Lightwave L22WH Quick Start Manual

Smart
Dimmer
Quick Start Guide
Model No. L22WH
Before you start
You will need
A back-box with a minimum depth of 35mm
Suitable electrical screwdrivers
Suitable dimmable lamps (bulbs)
Knowledge of how to safely turn off/on
mains electricity
Your Link Plus, smartphone and Dimmer
Hints and tips
Get the best out of your install
www.lightwaverf.com
Let's get started
Installing yourself?
Please note that all Lightwave products can be legally
DIY installed in your own home; however, if in doubt,
always consult a qualified electrician.
It is important to install this product in accordance with
these instructions. Failure to do so may risk personal safety,
could create a fire hazard and will also void your warranty.
If conducting an insulation resistance test, any hard-wired
Lightwave devices must be disconnected from the mains,
or damage to the unit may occur.
Help video & further guidance
For additional guidance, and to watch a video that will help
guide you through the installation process, please visit the
support section on www.lightwaverf.com
Back box and spacers
This Lightwave Smart Dimmer requires a 35mm deep back
box in which to mount it. If you have a back box that is
shallower than 35mm, then a Lightwave spacer can be used to
provide up to 10mm of extra clearance from the wall.
LED Lamp compatibility
Lightwave dimmers are designed to work with the majority
of dimmable LEDs, but, as every lamp can behave differently,
it is advisable to choose variants that have been tested and
proven to work well. If you plan to use LEDs, we strongly
recommend that you consult our compatibility chart (see
www.lightwaverf.com). The LEDs must be dimmable (not
all varieties are), and you should not exceed the maximum
loading recommendations provided on the compatibility
chart or damage could occur.
Environmentally
friendly disposal
Old electrical appliances must
not be disposed of together with
residual waste, but have to be
disposed of separately. The disposal
at the communal collecting point
via private persons is for free.
The owner of old appliances is
responsible to bring the appliances
to these collecting points or to
similar collection points. With this
little personal effort, you contribute
to recycle valuable raw materials and
the treatment of toxic substances.
In the box Specification
RF frequency:
868 MHz
Input rating:
230V~ 50Hz
Output rating:
250W max per gang
Incandescent Load:
10W min 250W max per gang
L22 Dimmer
Back Box Depth:
35mm min
Earthing Requirement:
Not essential (double insulated)
Standby Energy Use:
Less than 1W (per gang)
Wiring:
Neutral wire NOT required
Dimmer spacer
Warranty:
2 year standard warranty
x2 Fixing screws
Circuit Type:
non-SELV
Compatible lamps
• Mains voltage incandescent lamps (max 250W)
• GU10 / HI spot halogen lamps (max 250W)
• Selected dimmable LEDs (see www.lightwaverf.com)
Not compatible with:
• Wirewound transformers (generally older style)
• Electric motors
• CFLs and CFL tubes
• Incandescent lamps under 10W
Automations
Using the Link Plus and Lightwave App, you can create custom
automations for Lightwave devices. Automations provide a whole
host of clever features, including timers, group actions, triggers
and wireless 2-way switching. Find out more by exploring the
Lightwave App.
EU Declaration of Conformity
Product: Dual Channel Dimmer Conformity is shown by
Model/Type: L22WH
compliance with the applicable
Manufacturer: LightwaveRF requirements of the following
documents:
Address: Innovation Campus
Birmingham, Faraday Wharf,
Reference and date:
Holt Street, Birmingham, B7 4BB
EN301489-3 V1.6.1: (EMC),
EN300220-2 V3.1.1 (RF),
This declaration is issued under
EN62479:2010 (RF Exposure),
the sole responsibility of the
EN60669-2-5:2013 (Safety)
LighwaveRF. The object of the
declaration described above is in
Signed for and on behalf of:
conformity with the relevant union
Place of Issue: Birmingham
harmonisation legislation.
Date of Issue: 20th August 2017
Name: John Shermer
Directive 2011/65/EU ROHS,
Position: CTO
Directive 2014/53/EU: (The Radio
Equipment Directive)
