Item #1004 589 957
Model #59236
UL Model #32-STRE
USE AND CARE GUIDE
HARRINGTON 36-INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday.
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Home Decorators Collection!
Advertisement
Related Manuals for Home Decorators Collection HARRINGTON 59236
Summary of Contents for Home Decorators Collection HARRINGTON 59236
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..............2 Assembly ................7 Safety Information ............... 2 Operation ................15 Warranty ................3 Care and Cleaning ............. 16 Pre-Installation ..............3 Troubleshooting ..............16 Installation ................6 Safety Information READ AND SAVE THESE INSTRUCTIONS. WARNING: To reduce the risk of personal injury, do not bend the blade brackets (also referred to as To reduce the risk of electric shock, ensure the electricity has been... -
Page 3: Warranty
“wobble” is normal and should not be considered a defect. Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. Home Decorators Collection hereby disclaims any and all warranties, including but not limited to those of merchantability and fitness for a particular purpose to the extent permitted by law. - Page 4 Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Blade attachment screws Plastic wire connector Decorative frame screws Nuts Hanger pin Locking pin...
- Page 5 Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Slide-on mounting bracket (inside canopy) Stable pads Ball/downrod assembly Light kit pan Canopy Light kit fitter assembly Decorative motor collar cover Glass shade Fan-motor assembly Receiver Blade Remote control Cycle frame piece Lead wire Attachment frame piece Battery...
-
Page 6: Installation
Installation MOUNTING OPTIONS WARNING: To reduce the risk of fire, electric shock or NOTE: You may need a longer downrod to maintain proper personal injury, mount to outlet box marked “Acceptable blade clearance when installing on a steep, sloped ceiling. The for fan support of 35 lbs. -
Page 7: Assembly
Assembly Assembling the decorative frame Attaching the blades □ □ Attach three cycle frame pieces (G) to be a complete Attach a blade (F) to the fan motor assembly (E) by decorative frame, make them as as a cycle shade, then inserting the blade (F) into slots in the side of the fan insert stable tabs (I) by aligning the holes on cycle frame motor assembly (E) and aligning the three screws holes in... - Page 8 Assembly - Standard Ceiling Mount Installing the attachment frame Preparing for mounting pieces to motor housing □ Remove all nine screws (EE) from the top of the motor NOTE: The magnet is pre-attached on the canopy assembly (E). bottom cover (C) for you to remove and install easily. □...
- Page 9 Assembly - Standard Ceiling Mount (continued) Routing the wires Assembling the fan □ Route the wires exiting the top of the fan motor WARNING: Failure to properly install the locking pin (KK) could assembly (E) through the decorative motor collar cover result in the fan becoming loose and possibly falling.
- Page 10 Assembly - Hanging the Fan Attaching the fan to the electrical Hanging the fan □ Carefully lift the fan-motor assembly (E) up to the slide-on WARNING: To reduce the risk of fire, electric shock or mounting bracket (A). personal injury, mount to outlet box marked “Acceptable for fan support of 35 lbs.
- Page 11 Assembly - Hanging the Fan (continued) Setting the code on the remote Wiring the receiver to the control and receiver household wiring WARNING: To avoid possible electrical shock, turn the NOTE: The frequencies on your receiver and hand unit have electricity off at the main fuse box before wiring.
- Page 12 Assembly - Hanging the Fan (continued) Wiring the fan to the receiver Installing the receiver WARNING: To reduce the risk of fire or electrical shock, NOTE: The fan comes with 12 in. lead wires for use with the remember to disconnect power. The electrical wiring must meet provided 6 in.
- Page 13 Assembly - Hanging the Fan (continued) Mounting the fan-motor assembly (standard mount) □ Align the locking slots of the canopy (C) with the two screws (MM) and alignment post (RR) in the mounting bracket (A). □ Push up the canopy (C) and turn clockwise until the alignment post (RR) engages to the round hole and the screws (MM) engage to the key slots.
- Page 14 Assembly - Attaching the Light Kit (continued) Attaching the light kit fitter assembly Installing the glass bowl CAUTION: To reduce the risk of electric shock, disconnect WARNING: Allow the glass bowl to cool completely before the electrical supply circuit to the fan before installing the removing.
-
Page 15: Operation
Operation NOTE: Wait for the fan to stop before reversing the direction of the Warm weather blade rotation. Remote control Your fan is equipped with a remote control to operate the speed and lights for your new ceiling fan. Speed setting for warm or cool weather depends on factors such as the room size, ceiling height, number of fans and so on. -
Page 16: Care And Cleaning
Care and Cleaning WARNING: Make sure the power is off before cleaning your fan. □ Because of the fan’s natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure. It is not necessary to remove the fan from the ceiling. □... - Page 17 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
