- Page 1 Dimmer / 2-Way Dimmer Model No. JSJSLW455 Instruction Manual Connect Series www.lightwaverf.house Version 2...
- Page 2 EC DECLARATION OF CONFORMITY Responsible Authority: LightwaveRF PLC, Innovation Campus Birmingham Faraday Wharf Holt Street Birmingham B7 4BB Tel: +44 (0)121 250 3625 Email: enquiries@lightwaverf.com Model Number(s): JSJSLW455 Description: 2-Way Dimmer (Dimmer/2-Way) Directives this equipment Complies with: 2006/95/EC The Low Voltage Directive N/A 2004/108/EEC The Electromagnetic Compatibility Directive 1999/5/EC R&TTE Directive 93/68/EEC CE Marking Directive...
-
Page 3: Get Started
Get Started How do I get started? Please refer to the following installation and setup instructions. This will guide you, step by step, through the installation and setup process. What do I need? To install the dimmer, you will need to remove and replace the existing lightswitch. -
Page 4: Installation
Installation Overview Amber LED. ‘On’ button. Hold to raise light When illuminated, level. the dimmer is o . Blue LED. When ‘O ’ button. illuminated, the Hold to lower light dimmer is on. level. IMPORTANT: All LightwaveRF products can be legally DIY installed in your own home;... - Page 5 Installation Live in Switched live (live out) Screw 2-Way mounting hole switching connection IMPORTANT: If conducting an insulation resistance test, all LightwaveRF products must be disconnected from the mains, or damage will occur.
- Page 6 Quick Start Guide Installation Understanding the di erent dimmer gangs This dimmer comprises 2 gangs: one is a standard LightwaveRF Dimmer module and is labelled ‘Master’; the other is a 2-Way LightwaveRF Dimmer module and is labelled ‘Slave’. The standard gang can be wired as a standalone dimmer OR be connected to other LightwaveRF 2-Way Dimmers to perform 2-Way switching.
- Page 7 Quick Start Guide Installation VERY IMPORTANT • A LightwaveRF 2-Way Dimmer needs to be used in conjunction with a standard LightwaveRF dimmer to perform 2-Way Switching. The LightwaveRF 2-Way Dimmer cannot be used in conjunction with a standard lightswitch. This will cause damage to the dimmer. •...
- Page 8 Installation IMPORTANT: Turn o the mains electrical supply. Ensure that the wall (back) box has a minimum depth of 35mm. Remove and disconnect the existing lightswitch (if applicable). It may be useful at this point to mark out or take a photograph of the connections to the existing switch so that the correct wires can easily be transferred to the new dimmer.
- Page 9 Installation Connect the wiring as per the wiring diagram on the following page. Ensure that the terminals are properly tightened and that no bare wire is visible. Be aware that existing wiring circuits are not always correctly coloured, and that there may be other wired connections present in the back box;...
- Page 10 Installation (Standard Dimmer Gang) NOTE: Wiring shown for one of two The switched live may be gangs. Please repeat for other gang. marked by brown/red tape to emphasise that it is not Live wire In. This a neutral wire. should be brown or red in colour.
- Page 11 Installation (2-Way Dimmer Gang) From lighting circuit IMPORTANT: The signal cable input marked ‘S’ must ONLY be connected Live Switched live to the wire running to the other dimmer NOT live mains; this will 3 - C o re cause irreparable damage. cable Earth Live...
- Page 12 Installation Replace the plate – a ‘click’ sound should be heard to signify that the plate has been correctly replaced. Important things to consider • Wattage ratings for the Dimmers are per gang. The maximum circuit load for each 2-Way Dimmer Gang is equal to the maximum load on the standard LightwaveRF Dimmer it is connected to (i.e.
- Page 13 Compatibility & Lamps Compatibility Ensuring the compatibility of your lamps (bulbs) with LightwaveRF Dimmers will ensure that you get the best experience from your lighting setup. LightwaveRF dimmers are compatible with the following: • Selected dimmable LED lamps (see www.lightwaverf.house for further guidance and information).
-
Page 14: Manual Operation
Manual Operation Manual operation Manual dimming • Tap the ‘on’ (top) button once to switch the dimmer on (blue LED indicator will illuminate). Press and hold the ‘on’ button to raise the light level. • Tap the ‘o ’ (bottom) button once to switch the dimmer o (amber LED indicator will illuminate). -
Page 15: Troubleshooting
Troubleshooting Problem: The 2-Way Dimmer will not operate the lights and the LEDs on the Dimmer do not light up. Solution: Firstly, check that there is power to the dimmer. Make sure that the connected lamps (bulbs) are functioning correctly; the dimmer switch will not run unless it has a functioning lamp/s to complete the circuit. - Page 16 Troubleshooting Problem: The LED/CFL lamps that I am using flash / do not dim properly. Solution: Ensure that the lamps being used are dimmable; non dimmable lamps are not compatible with LightwaveRF dimmers. If the problem persists, the LED/CFL lamps may not be compatible with the dimmers; please contact technical help (via www.lightwaverf.com) for further advice.
- Page 17 How many devices can I have on the LightwaveRF system? Each device has 6 memory slots for up 6 controllers (one of these can be the Lightwave Link allowing up to 6 smartphones to control hundreds of devices. Can I use LED or CFL lamps? Most LEDs can be controlled as long as the lamps are dimmable variants (see www.lightwaverf.com for guidance).
- Page 18 The 2-Way Dimmer will, therefore, also default to o . This can be overridden using the Lightwave Link to set default status for devices on power up. See www.lightwaverf.com for details. Is it normal for the dimmer to get warm when it is turned on? Yes it is perfectly normal for dimmer switches to feel warm to the touch if left on for a period of time close to maximum load.
-
Page 19: Technical Specification
Technical Specification Specification Standard Gang: RF frequency: 433.92 MHz Input rating: 220-240V~ 50Hz. Output rating: 3W~250W max Incandescent Load: 20W min 250W max 2-Way Gang: Input rating: 220-240V~ 50Hz. Back Box Depth: 35mm min. Earthing Requirement: Not essential (double insulated) Standby Energy Use: Less than 1W (per gang) Wiring: Neutral wire NOT required Warranty: 2 year standard warranty... - Page 20 Version 2 2 Quadrant Park Mundells Welwyn Garden City Herts AL7 1FS 01707 386035 www.lightwaverf.house...
