 23052 No.3 Straight Connector 25mm x 15mm MI elson BUSHPEX Pull-On V3.1 Apr 2023... - Page 17 23422 No.14 Elbow 20mm x 15mm FI 23424 No.14 Elbow 20mm x 20mm FI NO.15 LUGGED FEMALE ELBOW Code Description 23120 No.15BP Elbow 16mm x 15mm FI 23122 No.15BP Elbow 20mm x 20mm FI elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 18 No.25 Tee Reduced Centre 32 x 32 x 25mm TEE REDUCED BOTH ENDS Code Description 23171 Tee Reduced Both Ends 16 x 16 x 20mm 23172 Tee Reduced Both Ends 20 x 20 x 25mm elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 19 No.27 Tee Reduced Centre+End 32 x 25 x 25mm NO.30 TEE Code Description 23388 No.30 Tee 16 x 16 x 15mmFI 23389 No.30 Tee 20 x 20 x 15mmFI NO.61 STOPPER Code Description 23260 No.61 Stopper 16mm 23262 No.61 Stopper 20mm elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 20 Flared Copper Compression Union 20mm x 20mm FL BATH/LAUNDRY ASSEMBLY Code Description 23280 Bath/Laundry Assembly Right Angled 200mm (FLOOR ENTRY) 23282 Bath/Laundry Assembly Right Angled 300mm (FLOOR ENTRY) 23286 Bath/Laundry Assembly Straight 300mm (SIDE ENTRY) elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 21 Connecting Barb Female 20mm 23454 Connecting Barb Female 25mm 23456 Connecting Barb Female 32mm COMPRESSION SLEEVE Code Description 23460 Compression Sleeve 16mm 23462 Compression Sleeve 20mm 23464 Compression Sleeve 25mm 23466 Compression Sleeve 32mm elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 22 ADAPTOR elson LF PRESS DN20 X BUSHPEX PULL-ON 20mm LF DR BRASS LF23884 ADAPTOR elson LF PRESS DN20 X BUSHPEX PULL-ON 25mm LF DR BRASS elson BUSHPEX PULL-ON PEX BALL VALVE LF DR BRASS Code Description LF72380 elson LF BUSHPEX PULL-ON WATER BALL VALVE...
-
Page 23: Tools & Jaws
NOVOPRESS BUSHPEX PULL-ON COMPRESSION TOOL KIT Code Description 23850 Novopress BUSHPEX Pull-On Compression Tool Kit 16-32mm NOVOPRESS BUSHPEX PULL-ON JAW SET Code Description 23860 Novopress BUSHPEX Pull-On Jaw Set 16-20mm 23862 Novopress BUSHPEX Pull-On Jaw Set 25-32mm NOVOPRESS BUSHPEX PULL-ON SECURING PIN... - Page 24 Including Jaw 16-20mm COMPRESSION JAW GEN2 BUSHPEX Code Description 22904 Compression Jaw GEN2 BUSHPEX 16-20mm 22906 Compression Jaw GEN2 BUSHPEX 25-32mm MANUAL EXPANDER TOOL GEN2 BUSHPEX Code Description 22910 Manual Expander Tool GEN2 BUSHPEX elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 25 T135 DAWN KWIKCUT Original Pipe Cutter 16mm-32mm PIPE CUTTER PEX PIPE & PEX/AL/PEX PIPE Code Description 21936 Pipe Cutter PEX Pipe & PEX/AL/PEX Pipe 16mm-32mm TOOL GREASE Code Description 23980 Tool Grease BRASS BRUSH Code Description 23940 Brass Brush elson BUSHPEX Pull-On V3.1 Apr 2023...
-
Page 26: Pipes And Accessories
Important: Below listed elson BUSHPEX PE-Xa Pipes and Accessories can be used with all two elson BUSHPEX Plumbing Systems - Pull-On, Crimp-On. HOT & COLD WATER PIPE (BLACK) STRAIGHT LENGTH Code Description 23700 Hot & Cold Water Pipe (Black) 5m Length 16mm 23702 Hot &... - Page 27 Code Description 23737 Recycled Water Pipe (Lilac) 5m Length 16mm 23738 Recycled Water Pipe (Lilac) 5m Length 20mm 23739 Recycled Water Pipe (Lilac) 5m Length 25mm 23736 Recycled Water Pipe (Lilac) 5m Length 32mm elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 28 Open Clip 20mm Masonry Nail 23814 Open Clip 25mm Masonry Nail CLIP TIMBER NAIL Code Description 23816 Open Clip 16mm Timber Nail 23817 Open Clip 20mm Timber Nail 23818 Open Clip 25mm Timber Nail elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 29 Profile Bend Bracket 90 Deg x 5D 25mm PROFILE BEND BRACKET Code Description 23831 Profile Bend Bracket w/ Spring 90 Deg 16mm 23833 Profile Bend Bracket w/ Spring 90 Deg 20mm 23835 Profile Bend Bracket w/ Spring 90 Deg 25mm elson BUSHPEX Pull-On V3.1 Apr 2023...
- Page 30 BUSHPEX Pull-On V3.1 Apr 2023...
- Page 32 Distributed by Disclaimer: The informa�on provided within this Product Informa�on and Installa�on Manual is designed as a guide only and is believed to be accurate at the �me of prin�ng. Elson Australasia Pty Ltd and its employees take no responsibility in regard to any specific installa�on. Installa�on must always require supervision and consulta�on from a licenced Plumber.
