Cornelius P/N 629087914 Installation Instructions

INSTALLATION INSTRUCTIONS

ED/DF 175 "K" S
These "K" style kits apply to the following ice makers:
Cornelius "I" Series 322, 522
Item No. Part No.
620043511
1
620043512
2 620046011
3 22127
4 70217
5 50904
6 90221
7 620919511
8 620701902
9 620701901
10 620042928
11 621701903
12 630000408
!
WARNING:
Disconnect power to the unit before installing the adaptor following all lockout/tag out procedures established by the
user. Verify that all the power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All ice baffle plates and bin stats, if included or recommended in this kit, must be installed as directed in this manual or
the equipment manufacturer's instructions.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All of the attachment screws and plates must be installed as directed in this manual.
Failure to comply could result in serious injury, death or damage to the equipment.
Perform the following procedure to install the adapter kit.
1. Unpack and inspect the kit.
2. Insert baffle assembly into the adapter lid.
3. Place (2) sealing washers (item 9) over studs and (2) flat washers (item 11), then fasten in place with (2)
plastic acorn nuts (item 8).
Revision Date: July 22, 2011
© 2000-2011, IMI Cornelius Inc.
L K , P/N 629087914 AND 629087915
TYLE ID ITS
Table 1. Applicable Models
Ice Maker
Table 2. Loose Shipped Parts
Cover, Gray (629087914)
Cover, Black – (629087915)
Lid Assembly
Bracket
#8 Screw
RTV
Label
Installation Instruction
Acorn Nut, 8-32 Nylon
Sealing Washer
Baffle Ice ED150 Adapter Lid
#8 Nylon Washer
Thermostat Kit
www.cornelius.com
ED/DF 175 ''K'' Style Lid Kit Installtion Instructions
Name
- 1 -
Width
22"
Qty.
1
1
1
2
12
1
1
1
2
1
1
2
1
Revision: E
Publication Number: 620919511
